RWZAMOIA90PCS GSM/GPRS Handset

-1- Thank you for choosing Amoi A90, the fashionable and elegant color screen mobile phone, especially for men. The A90 is the perfect integration of unparalleled contemporary design and consummate craftsmanship, bringing you easy communication, and entertainment, as well as highlighting your taste. Key features: Phonebook memory of 500 entries Schedule and Person Information PC Sync, Ebook, Voice memo Games, Karaoke, Music player 40-polyphonic ringtone (26) Internet access and surfing Message box lock function World time, Countdown Intelligent speed dial Vivid standby theme Dancing-Phone 3 Alarm clocks Specifications: GSM900/1800/1900MHz HR, FR and EFR voice codec GPRS class 10, WAP 1.2.1 SMS Size: 85x46x24 mm Weight: 80 g with slim batter The manufacturer may, at any time and without notice, make changes or improvements to the products offered, but will provide necessary corrigendum with this manual or release new version of this manual for the following lot. The Amoi logo and trademark are the property of the manufacturer. December 2003 TABLE OF CONTENTS Safety precautions.................................................6 Unpacking.............................................................8 Your Phone.........................................................11 Getting Started...................................................13 Installing a SIM Card.............................................13 -2- Charging a Battery.................................................16 Switching the Phone On/Off......................................19 Your Phones Modes.................................................20 Keys Description....................................................................21 Display....................................................................................22 Call Functions.....................................................24 Making Calls........................................................24 Making a Call From PhoneBook..................................24 Last Number Redialing.............................................25 Making International Calls.......................................25 Receiving Calls....................................................26 Missed Calls....................................................27 Call Menu......................................................28 Phonebook(PB)....................................................31 Storing a Phone Number in PB....................................32 PB Menu.............................................................33 Smart-Dial .........................................................33Search All.............................................................34 Search Name...............................................34 Search Number..............................................34 Add...................................................................34 PhBook Manager................................................34 Info....................................................................36 Call List............................................................37 Missed...............................................................37 Incoming.........................................................37 Outgoing..............................................................37 Entering Text......................................................38 Changing Text Input Mode........................................38 eZi Italian Mode.................................................39 eZi German Mode.................................................39 -3- eZi English Mode..................................................39 eZi French Mode..................................................41 eZi Spanish Mode..................................................41 ABC Mode.......................................................41 Numeric/123 Mode.................................................43 Using User’s Dictionary...........................................44 Adding a Word to the Dictionary.................................44 Deleting a Word from the Dictionary............................44 Using Menus......................................................45 Accessing a Menu Function........................................45 List of Menu Functions...........................................47 Displaying..........................................................53 Menu1-1...................................................53 Standby1- 2.....................................................53 Power Off1- 3....................................................54 Power On1- 4....................................................54 Internet...............................................................55 Audio Profile........................................................57 Settings...............................................................60 Clock4- 1.........................................................60 Mobile Setting4- 2..............................................60 Call Setting4- 3..................................................61 Security4- 4......................................................63 Network4- -4- 5.....................................................66 Divert4-6........................................................67 WAP 4-7.......................................................67 Toolbox................................................................71 Alarm5-1........................................................71 Voice Memo5- 2.................................................71 PC Sync5- 3.....................................................73 Calculator5- 4....................................................74 Countdown5- 5..................................................74 World Time5- 7.................................................75 Private info...........................................................76 Enable PWD6- 1................................................76 C…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST Federal Communications Commission Date: February 12, 2004 Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Amoi Electronics Co., Ltd respectfully requests confidentiality of certain materials provided with the submission of the Amoi A90 under FCC ID: RWZAMOIA90 in accordance with FCC Regulations 0.459. The confidentiality request applies to the following: Parts List, Operational Descriptions, Schematics Block Diagrams and Tune Up Procedures These items are considered as Trade Secrets and therefore public access to the proprietary material could possible result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Name: Louis A. Feudi Signature: Title: Operations Manager Date: February 12, 2004

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 17, 2004 RE: FCC ID: RM8AMOIA90_ATCB001046 Attention: Lou Feudi I have a few comments on this Application. 1. Please note that the equipment code PUE is for a part 101 unlicensed device. This device is a Part 24 device. Please correct the 731 to provide the proper equipment code (PCE). 2. Please provide a 731 form that give the EIRP power, frequency tolerance and emissions designator of this device. 3. Please note that the max conducted power in the EMC report is 28.02dBm while the maximum conducted power in the SAR report is 29.18dBm. Please note that this is a difference of more than 1 dB. If this were EIRP values the difference would be acceptable. However, since they are conducted powers, the FCC requires that the values between the EMC and SAR report be within 5%. Please explain why the EMC and SAR conducted power levels are about 25% different. Please correct as necessary. 4. Please note that once the initial device level and the substitution antenna level have been correlated, TIA603 EIRP calculation consists only of adding the measured signal generator output and the substitution antenna gain and then subtracting the cable loss giving a TIA603 EIRP value of 27.03dBm. As they have no appropriate place in the EIRP calculation, please explain why you included the other two values. Was this to correct for minor variations in the two initially measured values? 5. Please note that the OBW plots do not appear the same as an expected GSM signal. The OBW plots show an unexpected ‘spike’ that is 10dB higher than the rest of the signal. Please explain this spike. 6. Please note that the manual states GSM900 and GSM1800 use. Please note that these are EU frequencies and not US frequencies. Please provide a manual with reference to US frequencies. Also, does this device also operate on EU frequencies? 7. Please note that the manual provides no rf exposure information. Please provide a manual with all of the appropriate FCC information. 8. Please note that the schematics are unreadable. Please provide readable schematics for this device. 9. Please provide an operational description of the phone. You have only provided a theory of operation for the antenna. 10. Please provide the parts list and the factory tune up procedure for this device. Please note that if you want these held confidential, you will have to include them in the confidentiality request letter. 11. Please note that external and internal photos cannot be held confidential. Please provide a confidentiality request that only requests confidentiality for those items that can be held confidential. These include – Parts list, operational descriptions, schematics, Block diagrams and tune up procedures. 12. Please explain how the FCC ID label is permanently affixed to the device. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2 January 17, 2004 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

RE: FCC ID: RM8AMOIA90_ATCB001046 Attention: Lou Feudi I have a few comments on this Application. 1. Please note that the equipment code PUE is for a part 101 unlicensed device. This device is a Part 24 device. Please correct the 731 to provide the proper equipment code (PCE). The Form 731 has been corrected and uploaded. 2. Please provide a 731 form that give the EIRP power, frequency tolerance and emissions designator of this device. The Form 731 has been corrected and uploaded. 3. Please note that the max conducted power in the EMC report is 28.02dBm while the maximum conducted power in the SAR report is 29.18dBm. Please note that this is a difference of more than 1 dB. If this were EIRP values the difference would be acceptable. However, since they are conducted powers, the FCC requires that the values between the EMC and SAR report be within 5%. Please explain why the EMC and SAR conducted power levels are about 25% different. Please correct as necessary. The sample tested for SAR was originally non functional. The manufacturer sent new software to the SAR lab, which produced slightly higher results. In addition, the SAR lab allowed for a-.5 dB cable loss on the output cable. This accounts for the inconsistency in max conducted power. Yet, the SAR readings were still higher than the EMC readings. We corrected the conducted power measurement for the low channel. However, in order to assure correct EIRP radiated power measurement, we repeated the EIRP test on the low band, which had the highest EIRP measurement, at the higher conducted power level, using the upgraded software. Since the antenna has a –1dB gain at low channel, and a –2.2 dB gain at mid and high channel, the low channel EIRP measurement is the worst case application for the EIRP Power rating. Upon completion of the low channel measurement, we repeated mid channel and high channel conducted power and EIRP radiated power. Conducted power measurements were measured within .1 db lower than the original, so the original plots were provided. Radiated power has been repeated using the updated software commands, as well, and corrected based upon the values measured. The report and the Form 731 have been corrected to reflect the higher data, providing worst case results in all instances. 4. Please note that once the initial device level and the substitution antenna level have been correlated, TIA603 EIRP calculation consists only of adding the measured signal generator output and the substitution antenna gain and then subtracting the cable loss giving a TIA603 EIRP value of 27.03dBm. As they have no appropriate place in the EIRP calculation, please explain why you included the other two values. Was this to correct for minor variations in the two initially measured values? Yes. US Tech wished to be as accurate for each measurement as possible, so we included the values for each measurement. 5. Please note that the OBW plots do not appear the same as an expected GSM signal. The OBW plots show an unexpected ‘spike’ that is 10dB higher than the rest of the signal. Please explain this spike. Prior to submitting the application, and during testing, we noted the same “spike” on the OBW plots. After discussion with Tim Johnson and Bill Graff, Bill indicated that the design has a large over or undershoot on the PA turnoff. After further discussions, it was decided that the design flaw, while possibly a problem with the carrier purchasing the phones, was not a problem with the FCC. A copy of Bill’s and Tim’s email follows at the end of this correspondence. 6. Please note that the manual states GSM900 and GSM1800 use. Please note that these are EU frequencies and not US frequencies. Please provide a manual with reference to US frequencies. A copy of the manual is uploaded. On page 57, the manual references US frequencies. Also, does this device also operate on EU frequencies? Yes, it does. 7. Please note that the manual provides no rf exposure information. Please provide a manual with all of the appropriate FCC information. An updated copy of the manual has been uploaded 8. Please note that the schematics are unreadable. Please provide readable schematics for this device. The schematics are uploaded. Please note page 7 and 8 were uploaded separately. 9. Please provide an operational description of the phone. You have only provided a theory of operation for the antenna. Theory of operation of the phone has been uploaded. 10. Please provide the parts list and the factory tune up procedure for this device. Please note that if you want these held confidential, you will have to include them in the confidentiality request letter. Parts list and factory tune up procedure have been uploaded 11. Please note that external and internal photos cannot be held confidential. Please provide a confidentiality request that only requests confidentiality for those items that can be held confidential. These include – Parts list, operational descriptions, schematics, Block diagrams and tune up procedures. An updated letter has been uploaded 12. Please explain how the FCC ID label is permanently affixed to the device. The FCC ID is permanently affixed via an adhesive label inside the battery case. A Photo has been uploaded. Sincerely, Louis A. Feudi Operations Manager From:“William Graff” <[email protected]> To:“’Timothy R. Johnson’” <[email protected]> Subject:RE: 3 plots Date:Thu, 6 Nov 2003 11:02:32 -0700 X-Mailer:Microsoft Outlook, Build 10.0.4510 Importance:Normal Tim, They screwed up the design... Actually, try some zero-spam SA plots, or some o-scope plots with a diode detector. I think they will find a big over or undershoot during the PA turn on or turn off. Bill -----Original Message----- From:Timothy R. Johnson [mailto:[email protected]] Sent:Wednesday, November 05, 2003 11:51 AM To:[email protected]; [email protected]; [email protected] Subject:Fwd: 3 plots Bill, Can you comment on the attached plots. U.S. Tech is testing I belie…

Text truncated - open the document above for the full version.

Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. 1 of 25 DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab CELLTECH LABS INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information AMOI ELECTRONICS CO., LTD. 45 Tiyu Road, Xiamen Fujian, China 361 012 FCC Rule Part(s): 47 CFR §2.1093 Test Procedure(s): FCC OET Bulletin 65, Supplement C (01-01) IEEE Standard 1528-200X (Draft) FCC Device Classification: PCS Licensed Transmitter held to ear (PCE) Device Type: PCS GSM/GPRS Handset FCC ID: RWZAMOIA90 Model(s): A90 Mode(s) of Operation: PCS GSM (Voice) / PCS GPRS (Data) Tx Frequency Range(s): 1850.2 - 1909.8 MHz Max. RF Conducted Power Tested: 29.02 dBm (1850.2 MHz) 29.18 dBm (1880.0 MHz) 29.09 dBm (1909.8 MHz) Battery Type(s): Standard: 3.7 V Lithium-ion (950mAh) Slim: 3.7 V Lithium-ion (550mAh) Antenna Type(s): Stubby Body-Worn Accessories Tested: Ear-Microphone Max. SAR Measured: 1.06 W/kg (Head) / 0.763 W/kg (Body) Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), and IEEE Standard 1528-200X (Draft) for the General Population / Uncontrolled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Russell W. Pipe Senior Compliance Technologist Celltech Labs Inc. Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. 2 of 25 TABLE OF CONTENTS 1.0INTRODUCTION.....................................................................3 2.0DESCRIPTION OF DUT............................................................ 3 3.0SAR MEASUREMENT SYSTEM ............................................... 4 4.0MEASUREMENT SUMMARY..................................................... 5-7 5.0DETAILS OF SAR EVALUATION............................................... 8-9 6.0EVALUATION PROCEDURES................................................... 9-10 7.0SYSTEM PERFORMANCE CHECK............................................ 11 8.0SIMULATED TISSUE MIXTURES............................................... 12 9.0SAR SAFETY LIMITS............................................................... 12 10.0ROBOT SYSTEM SPECIFICATIONS........................................... 13 11.0PROBE SPECIFICATION (ET3DV6)............................................ 14 12.0SAM PHANTOM V4.0C............................................................. 14 13.0DEVICE HOLDER.................................................................... 14 14.0TEST EQUIPMENT LIST........................................................... 15 15.0MEASUREMENT UNCERTAINTIES............................................ 16-17 16.0REFERENCES........................................................................18 APPENDIX A - SAR MEASUREMENT DATA........................................... 19 APPENDIX B - SYSTEM PERFORMANCE CHECK DATA......................... 20 APPENDIX C - SYSTEM VALIDATION................................................... 21 APPENDIX D - PROBE CALIBRATION.................................................. 22 APPENDIX E - MEASURED FLUID DIELECTRIC PARAMETERS............... 23 APPENDIX F - SAM PHANTOM CERTIFICATE OF CONFORMITY............. 24 APPENDIX G - SAR TEST SETUP & DUT PHOTOGRAPHS...................... 25 Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. AMOI ELECTRONICS CO., LTD. FCC ID: RWZAMOIA90 3 of 25 Single-Mode PCS GSM/GPRS Handset (1850.2-1909.8 MHz) This measurement report shows that the AMOI ELECTRONICS CO., LTD. Model: A90 PCS GSM/GPRS Portable Handset FCC ID: RWZAMOIA90 complies with the SAR (Specific Absorption Rate) RF exposure requirements specified in FCC 47 CFR §2.1093 (see reference [1]) for the General Population / Uncontrolled Exposure environment. The test procedures described in FCC OET Bulletin 65, Supplement C, Edition 01-01 (see reference [2]), and IEEE Standard 1528-200X (Draft - see reference [3]) were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. DUT Type Single-Mode PCS GSM/GPRS Handset FCC Device Classification PCS Licensed Transmitter held to ear (PCE) FCC Rule Part(s) 47 CFR §2.1093 FCC OET Bulletin 65, Supplement C (01-01) Test Procedure(s) IEEE Standard 1528-200X (Draft) FCC ID RWZAMOIA90 Model(s) A90 Serial No. C57358N537X0T9N (Identical Prototype) Mode(s) of Operation PCS GSM (Voice) / PCS GPRS (Data) Tx Frequency Range(s) 1850.2 - 1909.8 MHz 1850.2 MHz 29.02 dBm 1880.0 MHz 29.18 dBm Max. RF Conducted Power Tested 1909.8 MHz29.09 dBm Standard 3.7V Lithium-ion 950mAh Battery Type(s) Slim 3.7V Lithium-ion 550mAh Antenna Type(s) Stubby Length: 22 mm Body-Worn Accessories Tested Ear-Microphone 1.0 INTRODUCTION 2.0 DESCRIPTION of DEVICE UNDER TEST (DUT) Test Report S/N: 111…

Text truncated - open the document above for the full version.

Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. AMOI ELECTRONICS CO., LTD. FCC ID: RWZAMOIA90 22 of 25 Single-Mode PCS GSM/GPRS Handset (1850.2-1909.8 MHz) APPENDIX D - PROBE CALIBRATION Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. AMOI ELECTRONICS CO., LTD. FCC ID: RWZAMOIA90 23 of 25 Single-Mode PCS GSM/GPRS Handset (1850.2-1909.8 MHz) APPENDIX E - MEASURED FLUID DIELECTRIC PARAMETERS 1800 MHz System Performance Check Measured Fluid Dielectric Parameters (Brain) November 27, 2003 Frequency 1.700000000 GHz 1.710000000 GHz 1.720000000 GHz 1.730000000 GHz 1.740000000 GHz 1.750000000 GHz 1.760000000 GHz 1.770000000 GHz 1.780000000 GHz 1.790000000 GHz 1.800000000 GHz 1.810000000 GHz 1.820000000 GHz 1.830000000 GHz 1.840000000 GHz 1.850000000 GHz 1.860000000 GHz 1.870000000 GHz 1.880000000 GHz 1.890000000 GHz 1.900000000 GHz e'e'' 39.092213.8027 39.041113.8187 38.989113.8199 38.929813.8440 38.862513.8790 38.801813.9013 38.750913.9489 38.708213.9765 38.648613.9988 38.612614.0228 38.553814.0419 38.504314.0801 38.466614.0692 38.420614.0936 38.391614.0991 38.362014.1020 38.317514.1081 38.278614.1318 38.250614.1520 38.203614.1927 38.181814.2240 1880 MHz DUT Evaluation (Head) Measured Fluid Dielectric Parameters (Brain) November 27, 2003 Frequency 1.800000000 GHz 1.810000000 GHz 1.820000000 GHz 1.830000000 GHz 1.840000000 GHz 1.850000000 GHz 1.860000000 GHz 1.870000000 GHz 1.880000000 GHz 1.890000000 GHz 1.900000000 GHz 1.910000000 GHz 1.920000000 GHz 1.930000000 GHz 1.940000000 GHz 1.950000000 GHz 1.960000000 GHz 1.970000000 GHz 1.980000000 GHz 1.990000000 GHz 2.000000000 GHz e'e'' 38.840913.3663 38.802513.3985 38.730713.4176 38.709213.4487 38.665413.4455 38.612313.4452 38.585513.4471 38.538613.4584 38.492713.4840 38.468713.5288 38.422313.5638 38.378813.6205 38.347813.6432 38.328913.7021 38.301113.7169 38.271813.7415 38.228613.7517 38.195213.7530 38.127713.7763 38.082513.8145 38.028413.8327 1800 MHz System Performance Check Measured Fluid Dielectric Parameters (Brain) November 28, 2003 Frequency 1.700000000 GHz 1.710000000 GHz 1.720000000 GHz 1.730000000 GHz 1.740000000 GHz 1.750000000 GHz 1.760000000 GHz 1.770000000 GHz 1.780000000 GHz 1.790000000 GHz 1.800000000 GHz 1.810000000 GHz 1.820000000 GHz 1.830000000 GHz 1.840000000 GHz 1.850000000 GHz 1.860000000 GHz 1.870000000 GHz 1.880000000 GHz 1.890000000 GHz 1.900000000 GHz e'e'' 38.883913.8932 38.846713.8990 38.772413.8916 38.725813.9093 38.649013.9258 38.590413.9721 38.533814.0297 38.482614.0781 38.436114.1056 38.397914.1345 38.335714.1774 38.300714.1865 38.242914.1910 38.197814.1945 38.154914.1849 38.121614.1849 38.069414.1815 38.036414.1936 37.992914.2211 37.959514.2780 37.941714.3196 1880 MHz DUT Evaluation (Head) Measured Fluid Dielectric Parameters (Brain) November 28, 2003 Frequency 1.800000000 GHz 1.810000000 GHz 1.820000000 GHz 1.830000000 GHz 1.840000000 GHz 1.850000000 GHz 1.860000000 GHz 1.870000000 GHz 1.880000000 GHz 1.890000000 GHz 1.900000000 GHz 1.910000000 GHz 1.920000000 GHz 1.930000000 GHz 1.940000000 GHz 1.950000000 GHz 1.960000000 GHz 1.970000000 GHz 1.980000000 GHz 1.990000000 GHz 2.000000000 GHz e'e'' 38.646013.3574 38.611513.3852 38.550113.3958 38.505213.3971 38.465613.4103 38.439013.4039 38.402713.4095 38.344313.4256 38.322913.4667 38.277813.4957 38.246313.5546 38.217713.5970 38.189213.6422 38.163013.6889 38.137513.7117 38.095913.7301 38.050913.7277 37.996213.7405 37.954013.7485 37.870013.7661 37.832113.8179 1800 MHz System Performance Check Measured Fluid Dielectric Parameters (Brain) December 01, 2003 Frequency 1.700000000 GHz 1.710000000 GHz 1.720000000 GHz 1.730000000 GHz 1.740000000 GHz 1.750000000 GHz 1.760000000 GHz 1.770000000 GHz 1.780000000 GHz 1.790000000 GHz 1.800000000 GHz 1.810000000 GHz 1.820000000 GHz 1.830000000 GHz 1.840000000 GHz 1.850000000 GHz 1.860000000 GHz 1.870000000 GHz 1.880000000 GHz 1.890000000 GHz 1.900000000 GHz e'e'' 39.012313.7879 38.973913.8096 38.921213.8146 38.859413.8343 38.785513.8734 38.728313.9124 38.667813.9535 38.622913.9980 38.562014.0334 38.526714.0633 38.477814.0830 38.420014.1322 38.367514.1364 38.319914.1469 38.277214.1487 38.232414.1552 38.184814.1753 38.139614.1824 38.100514.2128 38.051114.2583 38.026914.2946 1880 MHz DUT Evaluation (Body) Measured Fluid Dielectric Parameters (Muscle) December 01, 2003 Frequency 1.800000000 GHz 1.810000000 GHz 1.820000000 GHz 1.830000000 GHz 1.840000000 GHz 1.850000000 GHz 1.860000000 GHz 1.870000000 GHz 1.880000000 GHz 1.890000000 GHz 1.900000000 GHz 1.910000000 GHz 1.920000000 GHz 1.930000000 GHz 1.940000000 GHz 1.950000000 GHz 1.960000000 GHz 1.970000000 GHz 1.980000000 GHz 1.990000000 GHz 2.000000000 GHz e'e'' 51.889314.7615 51.855014.7936 51.788914.8240 51.764314.8629 51.723214.8801 51.683414.8966 51.656014.9171 51.610814.9318 51.567914.9592 51.544015.0061 51.516415.0386 51.467015.0764 51.460215.1159 51.417415.1450 51.397815.1858 51.378015.2125 51.324215.2313 51.293615.2579 51.258015.2966 51.204415.3523 51.171815.3748 Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. AMOI ELECTRONICS CO., LTD. FCC ID: RWZAMOIA90 24 of 25 Single-Mode PCS GSM/GPRS Handset (1850.2-1909.8 MHz) APPENDIX F - SAM PHANTOM CERTIFICATE OF CONFORMITY Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. AMOI ELECTRONICS CO., LTD. FCC ID: RWZAMOIA90 25 of 25 Single-Mode PCS GSM/GPRS Handset (1850.2-1909.8 MHz) APPENDIX G - SAR TEST SETUP & DUT PHOTOGRAPHS Test Report S/N: 111203-445RWZ Test Date(s): Nov. 27-28 & Dec. 1, 2003 Test Type: FCC SAR Evaluation © 2003 Celltech Labs Inc. AMOI ELECTRONICS CO., LTD. FCC ID: RWZAMOIA90 Single-Mode PCS GSM/GPRS Handset (1850.2-1909.8 MHz) with Standard Battery with Standard Battery with Slim Battery with Slim Battery …

Text truncated - open the document above for the full version.

FCC Part 24, Certification Application of the Connexcel Model: Amoi A90 Cell Phone Issue Date: December 4, 2003 UST Project No.: 03-0321 U.S. Technologies, Inc.Test Report, FCC Part 24 Report Number:03-0321Issue Date: December 4, 2003 Customer: Connexcel Model: Amoi A90 Cell Phone TABLE OF CONTENTS SECTION 1 GENERAL INFORMATION 1.1Product Description 1.2Related Submittal(s) SECTION 2 TESTS AND MEASUREMENTS 2.1Configuration of Tested EUT 2.2Test Facility 2.3Test Equipment 2.4Modifications 2.5Antenna Description 2.6 Conducted RF Power Output 2.7Radiated RF Power Output 2.8Band-Edge Compliance 2.999% Occupied Bandwidth 2.10Spurious Emissions at Antenna Terminals 2.11Field Strength of Spurious Radiation 2.12 Frequency Stability, Voltage and Temperature Variation SECTION 3 PHOTOGRAPHS U.S. Technologies, Inc.Test Report, FCC Part 24 Report Number:03-0321Issue Date: December 4, 2003 Customer: Connexcel, L.L.C. Model: Amoi A90 Cell Phone LIST OF FIGURES AND TABLES FIGURES 1)Test Configuration 2) Photographs for Spurious Emissions 3) Conducted RF Power Output 4) Radiated RF Power Output 5) Band-Edge Compliance 6) 99% Occupied Bandwidth 7) Spurious Emissions at Antenna Terminals TABLES 1)EUT and Peripherals 2) Test Instruments 3) Conducted RF Power Output 4) Radiated RF Power Output 5) Band-Edge Compliance 6) 99% Occupied Bandwidth 7) Spurious Emissions at Antenna Terminals 8) Field Strength of Spurious Radiation U.S. Technologies, Inc.Test Report, FC…
