T58SEV204H4CH Wireless NVR

RF_160, Issue 02 Declaration of Authorization We Name: NETIS SYSTEMS CO., LTD. Address: 4F&5F R&D Building,Oriental Cyberport High-Tech Industrial Park, Nanshan City: Shenzhen Country: China Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: 4CH Wireless NVR Type designation: SEV204, SEK204 Trademark: netis FCC ID: T58SEV204H on our behalf. Date: 2015-08-13 City: Shenzhen Name: Selena Bai Function: Director Signature: . Notes:

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the BTL EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment 4CH Wireless N VR / 4CH Wireless IP Camera & NVR Security Kit Model Name SE V204, SEK204 Brand Name netis Applicant NETIS SYSTEMS CO., LTD Address 4F&5F R&D Building, Oriental Cyberport, High-Tech Industrial Park, Nanshan, Shenzhen, China. Standard(s) FCC Part 15, Subpart B: 2014 ANSI C63.4-2014 Report(s) BTL-FCCE-1-1503C201A The test data, data evaluation, and equipment configuration contained in our test report(s) above was (were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory BTL INC. B1, No. 37, Lane 365, Yang-Guang St., Nei-Hu District, Taipei City 114, Taiwan. TEL:+886-2-2657-3299 FAX:+886-2-2657-3331

Project No.: 1503C201A Page 2 of 12 Project No.: 1503C201A Page 3 of 12

69.5*36.3mm 铜版纸+哑胶 Model: SEV204 4CH Wireless NVR Default Setting: Account Name: admin Password: (The password is empty) Input: 12V 3A FCC ID: T58SEV204HMADE IN CHINA Label location

Project No.: 1503C201A Page 4 of 12 Project No.: 1503C201A Page 5 of 12 Project No.: 1503C201A Page 6 of 12 Project No.: 1503C201A Page 7 of 12 Project No.: 1503C201A Page 8 of 12 Project No.: 1503C201A Page 9 of 12 Project No.: 1503C201A Page 10 of 12 Project No.: 1503C201A Page 11 of 12 Project No.: 1503C201A Page 12 of 12

FCC RF EXPOSURE REPORT FCC ID: T58SEV204H Project No. : 1503C201A Equipment : 4CH Wireless NVR Model : SEV204, SEK204 Applicant : NETIS SYSTEMS CO., LTD Address : 4F&5F R&D Building, Oriental Cyberport, High-Tech Industrial Park, Nanshan, Shenzhen, China. According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain(dBi) 1 RF21S00001ADipole R-SMA 5.24 2 RF21S00001ADipole R-SMA 5.24 TEST RESULTS EUT： 4CH Wireless NVR Model Name : SEV204, SEK204 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.24 3.3420 13.92 24.6604 0.016404021 Complies 5.24 3.3420 14.01 25.1768 0.016747511 Complies 5.24 3.3420 14.12 25.8226 0.017177121 Complies EUT： 4CH Wireless NVR Model Name : SEV204, SEK204 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.24 3.3420 13.88 24.4343 0.01625363 1 Complies 5.24 3.3420 13.79 23.9332 0.01592027 1 Complies 5.24 3.3420 13.67 23.2809 0.01548640 1 Complies EUT： 4CH Wireless NVR Model Name : SEV204, SEK204 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.24 3.3420 13.71 23.4963 0.01562969 1 Complies 5.24 3.3420 13.73 23.6048 0.01570183 1 Complies 5.24 3.3420 13.89 24.4906 0.01629110 1 Complies EUT： 4CH Wireless NVR Model Name : SEV204, SEK204 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-40M MODE_Total /CH03, CH06, CH09 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.24 3.3420 13.69 23.3884 0.01555788 1 Complies 5.24 3.3420 13.75 23.7137 0.01577431 1 Complies 5.24 3.3420 13.88 24.4343 0.01625363 1 Complies Note: the calculated distance is 20 cm.

Report No.: BTL-FCCP-1-1503C201A Page 1 of 144 FCC Radio Test Report FCC ID: T58SEV204H This report concerns (check one): Original Grant Class II Change Project No. : 1503C201A Equipment : 4CH Wireless NVR / 4CH Wireless IP Camera & NVR Security Kit Model Name : SEV204, SEK204 Applicant : NETIS SYSTEMS CO., LTD Address : 4F&5F R&D Building, Oriental Cyberport, High-Tech Industrial Park, Nanshan, Shenzhen, China. Date of Receipt : Jul. 06, 2015 Date of Test : Jul. 06, 2015~Aug. 07, 2015 Issued Date : Aug. 10, 2015 Tested by : BTL Inc. T esting Engineer : ( Niklaus Lai) Technical Manager: (David Mao) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-1-1503C201A Page 2 of 144 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-1-1503C201A Page 3 of 144 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 TEST PROCEDURE 14 4.1.3 DEVIATION FROM TEST STANDARD 14 4.1.4 TEST SETUP 15 4.1.5 EUT OPERATING CONDITIONS 15 4.1.6 EUT TEST CONDITIONS 15 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 EUT TEST CONDITIONS 19 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 20 4.2.8 TEST RESULTS (30MHZ TO 1000 MHZ) 20 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 20 5 . BANDWIDTH TEST 21 5.1 APPLIED PROCEDURES 21 5.1.1 TEST PROCEDURE 21 5.1.2 DEVIATION FROM STANDARD 21 5.1.3 TEST SETUP 21 5.1.4 EUT OPERATION CONDITIONS 21 5.1.5 EUT TEST CONDITIONS 21 5.1.6 TEST RESULTS 21 6 . MAXIMUM PEAK CONDUCTED OUTPUT POWER TEST 22 Report No.: BTL-FCCP-1-1503C201A Page 4 of 144 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 22 6.1.1 TEST PROCEDURE 22 6.1.2 DEVIATION FROM STANDARD 22 6.1.3 TEST SETUP 22 6.1.4 EUT OPERATION CONDITIONS 22 6.1.5 EUT TEST CONDITIONS 22 6.1.6 TEST RESULTS 22 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 23 7.1 APPLIED PROCEDURES / LIMIT 23 7.1.1 TEST PROCEDURE 23 7.1.2 DEVIATION FROM STANDARD 23 7.1.3 TEST SETUP 23 7.1.4 EUT OPERATION CONDITIONS 23 7.1.5 EUT TEST CONDITIONS 23 7.1.6 TEST RESULTS 23 8 . POWER SPECTRAL DENSITY TEST 24 8.1 APPLIED PROCEDURES / LIMIT 24 8.1.1 TEST PROCEDURE 24 8.1.2 DEVIATION FROM STANDARD 24 8.1.3 TEST SETUP 24 8.1.4 EUT OPERATION CONDITIONS 24 8.1.5 EUT TEST CONDITIONS 24 8.1.6 TEST RESULTS 24 9 . MEASUREMENT INSTRUMENTS LIST 25 10 . EUT TEST PHOTO 27 ATTACHMENT A - CONDUCTED EMISSION 31 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 34 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 36 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 43 ATTACHMENT E - BANDWIDTH 92 ATTACHMENT F – MAXIMUM PEAK CONDUCTED OUTPUT POWER 101 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 105 ATTACHMENT H - POWER SPECTRAL DENSITY 130 Report No.: BTL-FCCP-1-1503C201A Page 5 of 144 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-1-1503C201A Original Issue. Aug. 10, 2015 Report No.: BTL-FCCP-1-1503C201A Page 6 of 144 1. CERTIFICATION Equipment : 4CH Wireless NVR / 4CH Wireless IP Camera & NVR Security Kit Brand Name : netis Model Name : SEV204, SEK204 Applicant : NETIS SYSTEMS CO., LTD Manufacturer : Shenzhen Netcore Industrial Ltd. Address : 4F&5F R&D Building, Oriental Cyberport, High-Tech Industrial Park, Nanshan, Shenzhen, China. Factory : Dongguan City Netcore Network Technology Co.,Ltd. Address : No.10-1,Sankeng Road,Qinghutou,Tangxia Town,Dongguan City Date of Test : Jul. 06, 2015~Aug. 07, 2015 Test Sample : Engineering Sample Standard(s) : FCC Part15, Subpart C: 2014 (15.247) / ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-1-1503C201A) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1503C201A Page 27 of 144 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FCCP-1-1503C201A Page 28 of 144 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-1-1503C201A Page 29 of 144 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FCCP-1-1503C201A Page 30 of 144 Radiated Measurement Photos Above 1000MHz
