SSNUBIVUSB Driver

FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 1/1 ATTACHMENT E. - USER’S MANUAL - 1 2 Before Using USB Drive.......................................................................... 03 What is USB Drive? ................................................................................. 05 Installing/Using USB Drive in Microsoft Windows ME/2000/XP.......... 06 Installing/Using USB Drive in Microsoft Windows 98/98SE ................ 07 Installing/Using USB Drive in MacOS ( MacOS 9.0 or higher ) ........... 10 Using the SecureCell ™ Utility ............................................................... 11 USB Drive™ FAQs ................................................................................... 19 Specifications .......................................................................................... 22 Contents 3 Welcome to USB Drive. This user guide is designed to help you to use USB Drive correctly and safely. Please read this information carefully before using USB Drive. Please pay special attention to the sections that describe USB Drive operation for the Operating System being used by your computer. Safety Instructions These Safety Instructions include directions and precautions for you to follow when using USB Drive. The instructions aim to secure your safety and to prevent any damage to your computer, your USB Drive and your data. Warning instructions indicate that failure to follow the directions could result in possible personal injuries. Caution instructions indicate that failure to follow the directions could result in damage to the USB Drive or data. Warning - To reduce the possibility of electrical shock, do not use the USB Drive if wet with any liquids such as water or chemicals. - To reduce the possibility of an electrical short circuit, do not plug the USB Drive into your computer’s USB port if it is wet. Plugging a wet USB Drive in causes a danger of damaging the USB Drive and/or your computer. - If any smoke or strange smells or noise occurs when using USB Drive, be sure to turn off your computer and peripheral devices immediately and disconnect the power cords. Before Using USB Drive TM 4 Caution - Do not disconnect the USB Drive from the computer’s USB port while transferring (reading or writing) data. This will probably result in your data being corrupted - Make sure that you follow the instructions given in this guide when using or removing the product. Incorrect use of USB Drive may cause a malfunction of the product and/or loss of your data. - Be careful not to bend or twist the USB Drive. Do not place any heavy object on the product. - Please do not attempt to disassemble or modify the product. It can cause malfunction of the product. There are no user serviceable parts in the USB Drive. - Do not use your USB Drive in any place exposed to the following conditions, as it may cause a malfunction of the product : excessive vibration or shock; wetness, moisture or dust; heat and/or high temperature variation; strong electrical discharge; strong magnetic interference. - Be careful that any foreign material does not enter the insertion holes of USB Drive. LG Electronics Inc. assumes no responsibility for any corruption or loss of data and accompanying results due to incorrect use of the product. 5 USB Drive™ is a removable, portable, flash memory based data storage device that works via your computer’s Universal Serial Bus (USB) interface. USB Drive does not require a battery or any external power because the USB Drive uses the power supplied by the computer or USB device it is plugged into. USB Drive works with your computer’s plug-and-play system, For most operating systems, once it is plugged into the USB port of your computer. It is ideal for mobile professionals, or for anyone with a need to move data frequently and conveniently between devices or networks, since it is very small and lightweight. Through SecureCell™ Utility, you can make USB Drive to be security-enabled, bootable disk-enabled. The Security feature is currently compatible with Microsoft Windows XP, 2000, ME, 98 and 98SE. Formatting USB Drive USB Drive has already been formatted and initialized with the FAT file system before delivery and is ready for immediate use. Operating System Requirements What is USB Drive TM ? DriverInstallation O perating Systems 1.Microsoft Windows 98/98SE None re quired 1. Microsoft Windows ME/2000/XP 2. Mac OS 9.0 or higher 3. Linux 2.4.0 or higher 4. Microsoft Windows CE 3.0 or higher. Re quired When using Microsoft Windows ME/2000/XP, MAC 9.0 or higher, Linux 2.4.0 or higher, USB Drive can be installed and removed without powering down your computer. When using Microsoft Windows 98/98SE, you must install additional drivers before you can use the USB Drive. The additional Windows 98/98SE drivers can be downloaded from the www.lge.com homepage or loaded from your included CD-ROM. For Linux, it is re quired to mount SCSI. 6 1. Start Windows ME, Windows 2000 or Windows XP. 2. Remove the cover from your USB Drive and plug it into a USB port on your computer. If it is the first time to use USB Drive, Windows will automatically recognize it and install all required drivers. 3. The red Status LED will flash during the recognition and installation procedures. When USB Drive is ready to use, the Status LED will turn off. 4. Click My Computer on Windows Desktop. USB Drive is displayed as a removable disk, as is shown in the following figure. (The drive name may be different depending on the system you are using). 5. You can now read or write data using the installed USB Drive, the same as with any other hard drive. Removing USB Drive in Microsoft Windows ME/2000/XP 1. Close all files currently opened from USB Drive. 2. Click Safely Remove Hardware Icon on the Task Bar or the System Tray as shown…

Text truncated - open the document above for the full version.

FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 1/2 ATTACHMENT C. - BLOCK DIAGRAM - FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 2/2

LG ELECTRONICS INC. Date:2005.07.29 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.>, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.> on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.> as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, O byoung Kang Senior Engineer LG ELECTRONICS INC. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

1 Helen Zhao Subject: FW: LG Electronics Inc., FCC ID: SSNUBIV, Assessment NO.: AN06T5976, Notice#1 ATT.E_MANUAL.pdf0602-_UBIV_TestR eport.pdf ATT.A_label.pdfATT.C_BLOCK.pdf -----Original Message----- From: CHA Sent: Friday, July 21, 2006 12:17 AM To: Helen Zhao Subject: Re: LG Electronics Inc., FCC ID: SSNUBIV, Assessment NO.: AN06T5976, Notice#1 Dear Helen, Thank you for your help. Question #1: The FCC ID label format does not even show FCC ID. Please revise the ID label. By the way, because the device is a USB drive, you may not able to include 15.19 statement into the label. In that case, you may need to add 15.19 labelling requirement in the manual. -> Please kindly check ATT.A_label.pdf. Question #2: The user manual does not contain FCC regulatory statement. Please add FCC15.19 labelling statement, 15.21 user information and 15.105(b) user information into the manual -> Please kindly check last page of ATT.E_MANUAL.pdf. Question #3: The Block diagram does not show crystal/local oscillator frequencies. Please modify the block diagram to provide additional information. -> Please kindly check ATT.C_BLOCK.pdf. Question #4: The test report (page 1) shows the test was performed in accordance with ANSI C63.4-2006, please note the most current version is ANSI C63.4-2003. 2006 version has not been released yet. Please update the test report. -> Please kindly check first page of 0602-UBIV_TestReport.pdf. If you have any problem, Please contact me any time. Thank you & Best Regards CHA

FCC ID : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 1/5 ATTACHMENT B. - EXTERNAL PHOTOS - FCC ID : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 2/5 FCC ID : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 3/5 FCC ID : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 4/5 FCC ID : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 5/5

FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 1/2 ATTACHMENT A. - ID LABEL INFORMATION AND LOCATION PHOTOS - FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 2/2 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 3.1 PRODUCT LABEL FCC ID : SSNUBIV 1.2 Label Location Photos The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Lable Location Lable Location Lable Location

FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 1/3 ATTACHMENT F. - INTERNAL PHOTOS - FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 2/3 FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 3/3

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. Product Compliance Division, EMC Team SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNKI-DO, 467-701, KOREA TEST REPORT Rule Part(s): Equipment Class: Standard(s): EUT Type: This equipment has been shown to be in compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-2 003 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report prepared by : Gyeong Seon KIM Test engineer of EMC Tech.Part Approved by : Sang Jun LEE Manager of EMC Tech.Part HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. 1/ 19 SSNUBIV UBIV FCC ID : MODEL : Rule Part(s): Equipment Class: Standard(s): EUT Type: Model(s): Port/Connector(s) License Holder; LG Electronics Inc. 50 Hyangjeong-dong, Heungdeok-gu, Cheongju-si, Chungcheongbuk-do, 361-480, KOREA. LG Electronics Inc FRN : 0012281820 Date of Issue : June 27, 2006 Test Report No.: HCT-F06-0602 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. HCT FRN : 0005-8664-21 Part 15 FCC Class B Peripheral Device (JBP) FCC Class B: (CISPR 22) USB Drive UBIV USB FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 2/17 TABLE OF CONTENTS PAGE REPORT COVER 1 TABLE OF CONTENTS 2 1.1 SCOPE 3 2.1 INTRODUCTION (SITE DESCRIPTION) 4 3.1 PRODUCTION INFORMATION 5 4.1 DESCRIPTION OF TESTS (CONDUCTED) 6 4.3 DESCRIPTION OF TESTS (RADIATED) 7 5.1 LIST OF SUPPORT EQUIPMENT 8-9 6.1 TEST DATA (CONDUCTED) 10-12 7.1 TEST DATA (RADIATED) 13 8.1 SAMPLE CALCULATIONS 14 9.1 TEST EQUIPMENT 15 10.1 TEST SOFTWARE USED 16 11.1 CONCLUSION 17 ATTACHMENT A : ID LABEL & LOCATION ATTACHMENT B : EXTERNAL PHOTOGRAPHS ATTACHMENT C : BLOCK DIAGRAM ATTACHMENT D : TEST SETUP PHOTOGRAPHS ATTACHMENT E : USE’R MANUAL ATTACHMENT F : INTERNAL PHOTOGRAPHS FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 3/17 MEASUREMENT REPORT 1.Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. • FCC ID : SSNUBIV • Equipment Class: FCC Class B Peripheral Device (JBP) • EUT Type: UBIV • Interface: USB Spec 2.0/1.1 • Power : USB bus-powered(4.5V~5.5V) • Dates of Tests: May 24, 2006 • Place of Tests: 254-1,MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO,467-701,KOREA Applicant Name: Address: LG Electronics CO., LTD. 50, Hyangjeong-Dong, Heungdeok-Gu, Cheongju-Si, ChungcheongBuk-Do, 361-480,KOREA FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 4/17 2.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSIC63.4-2003) was used in determining radiated and conducted emissions emanating from LG Electronics CO., LTD. USB Drive FCC ID : SSNUBIV The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1, MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO, 467-701,KOREA. The site is constructed in conformance with the requirements of ANSI C63.4and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated July 23,2003 (Confirmation Number: EA90661) FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 5/17 3.1 PRODUCT INFORMATION 3.2 Equipment Description Equipment Under Test (EUT) is the LG Electronics CO., LTD. ( Model : UBIV ) USB Drive FCC ID : SSNUBIV Storage capacity : 512MB/1GB/2GB Maximum data rate : 480Mbps/ Operating Temperature Storage Humidity : 0 C ~ 45C / 5% ~ 95% Dimensions (Including cabinet) : 61mm x 17.5mm x 9mm Weight (Including cabinet) : 9g Description Capacity Model Differences Basic Model UBIV (2GB) Worst Case Multiple Model UBIV (512MB) UBIV (1GB) Only type designation by a memory size of the EUT. EMI Suppression Devices: None FCC ID : SSNUBIV HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F06-0602 6/17 4.1 Description of Tests(Conducted) 4.2 Powerline Conducted RFI (150kHz- 30MHz) The power line conducted RFI measurements were performed according to CISPR 22. The EUT was placed on a non-conducting 1.0 by 1.5 meter table which is 0.8 meters in height and 0.40 meters away from the vertical wall of the shielded enclosure. Power to the EUT is provided through a Rohde & Schwarz 50 Ω / 50 uH Line Impedance Stabilization Network (LISN) and the support equipment through a separate Solar 50 Ω / 50 uH Line- Conducted Test Facility LISN. Sufficient time for the EUT, support equipment, and test equipment were allowed in order for them to warm up to their normal operating condition. The RF output of the LISN was connected to the spectrum analyzer to determine the frequency producing the maximum EME. The spectru…

Text truncated - open the document above for the full version.

FCC ID : : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 1/4 ATTACHMENT D. - TEST SETUP PHOTOS- FCC ID : : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 2/4 1.CONDUCTED AND RADIATED MEASUREMENT PHOTOS [CONDUCTED MEASUREMENT PHOTO] FCC ID : : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 3/4 [RADIATED MEASUREMENT PHOTO] FCC ID : : SSNUBIV REPORT NO. : HCT-F06-0602 HCT 4/4
