T8VZKM013AIGNITION SW

User Manual Handsfree-System The document hereon is the property of Asahi Denso Co., Ltd. Page 1 of 17 ZKM013-820_0 User Manual Handsfree-System Models : ZKM013 ZKM013A ZKM013-903 ZKM013A-903 User Manual Handsfree-System The document hereon is the property of Asahi Denso Co., Ltd. Page 2 of 17 ZKM013-820_0  Revision history Rev. Date Points modified Changes description 00 20.Oct.2020 First Release 01 9.Nov.2020 Modify FCC ID (3.2.4) Replace NCC disclaimer (3.2.8) 02 17.Dec.2020 3.2.4 Change product name Steering lock ⇒ Ignition SW 3.2.5 Change product name Steering lock ⇒ Ignition SW Add Vietnam certification 1.Add and change sentence User Manual Handsfree-System The document hereon is the property of Asahi Denso Co., Ltd. Page 3 of 17 ZKM013-820_0 Index 1. Overview .......................................................................................................................................... 4 Motorcycle start (Turn on the ignition and start the engine) ................................................... 5 Smart key ............................................................................................................................ 5 Immobilizer key .................................................................................................................. 5 Turn off the ignition and stop the engine ................................................................................. 6 Parking (Lock of the steering) .................................................................................................. 6 Smart key ............................................................................................................................ 6 Immobilizer key .................................................................................................................. 6 Replacing the battery in the Smart Key .................................................................................... 7 2. Installation notes ............................................................................................................................ 11 Handsfree-System attachment................................................................................................ 11 Access to Smart key internal parts .......................................................................................... 11 Product modifications ............................................................................................................. 11 If the product fails ................................................................................................................... 11 3. Certification .................................................................................................................................... 12 Manufacturer .......................................................................................................................... 12 Approval of each country ........................................................................................................ 12 Australia certification ....................................................................................................... 12 China precautions for use ................................................................................................ 12 EU DoC ............................................................................................................................. 13 FCC(USA) certification ...................................................................................................... 15 ISED(Canada) certification ............................................................................................... 15 Korea certification ............................................................................................................ 16 Malaysia certification ....................................................................................................... 16 Taiwan certification .......................................................................................................... 16 Thailand certification ....................................................................................................... 16 Vietnam certification ..................................................................................................... 17 User Manual Handsfree-System The document hereon is the property of Asahi Denso Co., Ltd. Page 4 of 17 ZKM013-820_0 1. Overview This product is an steering lock with Handsfree-System designed to prevent theft. This product can be attached to the motorcycle. The system is composed of: - The Ignition SW (1) with its integral steering lock equipped control unit (4), which provides the following functions:  User recognizer, by means of a Smart key (2) or an Immobilizer Key (3).  Lock and Unlock of the steering, by moving the Lock bar (5).  Enable and disable of the ignition of the bike . - The Smart key (2) referred to as Active Transponder. It can also be used as an Immobilizer key. - The Immobilizer key (3) referred to as Passive Transponder. The Handsfree-System combines the LF: Low Frequency and the RF: Radio Frequency to recognize the right user of the motorcycle. The system is integrated in CAN bus for all data transfer with the other electronic units on the motorcycle. (3) (4) (1) (5) (2) (6) User Manual Handsfree-System The document hereon is the property of Asahi Denso Co., Ltd. Page 5 of 17 ZKM013-820_0 Motorcycle start (Turn on the ignition and start the engine) Smart key User recognition with the Smart key (2) is performed as described below: A. Press the knob on the Ignition SW (1). B. The Control unit (4) installed on the Ignition SW (1) requires the Smart key (2) for a radio frequency identification with an LF signal transmitted by the LF antenna incorporated in the Control unit (4). C. If the Smart key (2) is within a range of 1.0 m from the vehicle and the battery is adequately charged, replies …

Text truncated - open the document above for the full version.

CCAB20LPXXX0TY FCC ID:T8VZKM013A IC:6505A-ZKM013A

ZKM013A Product Photos ; Internal 正面 FRONT 背面 Back LF transmitting antenna LF送信アンテナ RF receiving antenna RF受信アンテナ

Test report No. : 13325697H-A-R1 Page : 1 of 20 Issued date : December 17, 2020 FCC ID : T8VZKM013A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Report Cover Page - 13-EM-F0429 Issue # 17.0 RADIO TEST REPORT Test Report No. : 13325697H-A-R1 Applicant : ASAHI DENSO CO., LTD. Type of EUT : IGNITION SW Model Number of EUT : ZKM013A FCC ID : T8VZKM013A Test regulation : FCC Part 15 Subpart C: 2020 Test Result : Complied (Refer to SECTION 3.2) 1. This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2. The results in this report appl y only to the sample tested. 3. This sample tested is in compliance with the limits of the above re gulation. 4. The test results in this test report are traceable to the national or international standards. 5. This test report must not be used by the customer to claim product certification, approval, or endorsement by the A2LA accreditation body. 6. This test report covers Radio technical requirements. It does not cover administrative issues such as Manual or non- Radio test related Requirements. (if applicable) 7. The all test items in this test report are conducted b y UL Japan, Inc. Ise EMC Lab. 8. The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan has been accredited. 9. The information provided from the customer for this report is identified in Section 1. 10. This report is a revised version of 13325697H-A. 13325697H-A is replaced with this report. Date of test: Se ptember 2, 2020 Representative test engineer: Junki Nagatomi Engineer Consumer Technology Division Approved by: Shinichi Miyazono Engineer Consumer Technology Division CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan. There is no testing item of "Non-accreditation". Test report No. : 13325697H-A-R1 Page : 2 of 20 Issued date : December 17, 2020 FCC ID : T8VZKM013A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 REVISION HISTORY Original Test Report No.: 13325697H-A Revision Test report No. Date Page revised Contents - (Ori ginal) 13325697H-A September 29, 2020 - - 1 13325697H-A-R1 December 17, 2020 P.5 Correction of the Radio specification description in Clause 2.2 1 13325697H-A-R1 December 17, 2020 P. 9 Correction of the Cable No.1 length in Clause 4.2; f rom 0.25 to 0.5 Test report No. : 13325697H-A-R1 Page : 3 of 20 Issued date : December 17, 2020 FCC ID : T8VZKM013A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Reference: Abbreviations (Including words undescribed in this report) A2LA The American Association for Laboratory Accreditation MCS Modulation and Coding Scheme AC Alternating Current MRA Mutual Recognition Arrangement AFH Adaptive Frequency Hopping N/A Not Applicable AM Amplitude Modulation NIST National Institute of Standards and Technology Amp, AMP Amplifier NS No signal detect. ANSI American National Standards Institute NSA Normalized Site Attenuation Ant, ANT Antenna NVLAP National Voluntary Laboratory Accreditation Program AP Access Point OBW Occupied Band Width ASK Amplitude Shift Keying OFDM Orthogonal Frequency Division Multiplexing Atten., ATT Attenuator P/M Power meter AV Average PCB Printed Circuit Board BPSK Binary Phase-Shift Keying PER Packet Error Rate BR Bluetooth Basic Rate PHY Physical Layer BT Bluetooth PK Peak BT LE Bluetooth Low Energy PN Pseudo random Noise BW BandWidth PRBS Pseudo-Random Bit Sequence Cal Int Calibration Interval PSD Power Spectral Density CCK Complementary Code Keying QAM Quadrature Amplitude Modulation Ch., CH Channel QP Quasi-Peak CISPR Comite International Special des Perturbations Radioelectriques QPSK Quadri-Phase Shift Keying CW Continuous Wave RBW Resolution Band Width DBPSK Differential BPSK RDS Radio Data System DC Direct Current RE Radio Equipment D-factor Distance factor RF Radio Frequency DFS Dynamic Frequency Selection RMS Root Mean Square DQPSK Differential QPSK RSS Radio Standards Specifications DSSS Direct Sequence Spread Spectrum Rx Receiving EDR Enhanced Data Rate SA, S/A Spectrum Analyzer EIRP, e.i.r.p. Equivalent Isotropically Radiated Power SG Signal Generator EMC ElectroMagnetic Compatibility SVSWR Site-Voltage Standing Wave Ratio EMI ElectroMagnetic Interference TR Test Receiver EN European Norm Tx Transmitting ERP, e.r.p. Effective Radiated Power VBW Video BandWidth EU European Union Vert. Vertical EUT Equipment Under Test WLAN Wireless LAN Fac. Factor FCC Federal Communications Commission FHSS Frequency Hopping Spread Spectrum FM Frequency Modulation Freq. Frequency FSK Frequency Shift Keying GFSK Gaussian Frequency-Shift Keying GNSS Global Navigation Satellite System GPS Global Positioning System Hori. Horizontal ICES Interference-Causing Equipment Standard IEC International Electrotechnical Commission IEEE Institute of Electrical and Electronics Engineers IF Intermediate Frequency ILAC International Laboratory Accreditation Conference ISED Innovation, Science and Economic Development Canada ISO International Organization for Standardization JAB Japan Accreditation Board LAN Local Area Network LIMS Laboratory Information Management System Test report No. : 13325697H-A-R1 Page : 4 of 20 Issued date : December 17, 2020 FCC ID : T8VZKM013A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ..................................................................................................... 5 SECTION 2: Equipment under test (EUT) ........................................................................................... 5 SECTION 3: Test s…

Text truncated - open the document above for the full version.

Test report No. : 13325697H-A-R1 Page : 19 of 20 Issued date : December 17, 2020 FCC ID : T8VZKM013A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 APPENDIX 3: Photographs of test setup Radiated Emission Photo 1 Photo 2 Test report No. : 13325697H-A-R1 Page : 20 of 20 Issued date : December 17, 2020 FCC ID : T8VZKM013A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position (EUT: X-axis / Antenna: Y-axis) X-axis Y-axis Z-axis End of Report
