T58331GU2006M1Wireless USB Adapter

Wireless Network Adapter User manual Page 1 of 24 Wireless Network Adapter User’s Manual Federal Communications Commission (FCC) Requirements, Part 15 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. Regulatory information / Disclaimers Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE (CO-LOCATION) FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Wireless Network Adapter User manual Page 2 of 24 Table of Contents Chapter 1 Introduction ...................................................................... 3 1.1 Welcome .............................................................................................................................. 3 1.2 About This Guide .............................................................................................................. 3 1.3 Copyright statement........................................................................................................ 3 1.4 Contents of Package........................................................................................................ 4 1.5 Before you begin............................................................................................................... 4 Chapter 2 Designing Your Wireless Network ..................................... 4 2.1 Cardbus adapter............................................................................................................... 4 2.2 PCI adapter......................................................................................................................... 5 2.3 USB adapter....................................................................................................................... 5 Chapter 3 Install Wireless Adapter.................................................... 6 3.1 Install Driver and Utility................................................................................................. 6 3.2 Install Adapter ................................................................................................................... 8 3.3 Configuration your wireless adapter ....................................................................... 11 Chapter 4 Using the Wireless Client Configuration Utility ................ 12 4.1 Network Status ................................................................................................................ 13 4.2 Site Survey ....................................................................................................................... 14 4.3 Admin .................................................................................................................................. 15 4.4 Profile Manager................................................................................................................ 18 Chapter 5 Troubleshooting .............................................................. 22 APPENDIX A Specifications.............................................................. 23 Wireless Network Adapter User manual Page 3 of 24 Chapter 1 Introduction 1.1 Welcome The Wireless Network Adapter is a powerful 32-bit Cardbus/PCI Adapter that installs quickly and easily into PCs. The Adapter can be used in Ad-Hoc mode to connect directly with other cards for peer-to-peer file sharing or in Infrastructure mode to connect with a wireless access point or router for access to the Internet in your office or home network. The Wireless Cardbus/PCI/USB Adapter connects you with 802.11g networks at up to an incredible 54Mbps! And for added versatility, it can also interoperate with all the up to 11Mbps 802.11b products found in homes, businesses, and public wireless hotspots around the country. And in either mode, your wireless communications are protected by industrial-strength WPA, so your data stays secure. 1.2 About This Guide This User Manual contains information on how to install and configure your Wireless Adapter to get your network started accessing the Internet. It will guide you through the correct configuration steps to get your device up and running. Note and Caution in this manual are highlighted with graphics as below to indicate important information. Contains related information corresponds to a topic. Necessary steps, actions or messages should not be ignored. 1.3 Copyright statement No part of this publication may be reproduced, stored in a retrieval system, or transm…

Text truncated - open the document above for the full version.

Netcore Technology Inc. ______ 14 Building, Jinhe Industrial Park, Yufeng Manage Dist., Zhangmutou Town, Dongguan City, Guangdong Province, China Date: 2006/8/4 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Shenzhen office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS SZ, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS SZ on our behalf shall have the same effect as acts of our own. In authorizing CCS SZ as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant.

Netcore Technology Inc. ______ 14 Building, Jinhe Industrial Park, Yufeng Manage Dist., Zhangmutou Town, Dongguan City, Guangdong Province, China Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: T58331GU2006M1 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards

Chris Harvey From: eric.wong [[email protected]] Sent: Tuesday, August 08, 2006 10:03 PM To: [email protected] Cc: [email protected]; [email protected]; [email protected] Subject: Re:Netcore Technology Inc., FCC ID: T58331GU2006M1, Assessment NO.: AN06T6031, Notice#1 Attachments: SZ060721B01-RP_0809.pdf; (331GU)UserMan_0809.pdf Page 1 of 2 8/9/2006 Hello Chris, Please find the materials updated upon your last comment, thank you!! Thank you!! Should you have any question, please don't hesitate to ask us.. Eric Wong Report & Certification Section Compliance Certification Services (Shenzhen) Inc. (aka Compliance Engineering Services, Inc.) TEL.: 86-755-28055000 Ext.102 FAX: 86-755-28055221 EMAIL: [email protected] / [email protected] ----Our mission: Helping customers speed to market in Conformance, Compliance & Certification!!--- - Dear Eric Wong, I have reviewed the above referenced TCB application and find that the following items need to be addressed before the review can be completed: 1. The Users Manual supplied does not contain any of the required compliance <[email protected]> 2006/08/08 08:31 PM 收件人： <[email protected]>, <[email protected]> 副本抄送： <[email protected]> 主旨： Netcore Technology Inc., FCC ID: T58331GU2006M1, Assessment NO.: AN06T6031, Notice#1 information. Please provide a revised manual which addresses: a. the text required by 15.19 ('This device complies with Pt. 15..') since it is not included on the label of this small device; b. the 15.105 and 15.21 Digital device required text; c. RF Exposure guidance ('This transmitter must not be co-located with any other transmitters or antennas.'). 2. The test report shows 3 different models (331GU / NC-331GUM1 / NE-331GUM1) and indicates that 'Model Difference' is 'based on same products.' Please clarify if there is any difference between the 3 different model numbers. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey [email protected] Page 2 of 2 8/9/2006

331GU uses microstrip antenna, max gain is 0dB

Compliance Certification Services (Shenzhen) Inc. Report No: SZ060721B01-RP FCC ID: T58331GU2006M1 Date of Issue: July 29, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 64 FCC 47 CFR PART 15 SUBPART C TEST REPORT For WIRELESS USB ADAPTER Model: 331GU / NC-331GUM1 / NE-331GUM1 Trade Name: N/A Prepared for NETCORE TECHNOLOGY INC. 14 BUILDING, JINHE INDUSTRIAL PARK, YUFENG MANAGE DISTRICT, ZHANGMUTOU TOWN, DONGGUAN CITY, GUANGDONG PROVINCE Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 5, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No: SZ060721B01-RP FCC ID: T58331GU2006M1 Date of Issue: July 29, 2006 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION....................................................................................................3 2. EUT DESCRIPTION ...........................................................................................................................4 3. TEST METHODOLOGY ....................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION........................................................................................................7 5. FACILITIES AND ACCREDITATIONS ..........................................................................................8 5.1 FACILITIES ........................................................................................................8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 6. SETUP OF EQUIPMENT UNDER TEST .........................................................................................9 6.1 SETUP CONFIGURATION OF EUT.........................................................................................................9 6.2 SUPPORT EQUIPMENT .................................................................................................................9 7. FCC PART 15.247 REQUIREMENTS.............................................................................................10 7.1 6DB BANDWIDTH.............................................................................................................................10 7.2 PEAK POWER....................................................................................................................................16 7.3 BAND EDGES MEASUREMENT ................................................................................................22 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................31 7.5 SPURIOUS EMISSIONS.................................................................................................................37 7.6 POWERLINE CONDUCTED EMISSIONS..............................................................................................59 APPENDIX 1 PHOTOGRPHS OF TEST SETUP .................................................................................63 Compliance Certification Services (Shenzhen) Inc. Report No: SZ060721B01-RP FCC ID: T58331GU2006M1 Date of Issue: July 29, 2006 Page 3 1. TEST RESULT CERTIFICATION Applicant: NETCORE TECHNOLOGY INC. 14 BUILDING, JINHE INDUSTRIAL PARK, YUFENG MANAGE DISTRICT, ZHANGMUTOU TOWN, DONGGUAN CITY, GUANGDONG PROVINCE Equipment Under Test: WIRELESS USB ADAPTER Trade Name: N/A Model: 331GU / NC-331GUM1 / NE-331GUM1 Date of Test: July 21-28, 2006 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services (Shenzhen) Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Tested By: Henry Ding Reviewed By: Harris Lai / General Manager Eric Wong / Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC. Compliance Certification Services (Shenzhen) Inc. Report No: SZ060721B01-RP FCC ID: T58331GU2006M1 Date of Issue: July 29, 2006 Page 4 2. EUT DESCRIPTION Product WIRELESS USB ADAPTER Trade Name N/A Model Number 331GU / NC-331GUM1 / NE-331GUM1 Model Difference EUT is identical except the model designation due to marketing purpose Power Supply Powered by the notebook Frequency Range 802.11b mode: 2412 ~ 2462 MHz 802.11g mode: 2412 ~ 246…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No: SZ060721B01-RP FCC ID: T58331GU2006M1 Date of Issue: July 29, 2006 Page 63 APPENDIX 1 PHOTOGRPHS OF TEST SETUP LINE CONDUCTED EMISSION TEST Compliance Certification Services (Shenzhen) Inc. Report No: SZ060721B01-RP FCC ID: T58331GU2006M1 Date of Issue: July 29, 2006 Page 64 RADIATED EMISSION TEST
