TDU-MF620BLUETOOTH MONO HEADSET

HEADSET MF620 WIRELESS User Manual Bluetooth Headset Ear Hook AC Adapter Ear Rubber User manual Using your Headset TURNING ON/ OFF Turning On : Press the Multi-Function button for 2 seconds. Turning Off : Press the Multi-Function button for 4 seconds. What’s in the box? Getting to know the MF620 -1- English Multi-Function Button Indication LED Ear Rubber Microphone Speaker Charging port Volume Button English CHARGE THE BATTERY Before using your headset, charge the battery completely. Connect an adapter to the charging port of the headset and plug it into home power outlet. The Red LED remains on while the headset is charging and LED turns off when charging is completed. [NOTE] Please use supplied power adaptor only. CHECKING THE BATTERY LEVEL Press the Volume button for 4 seconds, then the headset will announces the Battery level. LOW BATTERY ALARM When the battery is low, headset will alarm with beep sound every 30 seconds. Once you hear beep alert, please charge immediately. -2- 2 sec.4 sec. Turning On Turning Off PAIR THE HEADSET TO YOUR MOBILE PHONE 1. Turn the headset on. When turned on for the first time, headset will go to pairing mode automatically. (LED will blink Blue and Red) Or Press the Multi-Function buttons for 4 seconds until LED blink as Blue and Red. 2. Search the headset via your mobile phone and confirm it when the connection confirmation message appears on your mobile phone. PIN code is “0000” .(4 zeros) SIMPLE PAIRING: If your mobile phone supports Bluetooth version spec 2.1, you don’t need to put PIN code to pair. (This function is only available when your mobile phone supports Bluetooth version 2.1) PROXIMITY PAIRING 1. Set your mobile phone to Bluetooth discoverable mode or set visibility on. (See your phone’s manual for the detailed instruction) 2. Set your headset to pairing mode then press the Volume button twice. 3. Place the headset near to (10 cm) to your mobile phone. 4. Headset will pair automatically with your mobile phone. -3- English Input PIN Code 0000 Active Dev List Model Name MF620 EASY PAIRING : The headset goes into pairing (proximity pairing) mode automatically the first time you use it. MAKING A CALL 1. Last call-Redialing : Press the Multi-Function button. 2. Voice Dialing : Press the Multi-Function button for 2 seconds, then voice dialing is activated. If you want to cancel voice dialing, press the Multi-Function button for 2 second during the voice dial Mode. [NOTE] Please make sure that your phone supports voice dialing feature. (See your phone’s manual for the detailed instruction) RECEIVING A CALL Press the Multi-function button. REJECTING A CALL Press the Multi-function button for 2 seconds. ENDING A CALL Press the Multi-Function button during the call or just press the “End” button on the phone. -4- English TRANSFERRING A CALL To transfer a call from headset to your mobile phone and vice versa, press the Multi-Function button on headset during the call for 2 seconds. ADJUSTING A VOLUME There are 6 volume levels that cycle as you press the Volume button. When the highest level is reached, you can hear the beep. Press the Volume button again, the volume level cycles back down to the lowest. MIC MUTE If you press the Volume button for 2 seconds, the microphone will be muted and you will hear a beep every 5 seconds during the mute mode. [NOTE] The MIC mute mode can be deactivated by pressing Volume button for 2 seconds. CALL WAITING To activate call waiting function, you must subscribe to call waiting through your service provider, and your phone must support the hands-free profile. To put your current call on hold and switch to the waiting call, press Multi-Function button twice. If you want to switch back to the current call, press Multi-Function button twice again. -5- English MULTIPOINT : Using the Headset with two phones [NOTE] Some mobile phones are not available for Multipoint. 1. Multi-point Connect Set the headset into pairing mode first. After then search headset from each mobile phones at the same time. Please connect first mobile phone. Once the connection is completed, please connect the second mobile phones. [NOTE] Some mobile phones needs to connection process at the same time 2. Making a call [via the second mobile phone] Press the volume button twice shortly for last call-redialing from the second mobile phone. Press the volume button for about 2 seconds to activate the voice dialing of the second mobile phone. [NOTE] Making a call via the first mobile phones, please follow the same instruction as described on “MAKING A CALL”. 3. Receiving a call : Please use the general rule as you receive calls [NOTE] Each mobile phone plays different ring tones. 4. Call Waiting : For details refer to the Call waiting section on page 5. -6- English RESETTING THE Headset Press and hold Multi-Function button and volume button simultaneously for 4 seconds then all information in headset will be deleted. [NOTE] Resetting is only possible when standby mode after disconnecting with your mobile phone. Status indication StatusLED indicationAlarm or Voice announcement Power onBlue LED blinks 3 times.Power ON Pairing modeBlue & Red LED blink repeatedly.Beep sound ConnectableBlue LED blinks 1 time every 5 seconds Disconnected ConnectedBlue LED blinks 2 times every 5 seconds Connected Incoming callBlue LED blinks 2 times in every 2 seconds Ring tone Active CallBlue LED blinks 3 times every 5 seconds Low BatteryBlue LED turns to RedAlarm every 30 seconds Battery LevelBattery High Battery Medium Battery Low ChargingRed LED turns on Charging CompletedRed LED turns off -7- -8- Specifications Model Name MF620 Bluetooth Core Spec Bluetooth Specification 3.0 Profile HSP/HFP 1.5 Carrier Frequency 2402 MHz to 2480 MHz Modulation Method GFSK, 1Mbps, 0.5BT Gaussian Maximum Data Rate Asynchronous : 723.2 kbps / 57.6 kbps Synchronous : 433.9 kbps / 433.9 kbps Bluetooth Class Class 2 Hopping 1600 hops/sec, 1MHz Channel Space Transmit Power 1 dBm Coverage Range 10 …

Text truncated - open the document above for the full version.

MOVON CORPORATION 6Fl., Hyunjuk Bldg., 140-28, Samseong-Dong, Gangnam-Gu, Seoul, Korea Date: Mar. 31, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Timco Engineering, Inc. Certification Division 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA To whom it may concern: I, the undersigned, hereby authorize Technical Manager Tony Nam of MOVON CORPORATION and hereafter referred to as MOVON CORPORATION , to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these m atters. Any and all acts carried out by Technical Manager Tony Nam of MOVON CORPORATION on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing MOVON CORPORATION as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; MOVON CORPORATION 6Fl., Hyunjuk Bldg., 140-28, Samseong-Dong, Gangnam-Gu, Seoul, Korea e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Dominic So / Manager MOVON CORPORATION REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

MOVON CORPORATION 6Fl., Hyunjuk Bldg., 140-28, Samseong-Dong, Gangnam-Gu, Seoul, Korea Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: TDU-MF620 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operation Description Parts List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Dominic So MOVON CORPORATION August. 9, 2011

External photos of EUT Front view of EUT Rear view of EUT Top view of EUT Bottom view of EUT Side view of EUT

Internal photos of EUT Antenna view of EUT Internal view of EUT Chip Antenna Top view of Main PCB Bottom view of Main PCB

To : 모본 주식회사 귀중 製 品 規 格 承 認 願 製品名 Qualification of Products Approval Di l t i Chi A t Rm. 907, Union-Center, 837-11 Yeoksam-dong, Gangnam-Ku, Seoul, Korea Product 2011년 4월 21일 製 品 名 Dielectric Chip Antenna SEJONG TRONICS CO.,LTD Type TEL : 82)2-586-6012 FAX : 82)2-586-6082 型 名 申 請 日 Date AMAN301512ST01 승 인 원 품명 : Dielectric Chip Antenna Part No. : AMAN301512ST01 모델명 : MF210 (BT) 2011. 04. 21 주식회사 아 모 텍 모본주식회사 입안 심사 결정 일자 / / / TBBP-A FREE 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 2/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 목 차 *비고 : CTQ항목 및 공정능력지수, Sample 제작 현황 (P.P) 1. 제/개정 이력 ----------------------------- 3 2. 제품규격 ----------------------------- 4 2.1 전기적 특성 2.2 기구적 특성 2.3 모델 및 LOT 표기법 2.4 마킹 표기법 3. 시험방법 ----------------------------- 8 3.1 VSWR 규격 3.2 측정방법 4. 초기검사 성적서 ----------------------------- 9 5. 납땜조건(권고사항) ----------------------------- 11 5.1 납땜 온도 조건(무연납) 5.2 PCB 패턴 설계 조건(권고사항) 6. 구조 및 재질 ----------------------------- 12 6.1 재료사양 6.2 등가 회로 7. 주의 사항 ----------------------------- 12 8. 포장 사양 ----------------------------- 13 8.1 Carrier tape 사양 8.2 릴(Reel)사양 8.3 박스 포장 사양 8.4 포장 라벨 사양 9. 관리 공정도 ----------------------------- 17 10. 유해물질 성적서 ----------------------------- 18 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 3/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 1. 제/개정 이력 Date Content Page 2011.04.21 최초 작성 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 4/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 2. 제품 규격 2.1전기적 특성 구분 항목 규격 비고 1 VSWR SET특성 최대 2.5:1 @ 2442 ± 42 MHz MF210 2 E.V.B특성 최대 4.0:1 @ 2442 ± 42 MHz EVB 3 JIG특성 최대 3.0:1 @ 2442 ± 42 MHz JIG 4 방사이득 (dBi) Avg. H 최소 -5.0 EVB E1 최소 -3.5 E2 최소 -3.5 Peak H 최소 1.2 E1 최소 1.4 E2 최소 1.4 5 방사패턴 Omni-directional - 6 임피던스 공칭 50 Ω ※ 방사이득은 Reference Test Board에서 2.400~2.490GHz에 매칭 후 측정. (SET_ MF210 에서 측정) 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 5/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) (E.V. board에서 측정) (측정 지그에서 측정) Passband VSWR Passband VSWR Passband VSWR JIG 특성 2400MHz 1.0~2.5 2442MHz 1.0~2.2 2484MHz 1.0~2.5 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 6/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) (Radiation Pattern : Set 상에서 측정) Peak Gain 1.16 dBi Avg.Gain -2.80 dBi 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 7/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 2.2기구적 특성 (외형 및 치수) 2.3모델 및 Lot 표기법 Model : (1) : AMOTECH ANTENNA (2) : 칩 크기(가로X세로X높이) (3) : 공용품, 예) STANDARD Type – ST (4) : 공용품 번호 (예 : 첫번째-01) Lot: (1) : 소체 성형년도 (2) : 소체 성형월 (3) : 유전율 예)1 : 9.5, 2 : 20.5 (4) : 소체 SIZE 예) A : 542012, B : 542015, C: 903012, D : 903015, E:903040, F: 903045, G:542020 (5) : TYPE별 소체의 월 생산번호 2.4 마킹 표기법 ◀ 5 0 (1) (2) (1) : 방향 식별 표시 (2) : 제조 주차 표시 (예: 1~52 - 1~52주) 구 분 항 목 치 수 (mm) 소체 L (가로) 3.0±0.15 W (세로) 1.5±0.1 H (높이) 1.2±0.1 Pattern L1 2.0±0.2 AMAN 301512 ST 01 (1) (2) (3) (4) XX XX X X XX (1) (2) (3) (4) (5) 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 8/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 3. 시험 방법 (VSWR 측정) 3.1 VSWR 규격 - 제품규격 참조 3.2 측정방법 A) RF Cable까지 Calibration을 한다. - Center frequency : 제품규격 참조 - Span : 800MHz - Number of point : 801 B) RF Cable과 측정지그의 SMA 커넥터를 연결한다. C) Format을 VSWR(SWR)로 설정한다. D) MARKER1, MARKER2, MARKER3을 설정하여 VSWR값을 확인한다. E) MARKER1,2,3의 VSWR값이 SPEC를 만족하는지 확인한다. 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 9/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 4. 초기 검사 성적서 제품명 Dielectric Chip Antenna 시험항목 VSWR, Length, Width, Height 모델명 AMAN301512ST01 (MF210) 시험조건 LOT NO. 시험일자 2011. 04 .11 검사 항목 VSWR @ 2442 - 42MHz (2400MHz) VSWR @ 2442 +42MHz (2484MHz) Length Width Height Pattern 외관검사 (mm) (mm) (mm) (mm) SPEC 3.0 : 1 3.0 : 1 3.0 ±0.15 1.5 ±0.10 1.2 ±0.10 2.0 ±0.20 (양호할것) 1 1.93 1.65 2.94 1.53 1.18 2.01 OK 2 1.82 1.63 2.96 1.54 1.20 2.08 OK 3 1.63 1.93 2.94 1.51 1.20 2.06 OK 4 1.85 1.66 2.98 1.53 1.19 2.00 OK 5 1.72 1.68 2.95 1.54 1.22 2.01 OK 6 1.82 1.61 2.97 1.53 1.20 2.03 OK 7 1.65 1.89 2.94 1.54 1.19 2.02 OK 8 1.82 1.62 2.94 1.54 1.19 2.04 OK 9 1.85 1.62 2.98 1.53 1.20 2.05 OK 10 1.85 1.98 2.93 1.53 1.23 2.05 OK 11 1.88 1.65 2.96 1.53 1.20 2.04 OK 12 1.82 1.62 2.96 1.54 1.20 2.05 OK 13 1.84 1.64 3.00 1.53 1.21 2.01 OK 14 1.65 2.00 3.00 1.54 1.20 2.02 OK 15 1.62 1.79 2.98 1.53 1.23 2.01 OK 16 1.61 1.95 2.95 1.53 1.22 2.07 OK 17 1.70 1.63 2.98 1.53 1.20 2.02 OK 18 1.74 1.60 2.95 1.53 1.22 2.01 OK 19 1.78 1.65 2.93 1.55 1.19 2.04 OK 20 1.78 1.65 2.94 1.54 1.20 2.09 OK 21 1.73 1.65 2.94 1.53 1.22 2.01 OK 22 1.66 1.90 2.95 1.55 1.19 2.01 OK 23 1.82 1.62 2.97 1.53 1.22 2.06 OK 24 1.76 1.63 3.00 1.54 1.20 2.01 OK 25 1.79 1.65 3.00 1.53 1.20 2.00 OK 26 1.72 1.67 2.98 1.53 1.22 2.04 OK 27 1.75 1.66 3.00 1.54 1.19 2.02 OK 28 1.76 1.67 2.94 1.54 1.21 2.00 OK 29 1.76 1.66 2.98 1.54 1.20 2.04 OK 30 1.62 1.82 3.00 1.53 1.21 2.00 OK 31 1.89 1.64 2.97 1.55 1.20 2.08 OK 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 10/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 32 1.83 1.63 2.98 1.53 1.22 2.00 OK 33 1.78 1.66 2.94 1.53 1.21 2.03 OK 34 1.74 1.64 2.96 1.54 1.21 2.05 OK 35 1.86 1.60 2.95 1.54 1.20 2.00 OK 36 1.89 1.63 2.94 1.54 1.20 2.01 OK 37 1.82 1.62 2.98 1.54 1.20 2.09 OK 38 1.84 1.64 2.97 1.53 1.24 2.04 OK 39 1.82 1.64 2.95 1.53 1.20 2.05 OK 40 1.89 1.62 2.96 1.54 1.20 2.08 OK 41 1.90 1.62 2.98 1.55 1.19 1.98 OK 42 1.76 1.65 3.00 1.54 1.20 2.09 OK 43 1.73 1.63 2.99 1.55 1.20 2.05 OK 44 1.74 1.67 2.98 1.52 1.21 2.04 OK 45 1.75 1.62 2.94 1.54 1.20 2.00 OK 46 1.85 1.66 2.96 1.53 1.21 2.02 OK 47 1.62 1.96 2.98 1.54 1.23 2.05 OK 48 1.76 1.68 2.98 1.53 1.20 2.06 OK 49 1.72 1.63 2.95 1.54 1.19 2.01 OK 50 1.62 1.89 2.97 1.53 1.23 2.00 OK AVG 1.78 1.69 2.97 1.54 1.21 2.03 - STDEV 0.09 0.12 0.02 0.01 0.01 0.03 - Cpk 4.82 3.79 1.80 2.73 2.40 1.95 - 판정 OK OK OK OK OK OK OK 제 품 승 인 원 PAGE DIELECTRIC CHIP ANTENNA 11/44 AMT-D-059(A4) 주식회사 AMOTECH AMECS 사업부 2004.12.10(Rev.0) 5. 납땜 조건 5.1 납땜 온도 조건(Pb-free) Solder paste : Ag/Sn/Cu:3.0/96.0/0.5 - 안테나의 특성 저하를 막기 위해 다음과 같은 납땜 조건을 지켜야 한다. - Reflow soldering 조건으로 납땜을 진행하여야 하며, Flow soldering을 하여서는 안 된다. - 비활성 Flux를 사용하여야 한다.(최대 Cl 함…

Text truncated - open the document above for the full version.

MOVON CORPORATION Report Number: MOV-11-RF-014 Page : (39) of (41) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 13. RF exposure evaluation 13.1. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in §1.1307(b) Limits for maximum permissible exposure (MPE) 13.2. Friis transmission formula Pd = (PoutxG)/(4xpixR 2 ) Where Pd = power density in ㎽/㎠ Pout = output power to antenna in ㎽ G = gain of antenna in linear scale Pi = 3.141 6 R = distance between observation point and center of the radiator in ㎝ Pd the limit of MPE, 1 ㎽/㎠. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Frequency range (㎒) Electric field strength(V/m) Magnetic field strength (A/m) Power density (㎽/㎠) Average time (A) Limits for Occupational / Control exposures 300 – 1 500 -- -- F/300 6 1 500 – 100 000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300 – 1 500 -- -- F/1 500 6 1 500 – 100 000 -- -- 1 30 MOVON CORPORATION Report Number: MOV-11-RF-014 Page : (40) of (41) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 13.3. Test result of RF exposure evaluation Test Item ： RF Exposure evaluation data Test Mode ： Normal operation 13.4. Output power into antenna & RF exposure evaluation distance Operating mode Frequency (㎒) Output average power to antenna (㏈m) Antenna gain (㏈i) Power density at 20㎝ (㎽/㎠) Limit (㎽/㎠) GFSK 2 402 -0.63 1.16 0.000 23 1 2 441 -0.62 1.16 0.000 23 2 480 -1.30 1.16 0.000 19 ※ Remark The power density Pd (5th column) at a distance of 20 ㎝ calculated from the friis transmission formula is far below the limit of 1 ㎽/㎠ .

MOVON CORPORATION Report Number: MOV-11-RF-014(2) Page : (1) of (44) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. FCC Part 15 Subpart B&C §15.247 Test Report Equipment Under Test Bluetooth Mono Headset Model Name MF620 Applicant MOVON CORPORATION FCC ID TDU-MF620 Manufacturer QINGDAO MOVON ELECTRONICS CO., LTD. Date of Test(s) 2011.07.20 ~ 2011.08.05 Date of Issue 2011.08.08. In the configuration tested, the EUT complied with the standards specified above. Issue to Issue by MOVON CORPORATION Hyunjuk Bldg., 140-28, Sanseong-dong, Gangnam-Gu, Seoul, Korea Tel.: +82 +2 2050 4670 Fax: +82 +2 539 5692 MOVON CORPORATION 194-1, Geumeo-ri, Pogok-eup, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea, 449-812 Tel.: +82 +31 338 8837 Fax: +82 +31 338 8847 MOVON CORPORATION Report Number: MOV-11-RF-014(2) Page : (2) of (44) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Revision history Revision Date of issue Description Revised by -- August. 8, 2011 Initial -- 1 August. 11, 2011 Radiated emissions 3 orthogonal planes test added in page 10.13. 20 Issac Jin 2 September. 6, 2011 Conducted emission test added in page 41. 42. 43 Issac Jin MOVON CORPORATION Report Number: MOV-11-RF-014(2) Page : (3) of (44) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Table of contents 1. ATTESTATION OF TEST RESULTS ............................................................................. 4 2. EUT DESCRIPTION ........................................................................................................ 5 3. INFORMATION ABOUT THE FHSS CHARACTERISTICS ............................................ 5 4. MEASUREMENT EQUIPMENT ...................................................................................... 6 5. TRANSMITTER RADIATED SPURIOUS EMISSIONS AND CONDUCTED SPURIOUS EMISSIONS .................................................................................................................. 7 7. 20 ㏈ BANDWIDTH MEASUREMENT & 99 % BANDWIDTH MEASUREMENT ........ 21 8. MAXIMUM PEAK OUTPUT POWER MEASUREMENT ............................................... 26 9. HOPPING CHANNEL SEPARATION ........................................................................... 30 10. NUMBER OF HOPPING FREQUENCY ...................................................................... 32 11. TIME OF OCCUPANCY(DWELL TIME) ..................................................................... 34 12. ANTENNA REQUIREMENT ....................................................................................... 38 13. RF EXPOSURE EVALUATION .................................................................................. 39 14. CONDUCTED EMISSION ........................................................................................... 41 15. TEST SETUP PHOTO OF EUT .................................................................................. 44 b( ) Yg lt *,:':Tf;ff "T:;},,, -RF-o 1 4(2) 1. Attestation of test results 1.1. Details of applicant Applicant : MOVON CORPORATON Address : Hyunjuk Bldg., 14Q-28, Sanseong-dong, Gangnam-Gu, Seoul, Korea Contact Person : Wood Park Telephone : +82+220504670 Fax : +82 +2 539 9666 1.2. Summary of test results The EUT has been tested according to the following specifications; X Abbreviation C Complied N/A Not applicable F Fail Approval Signatories Page : (4) of (44) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Section in FGC part 15 Description Result $15.205(a) s15.209 815.247(d) Transmitter radiated spurious emissions, Conducted spurious emission c $15.10e(a) Receiver radiated spurious emission c $15.247(a)(1) 20dB bandwidth and 99 % bandwidth c s15.247(bX1) Maximum peak output power c $15.2a7(a)(1) Frequency separation c $15.247(a)(1Xiii) Number of hopping frequency c $15.2a7@)(1Xiii) Time of occupancy(Dwell time) c s15.247(i) s1.1307(bX1) RF exposure evaluation c s15.207 Conductd emission c Test and Report Completed by : ReportApproval by: ,.)J )h lssac Jin Test Engineer MOVON CORPORATION Tony Nam Technical Manager MOVON CORPORATION MOVON CORPORATION Report Number: MOV-11-RF-014(2) Page : (5) of (44) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 2. EUT Description Kind of product Bluetooth Mono Headset Model MF620 Serial Number N/A Power supply DC 3.70 V Frequency range 2 402 ㎒ ~ 2 480 ㎒ Modulation technique GFSK Number of channels 79 Operating conditions - 20 °C ~ + 55 °C Antenna gain 1.16㏈i ( M a x . ) 2.1. Declarations by the manufacturer The EUT is does not do anything at charging mode (Power is turned off when it is charging) 2.2. Details of modification None 3. Information about the FHSS characteristics 3.1. Pseudorandom frequency hopping sequence The channel is represented by a pseudo-random hopping sequence hopping through the 79 RF channels. The hopping sequence is unique for the piconet and is determined by the Bluetooth device address of the master; the phase in the hopping sequence is determined by the Bluetooth clock of the master. The channel is divided into time slots where each slot corresponds to an RF hop frequency. Consecutive hops correspond to different RF hop frequencies. The nominal hop rate is 1 600 hops/s. 3.2. Medium access protocol The manufacturer declares that the device uses Bluetooth protoco…

Text truncated - open the document above for the full version.

Test setup photo of EUT A. Setup photo of EUT
