SH6MD85XXP1Wireless Audio Module

Manual for MD8520P1 & MD8530P1 1. Description Raytac’s MD85XXP1 audio module is a cost-effective and low-power solution optimized for wireless transmission of high-quality digital audio. We use TI’s CC8520/CC8530 IC (Digital I2S I/O) and CC8521/CC8531 (USB full speed I/O) IC which includes a robust built-in wireless audio transmission protocol and can control selected external audio devices. The wireless range is up to 100 meters line of sight with an external PA (TI CC2590). Utilizing numerous coexistence mechanisms allows MD85XXP1 to avoid interfering with, or being interfered by other 2.4GHz radio systems. Therefore, MD85XXP1 has excellent anti-WiFi performance. MD85XXP1 operates autonomously, and can be used with or without an external MCU. An external host processor can be connected through SPI and control some aspects of its operation. Combined with the easy-to-use configuration tool and application reference designs, MD85XXP1 wireless audio module ensures flexibility, cost-efficiency and a fast time-to-market. 2. Features  SolutionTI CC8520/CC8530(Digital I2S I/O); TI CC8521/CC8531(USB 1.1 I/O)  Wireless range up to 100 meters line of sight with an external PA (TI CC2590)  Excellent Anti-WiFi Performance  Uncompressed stereo CD audio quality  Can be used autonomously, or being controlled by an external host MCU  Seamless connection and control of selected TI audio codecs, DACs/ADCs  Model No.: MD8520P1/ MD8521P1/ MD8530P1/ MD8531P1  Frequency Range: 2.4GHz – 2.483GHz  Solution: TI CC8520/CC8530 (Digital I2S I/O); TI CC8521/CC8531 (USB full speed I/O)  RF Channel No.: up to 18 channels  Modulation: 8GFSK (frequency hopping)  Data Rate: up to 5Mbps  Distance: up to 100 meters line of sight  Audio Channel No.: 2 for MD8520/MD8521P1; 3 or 4 for MD8530P1/MD8531P1  Software or Drivers: 2.0V ~ 3.6V  Operating Temperature: -40 ~ +85  Audio Sample Rate: up to 48kHz / 16bits (Uncompressed)  Transmitter Output Power: 11dBm  Receiver Sensitivity: -87dBm  Dimension (L x W): 34 x 14.7mm 3. Applications  Wireless speakers.  Home theater rear speakers.  Wireless audio sender for CD / DVD player.  USB and PC wireless audio  TV/Set-top box wireless audio  Music instrument 4. Block Diagram Note: I2C must be connected to external pull-up resister 2.7K. VBAT has internal resister 100K on Module. 5. Pin Assignment & Definition PCB Material Properties and plating Product Name FR-4 COPPER CLAD LAMINATE / PREPREG SM700,SM730,SM750,SM630,SM560) Manufacturer ShineMore Technology Materials Co. Flammability UL94V-0 Plating Gold ( Thickness 2.0 micro m) Pin Assignment Name Pin function Description GND Ground The exposed die attach pad must be connected to a solid ground plane underneath the chip VCC Power 2.0-3.6V analog power supply connection VBAT Analog input Battery voltage supervisor (threshold level programmable by external resistor to positive battery terminal) SCL GIO10 Digital I/O 1 I2C master clock line. Must be connected to external pull-up General-purpose digital I/O pin 10 SDA GIO11 Digital I/O 1 I2C master clock line. Must be connected to external pull-up General-purpose digital I/O pin 11 GIO12 Digital I/O 1 General-purpose digital I/O pin 12 GIO13 Digital I/O 1 General-purpose digital I/O pin 13 PAEN Digital I/O 2 Control external PA EN Digital I/O 2 Control external LNA XANTN USBN Digital I/O 1 CC85x0: DO NOT CONNECT (Future FW: Controlling external antenna switch) CC85x1: USB D- data line XANTP USBP Digital I/O 1 CC85x0: DO NOT CONNECT (Future FW: Controlling external antenna switch) CC85x1: USB D+ data line CSN Digital Input (pull-up) Serial SPI configuration interface, active low chip select SCLK Digital I/O 1 Serial SPI configuration interface, clock input/output MOSI Digital I/O 1 Serial SPI configuration interface, master data output, slave data input MISO Digital I/O 1 Serial SPI configuration interface, master data input, slave data output GIO1 Digital I/O 1 General-purpose digital I/O pin 1 Configurable with PurePath™ Wireless Configurator GIO2 Digital I/O 1 General-purpose digital I/O pin 2 GIO3 Digital I/O 2 General-purpose digital I/O pin 3 Configurable with PurePath™ Wireless Configurator RSTN Digital Input (pull-up) Active-low device reset MCLK GIO4 Digital I/O 1 Master clock output for external audio devices General-purpose digital I/O pin 4 BCLK GIO5 Digital I/O 1 I2S/DSP audio interface bit clock (in/out) General-purpose digital I/O pin 5 5 Name Pin function Description WCLK GIO6 Digital I/O 1 I2S/DSP audio interface word clock (in/out) General-purpose digital I/O pin 6 AD0 GIO7 Digital I/O 1 I2S/DSP audio interface data line 0 (in/out) General-purpose digital I/O pin 7 AD1 GIO8 Digital I/O 1 I2S/DSP audio interface data line 1 (in/out) General-purpose digital I/O pin 8 AD2 GIO9 Digital I/O 2 I2S/DSP audio interface data line 2 (in/out) Configurable with PurePath™ Wireless Configurator 1 Digital I/O pad with 4 mA source/sink capability. 2 Digital I/O pad with 20 mA source/sink capability. 6. Regulatory Notices: Federal Communication Commission Interference Statement: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, whi…
