TCLCL800BTProjection Keyboard

CL800BT MANUAL 2 Safety Precautions  Avoid long time expose to the direct light or heat.  Faults may occur if kept in extreme of temperatures.  May become damaged if dropped or knocked.  Problems may occur if exposed to humid and/or dusty conditions.  Do not use if power cable or plug are damaged.  Use only dedicated cable/adapter.  Do not disassemble.  Do not look directly at the light source, as this can cause damage to the eye. CL800BT MANUAL 3 Regulatory Information FCC compliance Information This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio Frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: CL800BT MANUAL 4 - Redirect or reposition the receiving antenna - Increase the separation between the equipment and receiver - Connect the equipment to a socket on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC WARNING: This equipment may generate or use radio- frequency energy. Changes or modifications to this equipment may cause harmful interference, unless such modifications are expressly approved in the instruction manual. The user’s license to operate this equipment may be revoked if an unauthorized change or modification is made. RF Exposure Information: The antenna used for this transmitter must be installed at a distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. CE : EN300328 EN301489 EN60950 CL800BT MANUAL 5 Laser Safety: Product is certified by the manufacturer to comply with DHHS Rules 21 CFR Subchapter J. Applicable at the date of manufacture. Environmental Notice This product does not any materials specified harmful to the human body. At the end of this product’s service life, please separate with the life waste and discharge or go to the Celluon service center for environmental protection. CL800BT MANUAL 6 Battery Information Battery service life: 220 minutes continuous use (max) Capacity: 830mAh (max) @ 3.7V Charging the Battery Use the adapter supplied for connection to the power supply. The battery will now start charging. Charging time: 150 min Caution - Use of any other adapter may cause the battery to explode. - After purchasing the product, charge the battery before use. - Charging time is dependent on ambient temperature i.e. it may be longer or shorter in extreme heat or cold. - It is possible that the battery is not fully charged even when the charging indicator is illuminated. - Since battery belongs to expendable supplies, service life gradually shortens after several uses. CL800BT MANUAL 7 Table Contents 1. FEATURES...................................................................................9 2. COMPONENTS ..........................................................................10 3. PARTS AND THEIR FUNCTIONS .............................................11 3.1 FRONT.................................................................................. 11 3.2 REAR....................................................................................12 3.3 TOP......................................................................................13 4. HOW TO OPERATE ...................................................................14 4.1 INSTALLATION..........................................................................14 4.2 IN BLUETOOTH MODE............................................................15 5. HOW TO INSTALL, REMOVE AND USE SOFTWARE .............15 5.1 POCKET PC ............................................................................15 5.1.1 System Requirements .................................................15 5.1.2 Installation/Upgrading/Uninstalling the Driver ..............15 5.1.3 Connection Method......................................................18 5.1.4 Disabling the Projection Keyboard Sound ...................22 5.1.5 PK Settings Application................................................23 5.1.6 Tutorial .........................................................................33 5.1.7 Shortcut Icon Keys.......................................................34 5.1.8 Function Key and Ctrl Key ...........................................35 CL800BT MANUAL 8 5.2 PALM OS ............................................................................36 5.2.1 System Requirements .................................................36 5.2.2 Installation/Upgrading/Uninstalling...............................36 5.2.4 PK Settings ..................................................................44 5.2.5 PK Tutorial ...................................................................49 5.2.6 Shortcut Icon Keys.......................................................52 5.2.7 Shortcut Keys ..............................................................53 6. KEYBOARD LAYOUT................................................................55 7. TYPING LATIN LETTERS AND ADDITIONAL CHARACTERS .55 8. ADJUSTING KEY SENSITIVITY............…

Text truncated - open the document above for the full version.

AA BB CC DD EE 4 4 3 3 2 2 1 1 Title Size Document Number R ev Date: Sheet of Bluetooth Part 0.3 Celluon CL800BT A4 34 Tuesday, May 17, 2005 PP-CK150KeyboardPatternProjectorSM-CK150 KeyboardSensorArray SensorControlLogic ImageProcessor ROM RAM Interface Control Logic LS-CK150KeyboardLightSource Projection Control Signals Light Source Control Signals RS-232Interface 3.3V_3.0V_2.5VReset Bluetooth SerialConnctor ANT PowerPart Reset Part ChargerPart 830mAh LI-ION DC 5V 1A DC INPUT 48Mhz 1 2

CELLUON, INC. IT Venture Tower West 16F, 78 Garak-bondong, Songpa-Gu, Seoul, 138-803 South Korea Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R) and Section §552(b)(4) of the Freedom of Information Act, CELLUON, INC. requests confidentiality for the following products: FCC ID Number Product Title / Model TCLCL800BT Projection Keyboard / CL800BT For the product stated above, we request that the following information be held confidential: 1) Schematic diagrams 2) Bill of materials (Part List) No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain CELLUON, INC. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our products. This material is not customarily available to the general public and we request that it be withheld from public inspection. Sincerely, Eric Lee / Director

SK TECH CO., LTD. Page 1 of 2 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT

SK TECH CO., LTD. Page 1 of 1 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER ∫∫∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase.

SK TECH CO., LTD. Page 1 of 1 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT FCC ID Label Sample

SK TECH CO., LTD. Page 1 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT Internal Photographs of EUT SK TECH CO., LTD. Page 2 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 3 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 4 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 5 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 6 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 7 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 8 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 9 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT SK TECH CO., LTD. Page 10 of 10 SKT SKTFCE-051214-100 FCC ID : TCLCL800BT

Specification No. AEC_CPK_110516_01 Messrs : Celluon Approval Sheet for Product Specification Issued Date : May. 12. 2005 Product Description : SMD Type Chip Antenna Customer Part No. : AUTO Part No. : AEC_CPK_001 Date : Company : Dept. : Approved by (Signature) (Type) The duplicate of this specification shall be returned to us with your authorized signature. Unless it reaches us by June. 15, 2005 it shallbe mutually understood that this specifications have been duly approved by you. Technical Dept. Prepared by (Signature) (Type) Approved by (Signature) (Type) Manager Product Engineering Section Antenna Products Department Auto Electronic Corp. (Company name/Dept.) AUTO ELECTRONIC CORP. Specification Sheet ObjectChip AntennaREV. 1.0 Page 1 of 6 Model NameAEC_CPK_001Date May. 12, 2005 SystemBluetooth ModuleWritten by S.O.Hong Electrical Specification Frequency2.4 2.485[GHz]～ Bandwidth200[MHz] V.S.W.R1.9:1[max] Gain (max)0[dBi] Input Impedance50[ ]Ω PolarizationLinear Mechanical Specifications Size11×5×1.6[mm] Weight0.2[g] Radiator MaterialCopper Operation Temperature-30 90[ ]～°C Operation Humidity10 90[%]～ Option Others이 반대이기 때문에를 뒤집어서 실장- Land PatternAntenna AUTO ELECTRONIC CORP. 1. Dimension 11mm(L)×5(W)×1.6(H). Dimension Bottom land pattern * The chip antenna is required to be used on our suggested PCB. Recommended landpattern (1) Feed point (2) NC(Mount points) (3) GND (1) (2) (3) (2) AUTO ELECTRONIC CORP. 2. Characteristics Return Loss (S 11 ) Smith Chart AUTO ELECTRONIC CORP. VSWR 3. Radiation Pattern E-Plane (90°) AUTO ELECTRONIC CORP. E-Plane (0°) H-Plane AUTO ELECTRONIC CORP. 4. Taping Dimension of Tape (Plastic Case).

SK TECH CO., LTD. Page 1 of 18 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT FCC-Certificate of Compliance Test Report No.: SKTFCE-051214-100 NVLAP CODE : 200220-0 Applicant: CELLUON, INC. Applicant Address: IT Venture Tower West 16F, 78 Garak-bondong, Songpa-Gu, Seoul, Korea 138-803 Manufacturer : CELLUON, INC. Manufacturer Address: IT Venture Tower West 16F, 78 Garak-bondong, Songpa-Gu, Seoul, Korea 138-803 Product: Projection Keyboard FCC ID: TCLCL800BT Model No.: CL800BT Receipt No.: SKTEU05-0743 Date of receipt: Nov. 23, 2005 Date of Issue: Dec. 14, 2005 Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 2003 Rule Parts: FCC part 15 Subpart B Equipment Class : Class B Digital Device Peripheral Test Result: The above mentioned product has been tested and passed. Prepared by: S.Y.Ye Tested by:S.B.Ko/Engineer Approved by: D.H.Kang /Manager& Chief Engineer Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 18 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT 》》 Contents 《《 Contents 2 List of Tables 2 List of Figures 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Date 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical Characteristics 5 3.2 Submitted Documents 5 4. Measurement Conditions 6 4.1 Modes of Operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 8 4.5 Uncertainty 9 5. EMISSION Test 12 5.1 Conducted Emissions 12 5.2 Radiated Emissions 17 》List of Tables Table 1 List of test and measurement Equipment 4 Table 2 Test Data, Radiated Emissions 18 》List of Figures Figure 1 Spectral Diagram, LINE-PE 13 Figure 2 Test Data, LINE-PE 14 Figure 3 Spectral NEUTRAL –PE 15 Figure 4 Test Data, NEUTRAL-PE 16 SK TECH CO., LTD. Page 3 of 18 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK Tech Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ISO/IEC 17025 for general requirements for the competence of testing and calibration laboratories. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200220-0 and DATech for DAR-Registration No.:DAT-P-076/97-01 SK TECH CO., LTD. Page 4 of 18 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment z Conducted Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESHS10 862970/019 09.2006 Artificial Mains Network ESH2-Z5 834549/011 08.2006 EMI Receiver ESHS10 835871/002 09.2006 Artificial Mains Network ESH3-Z5 836679/018 08.2006 z Radiated Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESVS 10 825120/013 09.2006 EMI Receiver ESVS 10 834468/008 09.2006 Spectrum Analyzer R3361A 11730187 09.2006 Amplifier 8447F 3113A05153 08.2006 Log Periodic Antenna UHALP9107 1819 11.2006 Biconical Antenna BBA9106 91031626 11.2006 Open Site Cable N/A N/A N/A Antenna Turntable Driver 5907 N/A N/A Antenna Turntable controller 5906 N/A N/A Amp & Receiver connection cable N/A N/A N/A Amp & Spectrum connection cable N/A N/A N/A 50Ω Switcher MP59B 6100214538 N/A 2.3 Test Date Date of Application : Nov. 23, 2005 Date of Test : Dec. 05, 2005 ~ Dec. 13, 2005 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 5 of 18 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT 3. Description of the tested samples The EUT is a Projection Keyboard with Bluetooth communication. This model is made possible by electronic perception technology. The electronic perception technology shows your fingers move and translates into keystrokes in the devices. 3.1 Rating and Physical Characteristics Keyboard Project Items Specifications Light source Red Laser diode Keyboard layout 17mm QWERTY layout Keyboard size Approx. 241mm* 106mm Keyboard position Approx. 100mm from keyboard device Projection surface Non-reflective, opaque flat surface Visibility Visible in 1000-5000 lux ambient light Keyboard Sensor Items Specifications Illumination Visible in incandescent light of 1800 lux or more Detection rate Up to 400 characters per minute Effective Key stroke Approx.2mm Operating surface Any flat surface Electrical Condition Items Specifications Power source Integral lithium battery Battery capacity 830mAH(Max)@3.7V Adapter Rating 1A@ 5 V Interface RS232C serial Bluetooth v1.1 class2 Power consumption Max. 3W @5V Environmental Condition Items Specifications Operating temperature Approx. 0~35°C Storage temperature Approx. –20~50°C 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 6 of 18 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT 4. Measurement Conditions The power of EUT is supplied by rechargeable battery or AC/DC adaptor that is supplied “DC 5 V/ 1A”. 4.1 Modes of Operation The EUT is connected to Personal computer, using ATM manager prog…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT Test set up photos Photograph 1: Setup for Conducted Emissions SK TECH CO., LTD. Page 2 of 2 SKT SKTFCE-051214-100 FCC ID :TCLCL800BT Photograph 2: Setup for Radiated Emissions
