TE7LM500Tapo Smart Light Bulb Wi-Fi Module

LM500 User Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1） This device may not cause harmful interference. 2） This device must accept any interference received, including interference that may cause undesired operation. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This device is intended only for OEM integrators under the following conditions: 1)The antenna must be installed such that 20cm is maintained between the antenna and users, and 2)The transmitter module may not be co-located with any other transmitter or antenna, 3)For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4Gband by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change. As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. IMPORTANT NOTE In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labelling The final end product must be labelled in a visible area with the following: “Contains FCC ID:TE7LM500”. Manual Information to the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. 1. Overview (这部分需要研发填写) The LM500 Wi-Fi module provides a highly-integrated and flexible platform for developing and evaluating products and applications based on the RTL8710BX SoC. The LM500 Wi-Fi module can be either used with development kit for software development or incorporated into OEM products to enable rapid deployment of Wi-Fi connected systems. The module includes the following components: RTL8710BX chip An integrated Balun A printed antenna 2MB SPI Flash Shield 2. Interface and pinout Interface: Debug UART I2C slave PWM x4 USB2.0 for ART tool Pinout: 3. Electric Feature Power Supply Type DC Input 3.3V0.3A Typical 700W Standby Mode 324mW 4. Mechanic Feature Size: 36.50mm*16.00mm*3.9mm 5. Wireless Feature Operating Frequency:2.4GHz:2412~2462MHz Transfer Rate: 802.11b: 11/5.5/2/1 Mbps 802.11g: 54/48/36/24/18/9/6 Mbps 802.11n: up to 150 Mbps Wireless Channel: ch1-ch11(ch1-ch9 for 11nHT40) Transimit Power:18dBm(max) Antenna Type: An printed Omni Directional antenna with 2.37dBi gain 6. Physical and Environmental Operating Temperature: 0°C～100°C Storage Temperature: -1 0°C～100°C Working Humidity: 10%～90% RH 7. Additional Description The module will be installed inside another device. And the outside of the device into which the module is installed will display a label referring to the enclosed module. This exterior label will use the wording such as “Contains FCC ID: TE7LM500”, or any other similar wording that expresses the same meaning.

TP-Link Technologies Co., Ltd. Authority to Act as Agent Date: 2020-01-23 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: BTL Inc./Mandy Wang is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 2021-01-23 By: __________________________ ________Jing Huang________ (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-Link Technologies Co., Ltd. (Company Name) Telephone: 75521534921 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Technologies Co., Ltd. Request for Confidentiality Date: 2020-01-23 Subject: Confidentiality Request for: TE7LM500 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* 3 User’s Manual TP-Link Technologies Co., Ltd.____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager __________ Jing Huang__________ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Technologies Co., Ltd. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2020-01-23 We, the undersigned company Company Name: TP-Link Technologies Co., Ltd. Address: Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen,518057 China Declare that: Product description: Tapo Smart Light Bulb Wi-Fi Module Type designation: LM500 Brand: tp-link FCC ID: TE7LM500 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Jing Huang Tel: 75521534921 Email: [email protected]

TP-Link Technologies Co., Ltd. 053019-02a Request for Modular/Limited Modular Approval Date: March 11, 2020 Subject: Manufacturer’s Declaration for ☒ - Modular Approval ☐ - Split Modular Approval ☐ - Limited Modular Approval ☐ - Limited Split Modular Approval Confidentiality Request for: ______ TE7LM500______ 8 Basic Requirements – FCC Part 15.212(a)(1) For Items Marked “NO(*)”, the Limited Module Description Must be Filled Out on the Following Pages Modular Approval Requirement Requirement Met 1. The modular transmitter must have its own RF shielding. This is intended to ensure that the module does not have to rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with FCC limits. It is also intended to prevent coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed. Such coupling may result in non-compliant operation. The physical crystal and tuning capacitors may be located external to the shielded radio elements. 15.212(a)(1)(i) ☒ - YES ☐ - NO(*) Details: < YES, Please refer to External Photos.> 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with FCC requirements under conditions of excessive data rates or over-modulation. 15.212(a)(1)(ii) ☒ - YES ☐ - NO(*) Details: < YES,U1 RTL8710BX is used for the function.> 3. The modular transmitter must have its own power supply regulation on the module. This is intended to ensure that the module will comply with FCC requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. 15.212(a)(1)(iii) ☒ - YES ☐ - NO(*) Details: < YES, the modular has its own power supply regulation.> 4. The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b), 15.204(c), 15.212(a), and 2.929(b). The antenna must either be permanently attached or employ a ‘‘unique’’ antenna coupler (at all connections between the module and the antenna, including the cable). The ‘‘professional installation’’ provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph 15.212(b). 15.212(a)(1)(iv) ☒ - YES ☐ - NO(*) Details: < YES, it is PCB antenna.> 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified or commercially available (see Section 15.31(i)). 15.212(a)(1)(v) ☒ - YES ☐ - NO(*) Details: < Yes, the module is tested in a stand-alone configuration as the test photos show.> TP-Link Technologies Co., Ltd. 053019-02a Modular Approval Requirement Requirement Met 6. The modular transmitter must be labeled with its own FCC ID number, or use an electron display (see KDB Publication 784748). If using a permanently affixed label with its own FCC ID number, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. 15.212(a)(1)(vi) ☒ - YES ☐ - NO(*) Details: < YES, please refer to the exhibition label sample for this module.> 7. The modular transmitter must comply with all specific rule or operating requirements applicable to the transmitter, including all the conditions provided in the integration instructions by the grantee. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. C…

Text truncated - open the document above for the full version.

Report No.: 1909C149 Page 2 of 5

16*13mm±0.2, 0.5R Model: LM500 FCC ID: TE7LM500 A1 LM500_1.0 LM500 1.0 3mm 3mm 2mm3mm 走纸示意图： 跳距：3mm 边距：3mm 间距：2mm

Report No.: 1909C149 Page 3 of 5 Antenna Report No.: 1909C149 Page 4 of 5 Report No.: 1909C149 Page 5 of 5

Report No.: B TL-FCCP-2-1909C149 Page 1 of 3 FCC RF EXPOSURE REPORT FCC ID: TE7LM500 Project No. : 1909C149 Equipment : Tapo Smart Light Bulb Wi-Fi Module Bra nd Na me : tp-link Test Model : LM500 Series Model : N/A Applicant : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Manufacturer : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Date of Receipt : Sep. 27, 2019 Da te o f Te st : Sep. 27, 2019 ~ Nov. 08, 2019 I ssu e d Da te : Feb. 27, 2020 Report Version : R02 Test Sample : Engineering Sample No.: DG2019102113 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Welly Zhou Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: B TL-FCCP-2-1909C149 Page 2 of 3 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Jan. 16, 2020 R01 Updated the data for power. Feb. 25, 2020 R02 Changed the model name. Feb. 27, 2020 Report No.: B TL-FCCP-2-1909C149 Page 3 of 3 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A PCB N/A 0.27 2. TEST RESULTS Antenna Gain (dBi) Antenna Gain (numeric) Max. Average Output Power (dBm) Max. Average Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 0.27 1.0641 17.76 59.7035 0.01265 1 Complies Note: 1) The calculated distance is 20 cm. 2) Output power including tune up tolerance (±0.5dB). End of Test Report

Report No.: B TL-FCCP-1-1909C149 Page 1 of 115 FCC Radio Test Report FCC ID: TE7LM500 This report concerns: Original Grant Project No. : 1909C149 Equipment : Tapo Smart Light Bulb Wi-Fi Module Bra nd Na me : tp-link Test Model : LM500 Series Model : N/A Applicant : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Manufacturer : TP-Link Technologies Co., Ltd. Address : Building 24(floors1,3,4,5) and 28(floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Date of Receipt : Sep. 27, 2019 Da te o f Te st : Sep. 27, 2019 ~ Nov. 08, 2019 I ssu e d Da te : Feb. 27, 2020 Report Version : R01 Test Sample : Engineering Sample No.: DG2019102113 Standard(s) : FCC Part15, Subpart C (15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipm ent has been tested and found compliance with the requi rement of the relati ve standards by BTL Inc. Prepared by : Welly Zhou Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: B TL-FCCP-1-1909C149 Page 2 of 115 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselve s, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance proc edures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s )/Item (s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: B TL-FCCP-1-1909C149 Page 3 of 115 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RES U LT S 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 T EST ENVIRO NM ENT CONDITIONS 8 2 . GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF EUT 9 2.2 DESCRIPTION OF TEST MODES 10 2.3 PAR AMETERS OF TEST SO FT WAR E 11 2.4 DUTY CYCLE 12 2.5 BLOCK DIAG R AM SHOWING THE CONFIGURAT IO N O F SYST EM T ESTED 13 2.6 SUPPORT UNITS 13 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 14 3.1 LIMIT 14 3.2 TEST PROCEDURE 14 3.3 DEVIATION FROM TEST STANDARD 14 3.4 T EST SETUP 15 3.5 EUT OPERATION CONDITIONS 15 3.6 TEST RESULTS 15 4 . RADIATED EMISSIONS TEST 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 17 4.3 DEVIATION FROM TEST STANDARD 17 4.4 T EST SETUP 18 4.5 EUT OPERATION CONDIT IONS 19 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 19 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 19 4.8 TEST RESULTS - ABOVE 1000 MHZ 19 5 . BANDWIDTH TEST 20 5.1 LIMIT 20 5.2 TEST PROCEDURE 20 5.3 DEVIATION FROM ST AN D AR D 20 5.4 T EST SETUP 20 Report No.: B TL-FCCP-1-1909C149 Page 4 of 115 Table of Contents Page 5.5 EUT OPERATION CONDIT IONS 20 5.6 T EST RESULTS 20 6 . MAXIMUM AVERAGE OUTPUT POWER TEST 21 6.1 LIMIT 21 6.2 TEST PROCEDURE 21 6.3 DEVIATION FROM ST AN D AR D 21 6.4 T EST SETUP 21 6.5 EUT OPERATION CONDITIONS 21 6.6 T EST RESULTS 21 7 . CONDUCTED SPURIOUS EMISSIONS 22 7.1 LIMIT 22 7.2 TEST PROCEDURE 22 7.3 DEVIATION F RO M ST AN D AR D 22 7.4 T EST SETUP 22 7.5 EUT OPERATION CONDITIONS 22 7.6 T EST RESULTS 22 8 . POWER SPECTRAL DENSITY TEST 23 8.1 LIMIT 23 8.2 TEST PROCEDURE 23 8.3 DEVIATION FROM ST AN D AR D 23 8.4 T EST SETUP 23 8.5 EUT OPERATION CONDITIONS 23 8.6 T EST RESULTS 23 9 . MEASUREMENT INSTRUMENTS LIST 24 10 . EUT TEST PHOTO 26 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 31 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MH Z 34 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 39 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MH Z 42 APPENDIX E - BANDWIDTH 103 APPENDIX F - MAXIMUM AVERAGE OUTPUT POWER 107 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 109 Report No.: B TL-FCCP-1-1909C149 Page 5 of 115 Table of Contents Page APPENDIX H - POWER SPECTRAL DENSITY 113 Report No.: B TL-FCCP-1-1909C149 Page 6 of 115 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Jan. 16, 2020 R01 Changed the model name. Feb. 27, 2020 Report No.: B TL-FCCP-1-1909C149 Page 7 of 115 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.247) Standard(s) Se ction Te st Ite m Te st Re su l t Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Average…

Text truncated - open the document above for the full version.

Report No.: B TL-FCCP-1-1909C149 Page 111 of 115 Test Mode TX G Mode Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: B TL-FCCP-1-1909C149 Page 112 of 115 Test Mode TX N-20M Mode Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: B TL-FCCP-1-1909C149 Page 113 of 115 APPENDIX H - POWER SPECTRAL DENSITY Report No.: B TL-FCCP-1-1909C149 Page 114 of 115 Test Mode TX B Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -10.23 8 Complies 06 2437 -10.32 8 Complies 11 2462 -9.79 8 Complies CH01 CH06 CH11 Test Mode TX G Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -11.76 8 Complies 06 2437 -12.35 8 Complies 11 2462 -12.44 8 Complies CH01 CH06 CH11 Report No.: B TL-FCCP-1-1909C149 Page 115 of 115 Test Mode TX N-20M Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -10.35 8 Complies 06 2437 -11.50 8 Complies 11 2462 -9.60 8 Complies CH01 CH06 CH11 End of Test Report

Report No.: BTL-FCCP-1-1909C149 Page 26 of 115 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-1909C149 Page 27 of 115 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-1-1909C149 Page 28 of 115 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-1-1909C149 Page 29 of 115 Radiated Emissions Test Photos Above 1 GHz Report No.: BTL-FCCP-1-1909C149 Page 30 of 115
