SG71005V-ME101EVDO Rev.A Data card

Welcome to your V-ME101 multimode radio card. CONTENTS V-ME101 Introduction ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． 1 System Requirements ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． 2 Operation Guide ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． 2 Care and maintenance ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． 6 Important safety information ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． 8 1 V-ME101 Introduction Connect V-ME101 with PC, you can enjoy the functions brought by it as the following: 1 ． Surfing Internet 2 ． Making Activation(only dial *228) 3 ． Setting System Requirements PC with USB Port Windows2000SP4/XP SP2/Vista Hardware configuration should satisfy the demand of the operating system. Display Resolution ： Above 800x600 Note: If your PC has lower configuration ， the performance of V-ME101 may be lower. Operation Guide: Insert RUIM Card Acquire a RUIM card, and apply for CDMA RUIM data service. Confirm the 2 PIN is not set, if it is set, cancel the PIN first. Installation of Software Different operating system, the installation process is different, please according to the operation information. For example in Windows XP. 1 ． Connect V-ME101 with PC Connect V-ME101 with PC via USB. 2 ． Installation of the driver program After connecting V-ME101 with PC, a prompt is pop-up. Please install the driver program of Qualcomm first. (fig1) fig1 3 ． Installation of V-ME101 1. First installation, enter “my computer”, the interface is shown in fig2. 3 fig2 2. Double click “CD driver’, choose the file “*.exe”, enter dialog box “choose language”, choose the appropriate language. If PC has auto run function, the “choose language” would appear automatic, click “yes”. 3. Click “next” > “license” appear. 4. Read License Agreement, click “I agree” > “next”, the dialog box “select the directory” appear. 5. Select the right directory, click “next”>“select additional tasks” in the pop-up window, you can select which you need. Then click “next”>“install” > “finish”. 6. After installation, enter “my computer”, choose “CD driver” and click the right key of the mouse, choose “pop-up”, wait few seconds, the “removable disk” and “CD driver” disappear. 4 7. Back to desktop, click icon of V-ME101 , the main interface appear.(fig 3) fig3 The installation of V-ME101 is finish ， you can use it. Uninstall of Application Software 1. Exit Management procedures. 2. Remove the V-ME101 from the system then pull it out. 3. Open “add/remove program” in the control panel. 5 4. Accord the prompt, finish uninstall. Care and maintenance Your radio card is a product of superior design and craftsmanship and should be treated with care. the suggestions below will help you to fulfil any warranty obligations and to enjoy this product for many years. · Keep the radio card and all its parts and accessories out of small children's reach. · Keep the radio card dry. precipitation, humidity, and all types of liquids or moisture can contain minerals that will corrode electronic circuits. · Do not use or store the radio card in dusty, dirty areas. · Do not store the radio card in hot areas. High temperatures can shorten the life of electronic devices, and warp or melt certain plastics. · Do not store the radio card in cold areas. When it warms up (to its normal temperature), moisture can form inside, which may damage electronic circuit boards. · Do not attempt to open the radio card. Non-expert handling may damage it. 6 · Do not drop, knock, or shake the radio card. Rough handling can break internal circuit boards. · Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the radio card. · Do not paint the radio card. Paint can prevent proper operation. Use only the supplied antenna. Unauthorised antennas, modifications, or attachments could damage the radio card and may violate regulations governing radio devices. All of the above suggestions apply equally to your radio card or any accessory. If any of them is not working properly, take it to your nearest qualified service facility. The personnel there will assist you and, if necessary, arrange for service. Important safety information Traffic safety Do not use the radio card while driving a vehicle. Do not place the radio card on the passenger seat or where it can break loose in a collision or sudden stop. Operating environment 7 Remember to follow any special regulations in force in any area and always power off your radio card whenever it is forbidden to use it, or when it may cause interference or danger. note that the radio card may cause similar interference as any cellular terminal (e.g. mobile phone) and must not be used in areas where the use of any such device is prohibited. Use the radio card in its normal operating positions. Electronic devices Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your radio card. Pacemakers Pacemaker manufacturers recommend that a minimum separation of 20 cm (6 inches) be maintained between a radio card and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of wireless technology research. Persons with pacemakers: You should always keep the radio card more than 20cm (6 inches) from 8 their pacemaker when the radio card is powered on. You should not carry the radio card in a breast pocket. If you have any reason to suspect that interference is taking place, power off your radio card immediately. Hearing aids Some digital radio cards may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider. Other medical devices Operation of any radio transmitting equipment, including radio cards, may interfere with the functionality of inad…

Text truncated - open the document above for the full version.

Date: May 13, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Haier Telecom (Qingdao) Co., Ltd. , the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Haier Telecom (Qingdao) Co., Ltd. solely in matters relating to the application for an FCC equipment authorization for FCC ID # SG71005V-ME101 including the signing of documents in connection with this Application. Necessary acts carried out by Haier Telecom (Qingdao) Co., Ltd. on our behalf of the Haier Telecom (Qingdao) Co., Ltd. in connection with the Application shall have the same effect as acts of the Haier Telecom (Qingdao) Co., Ltd.. The Haier Telecom (Qingdao) Co., Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Sincerely Yours, James Shi Type Approval Manager Haier Telecom (Qingdao) Co., Ltd.

Date: May 13, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Haier Telecom (Qingdao) Co., Ltd. FCC ID: SG71005V-ME101 FCC Part 15B Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Haier Telecom (Qingdao) Co., Ltd. requests that the following documents regarding this submission for FCC ID: SG71005V-ME101 be kept confidential: Exhibit Type File Name Block Diagram SG71005V-ME101_Block Diagram.pdf Operational Description SG71005V-ME101_Operational Description.pdf Those documents contain detailed system and equipment description and related information about the product which Haier Telecom (Qingdao) Co., Ltd. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Haier Telecom (Qingdao) Co., Ltd. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. James Shi Type Approval Manager Haier Telecom (Qingdao) Co., Ltd.

External Photos of EUT 1. Front View of EUT 2. Back View of EUT 3. Side View of EUT

Label Label Location

Internal Photos

Report No.: SZ10040101E01 Page 2 of 13 TABLE OF CONTENTS 1. TEST CERTIFICATION ........................................................................................................... 3 2. GENERAL INFORMATION .................................................................................................... 4 2.1 EUT Description ......................................................................................................................... 4 2.2 Test Standards and Results........................................................................................................ 5 2.3 Facilities and Accreditations ..................................................................................................... 6 2.3.1 Facilities ................................................................................................................................... 6 2.3.2 Test Environment Conditions ................................................................................................... 6 2.3.3 Measurement Uncertainty ........................................................................................................ 6 3. TEST CONDITIONS SETTING .............................................................................................. 7 3.1 Test Mode .................................................................................................................................... 7 3.2 Test Setup and Equipments List ............................................................................................... 8 3.2.1 Conducted Emission ................................................................................................................. 8 3.2.2 Radiated Emission .................................................................................................................... 9 4. 47 CFR PART 15B REQUIREMENTS .................................................................................. 10 4.1 Conducted Emission................................................................................................................. 10 4.1.1 Requirement ........................................................................................................................... 10 4.1.2 Test Description ...................................................................................................................... 10 4.1.3 Test Result .............................................................................................................................. 10 4.1.3.1 CDMA Test Mode ..................................................................................................................... 10 4.2 Radiated Emission .................................................................................................................... 12 4.2.1 Requirement ........................................................................................................................... 12 4.2.2 Test Description ...................................................................................................................... 12 4.2.3 Test Result .............................................................................................................................. 12 Change History Issue Date Reason for change 1.0 May 13, 2010 First edition 2.0 May 19, 2010 Add the test data of Conduct Emission Report No.: SZ10040101E01 Page 4 of 13 2. GENERAL INFORMATION 2.1 EUT Description EUT Type ............................. : EVDO Rev.A Data card Model Name ......................... : V-ME101 Serial No............................... : N/A Hardware Version ................. : SP Software Version .................. : R00.00.07 Power Supply ....................... : USB-Power Note 1: The EUT is an EVDO Rev.A Data card supported CDMA800/1900 and EVDO Rev.A, the EUT isn’t support USB Data storage function. Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ10040101E01 Page 5 of 13 2.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-05 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2003. Report No.: SZ10040101E01 Page 6 of 13 2.3 Facilities and Accreditations 2.3.1 Facilities Shenzhen Electronic Product Quality Testing Center Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L1659. All measurement facilities used to collect the measurement data are located at Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen 518055 CHINA. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 2.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 20 - 25 Relative Humidity (%): 40 - 60 Atmospheric Pressure (kPa): 96 2.3.3 Measurement Uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncertainty in Measurement" (GUM) published by ISO. Uncertainty of Conducted Emission: ±1.8dB Uncertainty of Radiated Emission: ±3.1dB Report No.: SZ10040101E01 Page 7 of 13 3. TEST CONDITIONS SETTING 3.1 Test Mode 1. CDMA Test Mode (1) The first test mode (CDMA800) The EUT configuration of the emission tests is EUT + PC. During the measurement of Traffic operating mode, a communication link was established between the EUT and a System Simul…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2. RE
