SLH-BT-3002BT V1.2 USB Module

BT-3002 BT V1.2 USB Module BT-3002 User’s Manual 華朗科技股份有限公司 HL-Tech Corporation HL-Tech Corporation 1 BT-3002 BT V1.2 USB Module Note: BT-3002 BT V1.2 USB Module BT-3002 User’s Manual 華朗科技股份有限公司 HL-Tech Corporation HL-Tech Corporation 2 Table of Contents.........................................................2 Introduction...............................................................................................3 1. Configuration and devices......................................................................................3 2. Device properties....................................................................................................4 3. Options....................................................................................................................4 4. Discovery.................................................................................................................4 5. Adding a COM port...................................................................................................5 6. Hardware.................................................................................................................5 7. Adding a device.......................................................................................................6 8. Joining a Personal Area Network............................................................................7 9. Adding a modem.....................................................................................................8 10. Adding a printer....................................................................................................8 11. File Sending and Receiving...................................................................................9 BT-3002 BT V1.2 USB Module BT-3002 User’s Manual 華朗科技股份有限公司 HL-Tech Corporation HL-Tech Corporation 3 Introduction This article describes how to install and configure a Bluetooth device in Microsoft Windows XP Service Pack 2 (SP2). Note If you install a Bluetooth adapter that is not supported in Windows XP SP2, follow the recommendations that the Bluetooth adapter's manufacturer provides. Installing a Bluetooth adapter that is on the list of supported adapters for Microsoft Windows XP Service Pack 2 (SP2) is only a matter of connecting the device. No configuration is needed before you make the connection. When you install a supported Bluetooth adapter in Windows XP SP2, the adapter becomes active together with the following Microsoft components: • Microsoft Bluetooth Enumerator This component enumerates Bluetooth devices and capabilities. • Bluetooth Device (Personal Area Network) This driver supports Personal Area Network (PAN) connections between devices. • Bluetooth Device (RFCOMM Protocol Transport Driver Interface [TDI]) This component supports dial-up networking (DUN). It also supports other types of connections between devices. • Bluetooth Support Service (BthServ) This service maintains and updates device pairing information. It also performs other functions that are related to Bluetooth features. These components are available in Device Manager after you install a Bluetooth adapter. Other drivers and components are also installed. 1. Configuration and devices You can use the Bluetooth Devices item in Control Panel to configure Bluetooth settings. By using Bluetooth Devices, you can do one or more of the following: • Add or remove a device. • View the properties of a device. • Change your Bluetooth options. • Add a COM port. In Bluetooth Devices, the Devices tab shows all the devices that are currently configured on your computer. By using the Devices tab, you can add a device, remove a device, or view the properties of a device. BT-3002 BT V1.2 USB Module BT-3002 User’s Manual 華朗科技股份有限公司 HL-Tech Corporation HL-Tech Corporation 4 2. Device properties When you view the properties of a Bluetooth device, you see the following information: • The device type • The hardware address of the Bluetooth adapter • The date and time of the last connection • Information about whether a passkey is used for pairing with the device You can also change the name that Windows uses for the device. This change also affects the name that is used by the Bluetooth File Transfer Wizard and by Add Modem. The Services tab shows information about the services that the device supports. For example, when a Bluetooth phone or a personal digital assistant (PDA) is connected to your computer, this tab may show COM ports that are available for synchronization. This tab may also show Internet dial-up networking connections. You can also select the services that you want to use. 3. Options The Options tab in Bluetooth Devices provides options that control how devices discover and connect to your computer. The main option is Turn discovery on. This option lets devices discover your computer so that you can make a connection. Other options on this tab include the following: • Allow Bluetooth devices to connect to this computer This check box controls whether any devices can connect to your computer. If this check box is cleared, no devices can connect to your computer. • Alert me when a new Bluetooth device wants to connect This option controls whether you receive notification when a device tries to connect to your computer. If this check box is cleared, you do not receive notification. Other options on the Options tab let you turn on or turn off the Bluetooth icon in the notification area and restore default settings. 4. Discovery Typically, your Bluetooth-enabled computer will discover other devices. Therefore, you only have to turn on the Turn discovery on option when your computer acts as a device. For example, you might want to turn on this option when your computer is connected to another computer by a Personal Area Network (PAN). When computers are connected by a PAN, one of the computers must have discovery turned on. By default, discovery is not turned on in Windows XP SP2, because a disco…

Text truncated - open the document above for the full version.

HL-Tech Corporation Date: 07/15/2005 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the TaiWan office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS TW, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS TW on our behalf shall have the same effect as acts of our own. In authorizing CCS TW as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Ken Sung /Manager HL-Tech Corporation REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

HL-Tech Corporation Federal Communications Commission Authorization and Evaluation Division FCC ID: SLH-BT-3002 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Ken Sung/ Manager HL-Tech Corporation

HL-Tech Corporation Modular Approval Request Letter July 14, 2005 Compliance Certification Services 561F Monterey Rd., Morgan Hill, CA 95037, USA To Whom It May Concern: HL-Tech Corporation‘s module, with the FCC ID: SLH-BT-3002 has your authorization as a modular approval specific to products below: The requirements of the Public Notice DA-00-1407 have been met and shown on the following statements: 1. The modular transmitter must have its own RF shielding: The radio portion of this module has been shielding, please refer to the external and internal photo. 2. The modular transmitter must have buffered modulation / data inputs: The EUT has buffered data inputs; it is integrated in CSR chip. 3. The modular transmitter must have its own power supply regulation: The chip's IF converter and RF/IF converter which will influence the frequency radiation ,and has to be 3.3VDC/1.8VDC powered. The USB interface provides 3.3VDC. So there are not regulators in front of these chip. 4. The modular transmitter must comply with the antenna requirements of the Section 15.203 and 15.204(c): The EUT meets the FCC antenna requirements. The spurious emission unique printed antenna and photo of antenna is shown in the EUT Photo. 5. The modular transmitter must be tested in a stand-alone configuration: The EUT was tested in a stand-alone configuration via a USB interface to test kit. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this test kit. 6. The modular transmitter must be labeled with its own FCC ID number and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements: The EUT is complied with all FCC rules. Please refer to user’s manual for detail. 8. The modular transmitter must comply with any applicable RF exposure requirements: For mobile configuration only. Refer to MPE calculation in the test report. RF Exposure is addressed in the RF exposure exhibition. Should you have any question, please don’t hesitate to ask us. Best regards, Ken Sung /Manager HL-Tech Corporation

Compliance Certification Services Inc. Report No: 50707006 Date of Issue: July 19, 2005 Page 1 Total Page: 2 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT

)&&,' SLH-BT-300 2 0$& 61 0DGH LQ7DLZDQ '& 3.3 9 +/7HFK %OXHWRRWK986%'RQJOH )&&,'6/+%70$&61 0DGHLQ7DLZDQ '&9 DC 3.3V

Compliance Certification Services Inc. Report No: 50707006 Date of Issue: July 19, 2005 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT

Compliance Certification Services Inc. Report No.: 50707006-RP1 FCC ID: SLH-BT-3002 Date of Issue: July 19, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 49 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For BT V1.2 USB Module Model: BT-3002 Trade Name: HL-Tech Issued to HL-Tech Corporation 1/2F, No. 13, Lane 120, Sec. 1, Nei Hu Rd., Taipei, Taiwan 114, R.O.C. Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No.: 50707006-RP1 FCC ID: SLH-BT-3002 Date of Issue: July 19, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ................................................................................................................3 2. EUT DESCRIPTION........................................................................................................................................4 3. TEST METHODOLOGY ................................................................................................................................5 3.1 EUT CONFIGURATION.....................................................................................................................................5 3.2 EUT EXERCISE................................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.........................................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ....................................................................6 3.5 DESCRIPTION OF TEST MODES........................................................................................................................6 4. INSTRUMENT CALIBRATION ....................................................................................................................7 5. FACILITIES AND ACCREDITATIONS ......................................................................................................8 5.1 FACILITIES .................................................................................................................................................8 5.2 EQUIPMENT .................................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING...............................................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS....................................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST ...................................................................................................10 6.1 SETUP CONFIGURATION OF EUT...................................................................................................................10 6.2 SUPPORT EQUIPMENT ..........................................................................................................................10 7. FCC PART 15.247 REQUIREMENTS.........................................................................................................11 7.1 PEAK POWER................................................................................................................................................11 7.2 BAND EDGES MEASUREMENT............................................................................................................12 7.3 PEAK POWER SPECTRAL DENSITY.................................................................................................................17 7.4 FREQUENCY SEPARATION ..................................................................................................................20 7.5 NUMBER OF HOPPING FREQUENCY..................................................................................................22 7.6 TIME OF OCCUPANCY (DWELL TIME) ..............................................................................................24 7.7 RADIO FREQUENCY EXPOSURE.....................................................................................................................31 7.8 SPURIOUS EMISSIONS ............................................................................................................................34 7.9 POWERLINE CONDUCTED EMISSIONS...........................................................................................................44 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ...........................................................................................47 Compliance Certification Services Inc. Report No.: 50707006-RP1 FCC ID: SLH-BT-3002 Date of Issue: July 19, 2005 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: HL-Tech Corporation 1/2F, No. 13, Lane 120, Sec. 1, Nei Hu Rd., Taipei, Taiwan 114, R.O.C. Equipment Under Test: BT V1.2 USB Module Trade Name: HL-Tech Model: BT-3002 Date of Test: July 11 ~ 15, 2005 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approv…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 50707006-RP1 FCC ID: SLH-BT-3002 Date of Issue: July 19, 2005 Page 47 Rev. 00 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No.: 50707006-RP1 FCC ID: SLH-BT-3002 Date of Issue: July 19, 2005 Page 48 Rev. 00 Conducted Emission Set Up Photos Compliance Certification Services Inc. Report No.: 50707006-RP1 FCC ID: SLH-BT-3002 Date of Issue: July 19, 2005 Page 49 Rev. 00
