SSNUBJGUSB Drive

Model : UBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 1/1 ATTACHMENT E. - USER’S MANUAL - 1 2 Before Using USB Drive.......................................................................... 03 What is USB Drive? ................................................................................. 05 Installing/Using USB Drive in Microsoft Windows ME/2000/XP.......... 06 Installing/Using USB Drive in Microsoft Windows 98/98SE ................ 07 Installing/Using USB Drive in MacOS ( MacOS 9.0 or higher ) ........... 10 Using the SecureCell ™ Utility ............................................................... 11 USB Drive™ FAQs ................................................................................... 19 Specifications .......................................................................................... 22 Contents 3 Welcome to USB Drive. This user guide is designed to help you to use USB Drive correctly and safely. Please read this information carefully before using USB Drive. Please pay special attention to the sections that describe USB Drive operation for the Operating System being used by your computer. Safety Instructions These Safety Instructions include directions and precautions for you to follow when using USB Drive. The instructions aim to secure your safety and to prevent any damage to your computer, your USB Drive and your data. Warning instructions indicate that failure to follow the directions could result in possible personal injuries. Caution instructions indicate that failure to follow the directions could result in damage to the USB Drive or data. Warning - To reduce the possibility of electrical shock, do not use the USB Drive if wet with any liquids such as water or chemicals. - To reduce the possibility of an electrical short circuit, do not plug the USB Drive into your computer’s USB port if it is wet. Plugging a wet USB Drive in causes a danger of damaging the USB Drive and/or your computer. - If any smoke or strange smells or noise occurs when using USB Drive, be sure to turn off your computer and peripheral devices immediately and disconnect the power cords. Before Using USB Drive TM 4 Caution - Do not disconnect the USB Drive from the computer’s USB port while transferring (reading or writing) data. This will probably result in your data being corrupted - Make sure that you follow the instructions given in this guide when using or removing the product. Incorrect use of USB Drive may cause a malfunction of the product and/or loss of your data. - Be careful not to bend or twist the USB Drive. Do not place any heavy object on the product. - Please do not attempt to disassemble or modify the product. It can cause malfunction of the product. There are no user serviceable parts in the USB Drive. - Do not use your USB Drive in any place exposed to the following conditions, as it may cause a malfunction of the product : excessive vibration or shock; wetness, moisture or dust; heat and/or high temperature variation; strong electrical discharge; strong magnetic interference. - Be careful that any foreign material does not enter the insertion holes of USB Drive. LG Electronics Inc. assumes no responsibility for any corruption or loss of data and accompanying results due to incorrect use of the product. 5 USB Drive™ is a removable, portable, flash memory based data storage device that works via your computer’s Universal Serial Bus (USB) interface. USB Drive does not require a battery or any external power because the USB Drive uses the power supplied by the computer or USB device it is plugged into. USB Drive works with your computer’s plug-and-play system, For most operating systems, once it is plugged into the USB port of your computer. It is ideal for mobile professionals, or for anyone with a need to move data frequently and conveniently between devices or networks, since it is very small and lightweight. Through SecureCell™ Utility, you can make USB Drive to be security-enabled, bootable disk-enabled. The Security feature is currently compatible with Microsoft Windows XP, 2000, ME, 98 and 98SE. Formatting USB Drive USB Drive has already been formatted and initialized with the FAT file system before delivery and is ready for immediate use. Operating System Requirements What is USB Drive TM ? DriverInstallation O perating Systems 1.Microsoft Windows 98/98SE None re quired 1. Microsoft Windows ME/2000/XP 2. Mac OS 9.0 or higher 3. Linux 2.4.0 or higher 4. Microsoft Windows CE 3.0 or higher. Re quired When using Microsoft Windows ME/2000/XP, MAC 9.0 or higher, Linux 2.4.0 or higher, USB Drive can be installed and removed without powering down your computer. When using Microsoft Windows 98/98SE, you must install additional drivers before you can use the USB Drive. The additional Windows 98/98SE drivers can be downloaded from the www.lge.com homepage or loaded from your included CD-ROM. For Linux, it is re quired to mount SCSI. 6 1. Start Windows ME, Windows 2000 or Windows XP. 2. Remove the cover from your USB Drive and plug it into a USB port on your computer. If it is the first time to use USB Drive, Windows will automatically recognize it and install all required drivers. 3. The red Status LED will flash during the recognition and installation procedures. When USB Drive is ready to use, the Status LED will turn off. 4. Click My Computer on Windows Desktop. USB Drive is displayed as a removable disk, as is shown in the following figure. (The drive name may be different depending on the system you are using). 5. You can now read or write data using the installed USB Drive, the same as with any other hard drive. Removing USB Drive in Microsoft Windows ME/2000/XP 1. Close all files currently opened from USB Drive. 2. Click Safely Remove Hardware Icon on the Task Bar or the System Tray as shown in …

Text truncated - open the document above for the full version.

Model : UBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 1/1 ATTACHMENT C. - BLOCK DIAGRAM - Great Company Great People 3 Fast Growth, Great RMC Flash Interface USB Transceiver Flash Memory Power Management PLL Regulator OSC 5V DC 3.3V DC 3.3V DC USB Drive

LG ELECTRONICS INC. Date:2005.07.29 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.>, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.> on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing < HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD.> as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, O byoung Kang Senior Engineer LG ELECTRONICS INC. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

Mike Kuo From: 차계영 [[email protected]] Sent: Monday, February 20, 2006 4:52 PM To: Mike Kuo Cc: 김근형(HCT) Subject: Fw: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1 Attachments: TestReport.pdf; LETTER.pdf; ATT.E_manual_.pdf  2/21/2006 Dear Sir. I always thank you for your help. Question #1: In the test report, the test procedure is referred per ANSI C63.4:2001. ANSI C63.4:2001 is no longer the current standards used by FCC. The current measurement standard should be ANSI C63.4:2003 per CFR 47 part 15.31(a)(3). Please make necessary correction. -> Please kindly check TestReport.pdf Question #2: User manual does not contain information required per section 15.21 and 15.105(b). Please provide revised user manual to comply this requirement. -> Please kindly check ATT.E_manual_.pdf Question #3: Please provide agency authorization letter. Please use the attached agency authorization letter format for all future TCB application. -> Please kindly check LETTER.pdf Please contact me if it has a problem. Thank you & Best regards, CHA GYE-YOUNG CHA --- EMC Part Hyundai Calibration & Certification Technologies Co., Ltd. San 136-1, Ami-ri, Bubal-eup, Icheon-si, Kyoungki-do, Korea 467-701 TEL : (82-31)639-8517,8 FAX : (82-31)639-8525 ----- Original Message ----- From: Sun-Hee Kim(HCT) To: 차계영 Sent: Monday, February 20, 2006 8:42 AM Subject: Fw: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1 ----- Original Message ----- From: Mike Kuo To: Sun -Hee Kim(HCT) Sent: Saturday, February 18, 2006 8:25 AM Subject: RE: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1 Hi Sun-Hee : Please ask your EMC department to update the status. Best Regards Mike Kuo Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 Tel: (408)463-0885 x: 105 Fax: (408)463-0888 e-mail:[email protected] http://www.ccsemc.com From: Sun-Hee Kim(HCT) [mailto:[email protected]] Sent: Monday, February 06, 2006 6:06 PM To: Mike Kuo Subject: Re: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1 Hello Mike, Thank you for your coperation. I forwarded this email to the EMC Part in HCT. They'll send you reply soon. Thank you. Best Regards, Sun- Hee KIM ----- Original Message ----- From: Mike Kuo To: Sun -Hee Kim(HCT) Sent: Tuesday, February 07, 2006 10:21 AM Subject: RE: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1 Hi Sun-Hee : Attached is the cover letter submitted in AN06T5467. Please check again. Best Regards Mike Kuo Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 Tel: (408)463-0885 x: 105 Fax: (408)463-0888 e-mail:[email protected] http://www.ccsemc.com  2/21/2006 From: Sun-Hee Kim(HCT) [mailto:[email protected]] Sent: Monday, February 06, 2006 5:14 PM To: Mike Kuo Cc: 신국선\(HCT\); 김기수\(HCT\); 박근호\(HCT\); 임지영\(HCT\); 김영관\(HCT\); 정문진\(HCT\); 김기수CJ Subject: Re: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1 Dear Sir, It seems you've sent an email to the wrong address. It's not our project. Please check again. And please inform us the follwing project as soon as possible. FCC ID: SDJKTFT-UV100 Assessment Number : AN06T5432 Applicant name : KTF Technologies Co., Ltd. Thank you. Best Regards, Sun- Hee KIM ----- Original Message ----- From: "Mike Kuo" <[email protected] > To: "Sun-Hee Kim(HCT)" <[email protected]> Cc: "??? ₩(HCT₩)" <[email protected]> Sent: Tuesday, February 07, 2006 4:14 AM Subject: FW: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1 Hi Sun-Hee : I have not yet received the replies to my questions Best Regards Mike Kuo Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 Tel: (408)463-0885 x: 105 Fax: (408)463-0888 e-mail:[email protected] http://www.ccsemc.com -----Original Message----- From: Mike Kuo Sent: Monday, January 30, 2006 2:51 PM To: ??? ₩(HCT₩) Subject: FW: LG Electronics Inc., FCC ID: SSNUBJG, Assessment NO.: AN06T5467, Notice#1  2/21/2006 Question #1: In the test report, the test procedure is referred per ANSI C63.4:2001. ANSI C63.4:2001 is no longer the current standards used by FCC. The current measurement standard should be ANSI C63.4:2003 per CFR 47 part 15.31(a)(3). Please make necessary correction. Question #2: User manual does not contain information required per section 15.21 and 15.105(b). Please provide revised user manual to comply this requirement. Question #3: Please provide agency authorization letter. Please use the attached agency authorization letter format for all future TCB application. Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. ================================================================= Ms. Sun-hee Kim Product Compliance Division Hyundai Calibration & Certification Co.,Ltd (HCT) San 136-1, Ami-ri , Bubal-eup, Icheon-si, Kyounki- do, Korea (467-701) Tel. : (82-31)639-8565/ 8518 Fax.: (82-31)639-8535 H.P.: 011-9558-9875 E-mail : [email protected] http :// www.hct.co.kr =================================================================  2/21/2006

FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 1/5 ATTACHMENT B. - EXTERNAL PHOTOS - FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 2/5 FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 3/5 FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 4/5 FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 5/5

FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 1/3 ATTACHMENT A. - ID LABEL INFORMATION AND LOCATION PHOTOS - FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 2/3 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Figure 3.1 PRODUCT LABEL Both the FCC ID and compliance statement are included in the product label Model NO : UBIU FCC ID : SSNUBJG Serial No : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. 50 Hyangjeong-dong, Heungdeok-gu, Cheongju-si, Chungcheongbuk-do, 361-480, Korea MANUFACTURED BY LG Electronics Inc. MADE IN KOREA FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 3/3 1.2 Label Location Photos The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) LABEL Location

FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 1/4 ATTACHMENT F. - INTERNAL PHOTOS - FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 2/4 FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 3/4 FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 4/4

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. Product Compliance Division, EMC Team SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNKI-DO, 467-701, KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 TEST REPORT Rule Part(s): Equipment Class: Standard(s): EUT Type: Model(s): Port/Connector(s) Manufacture This equipment has been shown to be in compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-2003 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report prepared by : Kun Hyoung KIM Test engineer of EMC Part Approved by : Sang Jun LEE Manager of EMC Part ▷▷ HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. ◁◁◁ 1/ 19 SSNUBJG UBJG FCC ID : MODEL: Part 15 FCC Class B Peripheral Device (JBP) FCC Class B: (CISPR 22) USB Drive UBJG USB IPIA License Holder; LG Electronics Inc. 50 Hyangjeong-dong, Heungdeok-gu, Cheongju-si, Chungcheongbuk-do, 361-480, KOREA. LG Electronics Inc FRN : 0012281820 Date of Issue : December 22.2005 Test Report No.: HCT-F05-1205 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. HCT FRN : 0005-8664-21 FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 2/19 TABLE OF CONTENTS PAGE REPORT COVER 1 TABLE OF CONTENTS 2 1.1 SCOPE 3 2.1 INTRODUCTION (SITE DESCRIPTION) 4 3.1 PRODUCTION INFORMATION 5 4.1 DESCRIPTION OF TESTS (CONDUCTED) 6 4.3 DESCRIPTION OF TESTS (RADIATED) 7 5.1 LIST OF SUPPORT EQUIPMENT 8-9 6.1 TEST DATA (CONDUCTED) 10-14 7.1 TEST DATA (RADIATED) 15 8.1 SAMPLE CALCULATIONS 16 9.1 TEST EQUIPMENT 17 10.1 TEST SOFTWARE USED 18 11.1 CONCLUSION 19 ATTACHMENT A : FCC ID LABEL & LOCATION ATTACHMENT B : EXTERNAL PHOTOGRAPHS ATTACHMENT C : BLOCK DIAGRAM ATTACHMENT D : TEST SETUP PHOTOGRAPHS ATTACHMENT E : USER’S MANUAL ATTACHMENT F : INTERNAL PHOTOGRAPHS FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 3/19 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. • FCC ID : SSNUBJG • Equipment Class: FCC Class B Peripheral Device (JBP) • EUT Type: USB Drive • Model(s):UBJG • Rule Part(s): FCC Part 15 Subpart B • Test Procedure(s): ANSI C63.4 (2003) • Dates of Tests: December 05, 2005 ~ December 19, 2005 • Place of Tests: 254-1,MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO,467-701,KOREA Applicant Name: Address: LG Electronics Inc 50 Hyangjeong-dong, Heungdeok-gu, Cheongju-si, Chungcheongbuk-do, 361-480, KOREA. FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 4/19 2.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSIC63.4-2003) was used in determining radiated and conducted emissions emanating from LG Electronics Inc, FCC ID: SSNUBJG, USB Drive (Model(s): UBJG) The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1, MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO, 467-701,KOREA. The site is constructed in conformance with the requirements of ANSI C63.4and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated July 23,2003 (Confirmation Number: EA90661) FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 5/19 3.1 PRODUCT INFORMATION 3.2 Equipment Description Equipment Under Test (EUT) is the LG Electronics Inc. FCC ID: SSNUBJG, USB Drive (Model(s): UBJG) Storage capacity : 128MB/256MB/512MB/1G/2GB Interface : usb Spec 2.0 Maximum data rate : 480Mbps Power : USB bus-powered(4.5V ~ 5.5V) Dimensions (including cabinet) : 70x22x10mm (WxHxD) Weight (including cabinet) : 9g Description ※ Capacity Model Differences Basic Model UBJG (2GB) Worst Case Multiple Model UBJG (128MB) UBJG (256MB) UBJG (512MB) UBJG (1GB) Only type designation by a memory size of the EUT. EMI Suppression Devices: None FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 6/19 4.1 Description of Tests(Conducted) 4.2 Powerline Conducted RFI (150kHz- 30MHz) The power line conducted RFI measurements were performed according to CISPR 22. The EUT was placed on a non-conducting 1.0 by 1.5 meter table which is 0.8 meters in height and 0.40 meters away from the vertical wall of the shielded enclosure. Power to the EUT is provided through a Rohde & Schwarz 50 Ω / 50 uH Line Impedance Stabilization Network (LISN) and the support equipment through a separate Solar 50 Ω / 50 uH Line- Conducted Test Facility LISN. Sufficient time for the EUT, support equipment, and test equipment were allowed in order for them to warm up to their normal operating condition. The RF output of the LIS…

Text truncated - open the document above for the full version.

FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 1/4 ATTACHMENT D. - TEST SETUP PHOTOS- FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 2/4 1.CONDUCTED AND RADIATED MEASUREMENT PHOTOS [CONDUCTED MEASUREMENT PHOTO] FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 3/4 [RADIATED MEASUREMENT PHOTO] FCC ID : SSNUBJG HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCT-F05-1205 4/4
