RYK-WMIA139AGXWireless 802.11a/b/g Mini PCI module

Installation Guide The combination of Antennas Type Ant model: Gain form antenna spec ANT.Type No1 EA-292B-1 2.4GHz:N/A 5.5~5.825GHz:4.15dBi Dipole Antenna No2 EA-292B 2.4GHz:N/A 5.15~5.35GHz:4.56dBi Dipole Antenna No3 HAO9SDP 2.4~2.5GHz:9dBi 5GHz:N/A High-Gain outdoor Directional antenna No4 HG2409UM 2.4GHz:8.5dBi 5GHz:N/A Omnidirectional WLAN marine antenna No5 HGA51G 2.4GHz:N/A 5.5~5.85GHz:8.0dBi TIKI (Printed antenna) Comment: Need professional installation to prefer only HAO9SDP part Please be notice that the end product which module installed for professional installation should meet the requirements as below: 1) Marketing * The device cannot be sold retail,to the general public or by mail order. It must be sold to dealers. 2) Requires professional installation; - installation must be controlled. - installed by licensed professionals ( EUT sold to dealer who hire installers) - installation requires special training ( special programming, access to keypad, field strength measurements made), this product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. 3) Application -The intended use is generally not for the general public. It is generally for industry/commercial use. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna, 3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change. As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, Indoor & Outdoor HD Multipoint Extender, etc.). IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: RYK-WMIA139AGX”. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.

3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C Phone: 02-2659-1880 FAX: 02-2659-5538 DECLARATION LETTER FCC ID: RYK-WMIA139AGX Date: October 23, 2007 To whom it may concern: We, the undersigned, declare that the WMIA-139AG ( FCC ID: RYK-WMIA139AGX ) doesn’t have“Ad Hoc on non-US frequencies＂ and/or “on DFS frequencies＂ Thank you. Sincerely, Mike Chen / CEO SparkLAN Communications, Inc. Tel: 02-2659-1880*100 Fax: 02-2659-5538 e-mail: [email protected] Web Site: http://www.sparklan.com

3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C Phone: 02-2659-1880 FAX: 02-2659-5538 Professional Installation Attestation DATE: 10.23.2007 Federal Communications Commission 445 12th Street, SW Washington, DC 20554 To Whom It May Concern: We, SparkLAN Communications, Inc., declare that radio module WMIA-139AG with antenna model “HAO9SDP” which has standard N type connector is for professionally installed end-product only. The module with antenna model HAO9SDP will be sold to clients who’s product can meet following “FCC professionally installed products guidelines” only: 1) The product cannot be sold retail to the general public or by mail order. It must be sold to dealers. 2) The product must required professional installation; - installation must be controlled. - installed by licensed professionals (EUT sold to dealer who hire installers) - installation requires special training (special programming, access to keypad, field strength measurements made) What is unique, sophisticated, complex, or specialized about the product which REQUIRES it to be installed by a professional installer. 3) The intended use of the product is generally not for the general public. It is generally for industry / commercial use. Thank you for your attention. Mike Chen / CEO SparkLAN Communications, Inc. Tel: 02-2659-1880*100 e-mail: [email protected] Web Site: http://www.sparklan.com

3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C Phone: 02-2659-1880 FAX: 02-2659-5538 FCC ID: RYK-WMIA139AGX Date: October 23, 2007 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Mike Chen / CEO SparkLAN Communications, Inc. Tel: 02-2659-1880*100 Fax: 02-2659-5538 e-mail: [email protected] Web Site: http://www.sparklan.com

3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C Phone: 02-2659-1880 FAX: 02-2659-5538 AGENCY AUTHORIZATION LETTER FCC ID: RYK-WMIA139AGX Date: October 23, 2007 To whom it may concern: We, the undersigned, hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by ADT within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Mike Chen / CEO SparkLAN Communications, Inc. Tel: 02-2659-1880*100 Fax: 02-2659-5538 e-mail: [email protected] Web Site: http://www.sparklan.com

FCC ID: RYK-WMIA139AGX Report No.: RF961003L09 Modular Approval Request Letter Advance Data Technology Nov. 06, 2007 Dear Application Examiner, SparkLAN Communications, Inc., It’s Wireless 802.11a/b/g Mini PCI module, FCC ID: RYK-WMIA139AGX would like to have your authorization as a modular approval specific to the mobile device. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip AR5112. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is AME8805MEFT, AME8802DEFT. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a PCMCIA to mini-PCI extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: RYK-WMIA139AGX Report No.: RF961003L09 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Gary Chang Assistant Manager Advance Data Technology

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID: RYK-WMIA139AGX Report No.: RF961003L09 Operational Description This device is a Wireless 802.11a/b/g Mini PCI module which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 108Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna for 2.4GHz is Hi-Gain Outdoor Directional Antenna with N Jack connector & Omnidirectional Wireless LAN Marine Antenna with RP-SMA plug connector. The antenna for 5GHz is Dipole antenna with Reverse SMA antenna connector and printed antenna with RP SMA Plug connector. This device is a 802.11abg wireless LAN, which operates in both of the 5GHz and 2.4GHz bands and can’t transmitting simultaneously, the maximum data rate could be 54Mbps. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met＂ Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

FCC ID: RYK-WMIA139AGX Report No: SA961003L09 1 RF EXPOSURE REPORT REPORT NO.: SA961003L09 MODEL NO.: WMIA-139AG ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: SparkLAN Communications, Inc. ADDRESS: 3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: RYK-WMIA139AGX Report No: SA961003L09 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: RYK-WMIA139AGX Report No: SA961003L09 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification A fixed radio is inside this device, so it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: RYK-WMIA139AGX Report No: SA961003L09 4 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are 9dBi or 7.943282(numeric) or 8.5dBi or 7.079458(numeric) (For 2.4G), 4.56dBi or 2.857591(numeric) or 8dBi or 6.309573(numeric) (For 5.0GHz) 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: 802.11b modulation For Antenna 9dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 22.803 0.036 1.0 6 2437 25.704 0.041 1.0 11 2462 28.249 0.045 1.0 For Antenna 8.5dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 22.803 0.032 1.0 6 2437 25.704 0.036 1.0 11 2462 28.249 0.040 1.0 802.11g modulation_Normal Mode For Antenna 9dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 25.235 0.040 1.0 6 2437 31.769 0.050 1.0 11 2462 28.973 0.046 1.0 For Antenna 8.5dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 25.235 0.036 1.0 6 2437 31.769 0.045 1.0 11 2462 28.973 0.041 1.0 FCC ID: RYK-WMIA139AGX Report No: SA961003L09 5 802.11g modulation_Turbo Mode For Antenna 9dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 6 2437 35.810 0.057 1.0 For Antenna 8.5dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 6 2437 35.810 0.050 1.0 802.11a modulation_Normal Mode For Antenna 4.56dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5180 20.184 0.011 1.0 2 5200 28.907 0.016 1.0 4 5240 28.445 0.016 1.0 9 5745 50.466 0.029 1.0 11 5785 50.933 0.029 1.0 13 5825 51.050 0.029 1.0 For Antenna 8dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5180 20.184 0.025 1.0 2 5200 28.907 0.036 1.0 4 5240 28.445 0.036 1.0 9 5745 50.466 0.063 1.0 11 5785 50.933 0.064 1.0 13 5825 51.050 0.064 1.0 802.11a modulation_Turbo Mode For Antenna 4.56dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5210 28.642 0.016 1.0 2 5760 50.466 0.029 1.0 3 5800 50.350 0.029 1.0 For Antenna 8dBi gain Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5210 28.642 0.036 1.0 2 5760 50.466 0.063 1.0 3 5800 50.350 0.063 1.0

Report No.: RF961003L09 1 Report Format Version 2.0.6 FCC TEST REPORT (15.247) REPORT NO.: RF961003L09 MODEL NO.: WMIA-139AG RECEIVED: Oct. 22, 2007 TESTED: Oct. 24 ~ Oct. 31, 2007 ISSUED: Nov. 02, 2007 APPLICANT: SparkLAN Communications, Inc. ADDRESS: 3Fl., No. 246, Sec. 1, Neihu Road., Neihu Chiu, Taipei Taiwan 114, R.O.C ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 122 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF961003L09 2 Report Format Version 2.0.6 TABLE OF CONTENTS 1. CERTIFICATION................................................................................................ 5 2. SUMMARY OF TEST RESULTS ....................................................................... 6 2.1 MEASUREMENT UNCERTAINTY .................................................................... 6 3. GENERAL INFORMATION ................................................................................ 7 3.1 GENERAL DESCRIPTION OF EUT .................................................................. 7 3.2 DESCRIPTION OF TEST MODES .................................................................... 8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ............................................... 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .................. 10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................. 14 3.4 DESCRIPTION OF SUPPORT UNITS ............................................................ 14 4. TEST TYPES AND RESULTS (FOR 2.4GHz)................................................. 15 4.1 RADIATED EMISSION MEASUREMENT ....................................................... 15 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ..................................... 15 4.1.2 TEST INSTRUMENTS..................................................................................... 16 4.1.3 TEST PROCEDURES ..................................................................................... 17 4.1.4 DEVIATION FROM TEST STANDARD............................................................ 17 4.1.5 TEST SETUP................................................................................................... 18 4.1.6 EUT OPERATING CONDITIONS .................................................................... 18 4.1.7 TEST RESULTS .............................................................................................. 19 4.2 CONDUCTED EMISSION MEASUREMENT .................................................. 35 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................ 35 4.2.2 TEST INSTRUMENTS..................................................................................... 35 4.2.3 TEST PROCEDURES ..................................................................................... 36 4.2.4 DEVIATION FROM TEST STANDARD............................................................ 36 4.2.5 TEST SETUP................................................................................................... 37 4.2.6 EUT OPERATING CONDITIONS .................................................................... 37 4.2.7 TEST RESULTS .............................................................................................. 38 4.3 6dB BANDWIDTH MEASUREMENT............................................................... 40 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ............................................ 40 4.3.2 TEST INSTRUMENTS..................................................................................... 40 4.3.3 TEST PROCEDURE........................................................................................ 40 4.3.4 DEVIATION FROM TEST STANDARD............................................................ 40 4.3.5 TEST SETUP................................................................................................... 41 4.3.6 EUT OPERATING CONDITIONS .................................................................... 41 4.3.7 TEST RESULTS .............................................................................................. 42 4.4 MAXIMUM PEAK OUTPUT POWER............................................................... 47 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ............... 47 4.4.2 INSTRUMENTS ............................................................................................... 47 4.4.3 TEST PROCEDURES ..................................................................................... 47 4.4.4 DEVIATION FROM TEST STANDARD............................................................ 48 4.4.5 TEST SETUP................................................................................................... 48 4.4.6 EUT OPERATING CONDITIONS .................................................................... 48 4.4.7 TEST RESULTS .............................................................................................. 49 4.5 POWER SPECTRAL DENSITY MEASUREMENT .......................................... 51 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ....................... 51 4.5.2 TEST INSTRUMENTS..................................................................................... 51 4.5.3 TEST PROCEDURE........................................................................................ 51 4.5.4 DEVIATION FROM TEST STANDARD............................................................ 52 Report No.: RF961003L09 3 Report Format Version 2.0.6 4.5.5 TEST SETUP...............…
