SG71007HG-U53MOBILE PHONE

1 Contents 1 About your phone ......................... ..................... 9 1.1 Appearance ......................... ..................... 9 1.2 Key instructions ........................ .............. 10 1.3 Icons ................................ ........................ 13 1.4 Earphone .............................. ................... 14 2 Getting started .......................... ........................ 15 2.1 The Battery .......................... ................... 15 2.1.1 Install & remove a battery ......... 16 2.1.2 Charging ........................ .............. 17 2.2 SIM card installation .............................. 19 2.3 Memory card installation ....................... 20 2.4 Storage Management ............................ 21 2.5 Power on and off ...................... .............. 23 3 Call functions ............................ ........................ 23 3.1 Make a call ........................... ................... 23 3.1.1 Make a domestic call ................. 24 3.1.2 Make an extension call .............. 24 3.1.3 Make an international call ......... 25 3.1.4 Make a call from Phone book .. 25 3.1.5 Redial a call by recent call lists 26 2 3.2 Answer a call ....................... ................... 26 3.3 Reject a call ......................... ................... 27 3.4 Call options .......................... ................... 27 4 Write text .............................. .............................. 28 4.1 Switch input methods ............................ 29 4.2 English method ........................ .............. 29 4.3 Input special character .......................... 29 5 Menu operation ........................ ........................ 30 5.1 Access menus by scrolling ................... 30 6 Menu functions ........................ ........................ 31 6.1 Extra ................................. ........................ 31 6.2 Phonebook ........................... ................... 33 6.2.1 Quick Search .............................. 34 6.2.2 Search contact ............................ 34 6.2.3 Add New contact ........................ 35 6.2.4 Copy All ......................... .............. 36 6.2.5 Delete ....................... ................... 36 6.2.6 Caller groups .............................. 36 6.2.7 Extra Number ............................. 37 6.2.8 Settings .......................... .............. 37 6.3 Fun & Games ...................... ................... 38 6.3.1 Games ...................... ................... 38 3 6.3.2 MSN .......................... ................... 38 6.4 Call center ............................ ................... 39 6.4.1 Call history .................... .............. 39 6.4.2 General call settings .................. 39 6.5 Messages ............................. ................... 43 6.5.1 SMS .......................... ................... 43 6.5.2 MMS ..................... ........................ 51 6.5.3 Chat ........................... ................... 57 6.5.4 Voice Mail Server ....................... 58 6.5.5 Broadcast Message ................... 58 6.6 Multimedia ............................ ................... 59 6.6.1 Camera .......................... .............. 59 6.6.2 Image Viewer .............................. 59 6.6.3 Video Recorder .......................... 60 6.6.4 Video player .................. .............. 60 6.6.5 Audio player .................. .............. 61 6.6.6 Sound Recorder ......................... 62 6.6.7 FM Radio ....................... .............. 63 6.7 Organizer ............................. ................... 64 6.7.1 Calendar ........................ .............. 64 6.7.2 To d o ......................... ................... 65 6.7.3 Alarm ......................... ................... 65 4 6.7.4 World Clock ................... .............. 65 6.7.5 E-book reader ............................. 66 6.8 Settings ............................ ........................ 66 6.8.1 Dual SIM settings ....................... 66 6.8.2 Phone Setup ................. .............. 67 6.8.3 Network Setup ............................ 68 6.8.4 Security Setup ............................ 69 6.8.5 Restore Factory se ttings ................ 73 6.8.6 Sound effect .................. .............. 73 6.9 User profiles ......................... ................... 73 6.10 File Manager ........................ ................... 74 6.11 Services ................................ ................... 75 6.11.1 STK ........................... ................... 75 6.11.2 WAP .......................... ................... 75 6.11.3 Data Account .............................. 78 6.12 Shortcuts .............................. ................... 79 7 Battery information ...................... ................... 79 8 Safety information ........................ ................... 81 8.1 Operating environment ......................... 81 8.2 Electronic devices .................... .............. 82 8.2.1 Pacemaker .................... .............. 82 8.2.2 Hearing aids .................. .............. 83 5 8.2.3 Other medical devices ............... 83 8.2.4 Vehicles ......................... .............. 84 8.3 Potentially dangerous situations .......... 84 9 Care and maintenance ................................... 85 Preface Thank you very much for your choice of this product designed by our company! Our phone complies with the Telecommunication industries standards of both the People's Republic of China and Europe. The product described in this guide is approved for use on the GSM networks, and has the GPRS functions. GSM network is a global cellular communications system of international standards. Allow you to receive an international telephone call used as in your homeland. However, before using these advanced network functions, you must firstly apply for these required 6services. In order to better use your cell phone, we suggest you to carefully rea…

Text truncated - open the document above for the full version.

Date: 03 Aug, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Haier Telecom (Qingdao) Co., Ltd. , the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Haier Telecom (Qingdao) Co., Ltd. solely in matters relating to the application for an FCC equipment authorization for FCC ID # SG71007HG-U53 including the signing of documents in connection with this Application. Necessary acts carried out by Haier Telecom (Qingdao) Co., Ltd. on our behalf of the Haier Telecom (Qingdao) Co., Ltd. in connection with the Application shall have the same effect as acts of the Haier Telecom (Qingdao) Co., Ltd.. The Haier Telecom (Qingdao) Co., Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Sincerely Yours, James Shi Type Approval Manager Haier Telecom (Qingdao) Co., Ltd.

Date: 03 Aug, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Haier Telecom (Qingdao) Co., Ltd. FCC ID: SG71007HG-U53 FCC Part 22H&24E Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Haier Telecom (Qingdao) Co., Ltd. requests that the following documents regarding this submission for FCC ID: SG71007HG-U53 be kept confidential: Exhibit Type File Name Block Diagram CONF APPENDIX HG-U53_Block Diagram.pdf Schematics CONF APPENDIX HG-U53_Schematics.pdf Operational Description CONF APPENDIX HG-U53_Operational description.pdf Part list CONF APPENDIX HG-U53_BOM.pdf Tune-Up-Procedure CONF APPENDIX HG-U53_Tune up procedure.pdf Those documents contain detailed system and equipment description and related information about the product which Haier Telecom (Qingdao) Co., Ltd. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Haier Telecom (Qingdao) Co., Ltd. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. James Shi Type Approval Manager Haier Telecom (Qingdao) Co., Ltd.

External Photos 1. Front View of EUT 2. Back View of EUT 3. Side View of EUT

Label Label Location

Date: 03 August, 2010 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: SG71007HG-U53 Dear Sirs: Haier Telecom (Qingdao) Co., Ltd. requests acceptance of the labeling proposal described below for mobile phone bearing FCC identifier SG71007HG-U53. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22 Subpart H and 24 Subpart E for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Haier Telecom proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Haier Telecom will add the FCC identifier "SG71007HG-U53" to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. James Shi Type Approval Manager Haier Telecom (Qingdao) Co., Ltd.

Internal Photos

Report No.: SZ10070126E01 Page 2 of 16 TABLE OF CONTENTS 1. TEST CERTIFICATION ...........................................................................................................3 2. GENERAL INFORMATION ....................................................................................................4 2.1 EUT Description .........................................................................................................................4 2.2 Test Standards and Results ........................................................................................................5 2.3 Facilities and Accreditations ......................................................................................................6 2.3.1 Facilities ....................................................................................................................................6 2.3.2 Test Environment Conditions....................................................................................................6 2.3.3 Measurement Uncertainty .........................................................................................................6 3. TEST CONDITIONS SETTING...............................................................................................7 3.1 Test Mode ....................................................................................................................................7 3.2 Test Setup and Equipments List................................................................................................9 3.2.1 Conducted Emission..................................................................................................................9 3.2.2 Radiated Emission...................................................................................................................10 4. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 4.1 Conducted Emission ................................................................................................................. 11 4.1.1 Requirement ............................................................................................................................11 4.1.2 Test Description ......................................................................................................................11 4.1.3 Test Result ...............................................................................................................................11 4.1.3.1 GSM Test Mode ........................................................................................................................11 4.1.3.2 USB Test Mode .........................................................................................................................13 4.2 Radiated Emission ....................................................................................................................14 4.2.1 Requirement ............................................................................................................................14 4.2.2 Test Description ......................................................................................................................14 4.2.3 Test Result ...............................................................................................................................14 Change History Issue Date Reason for change 1.0 August 10, 2010 First edition Report No.: SZ10070126E01 Page 4 of 16 2. GENERAL INFORMATION 2.1 EUT Description EUT Type ....................... Mobile phone Model Name................... HG-U53 Serial No. ....................... (n.a, marked #1 by test site) Hardware Version........... Q10_MB_C Software Version ............ U53-H01-S003-TIGO-S Modulation Type ............ GMSK Power Supply ................. Battery Model Name: H15195 Brand name: Haier Capacitance: 1450mAh Rated voltage: 3.7V Manufacturer: ShenZhen WISEWOD Technology Co., Ltd Manufacturer Address: C Spot, Industrial City Area, Liantang, Gongming, BaoAn District, ShenZhen City, China Ancillary Equipment 1 ... AC Adapter (Charger for Battery) Model Name: TS21-500550U Brand Name: Haier Serial No.: (n.a. marked #1 by test site) Rated Input: 100-240V, 50/60Hz, 150mA Rated Output: 5.0V, 550mA Manufacturer: SHENZHEN TENWEI ELECTRONICS CO.,LTD Manufacturer Address: Building 11, Fuqiao 3rd Industrial Zone, Qiaotou Village, Fuyong Town, Bao'an District, Shenzhen City, China Note 1: The EUT is a GSM Mobile phone; it supports GSM 850MHz, 1900MHz and ISM 2.4GHz Bluetooth module. GSM 850MHz and 1900MHz are tested in this report. Note 2: The EUT is equipped with a T-Flash card slot; equipped with a special port which can be connected to the ancillary equipments supplied by the manufacturer e.g. the AC Adapter and the USB Adapter Cable. Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ10070126E01 Page 5 of 16 2.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2003. Report No.: SZ10070126E01 Page 6 of 16 2.3 Facilities and Accreditations 2.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan …

Text truncated - open the document above for the full version.

Test Setup Photos 1. CS 2. RE
