SSNCM200Wireless Laser Mouse

4-way Navigation Wireless Laser Mouse User's Quick Guide Latest Laser Technology for Excellent Detection and Movement! 4-way Navigation Wireless Laser Mouse 4-way Navigation Wireless Laser Mouse - 1 - © 2006 All Rights Reserved. The copyright is the property of its respective owners. Federal Communications Commission (FCC) requirements, Part 15 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes of modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. This product complies with 21 CFR, Chapter 1, Sub-chapter J at the date of manufactured. This Class B digital apparatus meets all requirements of the Canadian interference-causing equipment regulations. Caution: Avoid direct or indirect (such as reflection) eye exposure to laser light! Keep out of the reach of children! CE Declaration Of Conformity Hereby, the manufacturer, declares that this 2.4GHz Wireless Laser Mouse is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Essential requirements - Article 3 Protection requirements for health and safety - Article 3.1a --Testing for electric safety according to EN 60950 has been conducted. These are considered relevant and sufficient. Protection requirements for electromagnetic compatibility -Article 3.1b --Testing for electromagnetic compatibility according to EN 301 489-1, EN 301 489-17 and EN 55024 has been conducted. These are considered relevant and sufficient. Effective use of the radio spectrum -Article 3.2 --Testing for radio test suites according to EN 300 328-2 has been conducted. These are considered relevant and sufficient. Congratulations on your purchase of this Advanced 2.4GHz 4- way Navigation Wireless Laser Mouse. Please carefully read the User's Quick Guide to learn about the installation and the powerful functions of your new Wireless Laser Mouse. 4-way Navigation Wireless Laser Mouse - 2 - Package Content ü 4-way Navigation Laser Mouse ü 2.4GHz Dongle ü Battery: Alkaline AA * 2 ü User's Quick Guide CAUTION: - The batteries may explode or leak if they are improperly recharged, inserted, disposed in fire or mixed with used or different battery types. - Risk of explosion will be caused if battery is replaced by an incorrect type. - Dispose of used batteries according to the instructions. - It's important that batteries should be recycled in a proper way for green environment. Install Hardware Note: - If you are running Windows 98 and plug the connector into the computer, you may find a pop-up window that requires to insert the Windows 98 CD-ROM. Please follow the window instruction to install the required driver or set the driver path as "Windows\system" or the other path that the driver located. n Install Receiver 1) Turn on the computer. 2) Connect the USB dongle to the computer. n Link Mouse with Receiver Note: - Please link the devices within the effective distance. - The linkage period is 15 seconds. Once press the dongle's Link Button, please complete the mouse linkage process within the linkage period. - There is a power switch located at the back of mice for some models. Please select "On" before linking the mouse with the dongle. 1) Place batteries into the mouse. 2) Press the ID Link Button on the receiver. There are 15 seconds for the mouse linkage. 3) Press the ID Link Button of the mouse. 4) The mouse is linked with the receiver. 5) The product designs with the unique Smart Link function. Once the linkage process is complete, you don't have to re-link the mouse even if you change batteries or restart the computer. 6) If the mouse does not link with the cradle, please repeat Step 2~3. 7) The 2.4GHz product features with 4 channels and there are 256 changeable IDs for each channel. If the selected channel or ID is interfered by other wireless- mouse users nearby, please change the Link ID by re-linkage the device immediately. The channel and the ID will automatically change. USB Port USB Version 4-way Navigation Wireless Laser Mouse - 3 - Install Software (Option) Note: - The driver supports Windows 98/ 2000/ ME/ XP. - When you change the interface port, please reinstall the driver. n Install Driver 1) Insert the driver CD-ROM to your computer. The PC system may automatically install the driver through selecting the PC auto-install function. 2) If the PC system does not set the auto-install function, please double click the file "Setup.exe" and follow …

Text truncated - open the document above for the full version.

LG Electronics 50 Hyuangjeong-dong, Heungdeok-gu, Cheongj-si,ChungCheongbuk-do, 361-480 Korea .April 26, 2007 Federal Communications Commission Authorization and Evaluation Division FCC ID: SSNCM200 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, --------------------------------- LG Electronics

Chris Harvey From: gina.lo [[email protected]] on behalf of application [[email protected]] Sent: Friday, May 18, 2007 3:15 AM To: [email protected] Subject: Re:LG Electronics Inc., FCC ID: SSNCM200, Assessment NO.: AN07T6785, Notice#1 Attachments: CM-200 Label Sample and Location Revised 0508.pdf; CM-200 Antenna spec. Revised 0508.pdf; CM-200 Block Diagram Revised 0517.pdf; CM-200 Schematics Revised 0517.pdf; CM-200 User Manual Revised 0517.pdf; CM-200 Test Report Revised 0508.pdf Page 1 of 2 5/18/2007 Dear Chris, Please see my reply, thank you. Best Regards, Gina Dear Seven Chen, I have reviewed the above referenced TCB application. The following items need to be addressed before the review can be completed: 1. The Antenna Specification indicates that: "It's up to the customer to use Monopole Antenna or our latest Wiggle Antenna. The type of antenna is customer's choice." The test report only indicates that this device uses a 0dBi monopole antenna. Please correct this discrepancy. Ans: The antenna spec had been revised. 2. The RF module and antenna or antenna location is not included in the schematic diagram. Please provide the complete RF schematic diagram. Ans:Please see the revised RF schematic diagram. <[email protected]> 2007/05/07 11:47 PM 收件人： <[email protected]> 副本抄送： <[email protected]> 主旨： LG Electronics Inc., FCC ID: SSNCM200, Assessment NO.: AN07T6785, Notice#1 3. The Users Manual informs the user to not use the mouse during charging. The test was performed with alkaline batteries and thus AC Line Conducted Emissions were not performed. Does this device utilize a charger? Please update the exhibits in the application to be consistent. Ans:Please see the revised Users Manual. 4. It appears as though the FCC label is on a removable battery door, which is not allowed by FCC Rules. Is the label on the removable battery door? Please provide a photo with the battery door open. Ans: Please see the revised label location. 5. Most of the test report states that this device is compliant with FCC 15.249, but page 4 of the report states 15.247. If this is a typo, please correct the report. Ans: Sorry, it's typo, please see the revised test report. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey [email protected] Page 2 of 2 5/18/2007

Compliance Certification Services Inc. Report No.: 70312004 Date of Issue: April 25, 2007 Page 1 Total Page: 4 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT

R&D3 Document No.: Version: A0 MODEL: Press Color: silver (background), Black (type) Final Size (mm/inside):請依圖示要求以打樣實貼為准 Date: 資料委任人: Special Instructions: 25-000015356~15357~15358 C409 16/Apr. / 2007 jade 曄盛電子(東莞)有限公司研發三部 DesignerSales Dept. Material Dept.Manuf. Dept. QA Dept. PM Manager The artwork was confirmed by : SCALE: 100% 25-000015356 25-000015358 25-000015357

Compliance Certification Services Inc. Report No.: 70312004 Date of Issue: April 25, 2007 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 70312004 Date of Issue: April 25, 2007 Page 3 Rev.00 Compliance Certification Services Inc. Report No.: 70312004 Date of Issue: April 25, 2007 Page 4 Rev.00

Antenna Spec

Compliance Certification Services Inc. Report No.: 70312004-RP1 FCC ID: SSNCM200 Date of Issue: April 25, 2007 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 24 Rev. 00 FCC 47 CFR PART 15 Subpart C TEST REPORT For Wireless Laser Mouse Model: CM-200 Tr a d e Na me : L G Issued to LG Electronics 50 Hyuangjeong-dong, Heungdeok-gu, Cheongj-si, ChungCheongbuk-do, 361-480 Korea Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 70312004-RP1 FCC ID: SSNCM200 Date of Issue: April 25, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION................................................................................................................ 3 2. EUT DESCRIPTION...................................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................................... 5 3.1 EUT CONFIGURATION................................................................................................................. 5 3.2 EUT EXERCISE............................................................................................................................. 5 3.3 GENERAL TEST PROCEDURES...................................................................................................... 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS................................................. 6 3.5 DESCRIPTION OF TEST MODES.................................................................................................... 6 4. INSTRUMENT CALIBRATION................................................................................................................... 7 4.1 MEASUREMENT EQUIPMENT USED.................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ...................................................................................................... 8 5.1 FACILITIES................................................................................................................................. 8 5.2 EQUIPMENT................................................................................................................................. 8 5.3 TABLE OF ACCREDITATIONS AND LISTINGS................................................................................ 9 6. SETUP OF EQUIPMENT UNDER TEST ...................................................................................................10 6.1 SETUP CONFIGURATION OF EUT................................................................................................ 10 6.2 SUPPORT EQUIPMENT ........................................................................................................ 10 7. FCC PART 15.249 REQUIREMENTS ........................................................................................................ 11 7.1 BAND EDGES MEASUREMENT ......................................................................................... 11 7.2 SPURIOUS EMISSION .......................................................................................................... 16 7.3 POWERLINE CONDUCTED EMISSIONS........................................................................... 23 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................................24 Compliance Certification Services Inc. Report No.: 70312004-RP1 FCC ID: SSNCM200 Date of Issue: April 25, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product Wireless Laser Mouse Trade Name LG Model Number CM-200 Model Discrepancy N/A Power Supply Batteries: AA*2 (DC 3V) Frequency Range 2406, 2410, 2454, 2458MHz Modulation Technique GFSK Antenna Gain 0 dBi Antenna Designation Monopole Antenna Remark: 1. The sample selected for test was production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: SSNCM200 filing to comply with Section 15.107 & 15.109, 15.207, 15.209, 15.249. Compliance Certification Services Inc. Report No.: 70312004-RP1 FCC ID: SSNCM200 Date of Issue: April 25, 2007 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.249. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the TX frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.107 and 15.109 under the FCC Rules Part 15 Subpart B and Section 15.207, 15.209,15.249 under the FCC Rules Part 15 Subpart C. 3.3 GENERAL TEST PROCEDURES Conducted Emissions The EUT is placed on the turntable, which is 0.8 m above ground plane. According to the requirements in Section 13.1.4.1 of ANSI C63.4 Conducted emissions from the EUT measured in the frequency range between 0.15 MHz and 30MHz using CISPR Quasi-peak and average detector modes. Radiated Emissions The EUT is placed on a turn table, which is 0.8 m above ground plane. The turntable shall rotate 360 degrees to determine the position of maximum emission level. EUT is set 3m away from the receiving antenn…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 70312004-RP1 FCC ID: SSNCM200 Date of Issue: April 25, 2007 Page 24 Rev. 00 APPENDIX I PHOTOGRAPHS OF TEST SETUP RADIATED EMISSION SET UP PHOTOS
