T58WF2113R300Mbps Wireless-N PCI-E Adapter

WF-2113 300Mbps Wireless-N PCI-E Adapter User Manual V1.0 2011-05-25 WF-2113 User Manual - 1 - WF-2113 User Manual - 2 - Certification FCC CE FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices) FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment WF-2113 User Manual - 3 - Package Contents The following items should be found in your package: ¾ 300Mbps Wireless-N PCI-E Adapter ¾ CD-ROM ¾ Quick Installation Guides Make sure that the package contains above items. If any of the listed items is damaged or missing, please contact with your distributor. WF-2113 User Manual 4 Content 1 INTRODUCTION .......................................................................................................................5 1.1 PRODUCT OVERVIEW.....................................................................................................................5 1.2 MAIN FEATURES...........................................................................................................................5 1.3 SUPPORTING STANDARD AND PROTOCOL...........................................................................................5 1.4 WORKING ENVIRONMENT..............................................................................................................6 1.5 SYSTEM REQUIREMENT..................................................................................................................6 2 DRIVER AND HARDWARE INSTALLATION ..................................................................................7 2.1 DRIVER INSTALLATION OF THE WF‐2113...........................................................................................7 2.2 HARDWARE INSTALLATION OF WF‐2113...........................................................................................9 2.2.1 Install the Wireless 11N PCI‐E adapter into your computer.................................................9 2.2.2 Restart your computer.......................................................................................................10 3 SYSTEM CONFIGURATION ......................................................................................................11 3.1 GENERAL...................................................................................................................................11 3.2 PROFILE....................................................................................................................................12 3.2.1 Add.....................................................................................................................................12 3.2.2 Remove ..............................................................................................................................14 3.2.3 Edit.....................................................................................................................................15 3.2.4 Duplicate............................................................................................................................16 3.2.5 Set default..........................................................................................................................17 3.3 AVAILABLE NETWORK..................................................................................................................18 3.4 STATUS.....................................................................................................................................20 3.5 STATISTICS.................................................................................................................................20 3.6 WI‐FI PROTECT SETUP..................................................................................................................21 4 FAQ ...................................…

Text truncated - open the document above for the full version.

DATE：2011-05-10 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Company name: Neutron Engineering Inc. Ms. Cathy Wang Address:No.3, JinShaGang 1 st Road, ShiXia, DaLang Town， City: Dong Guan Country: China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Company name: NETIS SYSTEMS CO., LTD. .Address: 9F, B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan City: Shenzhen Country: China __________ Dated this 2011-05-10 Agency agreement expiration date: Usually Give 8 - 12 Months By: Selena Bai Signature Printed Title: PD Assistant On behalf of : NETIS SYSTEMS CO., LTD. Telephone: +86-755-86186790

FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: 300Mbps Wireless-N PCI-E Adapter MODEL NO.: WF-2113 TRADE NAME: netis IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: NEI-FCCE-1-1104C220, ISSUED ON May 26, 2011 Testing lab: Neutron Engineering, Inc. Address: B1,No.37,Lane 365,Yang Guang St.,NeiHu District 114.,Taipei,Taiwan THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND; (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION: NETIS SYSTEMS CO., LTD. (COMPANY NAME) 9F, B Block, Tsinghua Information Park, High-tech Industrial Park , Nanshan, Shenzhen, China (COMPANY ADDRESS) TEL : +86-755-86186790 SelenaBai, PD Assistant (NAME) (TITLE) _____________________________________________ 2011-05-24 (SIGNATURE) (DATE)

DATE：2011-05-10 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: T58WF2113R Product Name: 300Mbps Wireless-N PCI-E Adapter Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2011-05-10 By: Selena Bai Signature Printed Title: PD Assistant On behalf of : NETIS SYSTEMS CO., LTD. Telephone: +86-755-86186790

Neutron Engineering Inc. Project No.: 1104C220 Page 2 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 2 of 6 1104C220 1104C220

Neutron Engineering Inc. Project No.: 1104C220 Page 3 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 3 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 4 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 4 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 5 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 5 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 6 of 6 1104C220 1104C220 Neutron Engineering Inc. Project No.: 1104C220 Page 6 of 6 1104C220 1104C220

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 1 of 140 FCC Radio Test Report FCC ID: T58WF2113R This report concerns (check one) : Original Grant Class II Change Issued Date : May. 26, 2011 Project No. : 1104C220 Equipment : 300Mbps Wireless-N PCI-E Adapter Model Name : WF-2113 Applicant : NETIS SYSTEMS CO., LTD. Address : 9F,B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Manufacturer : Shenzhen Netcore Industrial Ltd. Address : 9F,B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: May. 04, 2011 Date of Test: May. 04, 2011 ~ May. 23, 2011 Testing Engineer : (Ivan Cao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 2 of 140 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 3 of 140 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS (RADIATED MODE) 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 21 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 22 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 5 . BANDWIDTH TEST 72 5.1 APPLIED PROCEDURES / LIMIT 72 5.1.1 MEASUREMENT INSTRUMENTS LIST 72 5.1.2 TEST PROCEDURE 72 5.1.3 DEVIATION FROM STANDARD 72 5.1.4 TEST SETUP 72 5.1.5 EUT OPERATION CONDITIONS 72 5.1.6 TEST RESULTS 73 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 4 of 140 Table of Contents Page 6 . MAXIMUM OUTPUT POWER TEST 81 6.1 APPLIED PROCEDURES / LIMIT 81 6.1.1 MEASUREMENT INSTRUMENTS LIST 81 6.1.2 TEST PROCEDURE 81 6.1.3 DEVIATION FROM STANDARD 81 6.1.4 TEST SETUP 81 6.1.5 EUT OPERATION CONDITIONS 81 6.1.6 TEST RESULTS 82 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 95 7.1 APPLIED PROCEDURES / LIMIT 95 7.1.1 MEASUREMENT INSTRUMENTS LIST 95 7.1.2 TEST PROCEDURE 95 7.1.3 DEVIATION FROM STANDARD 95 7.1.4 TEST SETUP 95 7.1.5 EUT OPERATION CONDITIONS 95 7.1.6 TEST RESULTS 96 8 . POWER SPECTRAL DENSITY TEST 126 8.1 APPLIED PROCEDURES / LIMIT 126 8.1.1 MEASUREMENT INSTRUMENTS LIST 126 8.1.2 TEST PROCEDURE 126 8.1.3 DEVIATION FROM STANDARD 126 8.1.4 TEST SETUP 126 8.1.5 EUT OPERATION CONDITIONS 126 8.1.6 TEST RESULTS 127 9 . EUT TEST PHOTO 139 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 5 of 140 1. CERTIFICATION E q u i p m e n t : 300Mbps Wireless-N PCI-E Adapter Brand Name : netis Model Name : WF-2113 A p p l i c a n t : NETIS SYSTEMS CO., LTD. F a c t o r y : Dongguan City Netcore Network Technology Co.,Ltd. A d d r e s s : No.10-1,Sankeng Road,Qinghutou,Tangxia Town,Dongguan City Date of Test : May. 04, 2011 ~ May. 23, 2011 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1104C220) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 6 of 140 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power …

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 122 of 123 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 122 of 123 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 123 of 123 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1104C220 Page 123 of 123 Radiated Measurement Photos
