SBP2448A7INSTEON USB RF Dongle

Insteon Technologies, LLC
INSTEON USB RF Dongle - FCC ID SBP2448A7 - Insteon Technologies, LLC
Click to zoom

Application Details

Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant
Jun 13, 2010
Application Purpose
Original Equipment
Date of Application
Jun 09, 2010
Equipment Note
INSTEON USB RF Dongle
Frequency Range
914.90000000 - 915.10000000
Company
Insteon Technologies, LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Page 1 of 1 Rev. 05-10-2010 *USB Dongle Status LED will remain on as long as the unit is powered. Installing USB Drivers 1) Be sure the USB Dongle is not connected to your PC 2) Open a web browser, type in http://ftdichip.com/Drivers/CDM/CDM20600.exe and press enter “File Download” dialog box will appear NOTE: Driver is compatible with Windows, 2000, 2003, 2008, XP, Vista and 7. 3) Click Save, and then select a convenient location (like your desktop) and click Save 4) Locate the “CDM20600.exe” file on your PC, right-click on it, and then click Extract All... (Note: Unzip process may vary, depending on your default unzip utility) “Extraction Wizard” dialog box will appear 5) Follow the unzip utility steps until extraction is complete A folder containing “USB Drivers” will appear 6) Double-click on the folder “USB Drivers” and note the path. It will be needed for steps 10 and 14. 7) Plug USB Dongle into an available port on your PC The USB Dongle Status LED* will turn on solid green “Found New Hardware Wizard” will appear 8) Select Install from a list or specific location (Advanced) and click Next 9) Select Search for the best driver in these locations. Be sure the box “Include this location in the search” is checked, and then click Browse. 10) Locate the folder “USB Drivers” from step 6, select it in the dialog box and then click OK Once the driver is installed, wizard will display “Completing the Found New Hardware Wizard” 11) Click Finish Another “Found New Hardware Wizard” will appear 12) Repeat steps 8 - 11 13) Start your INSTEON software and follow its instructions to use USB Dongle EX: In HouseLinc, go to Tools -> Options Key Features • Works with HouseLinc and other INSTEON software • Straight-forward and simplified command set • Easy and trouble-free USB connection • Delivers commands to your INSTEON devices via RF technology • Stores over 1,023 INSTEON Links in 64KB of non-volatile memory Quick-Start Guide USB Dongle – INSTEON ® PowerLinc Modem USB Adapter Model: 2448A7 SmartLabs Limited Warranty – SmartLabs warrants to original consumer of this product for a period of 2 years from date of purchase, this product will be free from defects in material & workmanship & will perform in substantial conformity with its owner's manual. Warranty shall not apply to defects caused by misuse or neglect. U.S. Patent No. 7,345,998, International patents pending © Copyright 2010 SmartLabs, 16542 Millikan Ave., Irvine, CA 92606, 1-800-SMARTHOME (800-762-7846) Troubleshooting and Tech Support Call: Tech. Support @ 1-800-SMARTHOME (800-762-7846) Contact Us Online: http://www.smarthome.com/contactus.html FCC Compliance Statement This device complies with FCC Rules Part 15.Operation is subject to two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference that may be received or that may cause undesired operation. The digital circuitry of this device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and television reception. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause such interference, which can be verified by turning the device off and on, the user is encouraged to eliminate the interference by one or more of the following measures: • Re-orient or re-locate the receiving antenna of the device experiencing the interference. • Increase the distance between this device and the receiver. • Connect the device to an AC outlet on a circuit different from the one that supplies power to the receiver. • Consult the dealer or an experienced radio/TV technician. WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to o perate the equipment. Status LED

Cover Letter(s)

Non-Conformities FCC ID : SBP2448A7 (CKC CS Ref # E10-000040-FCC-01) The items listed below represent requests for information following review of this application for certification under United S tates (FCC) regulations. Further question may arise pending review of responses to these items. OK ID # Non-Conformity or Comment Subm itted Response Respondent / Date of Response x C 1 The operational description provided is missing RF characteristics information. Please provide some more details on the RF characteristics of the transmitter such as modulation type, pulse trains timing (if pulsed), etc. Operational Description Provided. John Lockyer 6/7/10 x TR 2 The test report does not include 15.207test data yet the device is powered via AC adapter from laptop. Please provide 15207 test data. Changes to the Reports Provided to the Report Department. Updated Test Report Provided. Eddie Wong 6/7/10 Report Department 6/9/10 T 3 4 5 6 The items indicated above must be submitted before processing can continue on the referenced application. Failure to provide t he requested information within 60 days may result in application dismissal pursuant to Section 2.917(c) and forfeiture of the filing fee pursuant to Se ction 1.1106. How to read the table: OK column indicates closure by CKC CS. ID column is for use with Agents to assist in identifying the probable source for closure. A – Application issue TL – Test lab issue C – Client issue R – Retesting may be necessary # column indicates unique or separate non-conformity items (note some items may be related). Non-Conformity or Comment column indicates the evaluators specific question or comment. Submitted response column indicates the response or a summary of the response provided. Respondent / Date of Response column indicates the responding party or agent and the date of the response was either received or logged.

Test Report

This report contains a total of 30 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. SmartLabs, Inc. ADDENDUM TO TEST REPORT 90598‐3 INSTEON USB RF Dongle, 2448A7 Tested To The Following Standards: FCC Part 15 Subpart C Sections 15.207, 15.249 & RSS‐210 Version 7 Report No.: 90598‐3A Date of issue: June 8, 2010 TESTING CERT #803.01, 803.02, 803.05, 803.06 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long‐term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2of 30 Report No.: 90598‐3A TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C .................................................................................................................................................... 6 Temperature and Humidity During Testing ............................................................................................................... 6 15.31(e) Voltage Variation ......................................................................................................................................... 6 15.33(a) Frequency Ranges Tested ............................................................................................................................ 6 EUT Operating Frequency .......................................................................................................................................... 6 15.207 AC Conducted Emissions................................................................................................................................ 7 15.249(a) Field Strength of Fundamental and Harmonics ....................................................................................... 14 15.249(d) 15.249(d) Field Strength of Spurious Emissions ...................................................................................... 18 Occupied Bandwidth (‐20dBc/RSS‐210) .................................................................................................................. 22 Bandedge ................................................................................................................................................................. 25 Supplemental Information .......................................................................................................................................... 29 Measurement Uncertainty ...................................................................................................................................... 29 Emissions Test Details .............................................................................................................................................. 29 Page 3of 30 Report No.: 90598‐3A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: SmartLabs, Inc. 16542 Millikan Ave. Irvine, CA 92606 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: John Lockyer Project Number: 90598 Customer Reference Number: 10‐3JL0319‐01 DATE OF EQUIPMENT RECEIPT: April9, 2010 DATE(S) OF TESTING: April9‐ 28, 2010 ‐June 7, 2010 Revision History Original: To perform testing of the INSTEON USB RF Dongle, 2448A7, with the requirements for FCC Part 15 Subpart C Sections 15.249 and RSS – 210. Addendum A: To add testing of the INSTEON USB RF Dongle, 2448A7, with the requirements for FCC Part 15 Subpart C Section 15.207. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Directo…

Text truncated - open the document above for the full version.

Contact Information

Applicant

John Lockyer(Suite 105-665)
[email protected]949-396-2114Fax: 949-396-2114

Technical Contact

CKC Certification Services, LLCJessina Hunter
[email protected]209-966-5240

4933 Sierra Pines Dr. · Mariposa, California · United States

Test Firm

CKC Laboratories, Inc.Steve Behm
[email protected]2099665240Fax: 2097426133

Technical Specifications

#Rule PartsFrequency RangePower Output
115C914.9 MHz - 915.1 MHz-
Confidentiality
Long Term
