Owner’s Manual INSTEON ® LED Bulb INSTEON I.D. printed on bulb Model: 2672-222 In the Box INSTEON LED Bulb Important: Read Before Installing INSTEON LED Bulb The INSTEON LED Bulb enters linking mode upon power-up if it does not contain any links. If not linked to a controller within 4 minutes, it will drop out of linking mode. Once linked to a controller, all linking and properties management must be done through a central controller or software. Installing INSTEON LED Bulb The INSTEON LED bulb is best setup and managed using home-management software such as HouseLinc. However, you can create a single responder link using these instructions. 1) Press and hold controller button until it beeps. (If using INSTEON app, tap Add button.) Controller LED will start blinking. You will have 4 minutes to complete the next step before linking mode automatically times out. 2) Screw INSTEON LED Bulb into a light socket. Bulb and controller will double-beep. 3) Test link by tapping controller button on and off. Bulb will turn on and off. Note: Bulb will only link at 100% brightness using these manual linking steps. It is capable of linking at all brightness levels via software. Troubleshooting Problem Possible Cause Solution The INSTEON signal may be too weak to reach INSTEON LED Bulb. Add additional INSTEON devices or relocate existing INSTEON devices. (All INSTEON devices act as network repeaters.) Make sure at least two dual-band INSTEON devices or Access Points (#2443) are properly installed to bridge the electrical phases. INSTEON LED Bulb won’t add to a scene as a responder. Certain products—such as TVs or refrigerators—may be producing noise or attenuation on the powerline. Install a powerline noise filter (FilterLinc #1626-10) to isolate the problem. INSTEON LED Bulb is taking a long time to respond to a controller. The controller may be sending commands to a responder that is no longer in use. Commands are being resent and delaying the signal to INSTEON LED Bulb. Remove all links from the controller to responders that are no longer in use. 2672-222 Rev. 6/5/2012 12:34 PM / See Owner’s Manual for Warranty Information. Protected under U.S. and foreign patents (see www.insteon.com) © Copyright 2012 INSTEON, 16542 Millikan Ave., Irvine, CA 92606, 800-762-7845 2672-222 Rev. 6/5/2012 12:34 PM / See Owner’s Manual for Warranty Information. Protected under U.S. and foreign patents (see www.insteon.com) © Copyright 2012 INSTEON, 16542 Millikan Ave., Irvine, CA 92606, 800-762-7845 INSTEON LED Bulb turned on by itself. INSTEON LED Bulb may be a member of a scene you’re not aware of. Remove all unwanted scene memberships from INSTEON LED Bulb using software. The controller can turn on INSTEON LED Bulb, but not turn it off. INSTEON LED Bulb may be linked at a very dim brightness level or at off. Relink INSTEON LED Bulb to the controller at a brighter level. If you have tried these suggested solutions, reviewed this Owner’s Manual and still cannot resolve an issue you are having with INSTEON LED Bulb, please call the INSTEON Support Line at 800-762-7845. Support Latest Owner’s Manual: http://www.insteon.com/support Call: INSTEON Support Line at 800-762-7845 FCC and Industry Canada Compliance Statement This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS-210. Operation is subject to the following two conditions: This device complies with FCC Rules Part 15C and Industry Canada RSS-210 (Rev. 8). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorise aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radiolectrique subi, mme si le brouillage est susceptible d'en compromettre le fonctionnement. The digital circuitry of this device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and television reception. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause such interference, which can be verified by turning the device off and on, the user is encouraged to eliminate the interference by one or more of the following measures: - Re-orient or relocate the receiving antenna of the device experiencing the interference - Increase the distance between this device and the receiver - Connect the device to an AC outlet on a circuit different from the one that supplies power to the receiver - Consult the dealer or an experienced radio/TV technician WARNING: Changes or modifications to this device not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Limited Warranty Seller warrants to the original consumer purchaser of this product that, for a period of two years from the date of purchase, this product will be free from defects in material and workmanship and will perform in substantial conformity to the description of the product in this Owner’s Manual. This warranty shall not apply to defects or errors caused by misuse or neglect. If the product is found to be defective in material or workmanship, or if the product does not perform as warranted above during the warranty period, Seller will either repair it, replace it, or refund the purchase price, at its option, upon receipt of the product …

Text truncated - open the document above for the full version.

Unit Label June 5, 2012 Subject: Unit Label BulbLinc TM – INSTEON ® LED Light Bulb #2672-222 FCC ID: SBP26722 IC: 5202A-26722 Label Text: Model: 2672-222 FCC ID: SBP26722 IC: 5202A-26722 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmul interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. 120 VAC 60Hz Assembled in USA www.insteon.com Protected by US and foreign patents

Unit Label Location June 5, 2012 Subject: Unit Label Location BulbLinc TM – INSTEON® LED Light Bulb #2672-222 FCC ID: SBP26722 IC: 5202A-26722

This report contains a total of 36 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. SmartLabs, Inc. TEST REPORT FOR INSTEON LED Light Bulb, 2672-222 BulbLinc Tested To The Following Standards: FCC Part 15 Subpart C Section 15.207 & 15.249 and RSS-210 Issue 8 Report No.: 93071-7 Date of issue: June 4, 2012 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 36 Report No.: 93071-7 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C ................................................................................................................................... 7 15.31(e) Voltage Variations ....................................................................................................................................... 7 15.207 AC Conducted Emissions ................................................................................................................................ 9 15.249(a) RF Power Output ..................................................................................................................................... 17 -20dBc Occupied Bandwidth ................................................................................................................................... 20 Bandedge ................................................................................................................................................................. 23 15.249(b)&(d) Field Strength of Spurious & Harmonic Emissions ........................................................................... 28 RSS-210 ....................................................................................................................................................... 33 99 % Bandwidth ....................................................................................................................................................... 33 Supplemental Information .......................................................................................................................... 35 Measurement Uncertainty ...................................................................................................................................... 35 Emissions Test Details .............................................................................................................................................. 35 Page 3 of 36 Report No.: 93071-7 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: SmartLabs, Inc. 16542 Millikan Ave. Irvine, CA 92606 Joyce Walker CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: Matthew Carter Project Number: 93071 Customer Reference Number: 12-3MC0417-01 DATE OF EQUIPMENT RECEIPT: May 21, 2012 DATE(S) OF TESTING: May 21 - 23, 2012 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 36 Report No.: 93071-7 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Brea A US0060 SL2-IN-E-1146R 3082D-1 90473 R-2945 C-3248 T-1572 Page 5 of 36 Report No.: 93071-7 SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C and RSS-…
