SEJ-V3RV3R

REV:02/14/13 Zonar Systems’ V3R ™ Hardware Installation Tips For Professional Installers Zonar Systems’ equipment will provide years of reliable service if properly installed and maintained. Zonar equipment is typically installed in heavy vehicle applications and is often subject to extreme temperatures, dust, dirt, vibration, and shock. Proper installation is the critical first step to equipment longevity and optimal performance. This guide is meant to be a general guideline for the professional installer and technician. While we attempt to point out the most common installation questions and issues; common sense, good housekeeping procedures, attention to detail, safety adherence, and technical competence of the professional installer is critical for a successful installation. Please refer to your specific vehicle manufacturer guidelines for the installation of electrical components and wiring. A professional team of Zonar support technicians and engineers are available to answer your installation questions. Contact Zonar at 1-877-843-3847 or by email at [email protected]. Thank you, Andre J Horochiwsky Technical Training Manager – Zonar Systems As Zonar Systems is continuously improving the Product, Zonar may make changes to the Product at any time which may not be reflected in this document. INTRODUCTION 2 V3R ™ Introduction................................................................................................2 System Overview........................................................................................4 V3R Equipment .........................................................................................5 General Guidelines.....................................................................................6 V3R Mounting............................................................................................7 V3R Cable Management.............................................................................8 Power Cable Wiring Guidelines...................................................................9 External GPS Antenna Installation.............................................................10 System Check..........................................................................................11 System Checklist......................................................................................12 System Components and Specifications..................................................13 Installation Examples................................................................................14 System Installation Diagram......................................................................15 Troubleshooting...................................................................................16-17 Warranty & Notices - FCC Compliance.....................................................18 TABLE OF CONTENTS 3 © 2013 Zonar Systems • EVIR, ZPass,Ground Traffic Control and V3R are trademarks of Zonar Systems. All Rights Reserved. Products and services protected by one or more of the following US patents: 6671646, 6804626, 7117121, 7362229, 7557696, 7564375 and Australian patent: 2002322510 REV: 02/14/13 SYSTEM OVERVIEW 4 CUSTOMER On-Site Location ZONAR Secure Servers CELL TOWER INTERNET V3R EQUIPMENT 5 Fuse Holders ATC Style Fuses Crimpable Butt Splices V3R POWER CABLE ZONAR V3R™ INSTALLATION HARDWARE Mounting Hardware Layout 1) V3R unit must be located a minimum of 8” from any person. 2)Do not place Zonar RFID tags, cables, or other equipment in any location or position which may compromise human or equipment safety. 3)Verify placement acceptability with State DOT/Law enforcement prior to installation. 4)V3R has a temperature range of -40 ̊C (-40 ̊F) to +85 ̊C (+185 ̊F). Do not mount V3 in hot engine compartments or near hot exhaust components. 5)Lay all components out prior to installation to check for proper cable length and interference issues. 6)Avoid mounting Zonar equipment, antennas and wiring near other radio equipment (e.g.,two-way radios), PA equipment and high energy electrical sources (e.g., cables, relays, amplifiers, etc.). Electrical 1)Consult the vehicles manufacturer for specific installation guidelines. (HIGHLY RECOMMENDED for Multiplex electrical systems) 2)All power leads (Red and White Power leads) must be connected to the vehicles protected circuitry (e.g. fuse panel, circuit breaker panel, protected circuits). Never electrically connect Zonar equipment to unprotected circuits (e.g. directly to battery). 3)It is also required that all power leads (Red and White Power leads) be protected with a 3 to 5 amp fuse and inline fuse holder (included) for optimal system protection. 4)Electrical fuses should be installed as close as possible to the source of power. Do not open V3R housing. To do so will void the warranty and possibly lead to moisture intrusion. Drill Holes 1)Do not drill into the V3R unit. This will void the warranty. 2)Capture all drill chips during drilling operations. Do not allow chips to fall onto equipment, furnishings, etc. 3)Deburr all drill holes on both sides of drilled surface. Example deburr tool: 4)All drill holes must have a rubber grommet or similar anti- chaffing system installed to protect cable assemblies (e.g. plastic conduit). 5)Seal all penetration drill holes which may pass rain water. Cable Management 1)Strain relieve and support all cable installations. 2)Avoid sharp bends and tight radius installations of cables. 3)Avoid moving components (e.g. doors, steering shafts, handles, fans, etc.). 4)Provide an adequate “Service Loop” i.e. “cable slack” to allow for servicing of equipment. 5)Avoid routing cables thru doors, windows, and other pinch points. 6)Avoid routing cables in high personnel traffic areas. 7)Avoid routing antenna cables near radio and PA equipment. GENERAL GUIDELINES 6 INCORRECT •Bend radius too tight •Hole has sharp edges •Hole has no grommet CORRECT •Bend radius adequate •Hole has grommet G…

Text truncated - open the document above for the full version.

WTD 13.4.9 FCC Compliance Opinion ZONA0044 Information about the Applicant Grantee (Company Name) Zonar Systems, LLC FCC Contact Person Kelly Niemi Address 18200 Cascade Ave. S Suite, 200 City, State, Zip Seattle, WA 98188 Job Number ZONA0044 Model V3R FCC ID SEJ-V3R Agent A. Chandrasekhar, Ying Wang (for signing confidentiality request only) Approval Type Original Equipment Class DTS Digital Transmission System PCB PCS Licensed Transmitter Rule Part 15C, 22H, 24E Overview The Model V3R is a heavy-vehicle mounted telematics device used for gathering vehicle data. The data is sent to a Zonar database server via a GSM Modem. The V3R also contains an 802.11 b/g/n radio module. Confidentiality requested for allowed files. Request is properly addressed and referenced. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 4/17/2013

2107 N. First Street, Suite 680, San Jose CA 95131 – 2019, USA Tel: 408-748-3385 Fax: 408-705-2019 www.redpinesignals.com Date : 12 April2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, We hereby respectfully request that under the provision of 47 CFR 0.459 and 0.457(d), the documents listed below and attached with this application for certification be provided with confidential status. • Schematics • Theory of Operation Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain trade secrets that are treated as confidential by us. Substantial competitive harm to us could result should they be made available to the public. Sincerely, A. Chandrasekhar Vice President–Systems Redpine Signals Inc.

February 22, 2013 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: Re: Confidentiality Request for Exhibits in Support of FCC Filing under FCC ID: SEJ-V3R We hereby request that the exhibits listed below for FCC ID: N7NSL8080, submitted in support of the certification application for FCC ID: SEJ-V3R, be withheld from public disclosure. This request is made under the provisions of Section 0.457(d) and 0.459 of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. We cite trade secrets as the reason and purpose of the request.  Schematics  Block Diagram  Operation Description  Tune Up Procedure Best Regards Ying Wang Manager, Regulatory Compliance

ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 V3R External Photos This document is provided to show external photos of the V3R Telematics Device in accordance with FCC requirements per 2.1033(b)(7). Figure 1 Top ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 2 Side 1 Figure 3 Side 2 ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 4 Side 3 Figure 5 Side 4 ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 6 Bottom

ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 FCC ID Label & Location Document The FCC ID label for the V3R is located on the back of the device enclosure. This single lable contains the FCC id, the IC id, the Zonar model of ‘V3R’ as well as the specific part number, SCID and GPSid number of the particular device. Figure 1 Label located on the enclosure back ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 2 Label Close-up on Backside of Device ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 3 Label Contents Drawing

ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 V3R Internal Photos This document is provided to show internal photos of the V3R Telematics Device in accordance with FCC requirements per 2.1033(b)(7). Figure 1 V3R Lower enclosure and pass-through PCB Figure 2 V3R Composite adapter plate ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 3 V3R PCB Component/Bottom Side Figure 4 V3R PCB Antenna/Top Side ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 5 V3R Lower enclosure and pass-through PCB with adapter plate installed Figure 6 V3R Complete iternal assembly (top cover removed) ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 7 V3R GSM Radio Sub-Circuit Figure 8 V3R WiFi radio Sub-Circuit

ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Zonar V3R Telematics Device GSM Antenna Information This document provides antenna compliance information for the Zonar V3R telematics device. 1) In compliance with FCC requiremens of paragraph 15.203 of the FCC rules; the GSM antenna component is permantly mounded to the printed circuit board. There is no provision made for alternate antennas nor connectivity for any additional/external antenna. 2) The V3R device uses a single surface mount chip type antenna. a. The antenna manufacturer is: Antenova b. Manfacturer part number is: Reflexus c. Specific RF paramaters are as such: Parameter Frequency Value Peak gain 876 MHz 2dBi 1917 MHz 3.7dBi Average gain (Linear) 824-960 MHz -1.3dBi 1710-2170 MHz -1.5dBi Average efficiency 824-960 MHz 70% 1710-217 MHz >60% Maximum Return Loss -8 dB Maximum VSWR 2.3:1 ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 3) Details and photos of V3R GSM antenna: Figure 1 Antenna/Top side of V3R Device GSM antenna in the upper left ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 2 Close-up of GSM sub-circuit with antenna in the lower right ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 3 Top of GSM antenna chip Figure 4 Bottom side of antenna chip showing PCB surface mounting

ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Zonar V3R Telematics Device WiFi Antenna Information This document provides antenna compliance information for the Zonar V3R telematics device. 1) In compliance with FCC requiremens of paragraph 15.203 of the FCC rules; the WiFi antenna component is permantly mounded to the printed circuit board. There is no provision made for alternate antennas nor connectivity for any additional/external antenna. 2) The V3 device uses a single surface mount chip type antenna. a. The antenna manufacturer is: Johanson Technology b. Manfacturer part number is: 2450AT18A100 c. Antenna Frequency range is: 2400 - 2500 Mhz d. Specific RF paramaters are as such: Parameter Value Peak gain 0.5 dBi typ. (XZ-V) Average gain -0.5 dBi typ. (XZ-V) Minimum Return Loss 9.5 dB Maximum VSWR 2.3:1 ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 3) Details and photos of V3R WiFi antenna: Figure 1 Antenna/Top side of V3 Device WiFi antenna in the upper right ELECTRONIC FLEET MANAGEMENT www.zonarsystems.com ALL INFORMATION CONTAINED HEREIN IS CONFIDENTIAL & PROPRIETARY INFORMATION OF ZONAR SYSTEMS, INC. 18200 Cascade Ave. S. Seattle, WA 98188-4728 Toll-Free 1.877.843.3847 Phone 206.878.2459 Fax 206.878.3082 Figure 2 Close-up of WiFi sub-circuit with antenna in the lower left

Zonar Systems, LLC V3R Report No. ZONA0044.2 Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Evaluation Date of Evaluation: March 1, 2013 Zonar Systems, LLC Model: V3R Emissions Description of Evaluation Specification Evaluation Method Pass/Fail Maximum Permissible Exposure FCC 2.1091:2013 OET Bulletin 65, Supplement C Ed 01-01 Pass Approved By: Don Facteau, IS Manager NVLAP Lab Code: 200630-0 This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Report No. ZONA0044.22/9 REV 2012.08.02 REVISION HISTORY Revision Number Description Date Page Number 00 None Barometric Pressure The recorded barometric pressure has been normalized to sea level. Report No. ZONA0044.23/9 REV 2012.05.24 ACCREDITATIONS AND AUTHORIZATIONS United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea KCC / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. Russia GOST – Accredited by Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC to perform EMC and Hygienic testing for Information Technology products to GOST standards. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ Report No. ZONA0044.24/9 REV 2013.02.26 LOCATIONS Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs NC01-05,SU02,SU07 19201 120 th Ave. NE Bothell, WA 98011 (425) 984-6600 VCCI A-0108 A-0029 A-0109 A-0110 Industry Canada 2834D-1, 2834D-2 2834B-1, 2834B-2, 2834B-3 2834E-1 2834C-1 NVLAP NVLAP Lab Code: 200630-0 NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200629-0 Report No. ZONA0044.25/9 Product Description Revision 09/01/11 Client and Equipment Under Test (EUT) Information Company Name: Zonar Systems, LLC Address: 18200 Cascade Ave. S Suite 200 City, State, Zip: Seattle, WA 98188 Test Requested By: David Pascoe Model: V3R Date of Evaluation: March 6, 2013 Information Provided by the Party Requesting the Test Functional Description of the EUT (Equipment Under Test): Vehicle mounted equipment that contains a GSM/UMTS cellular modem and 802.11b/g/n radio. Objective: To demonstrate compliance with FCC requirements for RF exposure for 2.1091 mobile devices Report No. ZONA0044.26/9 WD.12.29.11 Maximum Permissible Exposure (MPE) OVERVIEW Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. ANSI C95.1-1992 specifies a minimum separation distance of 20 cm for performing reliable field measurements to determine adherence to MPE limits. If the minimum separation distance between a transmitter and nearby persons is more than 20 cm under normal operating conditions, compliance with MPE limits may be determined at such distance from the transmitter. When applicable, operation instructions and prominent warning labels may be used to alert the exposed persons to maintain a specified distance from the transmitter or to limit their exposure durations and usage conditions to ensure compliance. If the use of warning labels on a transmitter is not effective or desirable, the alternative of performing SAR evaluation with the device at its closest range to persons under normal operating conditions may be used. The field strength and power density limits adopted by the FCC are based on whole-body averaged exposure and the assumption of RF field levels relate most accurately to estimating whole-body averaged SAR. This means some local values of exposures exceeding the stated field strength and power density limits may not necessarily imply non-compliance if the spatial average of spatially averaged RF fields over the exposed portion…

Text truncated - open the document above for the full version.

Zonar Systems, LLC V3R FCC 15.247:2013 Report #: ZONA0044.1 Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington WTD 12.5.23 CERTIFICATE OF TEST Last Date of Test: February 25, 2013 Zonar Systems, LLC Model: V3R Emissions Test Description Specification Test Method Pass/Fail Radiated Channel Power FCC 15.247:2013 ANSI C63.10:2009 Pass Spurious Radiated Emissions FCC 15.247:2013 ANSI C63.10:2009 Pass Deviations From Test Standards None Approved By: Tim O'Shea, Operations Manager NVLAP Lab Code: 200676-0 Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 41 Tesla Ave. Irvine, CA 92618 Phone: (503) 844-4066 Fax: 844-3826 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada (Site filing #2834B-1). This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. REV 2012.08.02 REVISION HISTORY Revision Number Description Date Page Number 00 None Barometric Pressure The recorded barometric pressure has been normalized to sea level. REV 2012.05.24 ACCREDITATIONS AND AUTHORIZATIONS United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea KCC / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. Russia GOST – Accredited by Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC to perform EMC and Hygienic testing for Information Technology products to GOST standards. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ REV 2013.02.19 MEASUREMENT UNCERTAINTY Measurement Uncertainty When a measurement is made, the result will be different from the true or theoretically correct value. The difference is the result of tolerances in the measurement system that cannot be completely eliminated. To the extent that technology allows us, it has been our aim to minimize this error. Measurement uncertainty is a statistical expression of measurement error qualified by a probability distribution. A measurement uncertainty estimation has been performed for each test per our internal quality document WP 342. The estimation is used to compare the measured result with its "true" or theoretically correct value. The expanded measurement uncertainty (K=2) for each test is on each data sheet. Our measurement data meets or exceeds the measurement uncertainty requirements of the applicable specification; therefore, the test data can be compared directly to the specification limit to determine compliance. The calculations for estimating measurement uncertainty are based upon ETSI TR 100 028 (or CISPR 16-4-1 as applicable), and are available upon request. The following table represents the Measurement Uncertainty (MU) budgets for each of the tests that may be contained in this report. Test + MU - MU Frequency Accuracy (Hz) 0.12 -0.01 Amplitude Accuracy (dB) 0.49 -0.49 Conducted Power (dB) 0.41 -0.41 Radiated Power via Substitution (dB) 0.69 -0.68 Temperature (degrees C) 0.81 -0.81 Humidity (% RH) 2.89 -2.89 Field Strength (dB) 3.80 -3.80 AC Powerline Conducted Emissions (dB) 2.94 -2.94 REV 2013.02.26 LOCATIONS Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs NC01-05,SU02,SU07 19201 120 th Ave. NE Bothell, WA 98011 (425) 984-6600 VCCI A-0108 A-0029 A-0109 A-0110 Industry Canada 2834D-1, 2834D-2 2834B-1, 2834B-2, 2834B-3 2834E-1 2834C-1 NVLAP NVLAP Lab Code: 200630-0 NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200629-0 WTD 12.5.23 PRODUCT DESCRIPTION Client and Equipment Under Test (EUT) Information Company Name: Zonar Systems, LLC Address: 18200 Cascade Ave. S Suite, 200 City, State, Zip: Seattle, WA 98188 Test Requested By: David Pascoe Model: V3R First Date of Test: February 11, 2013 Last Date of Test: February 25, 2013 Receipt Date of Samples: February 11, 2013 Equipment Des…

Text truncated - open the document above for the full version.

Zonar Systems, LLC V3R FCC 22H:2013 FCC 24E:2013 FCC 15.109:2013 Report #: ZONA0044 Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington WTD 12.5.23 CERTIFICATE OF TEST Last Date of Test: April 1, 2013 Zonar Systems, LLC Model: V3R Emissions Test Description Specification Test Method Pass/Fail Effective Radiated Power (ERP) FCC 22H:2013 ANSI/TIA/EIA-603-C-2004 Pass Effective Radiated Power (EIRP) FCC 24E:2013 ANSI/TIA/EIA-603-C-2004 Pass Transmitter Spurious Emissions FCC 22H:2013 ANSI/TIA/EIA-603-C-2004 Pass Transmitter Spurious Emissions FCC 24E:2013 ANSI/TIA/EIA-603-C-2004 Pass Receiver Spurious Emissions FCC 15.109:2013 Class B ANSI C63.4:2009 Pass Deviations From Test Standards None Approved By: Tim O'Shea, Operations Manager NVLAP Lab Code: 200676-0 Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 41 Tesla Ave. Irvine, CA 92618 Phone: (503) 844-4066 Fax: 844-3826 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada (Site filing #2834B-1). This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its…

Text truncated - open the document above for the full version.
