SGI-WL700easyPocket remote control 3.28 MHz
Sivantos GmbH
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Feb 04, 2013
- Application Purpose
- Original Equipment
- Date of Application
- Feb 04, 2013
- Equipment Note
- easyPocket remote control 3.28 MHz
- Frequency Range
- 3.28000000 - 3.28000000
- Company
- Sivantos GmbH
- Country
- Germany
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Life sounds brilliant. www.siemens.com/hearing easyPocket basic easyPocket advanced User Guide DRAFT 2013-01-21 2ContentDRAFT 2013-01-21 Content Your remote control 4 Overview 5 Display 6 Control buttons 8 Key lock switch 10 Programming connection 10 Batteries 11 Inserting batteries 11 Checking the battery status 13 Daily use 14 Adjusting the volume 14 Changing the hearing program 14 Turning on and off (mute) 16 Adjusting the tinnitus noiser level 18 Alarm clock 19 Setting the alarm clock 19 Ending the alarm 21 Turning the alarm clock off 22 Setup and service functions 23 Setting the time 23 Resetting volume and hearing program 25 Displaying contact data 26 Setting the language of the menu 26 3ContentDRAFT 2013-01-21 Maintenance and care 27 Troubleshooting 28 Important information 29 Intended use 29 Explanation of symbols 29 Transport and storage conditions 29 Disposal information 30 Technical information 30 Conformance information 32 Important safety information 33 Personal safety 33 Product safety 35 Country-specific information 37 Your remote control4DRAFT 2013-01-21 Your hearing instruments are equipped with wireless technology and can therefore be controlled by a remote control. Both easyPocket basic and easyPocket advanced pro- vide the same basic remote control functions for listening and program change. easyPocket advanced has additional comfort functions. The operating distance of the remote control is approxi- mately 40 inches (1 meter). u Make sure the distance between your remote control and hearing instrument does not exceed the operating distance. CAUTION Read this user guide thoroughly and completely and follow the safety information in this document to avoid damage or injury. Your remote control Your remote control5DRAFT 2013-01-21 Overview ΰ« ΰ« ΰ« β Display β Key lock switch β Programming con- nection β Control buttons β Program change button β Volume up/down buttons More functions are available in the menu. To enter or exit the menu, press the volume up button and the volume down button simultaneously. Your remote control6DRAFT 2013-01-21 Display All actions initiated with the remote control are immedi- ately reflected on the display. For example, if you press the volume up button, the following icon is shortly displayed. The remote control does not receive information from your hearing instru- ments. All actions that you initiate with the controls of your hearing instruments are not reflected on the remote controlβs display. Display of easyPocket basic ΰ« ΰ« β Indicates change of hearing program and volume β Alarm clock is activated β Batteries of the remote control are low β Function of control buttons Your remote control7DRAFT 2013-01-21 Display of easyPocket advanced β Indicates change of volume β Program name β Program icon β Program number β Alarm clock is activated β Batteries of the remote con- trol are low β Function of programmable control buttons Power save mode If the remote control is not used for some time, the dis- play automatically turns black. The remote control is then in its power save mode. u Press any button to activate the display again. Your remote control8DRAFT 2013-01-21 Control buttons You can quickly access two functions with the control buttons on the right hand side of the remote control. The control buttons of the easyPocket advanced can be configured by your Hearing Care Professional. Small icons on the display show the func- tions. Basic functions Turn hearing instruments on or off. Reset to default volume and hearing program. Your remote control9DRAFT 2013-01-21 Advanced functions (for easyPocket advanced only) Tinnitus noiser level up. Tinnitus noiser level down. Adjust treble. Adjust bass. All other icons: Shortcut to select a preferred hearing program. The available icons and hearing programs depend on your personal setup. Your remote control10DRAFT 2013-01-21 Key lock switch u To prevent any accidental operation while the remote control is in pockets or bags, move the key lock switch to lock position (red color vis- ible). When the key lock is active, all buttons on the remote control are disabled. The following icon is displayed. Programming connection This connection is only to be used by your Hearing Care Professional for program- ming the remote control. Batteries11DRAFT 2013-01-21 The remote control uses two AAA batteries. Inserting batteries u Slide the battery compartment cover in the direction of the arrow. u Insert the batteries. Make sure the "+" symbols on the bat- tery and compartment are aligned. Batteries Batteries12DRAFT 2013-01-21 u Attach the cover by sliding it onto the remote control. The current time setting is displayed. If you want to change it, refer to section "Setting the time". Batteries13DRAFT 2013-01-21 Checking the battery status When the batteries of the remote control are low, this is indicated in the status bar. Additionally, you can check the bat- tery status at any time in the menu. u To enter the menu, press the volume up button and the volume down button simultaneously. u Navigate to the menu entry Info by pressing the vol- ume up button or the volume down button. u Confirm your selection by pressing the program change button. The battery status is displayed: battery fullbattery empty u To return to the standard display, press the program change button. Remove empty batteries immediately and dispose of them according to local regulations. Daily use14DRAFT 2013-01-21 Adjusting the volume If you are wearing two hearing instruments, the volume will be adjusted on both instruments at the same time. u Press the volume up button or the volume down but- ton to adjust the volume by one step. Changing the hearing program If you are wearing two hearing instruments, the hear- ing program will be changed on both instruments. The procedure for changing the hearing program differs for easyPocket basic and easyPocket advanced. easyPocket basic u Press the program change button to switch to the next hearing program. Daβ¦
Text truncated - open the document above for the full version.
Users Manual
Life sounds brilliant. www.siemens.com/hearing easyPocket basic easyPocket advanced User Guide DRAFT 2013-01-21 2ContentDRAFT 2013-01-21 Content Your remote control 4 Overview 5 Display 6 Control buttons 8 Key lock switch 10 Programming connection 10 Batteries 11 Inserting batteries 11 Checking the battery status 13 Daily use 14 Adjusting the volume 14 Changing the hearing program 14 Turning on and off (mute) 16 Adjusting the tinnitus noiser level 18 Alarm clock 19 Setting the alarm clock 19 Ending the alarm 21 Turning the alarm clock off 22 Setup and service functions 23 Setting the time 23 Resetting volume and hearing program 25 Displaying contact data 26 Setting the language of the menu 26 3ContentDRAFT 2013-01-21 Maintenance and care 27 Troubleshooting 28 Important information 29 Intended use 29 Explanation of symbols 29 Transport and storage conditions 29 Disposal information 30 Technical information 30 Conformance information 32 Important safety information 33 Personal safety 33 Product safety 35 Country-specific information 37 Your remote control4DRAFT 2013-01-21 Your hearing instruments are equipped with wireless technology and can therefore be controlled by a remote control. Both easyPocket basic and easyPocket advanced pro- vide the same basic remote control functions for listening and program change. easyPocket advanced has additional comfort functions. The operating distance of the remote control is approxi- mately 40 inches (1 meter). u Make sure the distance between your remote control and hearing instrument does not exceed the operating distance. CAUTION Read this user guide thoroughly and completely and follow the safety information in this document to avoid damage or injury. Your remote control Your remote control5DRAFT 2013-01-21 Overview ΰ« ΰ« ΰ« β Display β Key lock switch β Programming con- nection β Control buttons β Program change button β Volume up/down buttons More functions are available in the menu. To enter or exit the menu, press the volume up button and the volume down button simultaneously. Your remote control6DRAFT 2013-01-21 Display All actions initiated with the remote control are immedi- ately reflected on the display. For example, if you press the volume up button, the following icon is shortly displayed. The remote control does not receive information from your hearing instru- ments. All actions that you initiate with the controls of your hearing instruments are not reflected on the remote controlβs display. Display of easyPocket basic ΰ« ΰ« β Indicates change of hearing program and volume β Alarm clock is activated β Batteries of the remote control are low β Function of control buttons Your remote control7DRAFT 2013-01-21 Display of easyPocket advanced β Indicates change of volume β Program name β Program icon β Program number β Alarm clock is activated β Batteries of the remote con- trol are low β Function of programmable control buttons Power save mode If the remote control is not used for some time, the dis- play automatically turns black. The remote control is then in its power save mode. u Press any button to activate the display again. Your remote control8DRAFT 2013-01-21 Control buttons You can quickly access two functions with the control buttons on the right hand side of the remote control. The control buttons of the easyPocket advanced can be configured by your Hearing Care Professional. Small icons on the display show the func- tions. Basic functions Turn hearing instruments on or off. Reset to default volume and hearing program. Your remote control9DRAFT 2013-01-21 Advanced functions (for easyPocket advanced only) Tinnitus noiser level up. Tinnitus noiser level down. Adjust treble. Adjust bass. All other icons: Shortcut to select a preferred hearing program. The available icons and hearing programs depend on your personal setup. Your remote control10DRAFT 2013-01-21 Key lock switch u To prevent any accidental operation while the remote control is in pockets or bags, move the key lock switch to lock position (red color vis- ible). When the key lock is active, all buttons on the remote control are disabled. The following icon is displayed. Programming connection This connection is only to be used by your Hearing Care Professional for program- ming the remote control. Batteries11DRAFT 2013-01-21 The remote control uses two AAA batteries. Inserting batteries u Slide the battery compartment cover in the direction of the arrow. u Insert the batteries. Make sure the "+" symbols on the bat- tery and compartment are aligned. Batteries Batteries12DRAFT 2013-01-21 u Attach the cover by sliding it onto the remote control. The current time setting is displayed. If you want to change it, refer to section "Setting the time". Batteries13DRAFT 2013-01-21 Checking the battery status When the batteries of the remote control are low, this is indicated in the status bar. Additionally, you can check the bat- tery status at any time in the menu. u To enter the menu, press the volume up button and the volume down button simultaneously. u Navigate to the menu entry Info by pressing the vol- ume up button or the volume down button. u Confirm your selection by pressing the program change button. The battery status is displayed: battery fullbattery empty u To return to the standard display, press the program change button. Remove empty batteries immediately and dispose of them according to local regulations. Daily use14DRAFT 2013-01-21 Adjusting the volume If you are wearing two hearing instruments, the volume will be adjusted on both instruments at the same time. u Press the volume up button or the volume down but- ton to adjust the volume by one step. Changing the hearing program If you are wearing two hearing instruments, the hear- ing program will be changed on both instruments. The procedure for changing the hearing program differs for easyPocket basic and easyPocket advanced. easyPocket basic u Press the program change button to switch to the next hearing program. Daβ¦
Text truncated - open the document above for the full version.
External Photos
Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 21 of 30 Annex B External photographs of the EUT Photo documentation: Photo 1: Photo 2: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 22 of 30 Photo 3: Photo 4: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 23 of 30 Photo 5: Photo 6: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 24 of 30 Photo 7: Photo 8: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 25 of 30 Photo 9:
External Photos
Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 21 of 30 Annex B External photographs of the EUT Photo documentation: Photo 1: Photo 2: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 22 of 30 Photo 3: Photo 4: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 23 of 30 Photo 5: Photo 6: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 24 of 30 Photo 7: Photo 8: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 25 of 30 Photo 9:
ID Label/Location Info
Test report no.: 1-4639/12-01-09 2012-11-22 Page 25 of 30 Photo 9:
ID Label/Location Info
Test report no.: 1-4639/12-01-09 2012-11-22 Page 25 of 30 Photo 9:
Internal Photos
Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 26 of 30 Annex C Internal photographs of the EUT Photo documentation: Photo 1: Photo 2: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 27 of 30 Photo 3: Photo 4: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 28 of 30 Photo 5:
Internal Photos
Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 26 of 30 Annex C Internal photographs of the EUT Photo documentation: Photo 1: Photo 2: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 27 of 30 Photo 3: Photo 4: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 28 of 30 Photo 5:
Test Report
2013-01-14 Page 1 of 30 TEST REPORT Test report no.: 1-4639/12-01-09-A Testing laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 β 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet:http://www.cetecom.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Area of Testing: Radio/Satellite Communications SIEMENS Audiologische Technik GmbH Gebbertstrasse 125 91058 Erlangen / GERMANY Phone: -/- Fax: -/- Contact: Clemens Meythaler e-mail: [email protected] Phone: +49 9131 308-3000 Manufacturer Hi-P (Shanghai) Housing Appliance Co., Ltd No. 79, Jinwen Road, Pudong New District PLZ Shanghai / CHINA Test standard/s 47 CFR Part 15Title 47 of the Code of Federal Regulations; Chapter I Part 15 - Radio frequency devices RSS - 210 Issue 8Spectrum Management and Telecommunications - Radio Standards Specification Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Remote Control Unit Model name: easyPocket FCC ID: SGI-WL700 IC: 267AB-WL700 Frequency: 3.28 MHz Technology tested: Magnetic coupling Antenna: Integrated ferrite core antenna Power Supply: 3.0 V DC by 3 * AAA Battery Temperature Range: -20Β°C to +62 Β°C This test report is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorised: Test performed: Marco Bertolino Tobias Wittenmeier Testing Manager Expert cn=Tobias Wittenmeier, o=CETECOM ICT Services GmbH, ou=WIT-111222, [email protected], c=DE 2013.01.14 07:52:34 +01'00' cn=Marco Bertolino, o=CETECOM ICT Services GmbH, ou=BTL-100826, [email protected], c=DE 2013.01.14 08:29:13 +01'00' Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 2 of 30 1 Table of contents 1Table of contents ............................................................................................................................................2 2General information .......................................................................................................................................3 2.1Notes and disclaimer ..........................................................................................................................3 2.2Application details ...............................................................................................................................3 3Test standard/s ...............................................................................................................................................3 4Test environment ............................................................................................................................................4 5Test item ..........................................................................................................................................................4 6Test laboratories sub-contracted .................................................................................................................4 7Summary of measurement results ...............................................................................................................5 8RF measurement testing ...............................................................................................................................6 8.1Description of test setup ....................................................................................................................6 8.1.1Radiated measurements.............................................................................................................6 8.1.2Conducted measurements..........................................................................................................7 8.2Additional comments ..........................................................................................................................7 8.3RSP100 test report cover sheet / performance test data ................................................................ 8 9Measurement results ......................................................................................................................................9 9.1Timing of the transmitter ....................................................................................................................9 9.2Bandwidth of the modulated carrier ................................................................................................10 9.3Field strength of the fundamental ...................................................................................................12 9.4Fieldstrength of the harmonics and spurious ................................................................................ 13 9.5Receiver spurious emissions ...........................................................................................................16 9.6Conducted limits ...............................................................................................................................16 10Test equipment and ancillaries used for tests ...................................................................................17 11Observations .........................................................................................................................................17 Annex APhotographs of the test setup ..........................................................................................β¦
Text truncated - open the document above for the full version.
Test Setup Photos
Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 18 of 30 Annex A Photographs of the test setup Photo documentation: Photo 1: Photo 2: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 19 of 30 Photo 3: Photo 4: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 20 of 30 Photo 5: Photo 6:
Test Setup Photos
Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 18 of 30 Annex A Photographs of the test setup Photo documentation: Photo 1: Photo 2: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 19 of 30 Photo 3: Photo 4: Test report no.: 1-4639/12-01-09-A 2013-01-14 Page 20 of 30 Photo 5: Photo 6:
Contact Information
Applicant
Juergen Reithinger
Test Firm
cetecom advanced GmbHGerald Schmidt
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 3.28 MHz - 3.28 MHz | - |
