SBP47157 Day Thermostat

Quick-Start Guide Page 1 of 2 Rev. 09-23-2010 SMART Limited Warranty – SMART warrants to original consumer of this product for a period of 2 years from date of purchase, this product will be free from defects in material & workmanship & will perform in substantial conformity with its Owner's Manual. Warranty shall not apply to defects caused by misuse or neglect. U.S. Patent No. 7,345,998, International patents pending © Copyright 2010 SMART, 16542 Millikan Ave., Irvine, CA 92606, 866-883-9220 Backlit LCD Display Up button (glows red) 7 Day Thermostat Model: 4715 Heat or Cool Demand Indicator Mode button Down button (glows blue) Installation 1) RF-only devices require at least one dual-band INSTEON product for communication. For the best INSTEON network performance, be sure you have properly installed at least two dual-band INSTEON products. 2) Remove the old thermostat, but keep the old thermostat for reference purposes, until 7 Day Thermostat is functioning properly 3) Remove the front cover from 7 Day Thermostat 4) Mount 7 Day Thermostat using the included hardware 5) Configure the jumpers. (See the 7 Day Thermostat Installation and Programming Guide.) 6) Refer to the chart and diagrams below for basic 1 stage cooling, 1 stage heat wiring. For other wiring diagrams, see the Installation and Programming Guide. Wire from the old thermostat terminal marked Function Install on the new thermostat connector marked G or F Fan G Y1, Y, or C Cooling Y1 W1, W or H Heating W1/O/B Rh, R, M, Vr, A Power R C Common C O/B Rev. Valve W1/O/B W2 2 nd Stage Heat W2 MISC1 Configurable Output #1 MISC1 MISC2 Configurable Output #2 MISC2 MISC3 Configurable Output #3 MISC3 RS+5 Remote Sensor +5vdc RS+5 RS1 Remote Sensor Signal RS1 RSGND Remote Sensor Ground RSGND RS2 Remote Sensor Signal #2 RS2 7) Reattach the front cover to 7 Day Thermostat Wiring Diagrams Residential & Commercial 1 Stage Cooling, with 1 st Stage Gas Heat Residential & Commercial 1 Stage Cooling, with 1 st Stage Electric Heat Controlling 7 Day Thermostat • Tap an On or Scene button on a Linked Controller to recall the thermostat mode and set points established during Linking • Tap an Off button on a Linked Controller to turn off the thermostat and set points established during Linking • Tap the Bright* button on a Linked Controller to raise the set point(s) by a single degree • Tap the Dim* button on a Linked Controller to lower the set point(s) by a single degree *To prevent “runawa y” temperature set points, these operations only apply to Controllers with Bright/Dim buttons. FCC & Industry Canada Compliance Statement This device complies with FCC Rules Part 15 and Industry Canada RSS-210 (Rev. 7). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. The digital circuitry of this device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and television reception. However, there is not guarantee that interference will no occur in a particular installation. If this device does cause such interference, which can be verified by turning the device off and on, the user is encouraged to eliminate the interference by one or more of the following measures: • Re-orient or relocate the receiving antenna of the device experiencing the interference • Increase the distance between this device and the receiver • Connect the device to an AC outlet on a circuit different from the one that supplies power to the receiver • Consult the dealer or an experienced radio/TV technician WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Complete Instructions, Troubleshooting, and Tech Support Call: Tech. Support @ 866-883-9220 Contact Us Online: www.smartproline.com Page 2 of 2 Rev. 09-23-2010 SMART Limited Warranty – SMART warrants to original consumer of this product for a period of 2 years from date of purchase, this product will be free from defects in material & workmanship & will perform in substantial conformity with its Owner's Manual. Warranty shall not apply to defects caused by misuse or neglect. U.S. Patent No. 7,345,998, International patents pending © Copyright 2010 SMART, 16542 Millikan Ave., Irvine, CA 92606, 866-883-9220

Label Placement (On inside of back case)

7 Day Thermostat FCC ID: SBP4715 IC: 5202A-4715. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in China. #4715 U.S. Patent No. 7,345,998 www.smartproline.com

This report c written cons e TE S CERT #803 803.05 ontains a total of ent of CKC Laborat STING 3.01, 803.02, 5, 803.06 12 pages and ma tories, Inc. Te FCC This test rep testing perfo of ISO/IEC 1 CKC Laborato We strive t o sound, adapt our custome processes, bu ay be reproduced Smart TEST 7 Day Th ested To The C Part 15 Sub Repor Date of iss port bears th ormed herein 17025 under ories, Inc. o create long‐t tive, customer ers’ unique EM ut rather as th in full only. Partia tLabs, REPORT FO hermostat, e Following S bpart C Sect rt No.: 91000 sue: August 31 e accreditati o meets the tes the applicab term, trust ba r first testing MC challenges, e reason we a al reproduction m Inc. OR 4715 Standards: ions 15.249 ‐3 , 2010 on symbol ind st and reporti ble scope of sed relations h services. We , not as an int are in business may only be done dicating that ing requireme EMC testing hips by provid embrace each terruption to . with the the ents for ding h of set Page 2of 12 Report No.: 91000‐3 TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C § 15.249 ..................................................................................................................................... 7 15.249(a)(b) Carrier and Spurious Emissions ............................................................................................................. 7 Supplemental Information .......................................................................................................................................... 11 Measurement Uncertainty ...................................................................................................................................... 11 Emissions Test Details .............................................................................................................................................. 11 Page 3of 12 Report No.: 91000‐3 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: SmartLabs, Inc. 16542 Milikan Ave. Irvine, Ca 92606 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Matthew Carter Project Number: 91000 Customer Reference Number: 10‐3MC0805‐01 DATE OF EQUIPMENT RECEIPT: August17, 2010 DATE(S) OF TESTING: August20, 2010 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4of 12 Report No.: 91000‐3 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Site Registration & Accreditation Information Location Japan Canada FCC Brea A R‐2945, C‐3248 & T‐1572 3082D‐1 90473 Page 5of 12 Report No.: 91000‐3 SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C Section 15.249 Description Test Procedure/Method Results Carrier and Spurious Emissions FCC Part 15 Subpart C Section 15.249(a)(b)Pass Conditions During Testing This list is a summary of the conditions noted for or modifications made to the equipment during testing. Summary of Conditions None Page 6of 12 Report No.: 91000‐3 EQUIPMENT UNDER TEST(EUT) EQUIPMENT UNDER TEST 7 Day Thermostat Manuf: SmartLabs, Inc. Model: 4715 Serial: 11.B5.65 PERIPHERAL DEVICES The EUT was not tested with peripheral devices. Page 7of 12 Report No.: 91000‐3 FCC PART 15 SUBPART C § 15.249 15.249(a)(b) Carrier and Spurious Emissions Test Data Sheets Test Location: CKC Laboratories, Inc • 110 N. Olinda Place • Brea, CA 92823 • (714) 993-6112 Customer: SmartLabs, Inc. Specification: 15.249 Carrier and Spurious Emissions (902-908 MHz Transmitter) Work Order #: 91000 Date: 8/20/2010 Test Type: Radiated Scan Time: 16:18:35 Equipment: 7 Day Thermostat Sequence#: 1 Manufacturer: SmartLabs, Inc. Tested By: E. Wong Model: 4715 S/N: 11.B5.65 Test Equipment: ID Asset…

Text truncated - open the document above for the full version.

27611 La Paz Rd., Suite C, Laguna Niguel, CA 92677 Date of Test: November 16 to 20, 2007 IC ID: 5202A-2441 FCC ID: SBP2441V Test Report for SmartHome, Inc. on the 2441V TEST REPORT Report Number: 3139455LAX-002 Project Number: 3139455 November 27, 2007 Testing performed on the Insteon Thermostat RF Adapter Model: 2441V to FCC Part 15.249 RSS-210 Part A2.9 For SmartHome, Inc. A2LA Certificate Number: 2085.01 Test Performed by: Test Authorized by: Intertek 27611 La Paz Rd., Suite C Laguna Niguel, CA 92677 SmartHome, Inc. 16542 Millikan Ave. Irvine, CA 92606 Prepared by: Date:11/27/07 Sergey Marker Reviewed by: Date:11/27/07 Ollie Moyrong This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. File: 3139455LAX-002 Page 1 of 29 27611 La Paz Rd., Suite C, Laguna Niguel, CA 92677 Date of Test: November 16 to 20, 2007 IC ID: 5202A-2441 FCC ID: SBP2441V Test Report for SmartHome, Inc. on the 2441V File: 3139455LAX-002 Page 2 of 29 Table of Contents 1.0 Summary of Test Results............................................................................................................... 4 2.0 General Description ....................................................................................................................... 5 2.1 Product Description ............................................................................................................5 2.2 Related Submittal(s) Grants ................................................................................................ 6 2.3 Test Methodology ...............................................................................................................6 2.4 Test Facility ........................................................................................................................ 6 3.0 System Test Configuration............................................................................................................ 7 3.1 Justification ......................................................................................................................... 7 3.2 EUT Exercising Software ................................................................................................... 7 3.3 System Test Configuration ................................................................................................. 7 3.3.1 Support Equipment ................................................................................................ 7 3.3.2 Block Diagram of Test Setup................................................................................. 8 3.4 Equipment Modification ..................................................................................................... 8 3.5 Mode(s) of operation .......................................................................................................... 8 4.0 Field Strength of Emission ............................................................................................................ 9 4.1 Field Strength of Fundamental and Harmonics. ................................................................. 9 4.1.1 Test Procedure ....................................................................................................... 9 4.1.2 Field Strength Calculation ..................................................................................... 9 4.1.3 Radiated Emission Data....................................................................................... 11 4.2 Radiated Emission from Digital Parts and Receiver......................................................... 13 4.2.1 Test Procedure ..................................................................................................... 13 4.2.2 Field Strength Calculation ................................................................................... 13 4.2.3 Radiated Emission Data....................................................................................... 14 5.0 Out of Band Emission .................................................................................................................. 16 5.1 Test Description .................................................................................................................... 16 5.2 Test Procedure ..................................................................................................................... 16 5.3 Test Results .......................................................................................................................... 16 6.0 Antenna Requirement ................................................................................................................. 21 6.1 Test description .................................................................................................................... 21 6.2 Test Procedure ..................................................................................................................... 21 6.3 Test Result ........................................................................................................................... 21 7.0 Line Conducted Emission.....................................................................…
