RYK-WHAB100125 Mbps 802.11g Wireless Powerline Access Point

1 Introduction The TRENDNET TPL-110AP Home Plug + Wireless 11g Access Point is like 2 devices in one box! The Home-Plug Wireless AP functions lets you to securely expand the range of your local area network, while Home-Plug utilizes the electric cord as the transfer media, the 11G utilizes the electric wave. The TRENDNET TPL-110AP Home Plug + Wireless 11g Access Point offers a convenient way to create a simple network through the existing power line of a home or office with the additional ability to provide you with access to your network without wires. Offering several levels of security, the TPL-110AP is built with 128-bit WEP encryption and 802.11i (WPA / TKIP, AES, PSK) for the wireless pass-through and 56-bit DES encryption for the Power line pass-through There are also some Enhanced Security Management Functions: Wireless/Wired 802.1x, and Embedded RADIUS Server so your data will always be secured—guaranteed. The TRENDNET TPL-110AP Home Plug + Wireless 11g Access Point has the latest IEEE 802.11g spec, which provide data rate at 54Mbps. Because of the high data rate and power line around everywhere, you can enjoy the high quality video or any service in any place. For the latest product information, please visit us on the web at http://www.TRENDnet.com ** FCC, CE, UL certificated ** 2 Important Safety Information This product is intended for connection to the AC power. The following precautions should be taken when using this product. - Read all instructions before installing and operating this product. - Follow all warnings and instructions marked on the product. - Do not operate this product near water. - This product relies on a building’s electrical installation for short-circuit (over current) protection. - Do not allow anything to rest on the product. - The HomePlug Wireless Access Point should be plugged directly into an AC wall outlet. - Only a qualified technician should service this product. Opening or removing covers may result in exposure to dangerous voltage points or other risks. (Note: Opening or removing the covers will void your product warranty). - Unplug the HomePlug Wireless Access Point from the AC wall outlet and refer the product to a qualified service representative for the following conditions: - If liquid has been spilled onto the product. - If the product has been exposed to rain or water. - If the product does not operate normally when the operating instructions have been followed. - If the product exhibits a distinct change in performance. 3 Getting start with your Powerline Device Before installing your Powerline networking device, please examine and familiarize yourself with it. Below is a diagram of the TPL-110AP along with a brief description of what each LED and slot represent. Collisions ActivityPower WLANCollisions ActivityPower WLAN LED LED STATUS INDICATION Collisions (COL) Blinking Collisions Detected OFF No Collisions Detected Activity (ACT) Blinking Looking for Powerline Devices Fast Blinking Transmit/receive data OFF No Network Traffic Power ON Power On Off Power Off WLAN ON Wireless Connection Blinking Transmitting/Receiving wireless data traffic What This Package Contains? Upon you receive your wireless access point, please check that the following contents are packaged: - HomePlug Wireless Access Point (TPL-110AP) - CD-Rom (User’s Guide) - Multi-Language Quick Install Guide Necessary Equipment? - One or more computers with wireless device, and it's software already installed - Microsoft TCP/IP networking protocol installed on each PC - Web browser installed on each PC 4 Equipment that can be used with the TPL-110AP? - Broadband modem - Powerline Router - Additional PCs with a wireless or Powerline Device Important: After receiving the wireless access point, please check for any shipping damages to the carton and camera before proceeding with any installations. PC or Laptop Setup Guide Note: If you have not installed your Wireless device to your laptop So far, please do so. For instructions on how to install your Wireless device, please contact the manufacturer of that wireless device. To configure the Wireless device to work with your TPL-110AP, please follow the following steps: 1. Plug TPL-110AP into an outlet. 2. Go to the wireless card's configuration screen or window. It should resemble figure 1 or others. 5 PC or Laptop Setup Guide Note: If you have not installed your Wireless device to your laptop So far, please do so. For instructions on how to install your Wireless device, please contact the manufacturer of that wireless device. To configure the Wireless device to work with your TPL-110AP, please follow the following steps: 1. Plug TPL-110AP into an outlet. 2. Go to the wireless card's configuration screen or window. It should resemble figure 1 or others. 3. Make sure Infrastructure is selected. 4. In the SSID field, type in the following: default (This is case sensitive) 5. Make sure Fully Automatic is selected. 6. Click OK to exit the configuration window. Note: If you are using Windows XP you will not need to configure the PCMCIA card because Windows XP has an auto sense function included in the operating system. TPL-110AP Setup Guide You will need to temporarily change the IP address of your PC/laptop to setup your TPL-110AP. Follow these steps depending on your operating system. Note: If you have not changed the default Powerline password (HomePlug) or you get the same subnet (10.0.0.1/16) on your network then there is no need to continue this setup. Windows 98 SE / ME 1. Click on Start, then Settings, and then Control Panel. 2. Double click on the Network icon. 3. Select the TCP/IP Protocol entry. 4. Click on the Properties button. 5. Select the IP Address tab. 6. Select Specify an IP address. 7. Type in the following address: 10.0.0.10. 8. For the Subnet Mask, type: 255.255.255.0. 9. Click OK to close the TCP/IP properties panel. 10. Click OK to close the Network panel. 11. Restart the PC 6 Windows 2000 / XP 1. Open Netwo…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Page 3 Page 4 Page 5 Page 6 Page 7

FCC ID: RYK-WHAB100 Report No.RF930821L01B Technical Description The transmitter of the EUT (125 Mbps 802.11g Wireless Powerline Access Point) is powered by AC line. The antenna is a Inverted-F Antenna without any antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. This device is a 125 Mbps 802.11g Wireless Powerline Access Point, which operates in the 2.4GHz bands and can not transmitting simultaneously, the maximum data rate could be 54Mbps. For more detailed instruction, please take a look at the user’s manual.

FCC ID: RYK-WHAB100 Report No: SA930821L01B 1 RF EXPOSURE REPORT REPORT NO.: SA930821L01B MODEL NO.: EP-6800, TPL-110AP ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: SparkLAN Communications, Inc. ADDRESS: 3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C. ISSUED BY: Advance Data Technology Corporation TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: RYK-WHAB100 Report No: SA930821L01B 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: RYK-WHAB100 Report No: SA930821L01B 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: RYK-WHAB100 Report No: SA930821L01B 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 0 dBi or 1.00 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance: For DSSS Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241225.1770.0051.0 6243725.2930.0051.0 11246225.1190.0051.0 For OFDM: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241225.1190.0051.0 6243725.1190.0051.0 11246225.3510.0051.0

FCC ID: RYK-WHAB100 Report No.: RF930821L01B1Report Format Version 2.0.3 Reference No.: 940823L29 FCC TEST REPORT REPORT NO.: RF930821L01B MODEL NO.: EP-6800 (refer to page 6 for other model) RECEIVED: NA TESTED: Jun. 15 ~ Sep. 09, 2004 ISSUED: Aug. 25, 2005 APPLICANT: SparkLAN Communications, Inc. ADDRESS: 3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 63 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: RYK-WHAB100 Report No.: RF930821L01B2Report Format Version 2.0.3 Reference No.: 940823L29 TABLE OF CONTENTS 1.CERTIFICATION .............................................................................................................4 2.SUMMARY OF TEST RESULTS ....................................................................................5 2.1 MEASUREMENT UNCERTAINTY ..................................................................................5 3. GENERAL INFORMATION.............................................................................................6 3.1 GENERAL DESCRIPTION OF EUT................................................................................6 3.2 DESCRIPTION OF TEST MODES..................................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.............................................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..................................8 3.2.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ...............................................10 3.2.4 DESCRIPTION OF SUPPORT UNITS..........................................................................10 4. TEST TYPES AND RESULTS ....................................................................................... 11 4.1 CONDUCTED EMISSION MEASUREMENT ................................................................ 11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................................. 11 4.1.2 TEST INSTRUMENTS .................................................................................................. 11 4.1.3 TEST PROCEDURES ...................................................................................................12 4.1.4 DEVIATION FROM TEST STANDARD .........................................................................12 4.1.5 TEST SETUP ................................................................................................................13 4.1.6 EUT OPERATING CONDITIONS..................................................................................13 4.1.7 TEST RESULTS ............................................................................................................14 4.2 RADIATED EMISSION MEASUREMENT .....................................................................20 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ..................................................20 4.2.2 TEST INSTRUMENTS ..................................................................................................21 4.2.3 TEST PROCEDURES ...................................................................................................22 4.2.4 DEVIATION FROM TEST STANDARD .........................................................................23 4.2.5 TEST SETUP ................................................................................................................23 4.2.6 EUT OPERATING CONDITIONS..................................................................................23 4.2.7 TEST RESULTS ............................................................................................................24 4.3 6dB BANDWIDTH MEASUREMENT.............................................................................32 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT..........................................................32 4.3.2 TEST INSTRUMENTS ..................................................................................................32 4.3.3 TEST PROCEDURE .....................................................................................................33 4.3.4 DEVIATION FROM TEST STANDARD .........................................................................33 4.3.5 TEST SETUP ................................................................................................................33 4.3.6 EUT OPERATING CONDITIONS..................................................................................33 4.3.7 TEST RESULTS ............................................................................................................34 4.4 MAXIMUM PEAK OUTPUT POWER.............................................................................40 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.............................40 4.4.2 INSTRUMENTS ............................................................................................................40 4.4.3 TEST PROCEDURES ...................................................................................................41 4.4.4 DEVIATION FROM TEST STANDARD .........................................................................41 4.4.5 TEST SETUP ................................................................................................................41 4.4.6 EUT OPERATING CONDITIONS................................................................................…

Text truncated - open the document above for the full version.

FCC ID: RYK-WHAB100 Report No.: RF930821L01B61Report Format Version 2.0.3 Reference No.: 940823L29 5. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: RYK-WHAB100 Report No.: RF930821L01B62Report Format Version 2.0.3 Reference No.: 940823L29 RADIATED EMISSION TEST
