SBCMP3200Mobile Printer with Bluetooth

User’s Guide VersaJet Mobile Printer MP3200 Series Notices PC Worth makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranty of merchantability and fitness for any particular purpose. PC Worth shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance, or use of this publication. This publication contains proprietary information that is protected by copyright. All rights are reserved. No part of this publication may be photocopied, reproduced or translated into any language, in any forms, in an electronic retrieval system or otherwise, without prior written permission of PC Worth. The information contained in this publication may be revised or withdrawn at any time without notice. Trademarks All registered and unregistered trademarks used herein are the exclusive property of their respective owners. Copyright Copyright 1998-2005 PC Worth Int'l Co., Ltd. Copyright 1998-2005 Cino Group Regulatory Information FCC ID : SBCMP3200 15.21 You are cautioned that changes or modifications not expressly approved by the parts responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: „ Reorient or relocate the receiving antenna. „ Increase the separation between the equipment and receiver. „ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. „ Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The CE mark as shown above displayed on MP3200 series mobile printer indicates that this product has been tested in accordance with the procedures given in European Council R&TTE Directive (99/5/EC) and confirmed to comply with the European Standard EN 301 489-17, EN 300 328-2, EN 50371, EN 60950. 率輻理 率不更率率更 率不立 率療輻 Table of Contents Getting Started 1 Getting Familiar with MP3200 Series 2 Installing and Charging the Battery 3 Loading the Media 5 Performing a Self -Test Print 8 Operation 9 Switch Functions 9 LED Indicators 11 Power Save Mode 12 Auto Power Off 14 Troubleshooting 15 Getting Started Thank you for purchasing VersaJet MP3200 Series Mobile Printer. The MP3200 Series is designed with rugged yet lightweight architecture, delivering the ultimate convenience of mobility to meet your on-demanding labels and receipts printing requirement. IrDA, RS232 and Optional Bluetooth, communication interfaces are supported by MP3200, you can select the most suitable one which meets your demand to generate real-time labels and receipts. This User’s Guide provides all of the information required for installation, operation, configuration, maintenance and troubleshooting. For further information or specialized programming, please refer to the Programming Manual available on our web site at : www.cino.com.tw. ---------------------------------------------------------------------------------------- This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Notice: Any changes or modification not expressly approved by the party responsible could void the user's authority to operate the device. 1 1 Getting familiar with MP3200 Please familiarize yourself with the features of your MP3200 Series as shown in the following diagram. 2 2 Installing and Charging the Battery One Battery Pack is included with the Printer and is shipped uncharged. Please unpack the Battery Pack prior to use. The Printer is powered by a 7.2V 2200mAH Li-Ion Battery Pack. Be sure to fully charge the new rechargeable Battery Pack before using it for the first time. Following the steps below to charge the Battery Pack : Installing the Battery (1) Open Battery Pack Compartment by pushing down the cover lock button. Open the Cover Push Down the Cover Lock button Align the arrow sign (2) Slide the Battery Pack into the Battery Pack Compartment aligning with the arrow sign. (3) Close the cover of the Battery Pack Compartment. Close the Cover 3 3 Charging the Battery (1) Insert the charge cable into the printer charger jack, then plug the charger into the appropriate A.C. wall socket. (2) Power on the Printer by pressing the POWER …

Text truncated - open the document above for the full version.

Apr.28, 2005 Federal Communications Commission Authorization and Evaluation Division FCC ID: SBCMP3200 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Block Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Johnson Yu / Technical Director PC Worth Int’l Co., Ltd.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 14, 2005 RE: PC Worth Int’l Co, Ltd. FCC ID: SBCMP3200 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram should show the frequencies of all oscillators in the TX device (CFR 2.1033(a)(5)), unless this portion of the device is an OEM part from a different manufacturer. Please provide either the block diagram for the TX portion, or alternatively provide a parts list that shows that this part is provided by another manufacturer. Please update the list of confidential exhibits if necessary. 2) The schematics do not include the TX. Note that a schematic for the TX portion of the device is required as specified 2.1033(b)(5) for the RF section. Please provide either a schematic for the TX card or as an alternative, you may provide a parts list that lists that shows that this part is provided by another manufacturer. Please provide either a schematic or parts list as specified. If necessary, please update the confidentiality letter to include the parts list. 3) For AC power line emissions tests, the power supply cable does not appear to be bundled as specified in ANSI C63.4. Please review and correct/retest as necessary. 4) Devices under 15.247 are subject to RF exposure requirements. Even though the EIRP of this device is < 24 mW, it would still be recommended to provide an appropriate RF exposure for this application. I have provided a sample (see attachment) that shows a good example on how to handle for these types of devices. 5) This device contains and RS-232 interface and is also considered a PC peripheral device (in addition to the TX requirements, i.e. Part 15 for Bluetooth, etc.) and is subject to either a Certification or DoC as a PC peripheral. Therefore the application must clarify if you are asking for: a) Certification of the device as a TX, and a DoC has been performed by an appropriately accredited test lab for a PC peripheral b) Certification as a TX + PC peripheral. Note 1: The option b) would be considered as a composite application and 2 certificates (one for the TX, one for the PC peripheral portion) would be issued. Note that there are additional review costs associated with this additional certification. Note 2: To qualify to perform DoC applications, the test lab must be accredited (i.e. NVLAP or A2LA) to perform testing under the DoC procedure. Note 3: Note that for DoC tests, the device is configured with a minimum test configuration as specified by ANSI C63.4 which includes complete computer + 2 I/O devices attached (one may be the EUT) during this particular test.. Note 4: Each path (DoC or Certificaiton) has particular labeling requirements that must be followed. For DoC authorizations, the label should also include specific DoC labeling information and also the users manual should include information regarding Part 2.1077. If the device is Certified, the FCC ID and current labeling requirements for the TX will cover the labeling requirements. However, additional grants are generated and review z Page 2 June 14, 2005 costs are higher. Currently labeling and users manual do not support a DoC Authorization. The manufacturer does have a choice of DoC or Certification, however the device labeling must match the appropriate methods used. 6) Please explain the use of 2, 4, and 6 in the calculations of section 12.3. It is thought this should be 1, 3, and 5. Please see attached theory. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 16, 2005 RE: PC Worth Int’l Co, Ltd. FCC ID: SBCMP3200 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The parts list does not appear to show the RF module utilized in the device, however the Bluetooth module information also uploaded is assumed to be the RF module utilized and manufactured by CC&C. If the module information provided is for the correct module, there are concerns regarding the Antenna gain and output power shown in the specification. The maximum antenna gain reported in the application is 3 dBi, while the antenna given in the specification is 2 dBi. The maximum output power measured was 6.1 dBm, while the specification shows 13 dBm. Please explain and help resolve these discrepancies. There is a concern that either the incorrect specification was provided, or that the device may not have been operating under maximum output power conditions during testing which would require retesting. Please review. 2) The updated MPE information in the report cites 20 cm as a estimation distance. Note that due to the use of this device, 20 cm can not be assumed. Additionally, MPE estimates for less than 20 cm are not considered valid. Note that the provided example for RF exposure did not calculate power density, but simply compared worse case conducted and EIRP power to the FCC requirements for when SAR is necessary if a device is considered portable and reached a conclusion based upon this. MPE was therefore not calculated. Please reference the attached example again. 3) FYI.....If this device is also being approved under a DoC for the PC peripheral portion, then the users manual must also include the following information for DoC’s on a single page . Please ensure that the manufacturer implements these changes to the manual. COMPLIANCE INFORMATION FOR DoC AUTHORIZATIONS (47CFR 2.1077) If a product is tested and authorized under a Declaration of Conformity, a compliance information statement shall be supplied with the product at the time of marketing or importation, containing the following information on a single page: (1) Identification of the product, i.e. name and model number. (2) A statement similar to that contained in Section 15.19(a)(3) that the product complies with Part 15 of the regulations. (3) The identification, by name, address and telephone number, of the responsible party. The responsible party is defined as either the manufacturer, or if the equipment is imported, the importer. The responsible party for a Declaration of Conformity must be located within the United States. z Page 2 June 16, 2005 Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 20, 2005 RE: PC Worth Int’l Co, Ltd. FCC ID: SBCMP3200 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The Bluetooth schematic is not high enough resolution to satisfy the FCC. Please correct. 2) Is there an explanation for the 6.1 dBm to 13 dBm power difference mentioned in the last set of comments? 3) There are a few errors still in the RF exposure information: a) Please label column for Pout conducted. I believe this should be in dBm. b) The maximum antenna gain here is 2 dBi, while this was questioned in the last set of comments and the antenna information provided still suggests 3 dBi. c) The Pout EIRP appears to be miscalculated. Using 6.1 dBm and 3 dBi, I show an EIRP of 8.13 mW. Please reverify. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Tim, I apologize for sending you a wrong spec of the Bluetooth module. I've upload schematic, block diagram, and Antenna spec of that module to ATCB website. Also, the modified test report. Should there be any mistake or problem, please feel free to let me know. Thank you very much for your favorable consideration upon this case! Sincerely, Elisa --- Elisa Chen E&E Lab. of SGS Taiwan Ltd. E-Mail: [email protected] TEL: +886 2 2299 3279 ext. 1161 FAX: +886 2 2298 2698 No. 134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan >From: Timothy R. Johnson [mailto:[email protected] ] >Sent: Thursday, June 16, 2005 5:17 PM >To: Chen, Elisa (Taipei); Su, Vincent (Taipei) ...snip... >and to delete the email and all attachments from your system. > >Visit http://www.sgs.com From: "Chen, Elisa (Taipei)" <[email protected]> Subject: RE: Review of PC Worth Int'l Co., Ltd., FCC ID: SBCMP3200 To: "Timothy R. Johnson" <tjohnson ...snip... Taipei)" <[email protected]> Page 1 of 1In 6/20/2005Printed for "Timothy R. Johnson" <[email protected]>

Tim, Please find attached files for this project. I also upload these files to ATCB web. As to the power difference in module spec, our client said that is a draft spec. They gave us a wrong version. Thank you for your consideration upon this case! Regards, Elisa --- Elisa Chen E&E Lab. of SGS Taiwan Ltd. E-Mail: [email protected] TEL: +886 2 2299 3279 ext. 1161 FAX: +886 2 2298 2698 No. 134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan >From: Timothy R. Johnson [mailto:[email protected] ] >Sent: Monday, June 20, 2005 5:41 PM >To: Chen, Elisa (Taipei); Su, Vincent (Taipei) ...snip... >and to delete the email and all attachments from your system. > >Visit http://www.sgs.com BT-0232 Schematics (high resolution).pdf Test Report (ver.03).pdf From: "Chen, Elisa (Taipei)" <[email protected]> Subject: RE: Review of PC Worth Int'l Co., Ltd., FCC ID: SBCMP3200 after recent uploads To: "Timothy R. Johnson" <tjohnson ...snip... Taipei)" <[email protected]>

Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 2 EXTERNAL OF EUT Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA All View of EUT Front View of EUT Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Back View of EUT Bottom View of EUT Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Right View of EUT Left View of EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: PC Worth Int’l Co., Ltd. FCC ID: SBCMP3200 FCC ID: SBCMP3200 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 3 INTERNAL OF EUT Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Inside View of EUT Open View of EUT Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal View of EUT – 1 Internal View of EUT – 2 Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal View of EUT – 3 Internal View of EUT – 4 Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal View of EUT – 5 Open View of EUT Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal View of EUT – 1 Internal View of EUT – 2

Report No.: EM/2005/40063 Issue Date: May 06, 2005 Page: 1 of 33 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT UN-INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART B REQUIREMENT OF Product Name: Mobile Printer Brand Name: Cino Model Name: MP3200 Report No.: EM/2005/40063 Issue Date: May 06, 2005 FCC Rule Part: Part 15 B Prepared for PC Worth Int’l Co., Ltd. 18F, No. 100, Hsin-Tai-Wu Rd., Sec.1, Hsi-Chih, Taipei, Taiwan, 22102, R.O.C. Prepared by SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei County, Taiwan. Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. Report No.: EM/2005/40063 Issue Date: May 06, 2005 Page: 2 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA VERIFICATION OF COMPLIANCE Applicant: PC Worth Int’l Co., Ltd. 18F, No. 100, Hsin-Tai-Wu Rd., Sec.1, Hsi-Chih, Taipei, Taiwan, 22102, R.O.C. Product Description: Mobile Printer Brand Name: Cino Model No.: MP3200 Model Difference: N/A File Number: EM/2005/40063 Date of test: Apr. 23, 2005 ~ May 05, 2005 Date of EUT Receive: Apr. 23, 2005 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15B. The test results of this report relate only to the tested sample identified in this report. Test By: Date May 06, 2005 Sky Wang Prepared By: Date May 06, 2005 Elisa Chen Approved By: Date May 06, 2005 Vincent Su Report No.: EM/2005/40063 Issue Date: May 06, 2005 Page: 3 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Version Version No. Date 00 May 06, 2005 01 Jun. 10, 2005 Report No.: EM/2005/40063 Issue Date: May 06, 2005 Page: 4 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Table of Contents 1. GENERAL INFORMATION ........................................................................................... 5 1.1 PRODUCT DESCRIPTION................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) .............................................................................................. 5 1.3 TEST METHODOLOGY....................................................................................................................... 5 1.4 TEST FACILITY................................................................................................................................. 5 2. SYSTEM TEST CONFIGURATION .............................................................................. 6 2.1 EUT CONFIGURATION...................................................................................................................... 6 2.2 EUT EXERCISE................................................................................................................................. 6 2.3 TEST PROCEDURE............................................................................................................................. 6 2.4 LIMITATION...................................................................................................................................... 7 2.5 CONFIGURATION OF TESTED SYSTEM.............................................................................................. 8 3. SUMMARY OF TEST RESULTS ................................................................................... 9 4. DESCRIPTION OF TEST MODES ................................................................................ 9 5. CONDUCTED EMISSIONS TEST ............................................................................... 10 5.1 MEASUREMENT PROCEDURE: ........................................................................................................ 10 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................ 10 5.3 MEASUREMENT EQUIPMENT USED: ............................................................................................... 11 5.4 MEASUREMENT RESULT: ............................................................................................................... 12 6. RADIATED EMISSION TEST .........................................................................…

Text truncated - open the document above for the full version.

Report No: ER/2005/40028 ID: SBCMP3200 Issue Date: May 06, 2005 Page: 1 of 54 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. S…

Text truncated - open the document above for the full version.
