T58WF2415R300Mbps Gigabit Wireless-N AP/ Repeater/ Router Client

CERTIFICATE OF COMPLIANCE Ref No.: NEI-FCCE-1-1212C196 Date of Issue: Jan. 09, 2013 Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment 300Mbps Gigabit Wireless-N AP/ Repeater/ Router Client Model Name WF2415 Brand Name netis Applicant NETIS SYSTEMS CO., LTD Address 9F,B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Measurement ANSI C63.4 (2009) Method The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-1212C196) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

Neutron Engineering Inc. Project No.: 1212C196 Page 2 of 8 Neutron Engineering Inc. Project No.: 1212C196 Page 3 of 8 Neutron Engineering Inc. Project No.: 1212C196 Page 4 of 8

Label location

Neutron Engineering Inc. Project No.: 1212C196 Page 5 of 8 Neutron Engineering Inc. Project No.: 1212C196 Page 6 of 8 Neutron Engineering Inc. Project No.: 1212C196 Page 7 of 8 Neutron Engineering Inc. Project No.: 1212C196 Page 8 of 8

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: T58WF2415R Project No. : 1212C196 Equipment : 300Mbps Gigabit Wireless-N AP/ Repeater/ Router Client Model : WF2415 Applicant : NETIS SYSTEMS CO., LTD Address : 9F,B Block,Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Manufacturer : Shenzhen Netcore Industrial Ltd. Address : 9F,B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna TypeConnector Gain (dBi) Note 1 Cortec AN2400-92F26BODipole Mini 5.56 TX/RX 2 Cortec AN2400-92F19BODipole Mini 5.71 TX/RX Note: The EUT incorporates a MIMO function. Physically, the EUT provides two completed transmitters and two receivers (2T2R) , This EUT supports MIMO 2T2R. Operating Mode TX Mode 1TX 2TX 802.11b V (ANT1 or ANT2) - 802.11g V (ANT1 or ANT2) - 802.11n(20MHz) - V (ANT1 & ANT2) 802.11n(40MHz) - V (ANT1 & ANT2) Neutron Engineering Inc. TEST RESULTS EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX B MODE CH01/CH06/CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.71 3.7239 17.86 61.0942 0.024828491 Complies 5.71 3.7239 17.90 61.6595 0.025058231 Complies 5.71 3.7239 17.92 61.9441 0.025173891 Complies EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX G MODE CH01/CH06/CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.71 3.7239 19.93 98.4011 0.039989901 Complies 5.71 3.7239 19.82 95.9401 0.038989741 Complies 5.71 3.7239 19.90 97.7237 0.039714621 Complies Neutron Engineering Inc. EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N20MHz MODE CH01/CH06/CH11-ANT1+ANT2 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 8.65 7.3282 17.44 55.4626 0.080900341 Complies 8.65 7.3282 17.63 57.9429 0.084518231 Complies 8.65 7.3282 17.76 59.7035 0.087086411 Complies EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N40MHz MODE CH03/CH06/CH09-ANT1+ANT2 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 8.65 7.3282 15.08 32.2107 0.046984041 Complies 8.65 7.3282 15.16 32.8095 0.047857541 Complies 8.65 7.3282 15.2 33.1131 0.048300361 Complies

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: T58WF2415R Project No. : 1212C196 Equipment : 300Mbps Gigabit Wireless-N AP/ Repeater/ Router Client Model : WF2415 Applicant : NETIS SYSTEMS CO., LTD Address : 9F,B Block,Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Manufacturer : Shenzhen Netcore Industrial Ltd. Address : 9F,B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna TypeConnector Gain (dBi) Note 1 Cortec AN2400-92F26BODipole Mini 5.56 TX/RX 2 Cortec AN2400-92F19BODipole Mini 5.71 TX/RX Note: The EUT incorporates a MIMO function. Physically, the EUT provides two completed transmitters and two receivers (2T2R) , This EUT supports MIMO 2T2R. Operating Mode TX Mode 1TX 2TX 802.11b V (ANT1 or ANT2) - 802.11g V (ANT1 or ANT2) - 802.11n(20MHz) - V (ANT1 & ANT2) 802.11n(40MHz) - V (ANT1 & ANT2) Neutron Engineering Inc. TEST RESULTS EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX B MODE CH01/CH06/CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.71 3.7239 17.86 61.0942 0.024828491 Complies 5.71 3.7239 17.90 61.6595 0.025058231 Complies 5.71 3.7239 17.92 61.9441 0.025173891 Complies EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX G MODE CH01/CH06/CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.71 3.7239 19.93 98.4011 0.039989901 Complies 5.71 3.7239 19.82 95.9401 0.038989741 Complies 5.71 3.7239 19.90 97.7237 0.039714621 Complies Neutron Engineering Inc. EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N20MHz MODE CH01/CH06/CH11-ANT1+ANT2 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 8.65 7.3282 17.44 55.4626 0.080900341 Complies 8.65 7.3282 17.63 57.9429 0.084518231 Complies 8.65 7.3282 17.76 59.7035 0.087086411 Complies EUT： Wireless Dual Band Router Model Name ： WF2471 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N40MHz MODE CH03/CH06/CH09-ANT1+ANT2 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 8.65 7.3282 15.08 32.2107 0.046984041 Complies 8.65 7.3282 15.16 32.8095 0.047857541 Complies 8.65 7.3282 15.2 33.1131 0.048300361 Complies

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 1 of 140 FCC Radio Test Report FCC ID: T58WF2415R This report concerns (check one) : Original Grant Class II Change Issued Date : Jan. 09, 2013 Project No. : 1212C196 Equipment : 300Mbps Gigabit Wireless-N AP/ Repeater/ Router Client Model Name : WF2415 Applicant : NETIS SYSTEMS CO., LTD Address : 9F,B Block,Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Manufacturer : Shenzhen Netcore Industrial Ltd. Address : 9F,B Block, Tsinghua Information Park, High-tech Industrial Park, Nanshan, Shenzhen, China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Dec. 20, 2012 Date of Test: Dec. 20, 2012 ~ Jan. 08, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 2 of 140 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 3 of 140 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 16 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 20 4.2.1 RADIATED EMISSION LIMITS 20 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 21 4.2.3 TEST PROCEDURE 22 4.2.4 DEVIATION FROM TEST STANDARD 22 4.2.5 TEST SETUP 23 4.2.6 EUT OPERATING CONDITIONS 24 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 25 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 28 5 . BANDWIDTH TEST 76 5.1 APPLIED PROCEDURES / LIMIT 76 5.1.1 MEASUREMENT INSTRUMENTS LIST 76 5.1.2 TEST PROCEDURE 76 5.1.3 DEVIATION FROM STANDARD 76 5.1.4 TEST SETUP 76 5.1.5 EUT OPERATION CONDITIONS 76 5.1.6 TEST RESULTS 77 6 . MAXIMUM OUTPUT POWER TEST 89 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 4 of 140 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 89 6.1.1 MEASUREMENT INSTRUMENTS LIST 89 6.1.2 TEST PROCEDURE 89 6.1.3 DEVIATION FROM STANDARD 89 6.1.4 TEST SETUP 89 6.1.5 EUT OPERATION CONDITIONS 89 6.1.6 TEST RESULTS 90 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 93 7.1 APPLIED PROCEDURES / LIMIT 93 7.1.1 MEASUREMENT INSTRUMENTS LIST 93 7.1.2 TEST PROCEDURE 93 7.1.3 DEVIATION FROM STANDARD 93 7.1.4 TEST SETUP 93 7.1.5 EUT OPERATION CONDITIONS 93 7.1.6 TEST RESULTS 94 8 . POWER SPECTRAL DENSITY TEST 124 8.1 APPLIED PROCEDURES / LIMIT 124 8.1.1 MEASUREMENT INSTRUMENTS LIST 124 8.1.2 TEST PROCEDURE 124 8.1.3 DEVIATION FROM STANDARD 124 8.1.4 TEST SETUP 124 8.1.5 EUT OPERATION CONDITIONS 124 8.1.6 TEST RESULTS 125 9 . EUT TEST PHOTO 139 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 5 of 140 1. CERTIFICATION Equipment : 300Mbps Gigabit Wireless-N AP/ Repeater/ Router Client Brand Name : netis Model Name : WF2415 Applicant : NETIS SYSTEMS CO., LTD Factory : Dongguan City Netcore Network Technology Co.,Ltd. Address : No.10-1,Sankeng Road,Qinghutou,Tangxia Town,Dongguan City Date of Test : Dec. 20, 2012 ~ Jan. 08, 2013 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1212C196) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 6 of 140 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.209…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 139 of 140 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 140 of 140 Radiated Measurement Photos

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 139 of 140 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1212C196 Page 140 of 140 Radiated Measurement Photos
