Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Version: A Issued Date: 2020/07/02 Approval Sheet (產品承認書) 產品名稱 (Product): Bluetooth Low Energy Module 產品型號 (Model No.): MDBT42T Series (Chip Antenna) MDBT42T – P Series (PCB Antenna) Index 1. Overall Introduction ...................................................................................................... 3 1.1. Application ............................................................................................................ 3 1.2. Features ............................................................................................................... 4 2. Product Dimension ....................................................................................................... 5 2.1. PCB Dimensions & Pin Indication ......................................................................... 5 2.2. Recommended Layout of Solder Pad ................................................................... 7 2.3. RF Layout Suggestion (aka Keep-Out Area) ....................................................... 11 2.4. Footprint & Design Guide ................................................................................... 13 2.5. Pin Assignment ................................................................................................... 14 3. Main Chip Solution ...................................................................................................... 15 4. Specification ................................................................................................................ 16 4.1. Absolute Maximum Ratings ................................................................................ 16 4.2. Operation Conditions .......................................................................................... 16 4.3. Electrical Specifications ...................................................................................... 17 5. FCC Compliance .......................................................................................................... 22 6. IC Caution .................................................................................................................... 25 7. NCC警語 ...................................................................................................................... 27 1. Overall Introduction Raytac’s MDBT42T & MDBT42T-P is a BT 5.1 stack (Bluetooth low energy or BLE) module designed based on Nordic nRF52805 SoC solution, which incorporates: GPIO, SPI, UART, I2C, and ADC interfaces for connecting peripherals and sensors. Features: 1. Dual Transmission mode of BLE & 2.4Ghz RF upon customer preference. 2. Compact size with (L) 11.2 x (W) 7.2 x (H) 2.05 or 1.80 mm. 3. Low power requirements, ultra-low peak, average and idle mode power consumption. 4. Be compatible with a large installed base of mobile phones, tablets and computers. 5. Fully coverage of BLE software stack. 6. BLE & RF transmission switching helps products fit all operation system and most hardware. 1.1. Application • Data bridge • Proprietary protocol devices • Network processor • Beacons • Smart Home sensors • Presenters/Stylus • Health monitoring • Drug delivery • Asset tags • Toys • Retail tags and labels 1.2. Features ‧Multi-protocol 2.4GHz radio ‧32-bit ARM Cortex – M4 processor ‧192KB flash programmed memory and 24KB RAM ‧Software stacks available as downloads ‧Application development independent from protocol stack ‧On-air compatible with nRF51, nRF24AP and nRF24L series ‧Programmable output power from +4dBm to -20dBm ‧RSSI ‧RAM mapped FIFOs using EasyDMA ‧Flexible and configurable 10 pin GPIO ‧Programmable peripheral interface - PPI ‧Full set of digital interface all with Easy DMA including: ‧1 x Hardware SPI master ; 1 x Hardware SPI slave ‧1 x two-wire master ; 1 x two-wire slave ‧1 x UART (CTS / RTS) ‧2 channel 12-bit / 200KSPS ADC ‧128-bit AES ECB / CCM / AAR co-processor ‧Low power 32MHz crystal and RC oscillators ‧Wide supply voltage range 1.7V to 3.6V ‧On-chip DC/DC buck converter ‧Individual power management for all peripherals ‧Timer counter ‧3x 32-bit ‧2 x 24-bit RTC 2. Product Dimension 2.1. PCB Dimensions & Pin Indication ‧MDBT42T PCB Size (in mm) Min. Norm MAX. L - 0.15 11.2 + 0.2 W 7.2 H 2.05 ‧MDBT42T-P PCB Size (in mm) Min. Norm MAX. L - 0.15 11.2 + 0.2 W 7.2 H 1.8 2.2. Recommended Layout of Solder Pad Graphs are all in Top View, Unit in mm. 2.3. RF Layout Suggestion (aka Keep-Out Area) Please follow below instruction to have better wireless performance. Make sure to keep the “No-Ground-Pad” as wider as possible when there is no enough space in your design. No-Ground Pad should be included in the corresponding position of the antenna in EACH LAYER. Place the module towards the edge of PCB to have better performance than placing it on the center. Welcome to send us your layout in PDF for review at [email protected] or your contact at Raytac with title “Layout reviewing –Raytac model no.–YOUR company’s name”. Examples of “NOT RECOMMENDED” layout 2.4. Footprint & Design Guide Please visit “Support” page of our website to download. The package includes footprint, 2D/3D drawing, reflow graph and recommended spec for external 32.768khz. 2.5. Pin Assignment Pin No. Name Pin function Description (1) GND Ground The pad must be connected to a solid ground plane (2) SWDIO Digital I/O Serial Wire debug I/O for debug and programming (3) SWDCLK Digital input Serial Wire debug clock input for debug and programming (4) P0.21 Digital I/O General-purpose digital I/O RESET Configurable as system RESET pin (5) P0.20 Digital I/O General-purpose digital I/O (6) P0.14 Digital I/O General-purpose digital I/O (7) P0.18 Digital I/O General-purpose digital I/O (8) P0.16 Digital I/O General-purpose digital I/O (9) P0.12 Digital I/O General-purpose digital I/O (10) GND Ground The pad must be connected to a solid ground plane (11) P0.05 Digital I/O General-purpose digital I/O AIN3 Analog input SAADC input (12) P0.04 Digital I/O General-purpose digital I/O AIN2 Ana…
Text truncated - open the document above for the full version.
Date: October 6, 2020 To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Raytac Corp. 5F., No.3, Jiankang Rd., Zhonghe Dist., New Taipei City 23586, Taiwan Regarding: Confidentiality Request regarding application for FCC ID: SH6MDBT42T LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Raytac Corp. Venson Liao / R&D Manager Phone: +886-2-32340208 ext. 304 E-Mail: [email protected]
Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Raytac Corp. Address 5F., No.3, Jiankang Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan Grantee Code SH6 FCC ID SH6MDBT42T Authorized Contact Name Venson Liao Contact Email [email protected] Contact Phone +886-2-32340208 ext. 304 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:October 6, 2020 Print Name: Venson Liao Title: R&D Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database
Date: 2020-10-07 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: Model Difference Letter for FCC: SH6MDBT42T To Whom It May Concern: Due to the business consideration, we hereby declare that our product of BLE Module, Model: MDBT42T, MDBT42T-P have as following difference Model Description: MDBT42T: with Chip antenna MDBT42T-P: with PCB antenna Any questions regarding this declaration, please don’t hesitate to contact us. Sincerely, _________________________________ Raytac Corp. Venson Liao / R&D Manager Phone: +886-2-32340208 ext. 304 E-Mail: [email protected]
Date: October 6, 2020 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding FCC ID: SH6MDBT42T To whom it may concern: We, the undersigned, hereby authorize Kevin Tsai / Deputy Manager of SGS Compliance Certification Services Inc. to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Raytac Corp.. This authorization is valid until further written notice from the applicant. Raytac Corp. Venson Liao / R&D Manager Phone: +886-2-32340208 ext. 304 E-Mail: [email protected]
6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: SH6MDBT42T” or “Contains FCC ID: SH6MDBT42T” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement.
This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 1 / 6 Report No.: T200824W09 Rev.: 00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Model: MDBT42T This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 2 / 6 Report No.: T200824W09 Rev.: 00 Model: MDBT42T-P
This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 3 / 6 Report No.: T200824W09 Rev.: 00 INTERNAL PHOTOGRAPHS OF EUT Model: MDBT42T This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 4 / 6 Report No.: T200824W09 Rev.: 00 Crystal Antenna (Chip Antenna) This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 5 / 6 Report No.: T200824W09 Rev.: 00 Model: MDBT42T-P This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 6 / 6 Report No.: T200824W09 Rev.: 00 Crystal Antenna (PCB Antenna)
FCC ID: SH6MDBT42T IC: 8017A-MDBT42T Page: 1 / 86 Report No.: T200824W09-RP Rev.: 01 No.11, Wugong 6th Rd., Wugu Dist., New Taipei City , Taiwan /新北市五股區五工六路11號 t:(886-2) 2299-9720 f:(886-2) 2299-9721 www.sgs.com.tw www.ccsrf.com Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明,此報告結果僅對測試之樣品負責,同時此樣品僅保留90天。本報告未經本公司書面許可,不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com.tw/Terms-and-Conditions and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com.tw/Terms-and-Conditions. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of client’s instruction, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced, except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Compliance Certification Services Inc. 程智科技股份有限公司 Member of the SGS Group RADIO TEST REPORT FCC 47 CFR PART 15 SUBPART C Test Standard FCC Part 15.247 RSS-247 issue 2 and RSS-GEN issue 5 Product name BLE Module Brand Name Raytac Corporation Model No. MDBT42T, MDBT42T-P Test Result Pass Statements of Conformity Determination of compliance is based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. The test Result was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were given in ANSI C63.10: 2013 and compliance standards. The test results of this report relate only to the tested sample (EUT) identified in this report. The test Report of full or partial shall not copy. Without written approval of Compliance Certification Services Inc. (Wugu Laboratory) Approved by: Tested by: Kevin Tsai Dally Hong Deputy Manager Sr. Engineer This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 2 / 86 Report No.: T200824W09-RP Rev.: 01 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 October 14, 2020 Initial Issue ALL Allison Chen 01 November 4, 2020 See the following note Rev.(01) P.6 Allison Chen Rev.(01) 1. Added uncertainty of 3M semi anechoic chamber 9kHz~30MHz in section 1.4. This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 3 / 86 Report No.: T200824W09-RP Rev.: 01 Table of contents 1. GENERAL INFORMATION ........................................................................................ 4 1.1 EUT INFORMATION .................................................................................................. 4 1.2 EUT CHANNEL INFORMATION ................................................................................ 5 1.3 ANTENNA INFORMATION ........................................................................................ 5 1.4 MEASUREMENT UNCERTAINTY .............................................................................. 6 1.5 FACILITIES AND TEST LOCATION .......................................................................... 7 1.6 INSTRUMENT CALIBRATION ................................................................................... 7 1.7 SUPPORT AND EUT ACCESSORIES EQUIPMENT ................................................. 8 1.8 TEST METHODOLOGY AND APPLIED STANDARDS ............................................. 8 2. TEST SUMMARY ....................................................................................................... 9 3. DESCRIPTION OF TEST MODES............................................................................ 10 3.1 THE WORST MODE OF OPERATING CONDITION ................................................ 10 3.2 THE WORST MODE OF MEASUREMENT .............................................................. 11 3.3 EUT DUTY CYCLE ................................................................................................... 12 4. TEST RESULT ......................................................................................................... 13 4.1 AC POWER LINE CONDUCTED EMISSION ........................................................... 13 4.2 6DB BANDWIDTH AND OCCUPIED BANDWIDTH (99%) ...................................... 14 4.3 OUTPUT POWER MEASUREMENT ........................................................................ 20 4.4 POWER SPECTRAL DENSITY ................................................................................ 23 4.5 CONDUCTED BAND EDGE AND SPURIOUS EMISSION ...................................... 27 4.6 RADIATION BANDEDGE AND SPURIOUS EMISSION .......................................... 34 APPENDIX 1 - PHOTOGRAPHS OF EUT This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: 4 / 86 Report No.: T200824W09-RP Rev.: 01 1. GENERAL INFORMATION 1.1 EUT INFORMATION Applicant Raytac Corp. 5F.,No.3, Jiankang Road, Zhonghe District, New Taipei City 23586, Taiwan Manufacturer Raytac Corp. 5F.,No.3, Jiankang Road, Zhonghe District, New Taipei City 23586, Taiwan Equipment BLE Module Model No. MDBT42T, MDBT42T-P Model Discrepancy Difference of the model numbers (list on this report) is difference between antenna type as below: Model: Antenna…
Text truncated - open the document above for the full version.
This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 FCC ID: SH6MDBT42T IC: 8017A-MDBT42T Page: 1 / 1 Report No.: T200824W09-MF Rev.: 02 FCC ID: SH6MDBT42T According to KDB 447498 section 4.3.1, the 1-g SAR test exclusion thresholds at test separation distance ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] *·[√f(GHz)] ≤ 3.0 The tune-up power is 5.73 dBm +/- 0dB, therefore the highest tune-up power is 5.73 dBm(3.74 mW)@ 2402 MHz When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. So, (3.74mW / 5mm)* (2.402GHz^0.5 )= 1.2 [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [√f(GHz)] = 1.2 < 3.0 Therefore, standalone SAR measurements are not required for both head and body. Note: 1. The tune up power referred the AVG power of the test report T200824W09-RP for SAR test exclusion purpose.
This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: A-1 / A-3 Report No.: T200824W09-RP Rev.: 01 APPENDIX-A Test Photo Model: MDBT42T (chip Antenna) Radiation (Below 1GHz) Radiation (Above 1GHz) This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: A-2 / A-3 Report No.: T200824W09-RP Rev.: 01 Model: MDBT42T-P (PCB Antenna) Radiation (Below 1GHz) Radiation (Above 1GHz) This document cannot be reproduced except in full, without prior written approval of the Company. 本報告未經本公司書面許可,不可部份複製。 Page: A-3 / A-3 Report No.: T200824W09-RP Rev.: 01 Conducted Emission Set up Photo
No.11, Wugong 6th Rd., Wugu Dist. · New Taipei City · Taiwan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 4.00 mW |
