T58WF2111R150Mbps Wireless-N USB Adapter

WF-2111 150Mbps Wireless-N USB Adapter User Manual V1.1 2011-05-25 WF-2111 User manual - 2 - Certification FCC CE FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices) FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment WF-2111 User manual - 3 - Package Contents The following items should be found in your package: ¾ 150Mbps Wireless-N USB Adapter ¾ Quick Installation Guide ¾ CD-Rom Make sure that the package contains above items. If any of the above items is missing or damaged, please contact the store you bought this product from. WF-2111 User manual - 4 - Content 1 INTRODUCTION ..........................................................................................................................‐ 5 ‐ 1.1 PRODUCT OVERVIEW..........................................................................................................................‐ 5 ‐ 1.2 MAIN FEATURES................................................................................................................................‐ 5 ‐ 1.3 STANDARDS......................................................................................................................................‐ 5 ‐ 1.4 WORKING ENVIRONMENT....................................................................................................................‐ 5 ‐ 1.5 SYSTEM REQUIREMENTS......................................................................................................................‐ 6 ‐ 2 DRIVER AND HARDWARE INSTALLATION....................................................................................‐ 7 ‐ 2.1 DRIVER AND SOFTWARE INSTALLATION...................................................................................................‐ 7 ‐ 2.2 INSERT THE ADAPTER..........................................................................................................................‐ 9 ‐ 3 SYSTEM CONFIGURATION.........................................................................................................‐ 11 ‐ 3.1 GENERAL........................................................................................................................................‐ 11 ‐ 3.2 PROFILE..........................................................................................................................................‐ 13 ‐ 3.2.1 Add....................................................................................................................................‐ 13 ‐ 3.2.2 Remove .............................................................................................................................‐ 15 ‐ 3.2.3 Edit....................................................................................................................................‐ 16 ‐ 3.2.4 Duplicate...........................................................................................................................‐ 17 ‐ 3.2.5 Set default.........................................................................................................................‐ 18 ‐ 3.3 AVAILABLE NETWORK.......................................................................................................................‐ 18 ‐ 3.4 STATUS..........................................................................................................................................‐ 20 ‐ 3.5 STATISTICS......................................................................................................................................‐ 20 ‐ 3.6 WI‐FI PROTECT SETUP......................................................................................................................‐ 21 ‐ 4 THE ACCESS POINT MODE.........................................................................................................‐ 24 ‐ 4.1 GENERAL........................................................................................................................................‐ 24 ‐ 4.2 ADVANCED.........................................................…

Text truncated - open the document above for the full version.

DATE：2011-05-10 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Company name: Neutron Engineering Inc. Ms. Cathy Wang Address:No.3, JinShaGang 1 st Road, ShiXia, DaLang Town， City: Dong Guan Country: China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Company name: NETIS SYSTEMS CO., LTD. .Address: 9F, B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan City: Shenzhen Country: China __________ Dated this 2011-05-10 Agency agreement expiration date: Usually Give 8 - 12 Months By: Selena Bai Signature Printed Title: PD Assistant On behalf of : NETIS SYSTEMS CO., LTD. Telephone: +86-755-86186790

FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: 150Mbps Wireless-N USB Adapter MODEL NO.: WF-2111 TRADE NAME: netis IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: NEI-FCCE-1-1104C218, ISSUED ON May 24, 2011 Testing lab: Neutron Engineering, Inc. Address: B1,No.37,Lane 365,Yang Guang St.,NeiHu District 114.,Taipei,Taiwan THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND; (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION: NETIS SYSTEMS CO., LTD. (COMPANY NAME) 9F, B Block, Tsinghua Information Park, High-tech Industrial Park , Nanshan, Shenzhen, China (COMPANY ADDRESS) TEL : +86-755-86186790 SelenaBai, PD Assistant (NAME) (TITLE) _____________________________________________ 2011-05-24 (SIGNATURE) (DATE)

DATE：2011-05-10 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: T58WF2111R Product Name: 150Mbps Wireless-N USB Adapter Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2011-05-10 By: Selena Bai Signature Printed Title: PD Assistant On behalf of : NETIS SYSTEMS CO., LTD. Telephone: +86-755-86186790

Neutron Engineering Inc. Project No.: 1104C218 Page 2 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 2 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 3 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 3 of 9 1104C218 1104C218

Neutron Engineering Inc. Project No.: 1104C218 Page 4 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 4 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 5 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 5 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 6 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 6 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 7 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 7 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 8 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 8 of 9 1104C218 1104C218 Neutron Engineering Inc. Project No.: 1104C218 Page 9 of 9 1104C218

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 1 of 123 FCC Radio Test Report FCC ID: T58WF2111R This report concerns (check one) : Original Grant Class II Change Issued Date : May. 24, 2011 Project No. : 1104C218 Equipment : 150Mbps Wireless-N USB Adapter Model Name : WF-2111 Applicant : NETIS SYSTEMS CO., LTD. Address : 9F,B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: May. 04, 2011 Date of Test: May. 04, 2011 ~ May. 23, 2011 Testing Engineer : (Ares Liu) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 2 of 123 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 3 of 123 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS (RADIATED MODE) 13 3.6 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 16 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 20 4.2.3 TEST PROCEDURE 21 4.2.4 DEVIATION FROM TEST STANDARD 21 4.2.5 TEST SETUP 22 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 23 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 25 5 . BANDWIDTH TEST 73 5.1 APPLIED PROCEDURES / LIMIT 73 5.1.1 MEASUREMENT INSTRUMENTS LIST 73 5.1.2 TEST PROCEDURE 73 5.1.3 DEVIATION FROM STANDARD 73 5.1.4 TEST SETUP 74 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 4 of 123 Table of Contents Page 5.1.5 EUT OPERATION CONDITIONS 74 5.1.6 TEST RESULTS 75 6 . MAXIMUM OUTPUT POWER TEST 83 6.1 APPLIED PROCEDURES / LIMIT 83 6.1.1 MEASUREMENT INSTRUMENTS LIST 83 6.1.2 TEST PROCEDURE 83 6.1.3 DEVIATION FROM STANDARD 83 6.1.4 TEST SETUP 83 6.1.5 EUT OPERATION CONDITIONS 83 6.1.6 TEST RESULTS 84 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 92 7.1 APPLIED PROCEDURES / LIMIT 92 7.1.1 MEASUREMENT INSTRUMENTS LIST 92 7.1.2 TEST PROCEDURE 92 7.1.3 DEVIATION FROM STANDARD 92 7.1.4 TEST SETUP 92 7.1.5 EUT OPERATION CONDITIONS 92 7.1.6 TEST RESULTS 93 8 . POWER SPECTRAL DENSITY TEST 113 8.1 APPLIED PROCEDURES / LIMIT 113 8.1.1 MEASUREMENT INSTRUMENTS LIST 113 8.1.2 TEST PROCEDURE 113 8.1.3 DEVIATION FROM STANDARD 113 8.1.4 TEST SETUP 113 8.1.5 EUT OPERATION CONDITIONS 113 8.1.6 TEST RESULTS 114 9 . EUT TEST PHOTO 122 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 5 of 123 1. CERTIFICATION E q u i p m e n t : 150Mbps Wireless-N USB Adapter Brand Name : netis Model Name : WF-2111 A p p l i c a n t : NETIS SYSTEMS CO., LTD. Date of Test : May. 04, 2011 ~ May. 23, 2011 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1104C218) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 6 of 123 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.209/15.205 Radiated Spurious Emission PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 116 of 117 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 116 of 117 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 117 of 117 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C218 Page 117 of 117 Radiated Measurement Photos
