Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: T58WF2411R Project No. : 1102C038 Equipment : 150Mbps Wireless-N AP/Repeater/Router client Model : WF2411 Applicant : NETIS SYSTEMS CO., LTD. Address : 9F, B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Brand name Model Name Antenna TypeConnector Gain (dBi) 1 Cortec AN2400-92 F19BO Integral N/A 5.0 TEST RESULTS EUT： 150Mbps Wireless-N AP/Repeater/Router client Model Name ： WF2411 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1016 hPa Test Voltage ： AC 120V/60Hz Test Mode ： CH00/CH07/CH14 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5 3.1623 19.5500 90.1571 0.056747981 Complies

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1112C038 Page 1 of 126 FCC Radio Test Report FCC ID: T58WF2411R This report concerns (check one) : Original Grant Class II Change Issued Date : Jan. 5, 2012 Project No. : 1112C038 Equipment : 150Mbps Wireless-N AP/Repeater/Router client Model Name : WF2411 Applicant : NETIS SYSTEMS CO., LTD. Address : 9F,B Block,Tsinghua Information Park, High-tech Industrial Park,Nanshan, Shenzhen,China Manufacturer : Shenzhen Netcore Industrial Ltd. Address : 9F,B Block,Tsinghua Information Park, High-tech Industrial Park,Nanshan, Shenzhen,China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Dec. 07, 2011 Date of Test: Dec. 07, 2011 ~ Jan. 3, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1112C038 Page 2 of 126 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1112C038 Page 3 of 126 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS (RADIATED MODE) 3.6 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 16 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 20 4.2.3 TEST PROCEDURE 21 4.2.4 DEVIATION FROM TEST STANDARD 21 4.2.5 TEST SETUP 22 4.2.6 EUT OPERATING CONDITIONS 23 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 25 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 27 5 . BANDWIDTH TEST 75 5.1 APPLIED PROCEDURES / LIMIT 75 5.1.1 MEASUREMENT INSTRUMENTS LIST 75 5.1.2 TEST PROCEDURE 75 5.1.3 DEVIATION FROM STANDARD 75 5.1.4 TEST SETUP 76 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1112C038 Page 4 of 126 Table of Contents Page 5.1.5 EUT OPERATION CONDITIONS 76 5.1.6 TEST RESULTS 77 6 . MAXIMUM OUTPUT POWER TEST 85 6.1 APPLIED PROCEDURES / LIMIT 85 6.1.1 MEASUREMENT INSTRUMENTS LIST 85 6.1.2 TEST PROCEDURE 85 6.1.3 DEVIATION FROM STANDARD 85 6.1.4 TEST SETUP 85 6.1.5 EUT OPERATION CONDITIONS 85 6.1.6 TEST RESULTS 86 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 94 7.1 APPLIED PROCEDURES / LIMIT 94 7.1.1 MEASUREMENT INSTRUMENTS LIST 94 7.1.2 TEST PROCEDURE 94 7.1.3 DEVIATION FROM STANDARD 94 7.1.4 TEST SETUP 94 7.1.5 EUT OPERATION CONDITIONS 94 7.1.6 TEST RESULTS 95 8 . POWER SPECTRAL DENSITY TEST 115 8.1 APPLIED PROCEDURES / LIMIT 115 8.1.1 MEASUREMENT INSTRUMENTS LIST 115 8.1.2 TEST PROCEDURE 115 8.1.3 DEVIATION FROM STANDARD 115 8.1.4 TEST SETUP 115 8.1.5 EUT OPERATION CONDITIONS 115 8.1.6 TEST RESULTS 116 9 . EUT TEST PHOTO 124 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1112C038 Page 5 of 126 1. CERTIFICATION E q u i p m e n t : 150Mbps Wireless-N AP/Repeater/Router client Brand Name : netis Model Name : WF2411 A p p l i c a n t : NETIS SYSTEMS CO., LTD. F a c t o r y : Dongguan City Netcore Network Technology Co.,Ltd. A d d r e s s : No.10-1,Sankeng Road,Qinghutou,Tangxia Town,Dongguan City Date of Test : Dec. 07, 2011 ~ Jan. 3, 2012 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1112C038) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1112C038 Page 6 of 126 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious EmissionPASS…
