User Guide Kasa Smart Wi-Fi Light Switch, Dimmer HS220 1910012356 REV1.0.0 Contents About This Guide ····················································1 Introduction ·······························································2 Appearance ·······························································3 Set Up Your Smart Dimmer ·······························4 Main Device Controls ···········································6 Configure Your Smart Dimmer ························7 Create Scenes··························································9 Discover Kasa ·························································10 Authentication ························································11 1 About This Guide This guide provides a brief introduction to Smart Dimmer and the Kasa app, as well as regulatory information. Please note that features of Smart Dimmer may vary slightly depending on the model and software version you have, and on your location, language and internet service provider. All images, parameters and descriptions documented in this guide are used for demonstration only. Conventions In this guide, the following convention is used: Convention Description Teal Key information appears in teal, including management page text such as menus, items, buttons and so on. Underline Hyperlinks are in teal and underlined. You can click to redirect to a website. More Info • Specifications can be found on the product page at http://www.tp-link.com . • Our Technical Support and troubleshooting information can be found at http://www.tp-link.com/support. 2 Introduction With the Smart Wi-Fi Dimmer, you can control the ambiance of any space with the push of a button. Download the Kasa app and control your dimmer remotely. The Kasa app provides easy step-by-step installation instructions and convenient remote control from anywhere. • Brightness Control - Control the brightness of your lights to set the perfect ambiance for any activity • Control Your Lights From Anywhere - Control your dimmer from wherever you are with the free Kasa app • Hands-free Experience - Control your lights by voice commands through support from Amazon Alexa, Google Assistant and Microsoft Cortana • Works with Nest - Automatically control devices when Nest detects that you're home and away • Works with IFTTT - Get your smart dimmer work together with other devices through support from IFTTT • Scheduling - Program lights to turn off and on at set times throughout the day or night Phone not included; Works with iOS and Android 3 Appearance Smart Dimmer has Up/Down buttons to adjust the brightness of your lights, an indicator that tell you the current brightness of your lights, two LEDs that changes color according to its status, a RESTART button and a RESET button. See the explanation below: RESET RESTART Press and hold (about 5 seconds) until the Wi-Fi status LED blinks amber and green alternately to initiate App-Config mode. Press and hold (about 10 seconds) until the Wi-Fi status LED blinks amber rapidly to factory reset the Smart Dimmer. Press to reboot the Smart Dimmer. Press to decrease the lighting brightness. Press to increase the lighting brightness. White Lit up when the light is switched OFF to show the Smart Dimmer location in the dark. Green Lit up for about 30 seconds when connected to the Wi-Fi network, then turns off. Blinking Amber Resetting. Blinking Green Searching for Wi-Fi. Red No Wi-Fi connection. Blinking Amber and Green App-Config mode initiated. Indicate the current lighting brightness. 4 Set Up Your Smart Dimmer Follow the steps below to set up your Smart Dimmer via Kasa for Mobile app. 1. Download and install Kasa app Go to Google Play or the Apple App Store or scan the QR code below to download the Kasa app on your Android or iOS smartphone or tablet. 2. Log in or sign up with TP-Link ID Open the app. Use your TP-Link ID to log in. If you don’t have a TP-Link ID, tap Create Account and the Kasa app will guide you through the rest. 4. Wire your Smart Dimmer Follow the Kasa app instructions to wire your Smart Dimmer. Then install and secure your dimmer after the wiring. 5 Set Up Your Smart Dimmer Follow the steps below to set up your Smart Dimmer via Kasa for Mobile app. 4. Connect to your home network Enter your Wi-Fi password and add your dimmer to your home Wi-Fi network. 5. Set dimmer range Find the minimum level that your bulbs light up and do the dimming test to ensure your bulbs are compatible with dimming. 6. Complete and enjoy Your Smart Dimmer is all set up and saved in your device list. You can now enjoy using it . 6 Main Device Controls After you successfully set up your Smart Dimmer, you will see the home page of the Kasa app. Here you can view the status of all devices that you've added to Kasa and manage them. Tap on a smart dimmer to check the current brightness of your dimmer . Home Page Device Status 7 Configure Your Smart Dimmer On Device Status page, you can add Presets, create Schedule, set Timer and change the settings of your dimmer. Add Presets Tap to add and edit brightness presets to your smart dimmer. Create Schedule Tap to create a schedule for your smart dimmer to simplify your daily routine by creating automatic On/Off action. 8 Configure Your Smart Dimmer On Device Status page, you can add Presets, create Schedule, set Timer and change the settings of your dimmer. Set Timer Tap to set the time to turn your smart dimmer on or off after specific times. Device Settings Tap to view and change the settings of your smart dimmer. Moreover, you can set smart configuration for easy control. 9 Create Scenes A scene is a preset group of smart devices that can be programmed, customized and activated simultaneously at the touch of a button from your smartphone or tablet, allowing you to easily set your mood, activity or fit any special occasion. This page allows you to preset how your smart home devices should act automatically at special occasions. 10 Discover Kasa Use…

Text truncated - open the document above for the full version.

TP-Link Technologies Co., Ltd. Authority to Act as Agent Date: _2019-12-23______ American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: _____BTL Inc/Mandy Wang______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____2020-12-23_____ By: _______________ _______Jing Huang_________________ (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-Link Technologies Co., Ltd. (Company Name) Telephone: _75521534921_ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Technologies Co., Ltd. Request for Confidentiality Date: 2019-12-23 Subject: Confidentiality Request for: TE7HS220V2 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* 3 User’s Manual TP-Link Technologies Co., Ltd.____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager __________ Jing Huang__________ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Technologies Co., Ltd. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2019-12-23 We, the undersigned company Company Name: TP-Link Technologies Co., Ltd. Address: Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen,518057 China Declare that: Product description: Kasa Smart Wi-Fi Light Switch, Dimmer Type designation: HS220 Brand: tp-link FCC ID: TE7HS220V2 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________ Name: Jing Huang Tel: 75521534921 Email: [email protected]

Project No.: 1911C107 Page 2 of 7 Project No.: 1911C107 Page 3 of 7

Project No.: 1911C107 Page 4 of 7 Project No.: 1911C107 Page 5 of 7 Project No.: 1911C107 Page 6 of 7 ANT Project No.: 1911C107 Page 7 of 7

Report No.: BTL-FCCP-2-1911C107 Page 1 of 3 FCC RF EXPOSURE REPORT FCC ID: TE7HS220V2 Project No. : 1911C107 Equipment : Kasa Smart Wi-Fi Light Switch, Dimmer Brand Name : tp-link Test Model : HS220 Series Model : N/A Applicant : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Manufacturer : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Date of Receipt : Nov. 19, 2019 Date of Test : Nov. 20, 2019~Dec. 06, 2019 Issued Date : Jan. 09, 2020 Report Version : R01 Test Sample : Engineering Sample No.: DG2019111913 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chay Cai Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-2-1911C107 Page 2 of 3 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Jan. 03, 2020 R01 Updated the Max. Output Power. Jan. 09, 2020 Report No.: BTL-FCCP-2-1911C107 Page 3 of 3 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand P/N Antenna Type Connector Gain (dBi) 1 6035500079 PIFA N/A 2.98 2. TEST RESULTS Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.98 1.9861 26.29 425.5984 0.16825 1 Complies Note: The calculated distance is 20 cm. Output power including tune up tolerance. End of Test Report

Report No.: BTL-FCCP-1-1911C107 Page 1 of 114 FCC Radio Test Report FCC ID: TE7HS220V2 This report concerns: Original Grant Project No. : 1911C107 Equipment : Kasa Smart Wi-Fi Light Switch, Dimmer Brand Name : tp-link Test Model : HS220 Series Model : N/A Applicant : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Manufacturer : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Date of Receipt : Nov. 19, 2019 Date of Test : Nov. 20, 2019 ~ Dec. 06, 2019 Issued Date : Jan. 03, 2020 Report Version : R00 Test Sample : Engineering Sample No.: DG2019111913 for conducted, DG2019111914 for radiated. Standard(s) : FCC Part15, Subpart C (15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chay Cai Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-1-1911C107 Page 2 of 114 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-1911C107 Page 3 of 114 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 8 2 . GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF EUT 9 2.2 DESCRIPTION OF TEST MODES 10 2.3 PARAMETERS OF TEST SOFTWARE 11 2.4 DUTY CYCLE 12 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.6 SUPPORT UNITS 13 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 14 3.1 LIMIT 14 3.2 TEST PROCEDURE 14 3.3 DEVIATION FROM TEST STANDARD 14 3.4 TEST SETUP 15 3.5 EUT OPERATION CONDITIONS 15 3.6 TEST RESULTS 15 4 . RADIATED EMISSIONS TEST 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 17 4.3 DEVIATION FROM TEST STANDARD 17 4.4 TEST SETUP 18 4.5 EUT OPERATION CONDITIONS 19 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 19 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 19 4.8 TEST RESULTS - ABOVE 1000 MHZ 19 5 . BANDWIDTH TEST 20 5.1 LIMIT 20 5.2 TEST PROCEDURE 20 5.3 DEVIATION FROM STANDARD 20 5.4 TEST SETUP 20 Report No.: BTL-FCCP-1-1911C107 Page 4 of 114 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 20 5.6 TEST RESULTS 20 6 . MAXIMUM OUTPUT POWER TEST 21 6.1 LIMIT 21 6.2 TEST PROCEDURE 21 6.3 DEVIATION FROM STANDARD 21 6.4 TEST SETUP 21 6.5 EUT OPERATION CONDITIONS 21 6.6 TEST RESULTS 21 7 . CONDUCTED SPURIOUS EMISSIONS 22 7.1 LIMIT 22 7.2 TEST PROCEDURE 22 7.3 DEVIATION FROM STANDARD 22 7.4 TEST SETUP 22 7.5 EUT OPERATION CONDITIONS 22 7.6 TEST RESULTS 22 8 . POWER SPECTRAL DENSITY TEST 23 8.1 LIMIT 23 8.2 TEST PROCEDURE 23 8.3 DEVIATION FROM STANDARD 23 8.4 TEST SETUP 23 8.5 EUT OPERATION CONDITIONS 23 8.6 TEST RESULTS 23 9 . MEASUREMENT INSTRUMENTS LIST 24 10 . EUT TEST PHOTO 26 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 30 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 33 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 38 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 41 APPENDIX E - BANDWIDTH 102 APPENDIX F - MAXIMUM OUTPUT POWER 106 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 108 Report No.: BTL-FCCP-1-1911C107 Page 5 of 114 Table of Contents Page APPENDIX H - POWER SPECTRAL DENSITY 112 Report No.: BTL-FCCP-1-1911C107 Page 6 of 114 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Jan. 03, 2020 Report No.: BTL-FCCP-1-1911C107 Page 7 of 114 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.247) Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emissions APPENDIX G PASS ------ 1…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1911C107 Page 26 of 114 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-1911C107 Page 27 of 114 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-1-1911C107 Page 28 of 114 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-1-1911C107 Page 29 of 114 Radiated Emissions Test Photos Above 1 GHz
