Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
User Manual Table of Contents1. Safety Precautions FCC Compliance Information FCC Class Notice FCC Caution FCC RF Radiation Exposure Statement Industry Canada Statement CE Caution IEC-60825-1 Caution 2. Certifications3. Environmentally Friendly Disposal and Recycling4. Package Contents 5. Product Features6. Identifying Parts7. Connecting PicoAir a. Compatible Operating Systems b. How to Connect c. Switching Connection Mode8. Making Adjustments a. Volume Adjustment b. Speaker / Earphone Usage c. Laser Alignment9. Charging the PicoAir10. Troubleshooting 11. Specifications12. Warranty 1. Safety PrecautionsThis product is not waterproof – avoid using it near water or wet places.There is a risk of malfunction if product is used in places where sudden or extreme temperature changes occur.Applying excessive force or impact to this product may result in product damage, and will void warranty.Never attempt to disassemble or service this product yourself. Doing so can result in electrical shock and void warranty.This is a Class 3R Laser product. For your safety, do not stare directly into the laser source. Doing so could damage your eyes . FCC Compliance Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:1. This device may not cause harmful interference to another device.2. This device must accept any interference received, including interference that may cause undesired operation.FCC Class NoticeThis equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to Part15 of the FC C Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a res idential environment. This equipment generates, uses, and radiates radio frequency energy, and if not installed and used in accordance with the instr uctions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur with special installation.If this equipment does cause interference to radio or television reception, which can bedetermined by turning the equipment off and on, the user is encouraged to correct theinterference by one of the following measures: Reorient or relocate the receiving antenna. Increase separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from which the receiver is connected. Consult the dealer or an experienced radio/TV technician. FCC CautionAny changes or modifications in construction of this device which are not expressly approved by the party responsible for compl iance could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement:This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or trans mitter. Industry Canada StatementThis device complies with Industry Canada license- exempt RSS standard(s).Operation is subject to the following two conditions:(1) This device may not cause interference.(2) This device must accept any interference, including interference that may cause undesired operation of the device. CE CautionRisk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.IEC-60825-1 CautionUse of control or adjustments or performances of procedures other than those specified here in may result in hazardous radiatio n exposure. KC : MSIP-CMM-CLK-PICOAIR FCC ID : TCLPICOAIR CE1177 compliant RoHS IC No : 10211A-PICOAIR CLASS 3R LASER PRODUCT IEC-60825-1 : Class 3R Laser 2. Certifications 4. Package Contents3. Environmentally Friendly Disposal and Recycling To protect the environment, dispose this product separately from household waste once it has reached its end of life, or take it to your local electronic waste disposal center.Built-in Battery Use supplied USB power adapter to begin charging the battery. Battery status is indicated by four blue LED indicators while charging. (4 LED : 100% / 3 LED : 75% / 2 LED : 50% / 1 LED : 25%) 3140 mAh @ 3.7V Battery Capacity Approx. 150 minutes (with continuous use) Battery Operating Time Rechargeable Lithium-ion Polymer Battery Battery Type Approx. 270 minutes Battery Charging Time Charging the Battery PicoAir User Manual Power Adapter Tripod Pouch 5. Product FeaturesPicoAir is a laser-based pico projector that easily fits in your pocket for superior portability. It allows you to project con tents in your mobile devices onto any surface via Miracast or DLNA capability. 6. Identifying Parts Reset Button FCC ID : TCLPICOAIR CE1177 KC : MSIP-CMM-CLK-PICOAIRIC : 10211A-PICOAIRModel : PicoAir DC : 5V 2A Celluon, Inc. Made in Korea Touch-sensitive Volume UpTouch-sensitive Volume DownBacklit Battery Indicator Light Speaker 3.5mm Audio Out Miracast or DLNA Switch CHARGE – Micro USB port for charging Battery Status Indicator Power Button Select Button 7. Connecting PicoAira. Compatible Operating Systems Miracast DLNA For Wireless Connection Android OS 4.2 or laterWindows OS 8.1 or higherAny OS that supports Screen Mirroring functionality Any digital devices that support DLNA protocol * Using DLNA connection requires downloading DLNA streaming app from the App Store or Play Store. b. How to ConnectUsing Miracast : The Miracast capability is called different names on difference devices. (Samsung/Sony – Screen Mirroring , HTC – Media Output) Please find this capability in the settings app on the device.1. Turn on PicoAir by pressing power button for 2-3 seconds. 2. Celluon logo will display upon power on. 3. After 20-30 seconds, “Ready to Connect” screen will display after Celluon logo. M/D 4. On a desired mobile device, find and select Screen Mirr…
Text truncated - open the document above for the full version.
CELLUON, INC. Ace High-END Tower 1101 235-2, Guro-Dong, Guro-Gu, Seoul, Korea, 152-740 Date: January 13, 2015 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Timco Engineering, Inc. Certification Division 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA To whom it may concern: I, the undersigned, hereby authorize Technical Manager Issac Jin of MOVON CORPORATION and here after referred to as MOVON CORPORATION , to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these m atters. Any and all acts carried out by Technical Manager Issac Jin of MOVON CORPORATION on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing MOVON CORPORATION as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; CELLUON, INC. Ace High-END Tower 1101 235-2, Guro-Dong, Guro-Gu, Seoul, Korea, 152-740 e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Chun bae, Park / Manager CELLUON, INC. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.
CELLUON, INC. Ace High-END Tower 1101 235-2, Guro-Dong, Guro-Gu, Seoul, Korea, 152-740 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: TCLPICOAIR To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics / Block Diagram / Operational Description / Parts List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. 2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos / Internal Photos / Test Setup Photos / User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Sincerely Yours, Chun bae, Park / Manager CELLUON, INC.
External photos of EUT Front view of EUT Rear view of EUT Side view of EUT Side view of EUT Side view of EUT Side view of EUT
Label information FCC ID: TCLPICOAIR CE1177 KC: MSIP-CMM-CLK-PICOAIR IC: 10211A-PICOAIR Model: PicoAir Input: 5V 2A Celluon, Inc. Made in Korea
Internal photos of EUT Main board (Front) Main board (Rear) WLAN module board (Front) WLAN module board (Rear) Internal photo (Front) WLAN Module – Internal PCB Antenna
MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (1) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. FCC Part 15 Subpart C §15.247 RSS-210 ISSUE No. :8 Test Report Equipment Under Test Pico projector Model Name Pico Air Applicant CELLUON, INC. FCC ID TCLPICOAIR IC 10211A-PICOAIR Manufacturer CELLUON, INC. Date of Test(s) 2014. 12. 29 ~ 2015. 01. 12 Date of Issue 2015. 01. 14 In the configuration tested, the EUT complied with the standards specified above. Issue to Issue by CELLUON, INC. Ace High-End Tower 1101 235-2, Guro-Dong, Guro-Gu, Seoul, Korea, 152-740 Tel.: +82-2-6220-3886 Fax: +82-2-6220-3899 MOVON CORPORATION 498-2, Geumeo-ro, Pogok-eup, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea, 449-812 Tel.: +82-31-338-8837 Fax: +82-31-338-8847 MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (2) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Revision history Revision Date of issue Description Revised by -- Jan. 14, 2015 Initial -- MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (3) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Table of contents 1. GENERAL INFORMATION ............................................................................................. 5 1.1. DETAILS OF APPLICANT .................................................................................................................................... 5 1.2. SUMMARY OF TEST RESULTS ............................................................................................................................ 5 2. EUT DESCRIPTION ........................................................................................................ 6 2.1. DECLARATIONS BY THE MANUFACTURER ............................................................................................................ 6 2.2. DETAILS OF MODIFICATION ............................................................................................................................... 6 3. MEASUREMENT EQUIPMENT ...................................................................................... 7 4. TRANSMITTER RADIATED SPURIOUS EMISSIONS AND CONDUCTED SPURIOUS EMISSIONS .................................................................................................................. 8 4.1. TEST SETUP ................................................................................................................................................... 8 4.1.1. TRANSMITTER RADIATED SPURIOUS EMISSIONS ............................................................................................... 8 4.2. LIMIT ............................................................................................................................................................. 9 4.3. TEST PROCEDURES ....................................................................................................................................... 11 4.3.1. TEST PROCEDURES FOR RADIATED SPURIOUS EMISSIONS ............................................................................... 11 4.3.2. TEST PROCEDURES FOR CONDUCTED SPURIOUS EMISSIONS ........................................................................... 11 4.4. TEST RESULT ............................................................................................................................................... 12 4.4.1. SPURIOUS RADIATED EMISSION ................................................................................................................... 12 4.4.2. SPURIOUS RADIATED EMISSION ................................................................................................................... 18 4.4.3. SPURIOUS RADIATED EMISSION ................................................................................................................... 21 THE AMPLITUDE OF SPURIOUS EMISSIONS FROM INTENTIONAL RADIATORS AND EMISSIONS FROM UNINTENTIONAL RADIATORS WHICH ARE ATTENUATED MORE THAN 20 DB BELOW THE PERMISSIBLE VALUE NEED NOT BE REPORTED UNLESS SPECIFICALLY REQUIRED ELSEWHERE IN THIS PART . ..................................................................................................................... 23 THE AMPLITUDE OF SPURIOUS EMISSIONS FROM INTENTIONAL RADIATORS AND EMISSIONS FROM UNINTENTIONAL RADIATORS WHICH ARE ATTENUATED MORE THAN 20 DB BELOW THE PERMISSIBLE VALUE NEED NOT BE REPORTED UNLESS SPECIFICALLY REQUIRED ELSEWHERE IN THIS PART . ..................................................................................................................... 24 THE AMPLITUDE OF SPURIOUS EMISSIONS FROM INTENTIONAL RADIATORS AND EMISSIONS FROM UNINTENTIONAL RADIATORS WHICH ARE ATTENUATED MORE THAN 20 DB BELOW THE PERMISSIBLE VALUE NEED NOT BE REPORTED UNLESS SPECIFICALLY REQUIRED ELSEWHERE IN THIS PART . ..................................................................................................................... 25 THE AMPLITUDE OF SPURIOUS EMISSIONS FROM INTENTIONAL RADIATORS AND EMISSIONS FROM UNINTENTIONAL RADIATORS WHICH ARE ATTENUATED MORE THAN 20 DB BELOW THE PERMISSIBLE VALUE NEED NOT BE REPORTED UNLESS SPECIFICALLY REQUIRED ELSEWHERE IN THIS PART . ..................................................................................................................... 26 4.4.4. BAND EDGE .............................................................................................................................................. 27 4.4.5 CONDUCTED POWER LINE TEST ..................................................…
Text truncated - open the document above for the full version.
MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (76) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 5. Receiver radiated spurious emissions 5.1. Test setup Same as clause 5.1. 5.1.1. Receiver radiated spurious emissions Same as clause 5.1.1 5.2. Limit According to §15.109(a), Except for Class A digital devices, the field strength of radiated emission from unintentional radiator at a distance of 3 m shall not exceed the following values: Frequency (㎒) Distance (Meters) Radiated (㏈㎶/m) Radiated (㎶/m) 0.009–0.490 300 See the remark 2400/F(㎑) 0.490–1.705 30 24000/F(㎑) 1.705–30.0 30 30 30 - 88 3 40.0 100 88 – 216 3 43.5 150 216 – 960 3 46.0 200 Above 960 3 54.0 500 5.3. Test procedures Same as clause 5.3. Radiated emissions from the EUT were measured according to the dictates of ANSI C63.4:2003 In case of the air temperature of the test site is out of the range is 10 to 40°C before the testing proceeds the warm-up time of EUT maintain adequately 5.3.1. Test procedures for radiated spurious emissions Same as Clause 5.3.1. MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (77) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 5.4. Test results Ambient temperature: 23 °C Relative humidity: 42 % R.H. 5.4.1. Spurious radiated emission. The frequency spectrum from 30 ㎒ to 26 ㎓ was investigated. Emission levels are not reported much lower than the limits by over 30 ㏈. All reading values are peak values. Operation mode: 802.11b/g/n20 mode A. LOW channel (2 412㎒) Radiated emissions Ant.Correction factors Total Limit Frequency (㎒) Reading (㏈㎶) Detector mode Pol. Ant. factor (㏈/m) Amp + CL (㏈) Actual (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1703.50 45.59 Peak H 28.86 43.65 30.8 74.00 43.20 - - - - - - - - - B. MID channel (2 437㎒) Radiated emissions Ant.Correction factors Total Limit Frequency (㎒) Reading (㏈㎶) Detector mode Pol. Ant. factor (㏈/m) Amp + CL (㏈) Actual (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1711.85 48.30 Peak H 28.86 43.65 33.51 74.00 20.49 - - - - - - - - - C. High channel (2 462 ㎒) Radiated emissions Ant.Correction factors Total Limit Frequency (㎒) Reading (㏈㎶) Detector mode Pol. Ant. factor (㏈/m) Amp + CL (㏈) Actual (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1705.60 45.01 Peak H 28.86 43.65 30.22 74.00 43.78 - - - - - - - - - ※ Remark: Actual = Reading + Ant. factor + Amp + CL (Cable loss) MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (78) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Operation mode: 802.11a/an20/an40 mode A. LOW channel (5 745㎒) Radiated emissions Ant.Correction factors Total Limit Frequency (㎒) Reading (㏈㎶) Detector mode Pol. Ant. factor (㏈/m) Amp + CL (㏈) Actual (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1766.55 43.31 Peak H 28.86 43.65 28.52 74.00 45.48 - - - - - - - - - B. MID channel (5 785㎒) Radiated emissions Ant.Correction factors Total Limit Frequency (㎒) Reading (㏈㎶) Detector mode Pol. Ant. factor (㏈/m) Amp + CL (㏈) Actual (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1759.45 46.99 Peak H 28.86 43.65 32.2 54.00 21.80 - - - - - - - - - C. High channel (5 805 ㎒) Radiated emissions Ant.Correction factors Total Limit Frequency (㎒) Reading (㏈㎶) Detector mode Pol. Ant. factor (㏈/m) Amp + CL (㏈) Actual (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1756.05 47.06 Peak H 28.86 43.65 32.27 74.00 41.73 - - - - - - - - - ※ Remark: Actual = Reading + Ant. factor + Amp + CL (Cable loss) MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (79) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 6. 6 ㏈ bandwidth & 99 % bandwidth measurement 6.1. Test setup EUT Spectrum analyzer 6.2. Limit According to §15.247(a)(2), systems using digital modulation techniques may operate in the 902~928 ㎒, 2 400~2 483.5 ㎒, and 5 725~5 825 ㎒ bands. The minimum of 6 ㏈ Bandwidth shall be at least 500 ㎑ 6.3. Test procedure 1. The 6 ㏈ band width was measured with a spectrum analyzer connected to RF antenna connector (conducted measurement) while EUT was operating in transmit mode at the appropriate center frequency. The analyzer center frequency was set to the EUT carrier frequency, using the analyzer. Display Line and Marker Delta functions, the 6 ㏈ band width of the emission was determined. 2. The bandwidth of the fundamental frequency was measured with the spectrum analyzer using RBW = 100 ㎑, VBW = 100 ㎑, Span = 5 ㎒. MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (80) of (126) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 6.4. Test results Ambient temperature: 23 °C Relative humidity: 51 % R.H. Mode Frequency(㎒) 6 ㏈ bandwidth(㎒) 99% bandwidth(㎒) 802.11b (Ant 1) 2 412 10.12 13.89 2 437 10.12 14.02 2 462 10.25 14.15 802.11b (Ant 2) 2 412 10.59 13.85 2 437 10.46 14.02 2 462 10.51 14.15 802.11g (Ant 1) 2 412 16.50 16.41 2 437 16.50 16.41 2 462 16.50 16.50 802.11g (Ant 2) 2 412 16.50 16.41 2 437 16.50 16.50 2 462 16.50 16.50 802.11n_20 (MIMO) 2 412 17.76 17.63 2 437 17.63 17.63 2 462 17.76 17.63 802.11a (Ant 1) 5 745 16.24 16.50 5 785 16.45 16.50 5 805 16.45 16.45 802.11a (Ant 2) 5 745 16.50 16.50 5 785 16.45 16.50 5 805 16.50 16.45 802.11an_20 (MIMO) 5 745 17.54 17.63 5 785 17.32 17.67 5 805 17.28 17.67 802.11an_40 (MIMO) 5 755 36.40 36.11 5 795 35.89 36.04 MOVON CORPORATION Report Number: MOV-15-RF-I006 Page : (81) of (126) The results sh…
Text truncated - open the document above for the full version.
Test setup photo of EUT A. Setup photo of EUT Photo of radiated spurious emission at below 30 ㎒ Photo of radiated spurious emission at 30 ㎒ ~ 1 000 ㎒ Photo of radiated spurious emission at above 1 000 ㎒ Photo of Conducted emission at below 30 ㎒
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 2 | 15C | 5.75 GHz - 5.80 GHz | 3.40 mW |

Pico projector
Equipment Class
DTS - Digital Transmission System
PROJECTION KEYBOARD
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
PROJECTION KEYBOARD
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
PROJECTION KEYBOARD
Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
Projection Keyboard
Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
