SH6MP01WIRELESS PRESENTER

TEST REPORT Report No. : AR0069991(1) Date : 13 Dec 2013 For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : Page 1 of 29 Mr. WONG Lap-pong, Andrew Assistant Manager Electrical Division FCC ID: SH6MP01 Application No. : LR045392(1) Applicant : Raytac Corporation 5F., No.3, Jiankang Road, Zhonghe District, Taipei City, 23586, Taiwan Sample Description : One(1) item of submitted sample stated to be Wireless Presenter of Model No. 2603766 Sample registration No. : RR049933-001 Radio Frequency : 2403MHz – 2474 MHz Transmitter Rating : 2 x 1.5V AA size batteries No. of submitted sample : One (2) piece (s) Date Received : 09 Dec 2013 Test Period : 09 Dec 2013 to 16 Dec 2013. Test Requested : FCC Part 15 Certificate Test Method : 47 CFR Part 15 (10-1-12 Edition), ANSI C63. 4 – 2009 Test Engineer : Mr. LEUNG Shu-kan, Ken Test Result : See attached sheet(s) from page 2 to 29. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. TEST REPORT Report No. : AR0069991(1) Date : 13 Dec 2013 Page 2 of 29 FCC ID: SH6MP01 Table of Contents 1 General Information ................................................................................................................................... 3 1.1 General Description ............................................................................................................................ 3 1.2 Location of the test site ....................................................................................................................... 4 1.3 List of measuring equipment............................................................................................................... 5 1.4 Measurement Uncertainty ................................................................................................................... 6 2 Description of the radiated emission test ................................................................................................... 7 2.1 Test Procedure .................................................................................................................................... 7 2.2 Test Result .......................................................................................................................................... 8 2.3 Radiated Emission Measurement Data ............................................................................................... 9 3 Description of the Line-conducted Test ................................................................................................... 11 3.1 Test Procedure .................................................................................................................................. 12 3.2 Test Result ........................................................................................................................................ 12 3.3 Graph and Table of Conducted Emission Measurement Data .......................................................... 12 4 Photograph ...............................................................................................................................................13 4.1 Photographs of the Test Setup for Radiated Emission and Conducted Emission ............................. 13 4.2 Photographs of the External and Internal Configurations of the EUT.............................................. 13 5 Supplementary document ......................................................................................................................... 14 5.1 Bandwidth ......................................................................................................................................... 14 5.2 Duty cycle ......................................................................................................................................... 14 5.3 Transmission time ............................................................................................................................. 14 5.4 Power Spectral Density..................................................................................................................... 14 5.5 Average on time ................................................................................................................................ 14 6 Appendices...............................................................................................................................................15 TEST REPORT Report No. : AR0069991(1) Date : 13 Dec 2013 Page 3 of 29 FCC ID: SH6MP01 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for presenter. The EUT is power by 2 x 1.5V AAA size batteries. It operates at 2403MHz – 2474 MHz. There are buttons on the EUT. When the buttons are pressed, the EUT will transmit radio signal to receiver. There is a display for down count timing. When timing finish, the motor will vibrate. The EUT also has a laser pointer for pointing. The brief circuit description is listed as follows: - U1 and its associated circuit act as RF circuit - X1 and its associated circuit act as Oscillator - U2 and its associated circuit act as MCU - LCD1 and its associated circuit act as Display - MG1 and its associated circuit act as Motor - U4 and its associated circuit act as Power control - Q2, Q3, Q4, LD1 and its associated circuit act as Laser module TEST REPORT Report No. : AR0069991(1) Date : 13 Dec 2013 Page 4 of 29 FCC ID: SH6MP01 1.2 Location of the test site FCC Registered Test Site Number: 552221 Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. A Semi-Anechoic Chamber Testing Site is set up for investigation and located at: Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. Conducted emissions measurements are investigated and also taken pursuant to the procedures of ANSI C63.4 – 2009. A shielded…

Text truncated - open the document above for the full version.

TEST REPORT Report No. : AR0069991(1) Date : 13 Dec 2013 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 24 of 29 FCC ID: SH6MP01 A5. Band Edge Lower Band (Peak measurement) Lower Band (Average measurement) TEST REPORT Report No. : AR0069991(1) Date : 13 Dec 2013 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 25 of 29 FCC ID: SH6MP01 A5. Band Edge Lower Band (Peak measurement) Lower Band (Average measurement) TEST REPORT Report No. : AR0069991(1) Date : 13 Dec 2013 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 26 of 29 FCC ID: SH6MP01 A5. Band Edge Higher Band (Peak measurement) Higher Band (Average measurement)
