SGJ-WFC017Wireless Communication Module

User’s Manual IM01W06D01-01EN 1st Edition XS110A Wireless Communication Module IM01W06D01-01EN CONTENTS Toc-1 1. Introduction .............................................................................................1-1 1.1 Radio Waves .........................................................................................................1-4 1.2 Warranty ................................................................................................................1-5 2. Notes on Handling ...................................................................................2-1  &KHFNWKH0RGHODQG6SHFL¿FDWLRQV ....................................................................2-1 2.2 Transport ..............................................................................................................2-1 2.3 Storage .................................................................................................................2-1 2.4 Selecting the Installation Location ........................................................................2-2 2.5 Restrictions on Use of Radio Transceivers ..........................................................2-3 2.6 Explosion Protected Instrument ............................................................................2-3 3. Component Names .................................................................................3-1 4. Installation ................................................................................................4-1 5. Operation .................................................................................................5-1 6. Maintenance .............................................................................................6-1 6.1 Replacing the Battery............................................................................................6-1 6.2 Handling the Battery .............................................................................................6-4  *HQHUDO6SHFL¿FDWLRQV ...........................................................................7-2 7.1 STANDARD SPECIFICATIONS ..........................................................................7-2  6RIWZDUH6SHFL¿FDWLRQV .......................................................................................7-5 7.3 MODEL AND SUFFIX CODES .............................................................................7-6 7.4 OPTIONAL ACCESSORIES ................................................................................7-6 7.5 Outline ..................................................................................................................7-7 7.6 Regulatory Compliance Statements .....................................................................7-8 Revision Information ........................................................................................i 1st Edition: July 2020 All Rights Reserved, Copyright © 2020, Yokogawa Electric Corporation 1-1 <Introduction> IM 01W06D01-01EN 1. Introduction Thank you for purchasing XS110A Wireless Communication Module. This manual provides important information and installation and maintenance instructions for using the XS110A Wireless Communication Module (Hereinafter, it is described as XS110A.) correctly and safely. The XS110A can be connected to an XS-series Measurement Module. The battery mounted on the XS110A supplies power to the connected Measurement Module. The function description, setting, operation, and maintenance of the XS-series are described in the Sushi Sensor Series Software Edition (IM01W06C01- 01EN), so be sure to read it and use it correctly. 7KH6XVKL6HQVRU6HULHV6RIWZDUH(GLWLRQ 3')¿OHV FDQGRZQORDGIURPRXU company home page (http://www.sushisensor.com/). Table 1.1 Related Documents Document NameDocument No. *HQHUDO6SHFL¿FDWLRQV XS110A Wireless Communications Module GS01W06D01-01EN User's Manual Sushi Sensor Series Software Edition IM01W06C01-01EN 1-2 <Introduction> IM 01W06D01-01EN „ Regarding This Manual ‡ 7KLVPDQXDOVKRXOGEHSURYLGHGWRWKHHQGXVHU ‡ 7KLVPDQXDODQGWKHLGHQWL¿FDWLRQWDJDWWDFKHGRQWKHSDFNLQJER[ are essential parts of the product; keep them in a safe place for future reference. ‡ 7KHFRQWHQWVRIWKLVPDQXDODUHVXEMHFWWRFKDQJHZLWKRXWSULRUQRWLFH ‡ $OOULJKWVUHVHUYHG1RSDUWRIWKLVPDQXDOPD\EHUHSURGXFHGLQDQ\IRUP without Yokogawa’s written permission. ‡ <RNRJDZDPDNHVQRZDUUDQW\RIDQ\NLQGZLWKUHJDUGWRWKLVPDQXDO LQFOXGLQJEXWQRWOLPLWHGWRLPSOLHGZDUUDQW\RIPHUFKDQWDELOLW\DQG¿WQHVV for a particular purpose. ‡ ,IDQ\TXHVWLRQDULVHVRUHUURUVDUHIRXQGRULIDQ\LQIRUPDWLRQLVPLVVLQJ IURPWKLVPDQXDOSOHDVHLQIRUPWKHQHDUHVW<RNRJDZDVDOHVRI¿FH ‡ 7KHVSHFL¿FDWLRQVFRYHUHGE\WKLVPDQXDODUHOLPLWHGWRWKRVHIRUWKH VWDQGDUGW\SHXQGHUWKHVSHFL¿HGPRGHOQXPEHUEUHDNGRZQDQGGRQRW FRYHUFXVWRPPDGHLQVWUXPHQWV:KHQSURGXFWVZKRVHVXI¿[FRGHRU optional codes contain code “Z” and an exclusive document is attached, please read it along with this manual. ‡ 3OHDVHQRWHWKDWFKDQJHVLQWKHVSHFL¿FDWLRQVFRQVWUXFWLRQRUFRPSRQHQW SDUWVRIWKHLQVWUXPHQWPD\QRWLPPHGLDWHO\EHUHÀHFWHGLQWKLVPDQXDODW the time of change, provided that postponement of revisions will not cause GLI¿FXOW\WRWKHXVHUIURPDIXQFWLRQDORUSHUIRUPDQFHVWDQGSRLQW „6DIHW\3URWHFWLRQDQG0RGL¿FDWLRQRIWKLV3URGXFW ‡ 7KLVSURGXFWLVGHVLJQHGWREHXVHGE\DSHUVRQZLWKVSHFLDOL]HG knowledge. ‡ 7RSURWHFWWKHRSHUDWRUSURGXFWDQGV\VWHPFRQWUROOHGE\WKHSURGXFW observe the safety precautions described in this manual. If users handle contrary to these instructions, we cannot guarantee safety. ‡ 7KH0RGL¿FDWLRQRIWKHSURGXFWLVVWULFWO\SURKLELWHG ‡ 5HSDLURUPRGL¿FDWLRQWRWKLVLQVWUXPHQWE\FXVWRPHUZLOOFDXVHD PDOIXQFWLRQRIH[SORVLRQSURWHFWIXQFWLRQDQGKD]DUGRXVVLWXDWLRQ,I\RX QHHGWRUHSDLURUPRGL¿FDWLRQSOHDVHFRQWDFWWKHQHDUHVW<RNRJDZDRI¿FH 1-3 <Introduction> IM…

Text truncated - open the document above for the full version.

Model: XS110A Doc. No.: WFC017-A04 Date: 13 April, 2020 1/4 Product External Photos Wireless Communication Module XS110A Model: XS110A Doc. No.: WFC017-A04 Date: 13 April, 2020 2/4 1. Product External Photos Figure 1. Front side Figure 2. Back side Model: XS110A Doc. No.: WFC017-A04 Date: 13 April, 2020 3/4 Figure 3. Right side Figure 4. Left side Front Front Model: XS110A Doc. No.: WFC017-A04 Date: 13 April, 2020 4/4 Figure 5. Top side Figure 6. Bottom side Front Front

Model: XS110A Doc. No.: WFC017-A06 Date: 13 April, 2020 1/3 Label Design and Location Wireless Communication Module XS110A Model: XS110A Doc. No.: WFC017-A06 Date: 13 April, 2020 2/3 1. Label design Figure1. Label design (Font Size: Larger than four-point) FCC ID: SGJ-WFC017 IC: 8999A-WIC016 Model: XS110A Doc. No.: WFC017-A06 Date: 13 April, 2020 3/3 2. Label Location Figure 2. Label Location Location

Model: XS110A Doc. No.: WFC017-A05 Date: 12 May, 2020 1/7 Product Internal Photos Wireless Communication Module XS110A Model: XS110A Doc. No.: WFC017-A05 Date: 12 May, 2020 2/7 1. Product Internal Photos 1.1. Product Internal Photos Figure 1.1.1. Front side Figure 1.1.2. Right side Front WCM ASSY Model: XS110A Doc. No.: WFC017-A05 Date: 12 May, 2020 3/7 Figure 1.1.3. Left side Figure 1.1.4. Back side Front Model: XS110A Doc. No.: WFC017-A05 Date: 12 May, 2020 4/7 1.2. WCM ASSY Figure 1.2.1. WCM ASSY A-side (Shielded) Figure 1.2.2. WCM ASSY A-side (Removed the shield) Model: XS110A Doc. No.: WFC017-A05 Date: 12 May, 2020 5/7 Figure 1.2.3. WCM ASSY B-side (Before molding) Figure 1.2.4. WCM ASSY B-side (After molding) Model: XS110A Doc. No.: WFC017-A05 Date: 12 May, 2020 6/7 1.3. CONNECT ASSY Figure 1.3.1. CONNECT ASSY A-side Figure 1.3.2. CONNECT ASSY B-side Model: XS110A Doc. No.: WFC017-A05 Date: 12 May, 2020 7/7 2. Antenna location Figure 2. Antenna location 3. RF IC location Figure 3. RF IC location Antenna (ANT1) RF IC (U4)

UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 RF Exposure / MPE Calculation No. : 13153638S-C Applicant : Yoko gawa Electric Corporation Type of Equipment : Wireless Communication Module Model No. : XS110A FCC ID : SGJ-WFC017 Yokogawa Electric Corporation declares that Model: XS110A complies with FCC radiation exposure requirement specified in the FCC Rule 2.1091 (for mobile). RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the “XS110A“ as calculated from (B) Limits for General Population / Uncontrolled Exposure of TABLE 1- LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) of §1.1310 Radiofrequency radiation exposure limits. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1mW/cm^2 uncontrolled exposure limit. The Friis formula used was: Where P =4.71 mW (Maximum average output power) Time average was used for the above value in consideration of 6-minutes time-averaging Burst power average was used for the above value in consideration of worst condition. G =0.724 Numerical Antenna gain; equal to -1.4dBi r =20 cm (Separation distance) 0.00068 mW/cm 2 Power Density Result S = 2 4r GP S     Even taking into account the tolerance, this device can be satisfied with the limits.

Test report No. : 13153638S-C-R1 P age: 1 of 33 Issued date : May 13, 2020 F CC ID : SGJ-WFC017 UL Japan, Inc. Shonan EM C Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401Report Cover Page - 13-EM-F0429 Issue # 16.0 CERTIFICATE 1266.03 RADIO TEST REPORT Test Report No. : 13153638S-C-R1 Applicant : Yokogawa Electric Corporation Type of EUT : Wireless Communication Module Model Number of EUT : XS110A FCC ID : SGJ-WFC017 Test regulation : FCC Part 1 5 Subpart C: 2020 * T x 500 kHz mode Test Result : Complied (Refer to SECTION 3.2) 1.This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2.The results in this report appl y only to the sample tested. 3. This sample tested is in compliance with the limits of the a bove regulation. 4. The test results in this test report are traceable to the national or international standards. 5. This test report must not be used by the customer to claim product certification, approval, or endorseme nt by the A2LA accreditation bod y. 6. This test report covers Radio te chnical requirements. It does not cover administrative issues such as Manual or non-Radio test related Requirement s. (if applicable) 7. The all test i tems in this test report are conducted by UL Japan, Inc. Shonan EMC Lab. 8.The opinions and the interpretations to the result of the description in this report are outside scopes wh ere UL Japan has been accredit ed. 9. The information provided from the customer for this report is i dentified in SECTION 1. 10. This report is a revised version of 13153638S-C. 13153638S-C is replace d with this report. Date of test: February 14 to 17, 2020 Representative test engineer: Hiromasa Sato Engineer Consumer Technology Division A pproved by: Kazutaka Takeyama Engineer Consumer Technology Division The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan. There is no testing item of "Non-accreditation". Test report No. : 13153638S-C-R1 Page : 2 of 33 Issued date : May 13, 2020 FCC ID : SGJ-WFC017 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 REVISION HISTORY Original Test Report No.: 13153638S-C Revision Test report No. Date Page revised Contents - (Original) 13153638S-C April 17, 2020 - - 1 13153638S-C-R1 May 13, 2020 1 Update of test specification From “FCC Part 15 Subpart C: 2019” To “FCC Part 15 Subpart C: 2020” 6 Update of test specification From “FCC Part 15 final revised on July 19, 2019 and effective August 19, 2019 except 15.258” To “FCC Part 15 final revised on April 1, 2020 and effective June 1, 2020 except 15.258 * The revision does not affect the test result conducted before its effective date.” 13 Addition of remarks “*5)” Test report No. : 13153638S-C-R1 Page : 3 of 33 Issued date : May 13, 2020 FCC ID : SGJ-WFC017 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Reference: Abbreviations (Including words undescribed in this report) A2LA The American Association for Laboratory Accreditation MCS Modulation and Coding Scheme AC Alternating Current MRA Mutual Recognition Arrangement AFH Adaptive Frequency Hopping N/A Not Applicable AM Amplitude Modulation NIST National Institute of Standards and Technology Amp, AMP Amplifier NS No signal detect. ANSI American National Standards Institute NSA Normalized Site Attenuation Ant, ANT Antenna NVLAP National Voluntary Laboratory Accreditation Program AP Access Point OBW Occupied Band Width ASK Amplitude Shift Keying OFDM Orthogonal Frequency Division Multiplexing Atten., ATT Attenuator P/M Power meter AV Average PCB Printed Circuit Board BPSK Binary Phase-Shift Keying PER Packet Error Rate BR Bluetooth Basic Rate PHY Physical Layer BT Bluetooth PK Peak BT LE Bluetooth Low Energy PN Pseudo random Noise BW BandWidth PRBS Pseudo-Random Bit Sequence Cal Int Calibration Interval PSD Power Spectral Density CCK Complementary Code Keying QAM Quadrature Amplitude Modulation Ch., CH Channel QP Quasi-Peak CISPR Comite International Special des Perturbations Radioelectriques QPSK Quadri-Phase Shift Keying CW Continuous Wave RBW Resolution Band Width DBPSK Differential BPSK RDS Radio Data System DC Direct Current RE Radio Equipment D-factor Distance factor RF Radio Frequency DFS Dynamic Frequency Selection RMS Root Mean Square DQPSK Differential QPSK RSS Radio Standards Specifications DSSS Direct Sequence Spread Spectrum Rx Receiving EDR Enhanced Data Rate SA, S/A Spectrum Analyzer EIRP, e.i.r.p. Equivalent Isotropically Radiated Power SG Signal Generator EMC ElectroMagnetic Compatibility SVSWR Site-Voltage Standing Wave Ratio EMI ElectroMagnetic Interference TR Test Receiver EN European Norm Tx Transmitting ERP, e.r.p. Effective Radiated Power VBW Video BandWidth EU European Union Vert. Vertical EUT Equipment Under Test WLAN Wireless LAN Fac. Factor FCC Federal Communications Commission FHSS Frequency Hopping Spread Spectrum FM Frequency Modulation Freq. Frequency FSK Frequency Shift Keying GFSK Gaussian Frequency-Shift Keying GNSS Global Navigation Satellite System GPS Global Positioning System Hori. Horizontal ICES Interference-Causing Equipment Standard IEC International Electrotechnical Commission IEEE Institute of Electrical and Electronics Engineers IF Intermediate Frequency ILAC International Laboratory Accreditation Conference ISED Innovation, Science and Economic Development Canada ISO International Organization for Standardization JAB Japan Accreditation Board LAN Local Area Network LIMS Laboratory Information Management System Test report No. : 13153638S-C-R1 Page : 4 of 33 Issued date : May 13, 2020 FCC ID : SGJ-WFC017 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 46…

Text truncated - open the document above for the full version.

Test report No. : 13153638S-C-R1 Page : 32 of 33 Issued date : May 13, 2020 FCC ID : SGJ-WFC017 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 APPENDIX 3: Photographs of test setup Radiated Spurious Emission Fron t Rear (Below 1 GHz) Rear (Above 1 GHz) Test report No. : 13153638S-C-R1 Page : 33 of 33 Issued date : May 13, 2020 FCC ID : SGJ-WFC017 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 Pre-check of Worst Case Position X-axis Y-axis Z-axis End of Report
