SOYHSB2APWLAN Booster + Access Point

Hawking Technologies, Inc.
WLAN Booster + Access Point - FCC ID SOYHSB2AP - Hawking Technologies, Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Sep 09, 2005
Application Purpose
Original Equipment
Date of Application
Sep 09, 2005
Equipment Note
WLAN Booster + Access Point
Frequency Range
2412.00000000 - 2462.00000000
Company
Hawking Technologies, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Signal Booster + 11g AP KIT HSB2 –AP Wireless Signal Booster (HSB2) Plus Wireless G AP (HWBA54G) CE MARK WARNING This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. LIMITED WARRANTY Hawking Technology guarantees that every HWBA54G Wireless-G AP / Bridge is free from physical defects in material and workmanship under normal use for two (2) years from the date of purchase. If the product proves defective during this two-year warranty period, call Hawking Customer Service in order to obtain a Return Authorization number. Warranty is for repair or replacement only. Hawking Technology does not issue any refunds. BE SURE TO HAVE YOUR PROOF OF PURCHASE. RETURN REQUESTS CAN NOT BE PROCESSED WITHOUT PROOF OF PURCHASE. When returning a product, mark the Return Authorization number clearly on the outside of the package and include your original proof of purchase. IN NO EVEN SHALL HAWKING TECHNOLOGY’S LIABILTY EXCEED THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFTWARE OR ITS DOCUMENTATION. Hawking Technology makes no warranty or representation, expressed, implied or statutory, with respect to its products or the contents or use of this documentation and all accompanying software, and specifically disclaims its quality, performance, merchantability, or fitness for any particular purpose. Hawking Technology reserves the right to revise or updates its products, software, or documentation without obligation to notify any individual or entity. Please direct all inquiries to:[email protected] TRADEMARKS AND COPYRIGHT Windows 95/98/ME and Windows NT/2000/XP are registered trademarks of Microsoft Corp. All other brands and product names are trademarks of their respective companies. No part of this publication may be reproduced in any form or by any means or used to make any derivative (such as translation, transformation or adaptation) without the express written consent of the manufacturer as stipulated by the United States Copyright Act of 1976. FCC WARNING This equipment has been tested and found to comply with the regulations for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with this user’s guide, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his/her own expense. Table of Contents Section 1 – HWBA54G Wireless 11g AP Chapter 1 Introduction..............................................................................1 1.1 Package Contents......................................................................................... 2 1.2 Features ....................................................................................................... 2 1.3 Specifications .............................................................................................. 2 1.4 Physical Description .................................................................................... 3 Chapter 2 Wireless LAN Access Point Connection ................................5 Chapter 3 Wireless LAN Access Point Configuration............................6 3.1 Getting Started............................................................................................. 6 3.2 Configuring the Access Point .................................................................... 11 3.2.1 Client Mode configuration ................................................................................. 12 3.2.2 AP Mode configuration...................................................................................... 15 3.2.3 P2P Mode configuration .................................................................................... 20 3.2.4 PMP Mode configuration ................................................................................. 21 3.2.5 WEP Setting.................................................................................................. 23 3.2.6 WPA Setting ................................................................................................. 25 3.2.7 Advanced Setting.......................................................................................... 26 3.2.8 Access Filter ................................................................................................. 27 3.2.9 Status Setup .................................................................................................. 29 3.2.10 Admin Setup ................................................................................................. 30 3.2.11 LAN Setup .................................................................................................... 32 Charpter 4 Troubleshooting ...................................................................33 Section 2 – HSB2 Wireless Signal Booster 1. Introduction .......................................................... 35 2. Installation Proceudre ............................................... 38 3. Product Specifications ................................................... 40 4. Networking terms ............................................................ 41 Chapter 1 Introduction Thank you for purchasing the Hawking Technologies Hi-Speed 54M Wireless-G Access Point and Ethernet Bridge. The HWBA54G is compliant with the IEEE 802.11g/b wireless standards. The Hi-Speed 54G Wireless AP/Bridge utilizes the highest wireless security standards (WPA) to protect your network from outside intruders, including WPA-PSK, WEP, ESSID an…

Text truncated - open the document above for the full version.

External Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A12 TEL : 886-2-2696-2468 ISSUED DATE : Jun,07,2005 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A12 TEL : 886-2-2696-2468 ISSUED DATE : Jun,07,2005 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A10 OF A12 TEL : 886-2-2696-2468 ISSUED DATE : Jun,07,2005 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A11 OF A12 TEL : 886-2-2696-2468 ISSUED DATE : Jun,07,2005 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A12 OF A12 TEL : 886-2-2696-2468 ISSUED DATE : Jun,07,2005 FAX : 886-2-2696-2255

Internal Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A6 TEL : 886-2-2696-2468 ISSUED DATE : Oct,03,2005 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A6 TEL : 886-2-2696-2468 ISSUED DATE : Oct,03,2005 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A6 TEL : 886-2-2696-2468 ISSUED DATE : Oct,03,2005 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A4 OF A6 TEL : 886-2-2696-2468 ISSUED DATE : Oct,03,2005 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A5 OF A6 TEL : 886-2-2696-2468 ISSUED DATE : Oct,03,2005 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A6 OF A6 TEL : 886-2-2696-2468 ISSUED DATE : Oct,03,2005 FAX : 886-2-2696-2255

RF Exposure Info

FCC ID: SOYHSB2AP Issued on June 07, 2005 Report No.: FR551701 SPORTON International Inc. Page No. : 44 of 49 TEL : 886-2-2696-2468 Issued Date : June 07, 2005 FAX : 886-2-2696-2255 5.8. RF Exposure 5.8.1. Limit For Maximum Permissible Exposure (MPE) This product can be classified as mobile device, so the 20cm separation distance warning is required. In this section, the power density at 20cm location is calculated to examine if it is lower than the limit. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm²) Averaging Time |E|²,|H|² or S ( minutes ) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 F = frequency in MHz *Plane-wave equivalent power density 5.8.2. MPE Calculation Method E (V/m) d GP××30 Power Density: Pd (mW/cm²) 377 2 E E Electric field (V/m) P Peak RF output power (mW) G EUT Antenna numeric gain (numeric) d Separation distance between radiator and human body (cm) The formula can be changed to Pd 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=20cm, as well as the gain of the used antenna, the RF power density can be obtained. FCC ID: SOYHSB2AP Issued on June 07, 2005 Report No.: FR551701 SPORTON International Inc. Page No. : 45 of 49 TEL : 886-2-2696-2468 Issued Date : June 07, 2005 FAX : 886-2-2696-2255 5.8.3. Calculated Result and Limit ‚ Modulation Type: DSSS ‚ Temperature: 26°C ‚ Relative Humidity: 64% ‚ Duty Cycle of the Equipment During the Test: 100.00% ‚ Test Engineer: Eason Lu Channel No. Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) 01 2.00 1.58 20.22 105.20 0.0331 1 06 2.00 1.58 20.51 112.46 0.0354 1 11 2.00 1.58 20.64 115.88 0.0364 1 ‚ Modulation Type: OFDM ‚ Temperature: 26°C ‚ Relative Humidity: 64% ‚ Duty Cycle of the Equipment During the Test: 100.00% ‚ Test Engineer: Eason Lu Channel No. Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) 01 2.00 1.58 17.54 56.75 0.0178 1 06 2.00 1.58 17.70 58.88 0.0185 1 11 2.00 1.58 17.42 55.21 0.0174 1

Test Report

FCC ID: SOYHSB2AP Issued on June 07, 2005 Report No.: FR551701 SPORTON International Inc. TEL : 886-2-2696-2468 FAX : 886-2-2696-2255 FCC TEST REPORT CATEGORY : Mobile PRODUCT NAME : BOOSTER+AP FCC ID. : SOYHSB2AP FILING TYPE : Certification BRAND NAME : HAWKING MODEL NAME : HSB2-AP APPLICANT : Hawking Technology, Inc. 15281A Barranca Parkway, Irvine, CA 92618, USA MANUFACTURER : Same as applicant ISSUED BY : SPORTON INTERNATIONAL INC. 6F, No. 106, Sec. 1, Hsin Tai Wu Rd., His Chih, Taipei Hsien, Taiwan, R.O.C. Statements: The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. Certificate or Test Report could not be used by the applicant to claim the product endorsement by CNLA and any agency of U.S. government. The test equipment used to perform the test is calibrated and traceable to NML/ROC or NIST/USA. 1190 ILAC MRA FCC ID: SOYHSB2AP Issued on June 07, 2005 Report No.: FR551701 SPORTON International Inc. Page No. : i TEL : 886-2-2696-2468 Issued Date : June 07, 2005 FAX : 886-2-2696-2255: Table of Contents HISTORY OF THIS TEST REPORT .....................................................................................................................II CERTIFICATE OF COMPLIANCE.......................................................................................................................III 1. GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST...........................................................................1 1.1. Applicant ......................................................................................................................................................................................... 1 1.2. Manufacturer ................................................................................................................................................................................... 1 1.3. Basic Description of Equipment under Test.................................................................................................................................... 1 1.4. Features of Equipment under Test ................................................................................................................................................. 1 1.5. Antenna Description........................................................................................................................................................................ 1 1.6. Table for Carrier Frequencies ......................................................................................................................................................... 2 2. TEST CONFIGURATION OF THE EQUIPMENT UNDER TEST .....................................................................3 2.1. Connection Diagram of Test System .............................................................................................................................................. 3 2.2. The Test Mode Description............................................................................................................................................................. 3 2.3. Description of Test Supporting Units .............................................................................................................................................. 4 3. GENERAL INFORMATION OF TEST ..............................................................................................................5 3.1. Test Facility ..................................................................................................................................................................................... 5 3.2. Standards for Methods of Measurement......................................................................................................................................... 5 3.3. DoC Statement ............................................................................................................................................................................... 5 3.4. Frequency Range Investigated ....................................................................................................................................................... 5 3.5. Test Distance .................................................................................................................................................................................. 5 3.6. Test Software .................................................................................................................................................................................. 5 4. LIST OF MEASUREMENTS .............................................................................................................................7 4.1. Summary of the Test Results.......................................................................................................................................................... 7 5. TEST RESULT ..................................................................................................................................................8 5.1. Test of 6dB Spectrum Bandwidth ................................................................................................................................................... 8 5.2. Test of Maximum Peak Conducted Output Power........................................................................................................................ 13 5.3. Test of Peak Power Spectral Density ........................................................................................................................................... 15 5.4. Test of Band Edges Emission....................................................................................................................................................... 20 5.5. Test of AC Power Line C…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: SOYHSB2AP Issued on June 07, 2005 Report No.: FR551701 SPORTON International Inc. Page No. : 31 of 49 TEL : 886-2-2696-2468 Issued Date : June 07, 2005 FAX : 886-2-2696-2255 5.5.8. Photographs of Conducted Emission Test Configuration Mode 1 FRONT VIEW REAR VIEW FCC ID: SOYHSB2AP Issued on June 07, 2005 Report No.: FR551701 SPORTON International Inc. Page No. : 32 of 49 TEL : 886-2-2696-2468 Issued Date : June 07, 2005 FAX : 886-2-2696-2255 Mode 2 FRONT VIEW REAR VIEW FCC ID: SOYHSB2AP Issued on June 07, 2005 Report No.: FR551701 SPORTON International Inc. Page No. : 42 of 49 TEL : 886-2-2696-2468 Issued Date : June 07, 2005 FAX : 886-2-2696-2255 5.6.11. Photographs of Radiated Emission Test Configuration FRONT VIEW REAR VIEW

Contact Information

Applicant

Amy Tang(Product Manager)
[email protected]949-206-6900Fax: 949-206-9074

Technical Contact

Sporton International Inc.Wayne Hsu
[email protected]886-3-327-3456

No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, · TaoYuan Hsien · Taiwan

Test Firm

Sporton International Inc.Kathy Lin
[email protected]886-2-2696-2468Fax: 886-2-2696-2255

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz115.88 mW
Confidentiality
Long Term
Grant Notes
Power output listed is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
