Bellwave Co.,Ltd Page 1 of 94 FCC ID : SY6BPP-UP500 SAR Report Reference No.: NK2GR181 SAR Evaluation Report FCC ID : SY6BPP-UP500 Project Reference No. : NK2GR181 Product Type : Dual-Band GSM Mobile Phone Brand Name : Bellwave Model : BPP-UP500 Tested According to : IEEE Standard C95.1 / OET Bulletin 65 Supplement C Tested Period : September. 13. 2006 to September. 18. 2006 Tested by Seob Lee date : September. 19. 2006 Verified by Seonteag.Jin date : September. 19. 2006 This test results are only related to the item tested. This test report is only limited to the client company and the product. This report must not be used by the client to claim product endorsement by any agency of the U.S. Government. Lab Address : Nemko Korea Co., Ltd 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Gyunggi-Do, Korea Phone : 82-31-322-2333 Fax : 82-31-322-2332 Bellwave Co.,Ltd Page 2 of 94 FCC ID : SY6BPP-UP500 SAR Report Reference No.: NK2GR181 Contents of This Report 1. General Information 4 1.1 Applicant 4 1.2 Manufacturer 4 1.3 Description of Device 4 2. General Test Condition 5 2.1 Location 5 2.2 Operating Environment 5 2.3 Test Frequency 5 2.4 Support Equipment 5 3. Description of Test Equipment 6 4. SAR Measurement Procedure 10 5. Definition of Reference Points 12 5.1 Ear Reference Point 12 5.2 Handset Reference Points 13 6. Test Configuration Positions 14 6.2 Cheek/Touch Position 14 6.2 Ear/Tilt 15Position 15 6.3 Body-worn and Other Configurations 16 7. Measurement Uncertainty 17 8. System Verification 18 8.1 Tissue Verification 18 8.2 Test System Validation 19 8.3 Measurement Result of Test Data (GSM 850MHz Head Validation) 20 8.4 Measurement Result of Test Data (GSM 850MHz Muscle Validation) 21 8.5 Measurement Result of Test Data (PCS 1900MHz Head Validation) 22 8.6 Measurement Result of Test Data (PCS 1900MHz Muscle Validation) 23 9. SAR Measurement Results 24 9.1 SAR Measurement Result(GSM 850MHz Right Head Touch Position) 26 9.2 SAR Measurement Result (GSM 850MHz Right Head Tilt Position) 31 9.3 SAR Measurement Result (GSM 850MHz Left Head Touch Position) 33 9.4 SAR Measurement Result (GSM 850MHz Left Head Tilt Position) 37 9.5 SAR Measurement Result (GSM 850MHz Muscle–15mm Distance- Position) 39 Bellwave Co.,Ltd Page 3 of 94 FCC ID : SY6BPP-UP500 SAR Report Reference No.: NK2GR181 9.6 SAR Measurement Result (GSM 850MHz Muscle–15mm Distance with Headset) 44 9.7 SAR Measurement Result (PCS 1900MHz Right Head Touch Position) 46 9.8 SAR Measurement Result (PCS 1900MHz Right Head Tilt Position) 51 9.9 SAR Measurement Result (PCS 1900MHz Left Head Touch Position) 53 9.10 SAR Measurement Result (PCS 1900MHz Left Head Tilt Position) 57 9.11 SAR Measurement Result (PCS 1900MHz Muscle–15mm Distance-Position) 59 9.12 SAR Measurement Result (PCS 1900MHz Muscle–15mm Distance with Headset) 63 10. SAR Test Equipment 66 11. References 67 Appendix A SAR Definition / RF Exposure Limits 68 Appendix B Probe Calibration 70 Appendix C Dipole Calibrations 79 Appendix D Photographs of EUT 91 Bellwave Co.,Ltd Page 4 of 94 FCC ID : SY6BPP-UP500 SAR Report Reference No.: NK2GR181 1.General Information 1.1 Applicant Company Name: Bellwave Co., Ltd Company Address: 23 rd ~24 th Fl. Construction Finance Center Bldg.395-70 Shindaebang-dong, Dongjak-gu,Seoul,156-714,Korea Phone/Fax: Phone: +82-2-829-7415 / +82-2-829-7499 Contact Name: Ju-Won, Seol 1.2 Manufacturer Company Name: Bellwave Co., Ltd Company Address: 23 rd ~24 th Fl. Construction Finance Center Bldg.395-70 Shindaebang-dong, Dongjak-gu,Seoul,156-714,Korea Phone/Fax: Phone: +82-2-829-7415 / +82-2-829-7499 Contact Name: Ju-Won, Seol 1.3 Description of Device Category: Dual-Band GSM Mobile Phone Model Name: BPP-UP500 Brand Name: Bellwave Serial Number: 0000001 Frequency Band Tx : 824MHz ~ 849MHz, Rx : 869MHz ~ 894MHz Tx : 1850MHz ~ 1910MHz, Rx : 1930MHz ~ 1990MHz Power Output (Conducted) GSM850: 32.42dBm PCS1900: 28.83dBm Frequency Error < 0.1ppm Operating Condition -30to +60 Power Supply Li-ion Battery: 3.7V DC, 650mAh Antenna Type Internal Dimensions 132 X 40 X 20mm (80 X 40 X 20mm) Weight 63g(with battery) Remarks: - Bellwave Co.,Ltd Page 5 of 94 FCC ID : SY6BPP-UP500 SAR Report Reference No.: NK2GR181 2. General Test Condition 2.1 Location Nemko Korea 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Gyunggi-Do Phone : 82-31-322-2333 , Fax : 82-31-322-2332 2.2 Operating Environment Parameters Recording during test Accepted deviation Ambient temperature 21 ~ 23 15 ~ 30 Relative humidity 35 ~ 65% 20 ~ 75% 2.3 Test Frequency GSM850 PCS1900 Test Channel Test Frequency (MHz)Test Channel Test Frequency (MHz) 128 824.2 512 1850.2 190 836.6 661 1880.0 251 848.8 810 1909.8 2.4 Support Equipment Equipment Manufacturer Model Name Serial Number - - - - Bellwave Co.,Ltd Page 6 of 94 FCC ID : SY6BPP-UP500 SAR Report Reference No.: NK2GR181 3. Description of Test Equipment 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, H/P computer, nearfield probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the H/P computer with Windows XP system and SAR Measurement Software DASY4, LCD monitor, mouse and keyboard. The Stäubli Robot is connected to the cell controller to allow software manipulation of the robot. A Data Acquisition Electronic (DAE) circuit that performs the signal amplification, signal multiplexing, A…
