RYKWL760AWLAN 802.11b/g PCI Adapter

Wireless Network Card Series User’s Guide Version 1 User’s Guide 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device has been designed to operate with an antenna having a maximum gain of 3 dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms. User’s Guide 2 Copyright statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise without the prior writing of the publisher. May 2005 User’s Guide 3 Contents 1. Introduction.............................................................................................................. 5 2. Wireless LAN Basics ............................................................................................... 6 3. Installation for Windows platform ............................................................................. 7 3.1. Installation Overview............................................................................................. 8 3.2. Install Procedure for Windows .............................................................................. 9 3.3 Uninstall Procedure ............................................................................................. 14 4. Configuration Utility ............................................................................................... 15 4.1 Link Information ................................................................................................... 16 4.2 AP List ................................................................................................................. 18 4.3 Profile Setting ...................................................................................................... 19 4.4 About ................................................................................................................... 23 5. Appendix ............................................................................................................... 24 User’s Guide 4 1. Introduction Thank you for purchasing your Wireless LAN Adapter. This User’ s Guide will assist you with the installation procedure. The package you have received should contain the following items: • Wireless LAN Adapter • Quick Installation Guide • CD containing Wireless network adapter utility & drivers and User’s Guide Note: if anything is missing, please contact your vendor Note: This manual is valid for all Wireless LAN adapters, such as PC Card, USB, mini- USB, PCI adapter, mini-PCI...etc. User’s Guide 5 2. Wireless LAN Basics Wireless LAN (Local Area Networks) systems offer a great number of advantages over a traditional, wired system. Wireless LANs (WLANs) are more flexible, easier to setup and manage and often more cost effective than their wired equivalence. Using radio frequency (RF) technology, WLANs transmit and receive data over the air, minimizing the need for wired connections. Thus, WLANs combine data connectivity with user mobility, and, through simplified configuration, enable movable LANs. With wireless LANs, users can access shared information without looking for a place to plug in and network managers can set up or augment network…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Label Location

Page 3

FCC ID: RYKWL760A Report No.: RF990628C13 Operational Description This device is a WLAN 802.11b/g PCI Adapter which operates in the 2.4GHz frequency spectrum with throughput of up to 108Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 108Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered from host equipment. The antenna is NMO Socket antenna with R-SMA antenna connector. The other instruction, please have a look at the users manual.

Report No.: SA990628C13 Report Format Version 3.0.1. 1 RF EXPOSURE REPORT REPORT NO.: SA990628C13 MODEL NO.: WL-760A FCC ID: RYKWL760A ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: SparkLAN Communications, Inc. ADDRESS: 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei City 11493, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan Report No.: SA990628C13 Report Format Version 3.0.1. 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 4. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) MAXIMUM ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 23.5 3 20 0.0889 1.00

Report No.: RF990628C13 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF990628C13 MODEL NO.: WL-760A FCC ID: RYKWL760A RECEIVED: June 28, 2010 TESTED: July 14 ~ 15, 2010 ISSUED: July 21, 2010 APPLICANT: SparkLAN Communications, Inc. ADDRESS: 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei City 11493, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 57 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990628C13 2 Report Format Version 3.0.1 TABLE OF CONTENTS 1. CERTIFICATION..........................................................................................4 2. SUMMARY OF TEST RESULTS.................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION..........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST..........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS............................10 3.4 DESCRIPTION OF SUPPORT UNITS.......................................................10 4. TEST TYPES AND RESULTS....................................................................11 4.1 RADIATED EMISSION MEASUREMENT..................................................11 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................11 4.1.2 TEST INSTRUMENTS...............................................................................12 4.1.3 TEST PROCEDURES...............................................................................13 4.1.4 DEVIATION FROM TEST STANDARD......................................................13 4.1.5 TEST SETUP.............................................................................................14 4.1.6 EUT OPERATING CONDITIONS...............................................................14 4.1.7 TEST RESULTS........................................................................................15 4.2 CONDUCTED EMISSION MEASUREMENT.............................................23 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................23 4.2.2 TEST INSTRUMENTS...............................................................................23 4.2.3 TEST PROCEDURES...............................................................................24 4.2.4 DEVIATION FROM TEST STANDARD......................................................24 4.2.5 TEST SETUP.............................................................................................25 4.2.6 EUT OPERATING CONDITIONS...............................................................25 4.2.7 TEST RESULTS........................................................................................26 4.3 6dB BANDWIDTH MEASUREMENT.........................................................28 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT.......................................28 4.3.2 TEST INSTRUMENTS...............................................................................28 4.3.3 TEST PROCEDURE..................................................................................28 4.3.4 DEVIATION FROM TEST STANDARD......................................................28 4.3.5 TEST SETUP.............................................................................................29 4.3.6 EUT OPERATING CONDITIONS...............................................................29 4.3.7 TEST RESULTS........................................................................................30 4.4 MAXIMUM OUTPUT POWER...................................................................33 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT..........33 4.4.2 INSTRUMENTS.........................................................................................33 4.4.3 TEST PROCEDURES...............................................................................33 4.4.4 DEVIATION FROM TEST STANDARD......................................................34 4.4.5 TEST SETUP.............................................................................................34 4.4.6 EUT OPERATING CONDITIONS...............................................................34 4.4.7 TEST RESULTS........................................................................................35 4.5 POWER SPECTRAL DENSITY MEASUREMENT....................................36 Report No.: RF990628C13 3 Report Format Version 3.0.1 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT..................36 4.5.2 TEST INSTRUMENTS...............................................................................36 4.5.3 TEST PROCEDURE..................................................................................36 4.5.4 DEVIATION FROM TEST STANDARD......................................................37 4.5.5 TEST SETUP.............................................................................................37 4.5.6 EUT OPERATING CONDITION.................................................................37 4.5.7 TEST RESULTS........................................................................................38 4.6 BAND EDGES MEASUREMENT...............................................................41 4.6.1 LIMITS…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST 3
