SBP4773120-277V Heavy-Duty RF InLine Switch

May 17, 2011 120-277V Heavy-Duty RF InLine Switch Model: 4773 and Model: 2475SDB FCC ID: SBP4773 IC: 5202A-4773 The owner’s manual below may be accessed freely via the Internet with any web browser and supports the PDF format. www.smartproline.com/4773.html Complies with Section 5 of FCC document 784748 D01 Labeling Part 15 18 Guidelines v07 where cautionary statements in the user manual may be provided over the Internet. On-Line Owner’s Manual Containing Cautionary FCC & IC Statements

Page 1 of 1 Rev. 04-29-2011 SMART Limited Warranty – SMART warrants to original consumer of this product for a period of 2 years from date of purchase, this product will be free from defects in material & workmanship & will perform in substantial conformity with its Installation and Programming Guide. Warranty shall not apply to defects caused by misuse or neglect. U.S. Patent No. 7,345,998, International patents pending © Copyright 2011 SMART, 16542 Millikan Ave., Irvine, CA 92606, 866-883-9220 *Setup Modes will automatically time out after 4 minutes. Wiring Diagram NOTE: Home’s wire color and wire location may vary Figure 1 Installation 1) Be sure to write down the INSTEON ID and location of the fixture you’ll be controlling (e.g., 01.F7.G5, Mike’s bedroom light) 2) At the circuit breaker or fuse panel, disable the circuit supplying power to the fixture 3) Remove the wallplate from the fixture you are replacing. Then, unscrew the fixture itself and pull it out from the junction box. 4) Disconnect the wires from the fixture you will be controlling and ensure you have 1/2” of bare wire on the ends. If the wires cannot be detached by unscrewing them, cut the wires where they enter the switch and then strip ½ inch of insulation off the ends. 5) See Figure 1 to identify and connect the LINE, LOAD, NEUTRAL, and GROUND wires on In-Line Switch. Be sure you have correctly identified the wires in the junction box before connecting them. 6) After you have connected all the wires, ensure that the wire connectors are firmly attached and that there is no exposed copper except for the GROUND wire 7) Prior to reinstalling the fixture, enable power to the fixture from the circuit breaker or fuse panel 8) Use the On/Off buttons to test that the module is working and controlling the load 9) Link In-Line Switch to the desired INSTEON Controllers: a. Set the Controller to Linking Mode.* (For most Controllers, press & hold an On or Scene button for 10 seconds or the Set button for 3 seconds.) b. Press & hold the Set button on In-Line Switch until it double-beeps (3 seconds) The In-Line Switch Status LED will flash once and then turn on solid if the load is off or turn off if the load is on c. Confirm that Linking was successful by tapping the button you just Linked to on the Controller In-Line Switch will respond appropriately 10) Gently place In-Line Switch into the junction box, making sure that nothing could accidentally be pressing any of the buttons on its face 11) Reinstall the fixture Quick-Start Guide In-Line Switch, 277V Model: 4773 Tools Needed • Phillips screwdriver • Wire cutter / stripper • Voltage tester • Non-conductive probe Complete Instructions, Troubleshooting, and Tech Support Call: Tech. Support @ 866-883-9220 Contact Us Online: www.smartproline.com Set button On button Off button

External Photos FCC ID: SBP4773 IC: 5202A-4773 Front View External Photos FCC ID: SBP4773 IC: 5202A-4773 Rear View External Photos FCC ID: SBP4773 IC: 5202A-4773 Bottom End View External Photos FCC ID: SBP4773 IC: 5202A-4773 Top-End View External Photos FCC ID: SBP4773 IC: 5202A-4773 Right-Side View External Photos FCC ID: SBP4773 IC: 5202A-4773 Left-Side View

May 17, 2011 Subject: Unit Label 120-277V Heavy-Duty RF InLine Switch Model: 4773 and Model: 2475SDB FCC ID: SBP4773 IC: 5202A-4773 Specs: Width – 1.50 inches (36.1mm) Height – 1.573 inches (40mm) Surface Material: gloss white polyester face stock with a smooth, absorbent ink-receptive top coating Surface Material Thickness - .050 mm ± 10% ISO534 Base Material – Super-Calendared White Glassine Paper Base Thickness - 0.070mm ± 10% ISO534 Adhesive Base – Acrylic .025mm Thickness 24 hour 90° Peel (st,st)-FTM 2: 7.5 Service Temperature Range: -40°C~+80°C (when applied to polycarbonate) UL Recognized Listing # MH47798 Unit Label

May 17, 2011 120-277V Heavy-Duty RF InLine Switch Model: 4773 and Model: 2475SDB FCC ID: SBP4773 IC: 5202A-4773 Unit Label Location

Internal Photos FCC ID: SBP4773 IC: 5202A-4773 Back Case Removed Top View Back Case Removed Side View Internal Photos FCC ID: SBP4773 IC: 5202A-4773 Logic-Power PCB Side View Logic-Power PCB Side View Logic-Power PCB Side View Logic-Power PCB Side View Internal Photos FCC ID: SBP4773 IC: 5202A-4773 Logic-Power PCB Bottom View Top Metal Bracket Inside View Internal Photos FCC ID: SBP4773 IC: 5202A-4773 Switch-LED PCB Top View Switch-LED PCB Bottom View Internal Photos FCC ID: SBP4773 IC: 5202A-4773 RF Daughter PCB Top View RF Daughter PCB Top View RF Daughter PCB - Side View & Antenna Close-up

This report contains a total of 44 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. SmartLabs, Inc. TEST REPORT FOR 120‐277V Heavy‐Duty RF InLine Switch, 4773 Tested To The Following Standards: FCC Part 15 Subpart C Sections 15.207, 15.249 and RSS‐210 Issue 8 Report No.: 91847‐2 Date of issue: May 9, 2011 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long‐term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2of 44 Report No.: 91847‐2 TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C .................................................................................................................................................... 7 15.31(e) Voltage Variation on Power ........................................................................................................................ 7 15.207 AC Conducted Emissions................................................................................................................................ 9 15.249(a) Field Strength of Harmonics .................................................................................................................... 22 ‐20dBc Occupied Bandwidth ................................................................................................................................... 26 Bandedge ................................................................................................................................................................. 29 15.249(d) / 15.209 ‐ Field Strength of Spurious Emissions ...................................................................................... 33 RSS‐210 ........................................................................................................................................................................ 40 Supplemental Information .......................................................................................................................................... 43 Measurement Uncertainty ...................................................................................................................................... 43 Emissions Test Details .............................................................................................................................................. 43 Page 3of 44 Report No.: 91847‐2 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: SmartLabs, Inc. 16542 Millikan Ave. Irvine, CA 92606 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: John Lockyer Project Number: 91847 Customer Reference Number: 11‐3JL0411 DATE OF EQUIPMENT RECEIPT: April27, 2011 DATE(S) OF TESTING: April27‐29, 2011 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4of 44 Report No.: 91847‐2 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Site Registration & Accreditation Information Location CB # JAPAN CANADA FCC Brea A US0060 R‐2945, C‐3248 & T‐1572 3082D‐1 90473 Page 5of 44 Report No.: 91847‐2 SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C 15.207, 15.249 and RSS‐210 Issue 8 Description Test Procedure/Method Results Voltage Variation on Power FCC Part 15 Subpart C Section 15.31(e)Pa…
