SGI-WL101RC for hearing instruments

www.siemens.com /hearing Siemens Audiologische Technik GmbH Gebbertstrasse 125 91058 Erlangen Germany Phone +49 9131 308 0 © 01.2008, Siemens AG · SB Document No. A91SAT-00370-99T1-7600 Order/Item No. 103 029 99 Printed in Germany ProPocket TM User Guide A A Introduction Dear customer, Your hearing instruments are equipped with wireless technology and can therefore be controlled by your ProPocket™. These instruction describes how to operate your ProPocket rapidly and easily. It also provides you with important information on how to handle your instruments. Your Hearing Care Professional can answer any further questions about instructions and proper use. 1 2 A A 2 3 4 5 6 7 8 9 11 10 Contents Your ProPocket4 Intended use 5 General notes on safety 6 Safety notes for batteries 8 Changing the batteries 9 Key lock1 0 Turning your hearing instruments on and off1 1 Adjusting the volume1 2 Changing the program1 3 Maintenance and care1 4 Troubleshooting1 5 Technical information1 6 Disposal Information1 8 12 13 14 15 3 The remote control uses two AAAA batteries. 1 Key lock 2 On/Off of hearing instruments 3 Program change 4 Volume up 5 Volume down 6 Accessory ring 7 LED 1 2 3 4 5 6 7 Your ProPocket Clip The clip allows you to attach the remote control to your belt. Cover The cover protects the remote control from damage that can be caused by scratches or water splashes. It does not make the remote control water- proof! 3 4 Intended use 4 This remote control is intended to operate hearing instru- ments. Hearing instruments are intended to improve the hearing of hearing impaired persons. Diagnosis and prescription of a hearing instrument must be performed by hearing health specialists, e.g. ENT doctors, audiologists or acou- sticians. Read and follow the instructions of this user guide to avoid injuries or damage to remote control. Symbols: Be aware of information marked with the warning symbol WARNING,CAUTION or NOTICE! WARNING points out a situation that could lead to serious injuries, CAUTION indicates a situation that could lead to minor and moderate injuries. NOTICE NOTICE indicates possible property damage. Advice and tips on how to handle your hearing instrument better. Instruction. Indicates that something has to be done. 5 NOTICE The remote control is sensitive to extreme heat, high humidity, strong magnetic fields (> 0.1T), X-rays and mechanical stress. Do not expose the remote control to extreme tempera- ture or high humidity. Do not leave it in direct sunlight. Do not immerse it in water. X X X In case the hearing instrument is controlled by ano- ther person’s remote control unit (RCU), please return RCU and hearing instrument to your Hearing Care Professional. X WARNING Wireless systems may interfere with measuring devices and electronic equipment. Do not use remote control in hospitals or airplanes. Have the key lock activated in hospitals or airplanes. Prior to use in conjunction with an electronic implant or life supporting system, have the electromagnetic compatibility verified. X X X General notes on safety 5 In some countries restrictions for the usage of wireless equipment exist. Refer to local authorities for further information. X 6 WARNING Risk of interference with cardiac pacemakers. Do not use the remote control if you are fitted with a cardiac pacemaker. X WARNING Risk in explosive environments, e.g. mining areas! Don't use your hearing instruments and remote control in areas where there is a danger of explosions. X 5 General notes on safety 7 NOTICE Leaking batteries damage the instrument. Remove batteries when the instrument is not in use for a prolonged period of time. X Do not throw used batteries into household trash. Return them to your Hearing Care Professional for environmentally correct disposal. X WARNING Choking hazard posed by small parts. Keep batteries and remote control out of children‘s reach. If swallowed consult a physician or hospital immediately. X X 6 Safety notes for batteries 8 Press the rippled part on the co- ver of the remote control battery compartment to slide it open. Insert two batteries as shown in the picture. Make sure the polarity symbols on the battery and compartment are aligned. Close the battery compartment. A click is audible when the battery compartement is fully closed. X X X + + The remote control ist powered by two AAAA batteries. Changing the batteries 7 9 The key lock deactivates the buttons on the remote control so that accidentally pressing the buttons will not have any effect. Lock Slide the control over so the green section is covered. The key lock is activated. When pressing a button the LED blinks 3 times to indicate that the key lock is activa- ted. Unlock Slide the control to the other direction, so the green section shows. The key lock is deactivated. The remote control works and the LED blinks only once when pressing a button. X X Key lock 8 10 Make sure the distance between your remote control and hearing instrument does not exceed 40 inches (1 meter). If you are wearing two hearing instruments, both in- struments will be turned on/ off at the same time. X X Press the On/Off button to turn your hearing instruments on. Press the On/Off button to turn your hearing instruments off. X X Turning your hearing instruments on and off 9 11 Press the "Volume up" (+) button to increase the volume of your hearing instruments. Press the "Volume down" (-) button to decrease the volume of your hearing instruments. Your Hearing Care Professional can activate acoustic si- gnals to indicate when the volume has been changed and when the volume limit has been reached. X X Make sure the distance between your remote control and hearing instrument does not exceed 40 inches (1 meter). If you are wearing two hearing instruments, the volume will be changed on both instruments at the same time. X X Adjusting the volume 10 12 Make sure the distance between your remote control and hearing instrument does not exceed 40 inches (1 meter). If you are w…

Text truncated - open the document above for the full version.

Mr. Thomas Ring . Jürgen Reithinger

. . Jürgen Reithinger

FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 1 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 EMI -- T E S T R E P O R T Test Report No. : T32350-00-01KG 05. February 2008 ______________________________________________________________________________________________ Date of issue Type / Model Name : ProPocket Product Description : Remote control for hearing instruments Applicant : Zollner Elektronik AG Address : Industriestrasse 2-14 93499 Zandt Manufacturer : Zollner Elektronik AG Address : Industriestrasse 2-14 93499 Zandt Licence holder : Siemens Audiologische Technik GmbH Address : Gebberstrasse 125 91058 Erlangen Test Result according to the standards listed in clause 1 test standards: POSITIVE The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test DAT-P-207/05-00 laboratory. Registration No. DAT-P-207/05 FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 2 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 Contents 1 TEST STANDARDS 3 2 SUMMARY 4 3 EQUIPMENT UNDER TEST 5 3.1 PHOTO DOCUMENTATION OF THE EUT 5 3.2 POWER SUPPLY SYSTEM UTILISED 8 3.3 SHORT DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) 8 4 TEST ENVIRONMENT 9 4.1 ADDRESS OF THE TEST LABORATORY 9 4.2 ENVIRONMENTAL CONDITIONS 9 4.3 STATEMENT OF THE MEASUREMENT UNCERTAINTY 9 4.4 MEASUREMENT PROTOCOL FOR FCC, VCCI AND AUSTEL 9 5 TEST CONDITIONS AND RESULTS 11 5.1 CONDUCTED EMISSIONS 11 5.2 FIELD STRENGTH OF THE FUNDAMENTAL WAVE 12 5.3 SPURIOUS EMISSIONS (MAGNECTIC FIELD) 9 KHZ – 30 MHZ 14 5.4 RADIATED EMISSIONS (ELECTRIC FIELD) 30 MHZ – 1 GHZ 17 5.5 EMISSION BANDWIDTH 19 6 USED TEST EQUIPMENT AND ACCESSORIES 21 FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 3 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 1 TEST STANDARDS The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C- Intentional Radiators (October 01, 2007) Part 15, Subpart C, Section 15.223 Operation in the band 1.705-10 MHz §15.223(a) Radiated emissions, Fundamental & Harmonics Part 15, Subpart C, Section 15.209 Radiated emissions, general requirements FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 4 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 2 SUMMARY GENERAL REMARKS: None FINAL ASSESSMENT: The equipment under test fulfills the EMI requirements cited in clause 1 test standards. Date of receipt of test sample : acc. to storage records Testing commenced on : 23. January, 2008 Testing concluded on : 24. January, 2008 Checked by: Tested by: Thomas Weise Dipl.-Ing.(FH) Laboratory Manager Gegenfurtner Klaus Dipl.-Ing.(FH) FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 5 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 3 EQUIPMENT UNDER TEST 3.1 Photo documentation of the EuT External Photos Front Rear FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 6 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 Label location FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 7 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 Internal Photos FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 8 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 3.2 Power supply system utilised Power supply voltage : 3 V / DC 3.3 Short description of the Equipment under Test (EuT) The ProPocket is a programmer for hearing instruments. With the remote control is it possible to increase or decrease wireless the volume of the hearing instruments. Number of tested samples: 1 Serial number: 52 EuT operation mode: The equipment under test was operated during the measurement under the following conditions: - Continuous transmission mode (modulated) EuT configuration: (The CDF filled by the applicant can be viewed at the test laboratory.) The following peripheral devices and interface cables were connected during the measurements: - Hearing aid Model : D6 of Siemens - Model : - Model : - Model : - Model : - Model : FCC ID:SGI-WL101 mikes-testingpartners gmbh File No. T32350-00-01KG, page 9 of 21 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 4 TEST ENVIRONMENT 4.1 Address of the test laboratory mikes-testingpartners gmbh Ohmstrasse 2-4 94342 Strasskirchen Germany 4.2 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 86-106 kPa 4.3 Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to CISPR 16-4-2 /11.2003 „Uncertainties, statistics and limit modelling – Uncertainty in EMC measurements“ and is documented in the quality system acc. to DIN EN ISO/IEC 17025. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of the device. 4.4 Measurement Protocol for FCC, VCCI and AUSTEL 4.4.1 GENERAL INFORMATION 4.4.1.1 Test Methodology Conducted and radiated disturbance testing is performed according to the procedures in International Special Committee on Radio Interference (CISPR) Pu…
