RUF150704Door/Window Sensor

Document # E.0015.16.07 396333 IntegrAlarm USER AND INSTALLER MANUAL (DOOR / WINDOW CONTACT SENSOR) IntegrAlarm MODEL IA-DWC1 February 09, 2004 Document # E.0015.16.07 396333 Table of Contents 1 IntegrAlarm Overview..........................................................................3 2 Door / Window Sensor........................................................................5 2.1 Description............................................................................................5 2.2 Technical Specifications......................................................................5 2.3 Installation.............................................................................................6 2.3.1 Registration...........................................................................................6 2.3.2 Mounting................................................................................................6 2.3.3 Te s t i n g....................................................................................................7 Document # E.0015.16.07 396333 1 IntegrAlarm Overview The IntegrAlarm wireless security system includes a Control Panel and a number of wireless peripheral units. The system operates on the ISM wireless band of 902-928 MHz, in frequency hopping mode, transmitting short (about 10 ms) packets of data, with each packet transmitted on a different frequency. Time and frequency synchronization is maintained by a synchronization signal transmitted by the system Control Panel to the various peripherals (including the IA DWC-1) every 3 minutes. The system operates on 56 pseudo random selected channels. In its present configuration, the system includes five types of peripheral units: • Door / window sensor. • PIR sensor. • Smoke detector. • Handheld remote control. • Remote siren. This manual is devoted to the installation instructions for the IntegrAlarm IA DWC-1 door / window sensor. The installation instructions for the other IntegrAlarm peripherals and the IntegrAlarm Control Panel appear in the User and Installer Manuals for the respective units. Document # E.0015.16.07 396333 FCC Compliance Statement The FCC Wants You to Know This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: a) Reorient or relocate the receiving antenna. b) Increase the separation between the equipment and receiver. c) Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. d) Consult the dealer or an experienced radio technician. FCC ID: RUF150704 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Warning Modifications not expressly approved by the manufacturer could void the user authority to operate the equipment under FCC Rules. Instructions concerning human exposure to radio frequency electromagnetic fields. To comply with FCC Section 1.307 (b)(1) for human exposure to radio frequency electromagnetic fields, implement the following instruction: A distance of at least 20cm. between the equipment and all persons should be maintained during the operation of the equipment. Document # E.0015.16.07 396333 2 Door / Window Sensor 2.1 Description The door / window sensor unit consists of an RF transceiver, a micro-controller, a non- volatile memory, a power supply, a magnetic switch, a tamper switch and a battery. The sensor unit is composed of the following principal parts: • Sensor assembly. • Magnet block. • 3V Lithium HNO 2 battery type CR2. The sensor assembly includes the following subassemblies: • Mounting plate. • Sensor base. • Sensor PCB with RF controller, terminal block, reed switch and LED. • Cover. An exploded view of the door / window sensor unit is shown in Figure 1 below. 2.2 Technical Specifications Operating frequency band – ISM 902-928 MHz. Mode of operation – frequency hopping; every data packet is transmitted on a different pseudo random selected frequency. Data packet transmission duration – less than 7 milliseconds. Data packet validity check – CRC. Transmission and reception verification – two-way communication; each received packet is acknowledged, with an automatic repeat request (ARQ) in case of unacknowledged data packet. Events reported – door / window opened, door / window closed, tamper. Automatic self-test (transmission of a data packet and receipt of acknowledgment). Magnet gap from sensor – 3 mm max. Power source – 3V Lithium MNO 2 battery type CR2. Average current drain in normal use – 8 uA Current drain in “no change” state – 5 uA Sensor dimensions (mm): L-58, W-58, D-29. Magnet dimensions (mm): L-37, W-13, D-13. Weight (grams): 55. Document # E.0015.16.07 396333 2.3 Installation Installation of each door / window sensor is a three-step procedure. The sensor should first be registered via the IntegrAlarm Control Panel. It should then be mounted on the door or window to be secured, and then tested to confirm that it operates properly. 2.3.1 Registration From Installer Menu on Control Panel, select ENROLL. Screen will show: ENTER ZONE # Use numeric keypad at right of Cont…

Text truncated - open the document above for the full version.

1. External Photographs of Tested E.U.T. Figure 1 Front View Figure 2 Rear View With Window/Door Mounting Assembly Figure 3 Window/Door Mounting Assembly

IA-DWC1 Door/Window Magnetic Sensor Labels Size and location 60 mm 60 mm FCC ID: RUF150704This device complies with Part 15 of the FCCrules. Operation is subject to the following twoconditions:(1)This device may not cause harmful interferenceand (2) This device must accept any interferencereceived, including interference that may causeundesired operation IntegrAlarm Door/Window Magnetic Sensor Model IA-DWC1 S/N xxxxxxxx FCC ID: RUF150704This device complies with Part 15 of the FCCrules. Operation is subject to the following twoconditions:(1)This device may not cause harmful interferenceand (2) This device must accept any interferencereceived, including interference that may causeundesired operation 20 mm 50 mm FCC label 30 mm 20 mm IntegrAlarm Door/Window Magnetic Sensor Model IA-DWC1 S/N xxxxxxxx Product label Labels location: on the product back cover between the back cover and the mounting bracket

Spurious Radiated Measurement Photos Figure 1. Spurious Radiated Emission Test. Front

1. Internal Photographs of Tested E.U.T. Figure 1 Front Cover Internal View Figure 2 PCB in Unit Figure 3 PCB Side 1 Without Battery and Shield Figure 4 PCB Side 2

Close From: Chris Harvey [SMTP:[email protected]] To: [email protected] Cc: 'Marianne Bosley' Subject: ITL Applications for EMTS Inc MT#'s 14925, 14926 & 14927 Sent: 1/14/2004 8:04 AM Importance: Normal David, I have reviewed the following 3 applications (please note the following MT#’s apply) and have the questions listed below: MT#14925 FCC ID: RMZ150702 MT#14926 FCC ID: RMZ150703 MT#14927 FCC ID: RMZ150704 For All 3 Applications: Does the frequency hopping system comply with the non-coordination requirement of 15.247(h)? Does this transmitter use equally on average each of the transmitter frequencies to comply with the requirement of FCC 15.247(a)(1)? Does this device have a receiver input bandwidth that matches the hopping channel bandwidths of the corresponding transmitters and shift in synchronizations with the transmitted signals? This device is a composite device with a Transmitter and receiver contained in a single enclosure. Please confirm that the receiver (operating from 913.5-926.5MHz) complies with the FCC requirements for a receiver. ITL needs a letter of authorization if they are to provide responses since you have submitted the application and are acting on EMTS’s behalf. Please confirm that only one 10msec packet is transmitted for each ‘event’ (IR detection or button being pressed and that no other transmission occurs until the next event. The MPE was calculated for a single packet transmission. If the transmission is only one 10msec packet per on time at one frequency, please confirm that this device actually meets the definition of a FHSS transmitter. For MT#14926 FCC ID: RMZ150703 Please provide a photograph of the SEN-003 PCB removed from the SEN-001 main PCB (per mechanical drawing), showing the areas of both boards that does not appear in the photographs submitted. For MT#14925 FCC ID: RMZ150702 and MT#14926 FCC ID: RMZ150703 Although Marianne has already requested this, in the interest of a complete request, please submit the Schematic Diagrams for these 2 applications. The items listed above must be submitted before continued review of this application can be performed. Please respond directly to [email protected] or reply to this e-mail. Best regards, Chris Harvey

Close From: EMC [SMTP:[email protected]] To: Chris Harvey (E-mail 3) Cc: Doron Lavee (E-mail); Marianne Bosley (E-mail); Len Knight (E-mail) Subject: ITL Applications for MT#14925; MT#14926; MT#14927 Sent: 1/15/2004 6:05 AM Importance: Normal Ref: You emails of 14 January 2004 Hi Chris, 1. Thank you for your prompt responses. 2. Concerning your comment to all 3 applications: " This device is a composite device with a transmitter and receiver contained... FCC requirements for a receiver" please be advised: 2.1. We tested separately all the receivers to Sub-part B. 2.2. The receiver frequency range of operation is 916.5MHz to 926.5MHz. 3. We will respond to all your other comments shortly. Regards Shaike Raz EMC Laboratory Manager EMC Laboratory ITL (Product Testing) Ltd. Kfar Bin Nun Israel Tel: +972-8-9797799 Fax: +972-8-9797702 Email: [email protected] http://www.itl.co.il http://www.i-spec.com This e-mail message may contain privileged or confidential information. If you are not the intended recipient, you may not disclose, use, disseminate, distribute, copy or rely upon this message or attachment in any way. If you received this e-mail message in error, please return by forwarding the message and its attachments to the sender.

Close From: EMC [SMTP:[email protected]] To: Chris Harvey (E-mail 3) Cc: Doron Lavee (E-mail); Marianne Bosley (E-mail); Len Knight (E-mail) Subject: ITL Applications for MT#14925; MT#14926; MT#14927 Sent: 1/15/2004 6:05 AM Importance: Normal Ref: You emails of 14 January 2004 Hi Chris, 1. Thank you for your prompt responses. 2. Concerning your comment to all 3 applications: " This device is a composite device with a transmitter and receiver contained... FCC requirements for a receiver" please be advised: 2.1. We tested separately all the receivers to Sub-part B. 2.2. The receiver frequency range of operation is 916.5MHz to 926.5MHz. 3. We will respond to all your other comments shortly. Regards Shaike Raz EMC Laboratory Manager EMC Laboratory ITL (Product Testing) Ltd. Kfar Bin Nun Israel Tel: +972-8-9797799 Fax: +972-8-9797702 Email: [email protected] http://www.itl.co.il http://www.i-spec.com This e-mail message may contain privileged or confidential information. If you are not the intended recipient, you may not disclose, use, disseminate, distribute, copy or rely upon this message or attachment in any way. If you received this e-mail message in error, please return by forwarding the message and its attachments to the sender.

Cert. No. 1152.01 Electrical (EMC) Test Report E52235.01 EMTS Inc. Page 1 of 52 FCC ACC M Ver 1.1 05Mayl 2000 DATE: 10 February 2004 I.T.L. (PRODUCT TESTING) LTD. EMC Test for EMTS Inc. Equipment under test: IntegrAlarm Door/Window Contact Sensor (Transmitter Section) IA-DWC1 Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Cert. No. 1152.01 Electrical (EMC) Test Report E52235.01 EMTS Inc. Page 2 of 52 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for EMTS Inc. IntegrAlarm Door/Window Contact Sensor (For Transmitter Section) IA-DWC1 FCC ID:RUF150704 10 February 2004 This report concerns: Original Grant x Class II change Class B verification Class A verification Class I change Equipment type: Radio Telemetry Transmitter Request Issue of Grant: x Immediately upon completion of review Limits used: CISPR 22 Part 15 x Measurement procedure used is ANSI C63.4-2001. Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaishou Raz Doron Lavee ITL (Product Testing) Ltd. EMTS Inc. Kfar Bin Nun 300 Alden Road D.N. Shimshon 99780 Markham, Ontario, L3R4C1 Israel Canada e-mail [email protected] Tel: +1-905-946-8589 Fax: +1-905-947-0138 e-mail: [email protected] Test Report E52235.01 EMTS Inc. Page 3 of 52 FCC ACC M Ver 1.1 05Mayl 2000 TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1 Administrative Information.................................................................................4 1.2 List of Accreditations .........................................................................................5 1.3 Product Description ...........................................................................................6 1.4 Test Methodology..............................................................................................7 1.5 Test Facility .......................................................................................................8 1.6 Measurement Uncertainty .................................................................................8 2. PRODUCT LABELING ------------------------------------------------------------------------------------ 9 3. SYSTEM TEST CONFIGURATION--------------------------------------------------------------------10 3.1 Justification......................................................................................................10 3.2 EUT Exercise Software ...................................................................................10 3.3 Special Accessories ........................................................................................10 3.4 Equipment Modifications .................................................................................10 3.5 Configuration of Tested System ......................................................................11 4. BLOCK DIAGRAM-----------------------------------------------------------------------------------------11 4.1 Schematic Block/Connection Diagram............................................................11 4.2 Theory of Operation ........................................................................................11 5. CUSTOMER’S DECLARATION ------------------------------------------------------------------------12 6. SPURIOUS RADIATED MEASUREMENT PHOTOS ---------------------------------------------13 7. SPURIOUS RADIATED EMISSION, BELOW 1 GHZ---------------------------------------------14 7.1 Test Specification ............................................................................................14 7.2 Test Procedure................................................................................................14 7.3 Measured Data................................................................................................15 7.4 Test Instrumentation Used, Radiated Measurements ....................................16 7.5 Field Strength Calculation ...............................................................................17 8. SPURIOUS RADIATED EMISSION ABOVE 1 GHZ ----------------------------------------------18 8.1 Radiated Emission Above 1 GHz....................................................................18 8.2 Test Data .........................................................................................................18 8.3 Test Instrumentation Used, Radiated Measurements Above 1 GHz ..............27 9. MAXIMUM TRANSMITTED PEAK POWER OUTPUT -------------------------------------------28 9.1 Test procedure ................................................................................................28 9.2 Results table....................................................................................................29 9.3 Test Equipment Used......................................................................................30 10. PEAK POWER OUTPUT OUT OF 902-928 MHZ BAND ----------------------------------------31 10.1 Test procedure ................................................................................................31 10.2 Results table....................................................................................................38 10.3 Test Equipment Used......................................................................................39 11. 20 DB BANDWIDTH---------------------------------------------------------------------------------------40 11.1 Test procedure ................................................................................................40 11.2 Results table....................................................................................................41 11.3 Test Equipment Used......................................................................................42 12. BAND EDGE SPECTRUM…

Text truncated - open the document above for the full version.

Spurious Radiated Measurement Photos Figure 1. Spurious Radiated Emission Test. Front
