TE7AX90AX6600 Tri-Band Wi-Fi 6 Router

TP-Link Technologies Co., Ltd.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Jun 15, 2020
Application Purpose: Original Equipment
Date of Application: Jun 09, 2020
Equipment Note: AX6600 Tri-Band Wi-Fi 6 Router
Frequency Range: 5745.00000000 - 5825.00000000
Company: TP-Link Technologies Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

REV1.0.0 1910012810 User Guide AX6600 Tri-Band Wi-Fi 6 Router Contents About This Guide .........................................................................................................1 Chapter 1. Get to Know About Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . .3 1. 1. Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. 1. Top Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. 2. The Back and Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Chapter 2. Connect the Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 2. 1. Position Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2. 2. Connect Your Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Chapter 3. Log In to Your Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Chapter 4. Set Up Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 4. 1. Use Quick Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 4. 2. Quick Setup Via TP-Link Tether App. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 4. 3. Manually Set Up Your Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 4. 4. Set Up the Router as an Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 4. 5. Set Up an IPv6 Internet Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Chapter 5. TP-Link Cloud Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 5. 1. Register a TP-Link ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 5. 2. Change Your TP-Link ID Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 5. 3. Manage the User TP-Link IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 5. 3. 1. Add TP-Link ID to Manage the Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 5. 3. 2. Remove TP-Link ID(s) from Managing the Router. . . . . . . . . . . . . . . . . . . . . .24 5. 4. Manage the Router via the TP-Link Tether App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Chapter 6. Guest Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 6. 1. Create a Network for Guests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 6. 2. Customize Guest Network Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Chapter 7. Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 7. 1. Setting Up Access Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 7. 2. Monitoring Internet Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 Chapter 8. QoS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Chapter 9. Network Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 9. 1. Protect the Network from Cyber Attacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 9. 2. Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 9. 3. IP & MAC Binding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 Chapter 10. NAT Forwarding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 10. 1. Share Local Resources on the Internet by Port Forwarding . . . . . . . . . . . . . . . . . .43 10. 2. Open Ports Dynamically by Port Triggering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 10. 3. Make Applications Free from Port Restriction by DMZ . . . . . . . . . . . . . . . . . . . . . . .46 10. 4. Make Xbox Online Games Run Smoothly by UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Chapter 11. VPN Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 11. 1. Use OpenVPN to Access Your Home Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 11. 2. Use PPTP VPN to Access Your Home Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 Chapter 12. Customize Your Network Settings. . . . . . . . . . . . . . . . . . . . . . . 57 12. 1. Change the LAN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 12. 2. Configure to Support IPTV Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 12. 3. Specify DHCP Server Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60 12. 4. Set Up a Dynamic DNS Service Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 12. 5. Create Static Routes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62 12. 6. Specify Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Cover Letter(s)

Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: TP-Link Technologies Co., Ltd. Address: Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park, Nanshan Shenzhen, 518057 China Declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. Product: AX6600 Tri-Band Wi-Fi 6 Router FCC ID: TE7AX90 Model: Archer AX90 Brand: tp-link Sincerely, _________________ Name: Huang Jing Position: Regulatory Compliance Manager Date: 2020-04-19

Cover Letter(s)

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: TE7AX90 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ________________ Name: Huang Jing Position: Regulatory Compliance Manager Date: 2020-04-19

Cover Letter(s)

Declaration of Authorization We Name: TP-Link Technologies Co., Ltd. Address: Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park, Nanshan Shenzhen, 518057 China Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: AX6600 Tri-Band Wi-Fi 6 Router FCC ID: TE7AX90 Model: Archer AX90 Brand: tp-link Sincerely, _________________ Name: Huang Jing Position: Regulatory Compliance Manager Date: 2020-04-19

Cover Letter(s)

Declaration of Conformity We Name: TP-Link Technologies Co., Ltd. Address: Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park, Nanshan Shenzhen, 518057 China Declare that: Product: AX6600 Tri-Band Wi-Fi 6 Router FCC ID: TE7AX90 Model: Archer AX90 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Huang Jing Position: Regulatory Compliance Manager Date: 2020-04-19

External Photos

Report No.: 2004TW0003-CE 1 of 5 EUT Photograph (1) EUT Photo (2) EUT Photo Report No.: 2004TW0003-CE (3) EUT Photo (4) EUT Photo Report No.: 2004TW0003-CE (5) EUT Photo (6) EUT Photo Report No.: 2004TW0003-CE (7) EUT Photo (8) EUT Photo Report No.: 2004TW0003-CE (9) EUT Photo

External Photos

Report No.: 2004TW0003-UE 1 of 5 EUT Photograph (1) EUT Photo (2) EUT Photo Report No.: 2004TW0003-UE (3) EUT Photo (4) EUT Photo Report No.: 2004TW0003-UE (5) EUT Photo (6) EUT Photo Report No.: 2004TW0003-UE (7) EUT Photo (8) EUT Photo Report No.: 2004TW0003-UE (9) EUT Photo

ID Label/Location Info

Label Label Location

Internal Photos

RF Exposure Info

MRT Technology (Taiwan) Co., Ltd Report No.: 2004TW0003-U4 Phone: +886-3-3288388 Report Version: V01 Web: www.mrt-cert.com Issue Date: 05-27-2020 Page Number: 1 of 7 RF Exposure Evaluation Declaration FCC ID: TE7AX90 APPLICANT: TP-Link Technologies Co., Ltd. Application Type: Certification Product: AX6600 Tri-Band Wi-Fi 6 Router Model No.: Archer AX90 Trademark: tp-link FCC Classification: Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) Test Procedure(s): KDB 447498 D01v06 Test Date: May 15, 2020 Reviewed By: ( Paddy Chen ) Approved By: (Chenz Ker) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2004TW0003-U4 Page Number: 2 of 7 Revision History Report No. Version Description Issue Date Note 2004TW0003-U4 Rev. 01 Initial report 05-27-2020 Valid Report No.: 2004TW0003-U4 Page Number: 3 of 7 1. PRODUCT INFORMATION 1.1. Equipment Description 1.2. Description of Available Antennas Antenna Type Frequency Band (MHz) T X Paths Number of spatial streams Max Antenna Gain (dBi) Beamforming Directional Gain (dBi) CDD Directional Gain (dBi) For Power For PSD Dipole Antenna 2412 ~ 2462 2 1 3.52 6.53 3.52 6.53 5150 ~ 5250 2 1 3.54 6.55 3.54 6.55 5470 ~ 5725 4 1 3.20 9.22 3.20 9.22 4 2 3.20 -- 3.20 6.21 5725 ~ 5850 4 1 3.20 9.22 3.20 9.22 Note: 1. The EUT supports Cyclic Delay Diversity (CDD) mode, and CDD signals are correlated. If all antennas have the same gain, G ANT , Directional gain = G ANT + Array Gain, where Array Gain is as follows. • For power spectral density (PSD) measurements on all devices, Array Gain = 10 log (N ANT / N SS ) dB; • For power measurements on IEEE 802.11 devices, Array Gain = 0 dB for N ANT ≤ 4; 2. The EUT also supports Beam Forming mode, and the Beam Forming support 802.11ac/ax, not include 802.11a/b/g/n. BF Directional gain = G ANT + 10 log (N ANT ). Product Name AX6600 Tri-Band Wi-Fi 6 Router Model No. Archer AX90 Brand Name: tp-link Wi-Fi Specification: 802.11a/b/g/n/ac/ax Report No.: 2004TW0003-U4 Page Number: 4 of 7 1.3. Description of Antenna RF Port Antenna RF Port Software Control Port 2.4GHz RF Port 5GHz RF Port U-NII - 1 U-NII – 2C / -3 Ant 0 Ant 1 Ant 0 Ant 1 Ant 0 Ant 1 Ant 2 Ant 3 Report No.: 2004TW0003-U4 Page Number: 5 of 7 2. RF Exposure Evaluation 2.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- f/1500 6 1500-100,000 -- -- 1 30 f= Frequency in MHz Calculation Formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 r = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1mW/cm². If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No.: 2004TW0003-U4 Page Number: 6 of 7 2.2. Test Result of RF Exposure Evaluation Product AX6600 Tri-Band Wi-Fi 6 Router Test Item RF Exposure Evaluation Antenna Gain: Refer to clause 1.2. Test Mode Frequency Band (MHz) Conducted Power (dBm) Antenna Gain (dBi) Maximum EIRP (dBm) 802.11b/g/n/ax 2412 ~ 2462 29.22 3.52 32.74 802.11a/n/ac/ax 5180 ~ 5240 28.24 6.55 34.79 802.11a/n/ac/ax 5500 ~ 5720, 5745 ~ 5825 26.66 9.22 35.88 Test Mode Frequency Band (MHz) Maximum EIRP (dBm) Safety Distance (cm) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 802.11b/g/n/ax 2412 ~ 2462 32.74 26.5 0.2130 1 802.11a/n/ac/ax 5180 ~ 5240 34.79 26.5 0.3414 1 802.11a/n/ac/ax 5500 ~ 5720, 5745 ~ 5825 35.88 26.5 0.4388 1 CONCLUSION: The WLAN 2.4GHz Band, WLAN 5GHz Low Band(U-NII-1) and WLAN 5GHz upper Band(U-NII-2C/-3) can transmit simultaneously. The max Power Density at R (26.5 cm) = 0.2130mW/cm 2 + 0.3414mW/cm 2 + 0.4388mW/cm 2 = 0.9932mW/cm 2 < 1mW/cm 2 . So the safety distance is 26.5cm for device installed without any other radio equipment. The End Report No.: 2004TW0003-U4 Page Number: 7 of 7 Appendix A - EUT Photograph Refer to “2004TW0003-UE” file.

Test Report

MRT Technology (Taiwan) Co., Ltd Report No.: 2004TW0003-U2 Phone: +886-3-3288388 Report Version: V01 Web: www.mrt-cert.com Issue Date: 05-27-2020 Page Number: 1 of 665 FCC ID: TE7AX90 APPLICANT: TP-Link Technologies Co., Ltd. Application Type: Certification Product: AX6600 Tri-Band Wi-Fi 6 Router Model No.: Archer AX90 Brand Name: tp-link FCC Classification: Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): Part15 Subpart E (Section 15.407) Test Procedure(s): ANSI C63.10-2013, KDB 789033 D02v02r01, KDB 662911 D01v02r01 Test Date: March 30 ~ May 15, 2020 MEASUREMENT REPORT FCC PART 15.407 WLAN 802.11a/n/ac/ax Reviewed By: ( Paddy Chen ) Approved By: (Chenz Ker) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in KDB 789033 D02v02r01. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2004TW0003-U1 Page Number: 2 of 665 Revision History Report No. Version Description Issue Date Note 2004TW0003-U2 Rev. 01 Initial report 05-27-2020 Valid Report No.: 2004TW0003-U1 Page Number: 3 of 665 CONTENTS Description Page General Information ....................................................................................................................... 6 1. INTRODUCTION ..................................................................................................................... 7 1.1. Scope ........................................................................................................................... 7 1.2. MRT Test Location ....................................................................................................... 7 2. PRODUCT INFORMATION ..................................................................................................... 8 2.1. Equipment Description .................................................................................................. 8 2.2. Product Specification Subjective to this Report ............................................................. 8 2.3. Working Frequencies for this report .............................................................................. 9 2.4. Description of Available Antennas ............................................................................... 10 2.5. Description of Antenna RF Port ................................................................................... 11 2.6. Test Mode .................................................................................................................. 12 2.7. Description of Test Software ....................................................................................... 12 2.8. Duty Cycle .................................................................................................................. 13 2.9. Test Configuration ...................................................................................................... 16 2.10. EMI Suppression Device(s)/Modifications ................................................................... 16 2.11. Labeling Requirements ............................................................................................... 16 3. DESCRIPTION OF TEST ...................................................................................................... 17 3.1. Evaluation Procedure ................................................................................................. 17 3.2. AC Line Conducted Emissions ................................................................................... 17 3.3. Radiated Emissions .................................................................................................... 18 4. ANTENNA REQUIREMENTS ................................................................................................ 19 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 20 6. MEASUREMENT UNCERTAINTY ......................................................................................... 21 7. TEST RESULT ...................................................................................................................... 22 7.1. Summary .................................................................................................................... 22 7.2. 26dB Bandwidth Measurement ................................................................................... 23 7.2.1. Test Limit .................................................................................................................... 23 7.2.2. Test Procedure used ................................................................................................... 23 7.2.3. Test Setting ................................................................................................................. 23 7.2.4. Test Setup .................................................................................................................. 23 7.2.5. Test Result .................................................................................................................. 24 7.3. 6dB Bandwidth Measurement ..................................................................................... 42 7.3.1. Test Limit .................................................................................................................... 42 Report No.: 2004TW0003-U1 Page Number: 4 of 665 7.3.2. Test Procedure used ................................................................................................... 42 7.3.3. Test Setting ................................................................................................................. 42 7.3.4. Test Setup ..............................…

Text truncated - open the document above for the full version.

Test Report

Report No.: 2004TW0003-U1 Page Number: 36 of 665 8802.11ax-HE80 26dB Bandwidth & 99% Bandwidth Channel 42 (5210MHz) Channel 106 (5530MHz) Channel 122 (5610MHz) Channel 138 (5690MHz) Channel 155 (5775MHz) 802.11ax-HE160 26dB Bandwidth & 99% Bandwidth Channel 114 (5570MHz) Report No.: 2004TW0003-U1 Page Number: 37 of 665 Product AX6600 Tri-Band Wi-Fi 6 Router Temperature 24 ~ 25°C Test Engineer Kevin Ker Relative Humidity 48 ~ 56% Test Site SR1 Test Date 2020/04/14 Test Mode U-NII-2C (N SS =2) Test Mode Data Rate/ MCS Channel No. Frequency (MHz) 26dB Bandwidth (MHz) 99% Bandwidth (MHz) Ant 1 / Ant 0 + 1 + 2 + 3 802.11ac-VHT20 MCS0 100 5500 21.19 17.81 802.11ac-VHT20 MCS0 116 5580 21.11 17.79 802.11ac-VHT20 MCS0 140 5700 21.26 17.80 802.11ac-VHT20 MCS0 144 5720 21.22 17.78 802.11ac-VHT40 MCS0 102 5510 39.39 36.24 802.11ac-VHT40 MCS0 110 5550 39.19 36.28 802.11ac-VHT40 MCS0 134 5670 39.35 36.30 802.11ac-VHT40 MCS0 142 5710 39.55 36.30 802.11ac-VHT80 MCS0 106 5530 80.66 75.54 802.11ac-VHT80 MCS0 122 5610 80.28 75.71 802.11ac-VHT80 MCS0 138 5690 80.93 75.51 802.11ac-VHT160 MCS0 114 5570 163.30 153.33 802.11ax-HE20 MCS0 100 5500 21.35 19.04 802.11ax-HE20 MCS0 116 5580 21.35 18.99 802.11ax-HE20 MCS0 140 5700 21.36 18.99 802.11ax-HE20 MCS0 144 5720 21.10 18.98 802.11ax-HE40 MCS0 102 5510 39.29 37.49 802.11ax-HE40 MCS0 110 5550 39.90 37.43 802.11ax-HE40 MCS0 134 5670 39.36 37.50 802.11ax-HE40 MCS0 142 5710 39.47 37.62 802.11ax-HE80 MCS0 106 5530 80.75 76.74 802.11ax-HE80 MCS0 122 5610 80.71 76.83 802.11ax-HE80 MCS0 138 5690 79.28 76.87 802.11ax-HE160 MCS0 114 5570 163.10 154.48 Report No.: 2004TW0003-U1 Page Number: 38 of 665 802.11ac-VHT20 26dB Bandwidth & 99% Bandwidth Channel 100 (5500MHz) Channel 120 (5580MHz) Channel 140 (5700MHz) Channel 144 (5720MHz) 802.11ac-VHT40 26dB Bandwidth & 99% Bandwidth Channel 102 (5510MHz) Channel 110 (5550MHz) Channel 134 (5670MHz) Channel 142 (5710MHz) Report No.: 2004TW0003-U1 Page Number: 39 of 665 802.11ac-VHT80 26dB Bandwidth & 99% Bandwidth Channel 106 (5530MHz) Channel 122 (5610MHz) Channel 138 (5690MHz) 802.11ac-VHT160 26dB Bandwidth & 99% Bandwidth Channel 114 (5570MHz) Report No.: 2004TW0003-U1 Page Number: 40 of 665 802.11ax-HE20 26dB Bandwidth & 99% Bandwidth - Ant 2 / Ant 1+ 2 +3 +4 Channel 100 (5500MHz) Channel 116 (5580MHz) Channel 140 (5700MHz) Channel 144 (5720MHz) 802.11ax-HE40 26dB Bandwidth & 99% Bandwidth - Ant 2 / Ant 1+ 2 +3 +4 Channel 102 (5510MHz) Channel 110 (5550MHz) Channel 134 (5670MHz) Channel 142 (5710MHz) Report No.: 2004TW0003-U1 Page Number: 41 of 665 802.11ax-HE80 26dB Bandwidth & 99% Bandwidth - Ant 2 / Ant 1+ 2 +3 +4 Channel 106 (5530MHz) Channel 122 (5610MHz) Channel 138 (5690MHz) 802.11ax-HE160 26dB Bandwidth & 99% Bandwidth - Ant 2 / Ant 1+ 2 +3 +4 Channel 114 (5570MHz) Report No.: 2004TW0003-U1 Page Number: 42 of 665 7.3. 6dB Bandwidth Measurement 7.3.1.Test Limit The minimum 6dB bandwidth shall be at least 500 kHz. 7.3.2.Test Procedure used KDB 789033 D02v02r01 - Section C.2 7.3.3.Test Setting 1. Set center frequency to the nominal EUT channel center frequency. 2. RBW = 100 kHz. 3. VBW≧ 3 × RBW. 4. Detector = Peak. 5. Trace mode = max hold. 6. Sweep = auto couple. 7. Allow the trace to stabilize. 8. Measure the maximum width of the emission that is constrained by the frequencies associated with the two outermost amplitude points (upper and lower frequencies) that are attenuated by 6 dB relative to the maximum level measured in the fundamental emission. 7.3.4.Test Setup Report No.: 2004TW0003-U1 Page Number: 43 of 665 7.3.5.Test Result Product AX6600 Tri-Band Wi-Fi 6 Router Temperature 24°C Test Engineer Kevin Ker Relative Humidity 56% Test Site SR1 Test Date 2020/04/07 Test Mode U-NII-3 Test Mode Data Rate/ MCS Channel No. Frequency (MHz) 6dB Bandwidth (MHz) Limit (MHz) Result Ant 1 / Ant 0 + 1 + 2 + 3 802.11a 6Mbps 149 5745 15.98 ≥ 0.5 Pass 802.11a 6Mbps 157 5785 16.32 ≥ 0.5 Pass 802.11a 6Mbps 165 5825 16.33 ≥ 0.5 Pass 802.11ac-VHT20 NSS2MCS0 149 5745 17.56 ≥ 0.5 Pass 802.11ac-VHT20 NSS2MCS0 157 5785 17.63 ≥ 0.5 Pass 802.11ac-VHT20 NSS2MCS0 165 5825 17.33 ≥ 0.5 Pass 802.11ac-VHT40 NSS2MCS0 151 5755 36.36 ≥ 0.5 Pass 802.11ac-VHT40 NSS2MCS0 159 5795 36.37 ≥ 0.5 Pass 802.11ac-VHT80 NSS2MCS0 155 5775 75.31 ≥ 0.5 Pass 802.11ax-HE20 NSS2MCS0 149 5745 18.63 ≥ 0.5 Pass 802.11ax-HE20 NSS2MCS0 157 5785 18.90 ≥ 0.5 Pass 802.11ax-HE20 NSS2MCS0 165 5825 18.91 ≥ 0.5 Pass 802.11ax-HE40 NSS2MCS0 151 5755 36.02 ≥ 0.5 Pass 802.11ax-HE40 NSS2MCS0 159 5795 36.30 ≥ 0.5 Pass 802.11ax-HE80 NSS2MCS0 155 5775 75.79 ≥ 0.5 Pass Report No.: 2004TW0003-U1 Page Number: 44 of 665 802.11a 6dB Bandwidth Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) 802.11ac-VHT20 6dB Bandwidth Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) Report No.: 2004TW0003-U1 Page Number: 45 of 665 802.11ac-VHT40 6dB Bandwidth Channel 151 (5755MHz) Channel 159 (5795MHz) 802.11ac-VHT80 6dB Bandwidth Channel 155 (5775MHz) 802.11ax-HE20 6dB Bandwidth Channel 149 (5745MHz) Channel 157 (5785MHz) Report No.: 2004TW0003-U1 Page Number: 46 of 665 Channel 165 (5825MHz) 802.11ax-HE40 6dB Bandwidth Channel 151 (5755MHz) Channel 159 (5795MHz) 802.11ax-HE80 6dB Bandwidth Channel 155 (5775MHz) Report No.: 2004TW0003-U1 Page Number: 47 of 665 7.4. Output Power Measurement 7.4.1.Test Limit For the band 5.15 - 5.25 GHz, the maximum conductedoutput power over the frequency band of operation shall not exceed 1 W provided the maximumantenna gain does not exceed 6 dBi. For the 5.25 - 5.35 GHz and 5.47 - 5.725 GHz bands, the maximum conducted output power over the frequency bands of operation shall not exceed the lesser of 250 mW or 11 dBm + 10 log B, where B is the 26 dB emission bandwidth in megahertz. For the band 5.725 - 5.85 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W (30dBm). If transmitting antennas of directional gain greater than 6dBi are used, the maximumconducted output power shall be reduced by the…

Text truncated - open the document above for the full version.

Test Report

Report No.: 2004TW0003-U1 Page Number: 64 of 665 802.11ac-VHT40 Power Spectral Density - Ant 1 / Ant 0 + 1 Channel 38 (5190MHz) Channel 46 (5230MHz) 802.11ac-VHT80 Power Spectral Density - Ant 1 / Ant 0 + 1 Channel 42 (5210MHz) 802.11ax-HE20 Power Spectral Density - Ant 1 / Ant 0 + 1 Channel 36 (5180MHz) Channel 44 (5220MHz) Report No.: 2004TW0003-U1 Page Number: 65 of 665 Channel 48 (5240MHz) 802.11ax-HE40 Power Spectral Density - Ant 1 / Ant 0 + 1 Channel 38 (5190MHz) Channel 46 (5230MHz) 802.11ax-HE80 Power Spectral Density - Ant 1 / Ant 0 + 1 Channel 42 (5210MHz) Report No.: 2004TW0003-U1 Page Number: 66 of 665 802.11a Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 100 (5500MHz) Channel 116 (5580MHz) Channel 140 (5700MHz) Channel 144 (5720MHz) Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) Report No.: 2004TW0003-U1 Page Number: 67 of 665 802.11ac-VHT20 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 100 (5500MHz) Channel 116 (5580MHz) Channel 140 (5700MHz) Channel 144 (5720MHz) Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) Report No.: 2004TW0003-U1 Page Number: 68 of 665 802.11ac-VHT40 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 102 (5510MHz) Channel 110 (5550MHz) Channel 134 (5670MHz) Channel 142 (5710MHz) Channel 151 (5755MHz) Channel 159 (5795MHz) Report No.: 2004TW0003-U1 Page Number: 69 of 665 802.11ac-VHT80 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 106 (5530MHz) Channel 122 (5610MHz) Channel 138 (5690MHz) Channel 155 (5775MHz) 802.11ac-VHT160 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 114 (5570MHz) Report No.: 2004TW0003-U1 Page Number: 70 of 665 802.11ax-HE20 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 100 (5500MHz) Channel 116 (5580MHz) Channel 140 (5700MHz) Channel 144 (5720MHz) Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) Report No.: 2004TW0003-U1 Page Number: 71 of 665 802.11ax-HE40 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 102 (5510MHz) Channel 110 (5550MHz) Channel 134 (5670MHz) Channel 142 (5710MHz) Channel 151 (5755MHz) Channel 159 (5795MHz) Report No.: 2004TW0003-U1 Page Number: 72 of 665 802.11ax-HE80 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 106 (5530MHz) Channel 122 (5610MHz) Channel 138 (5690MHz) Channel 155 (5775MHz) 802.11ax-HE160 Power Spectral Density - Ant 0 / Ant 0 + 1 + 2+ 3 Channel 114 (5570MHz) Report No.: 2004TW0003-U1 Page Number: 73 of 665 802.11a Power Spectral Density - Ant 1 / Ant 0 + 1 + 2+ 3 Channel 100 (5500MHz) Channel 116 (5580MHz) Channel 140 (5700MHz) Channel 144 (5720MHz) Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz)

Test Report

Report No.: 2004TW0003-U1 Page Number: 74 of 665 802.11ac-VHT20 Power Spectral Density - Ant 1 / Ant 0 + 1 + 2+ 3 Channel 100 (5500MHz) Channel 116 (5580MHz) Channel 140 (5700MHz) Channel 144 (5720MHz) Channel 149 (5745MHz) Channel 157 (5785MHz) Channel 165 (5825MHz) Report No.: 2004TW0003-U1 Page Number: 75 of 665 802.11ac-VHT40 Power Spectral Density – Ant 1 / Ant 0 + 1 + 2 + 3 Channel 102 (5510MHz) Channel 110 (5550MHz) Channel 134 (5670MHz) Channel 142 (5710MHz) Channel 151 (5755MHz) Channel 159 (5795MHz) Report No.: 2004TW0003-U1 Page Number: 76 of 665 802.11ac-VHT80 Power Spectral Density - Ant 1 / Ant 0 …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jing Huang(Regulatory Compliance Manager)

[email protected]75521534921Fax: 75526508930

Technical Contact

MRT Technology (Taiwan) Co., LtdChenz Ker

[email protected]886-3-3288388

No. 38, Fuxing Second Rd., Guishan Dist., · Taoyuan · China

Test Firm

MRT Technology (Taiwan) Co.,LtdChenz Ker

[email protected]+886-3-328-8388Fax: +886-3-328-8918

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
3	15E	5.75 GHz - 5.83 GHz	988.60 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. Device is a 802.11 a/n/ac/ax device in a 4x4 MIMO configuration as described in this filing. This filing meets KDB 447498 as a mobile device at the distance specified within thefiling. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Endusers and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz, 40 MHz, 80 MHz and 160 MHz bandwidth modes and it contains 2.4GHz WLAN transmitter.
