TE7SC4171GWireless Pan/Tilt Surveillance Camera

TL-SC4171G Wireless Pan/Tilt Surveillance Camera Rev: 1.0.0 1910010423 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2010 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. CONTENTS Package Contents.........................................................................................................................1 Chapter 1 Safety Instruction.....................................................................................................2 Chapter 2 Minimum System Requirement & Product Feature...............................................3 2.1 System Requirement...................................................................................................3 2.2 Product Feature..........................................................................................................3 Chapter 3 Using IP Camera via Web Browser .........................................................................7 3.1 Obtain the IP Address .................................................................................................7 3.2 Windows Web Browser ...............................................................................................8 3.3 Mac Web Browser .....................................................................................................10 Chapter 4 Using IP Camera via Mobile Phone......................................................................13 4.1 Mobile Phone Viewing ...............................................................................................13 4.1.1 3G Mobile Phone Streaming Viewing...................................................................13 4.1.2 2.5G Mobile Phone WAP Viewing ........................................................................13 4.1.3 2.5G Mobile Phone Browser Viewing ...................................................................13 4.2 Using IP Camera via iPhone .....................................................................................13 Chapter 5 MSN Messenger.....................................................................................................15 Chapter 6 Configuration of Main Menu..................................................................................22 6.1 Live View...................................................................................................................22 6.1.1 Snapshot..............................................................................................................22 6.1.2 Zoom in / out the image via the monitor window ..................................................23 6.1.3 Video play buttons................................................................................................23 6.1.4 Audio buttons.......................................................................................................23 6.2 Setting .......................................................................................................................24 6.3 Client Setting.............................................................................................................24 6.3.1 Mode ....................................................................................................................25 6.3.2 View Size .............................................................................................................25 6.3.3 Protocol................................................................................................................25 6.3.4 Video Buffer .........................................................................................................25 6.4 Image Setup..............................................................................................................25 6.4.1 Brightness............................................................................................................25 6.4.2 Contrast.…

Text truncated - open the document above for the full version.

36 20. r “frames per second”. Quality: You can select the value of quality among Medium, Standard, Good, Detailed able image quality for Fixed Quality or Fixed Bitrate, please refer to the A. Frame-rate and Bitrate Table  Image Size: Specify the image size when the network camera transmits. You can choose among 640 x 480, 320 x 240, and 160 x 1  Frame Rate: Set the frame rate of the MJPEG image. You can choose values from 1, 2, 3, 4, 5, 7, 10, and 15 fps. The unit “fps” stands fo  Quality:  Auto: The quality will be automatically decided.  Fixed and Excellent.  Note: Concerning how to select the suit APPENDIX . etwork to display the sub folders including Information, PPPoE, DDNS, UPnP, tion, Wireless (for wireless models) and Messenger. 7.3 Network Click the folder of N Bonjour, IP Notifica 37 7.3.1 Information The page of Information displays the MAC address of the device.  Obtain an IP address automatically (DHCP): If a DHCP server is installed on the network, to select this while the IP address is assigned by the DHCP server.  Obtain DNS server address automatically: Select this to obtain the address of DNS server automatically.  Use the following IP address: Select this when the fixed IP address is set.  IP address: Enter the IP address of the device.  Subnet mask: Enter the subnet mask.  Default gateway: Enter the default gateway.  Use the following DNS server address: Select this when you set the fixed address as the IP address of DNS server.  Primary DNS server: Enter the IP address of the primary DNS server.  Secondary DNS server: Enter the IP address of the secondary DNS server, if necessary.  HTTP port number: Select 80 in general situations. If you want to use a port number other than 80, select the text box and enter a port number between 1024 and 65535. When you have set the HTTP port number to a number other than 80 on the Network setting page or in the Setup Program, access the device by typing the IP address of the device on the web browser as follows: for example, when HTTP port number is set to 2000 and the IP address of your camera is set to 192.168.1.100, you should type in http://192.168.1.100:2000/ to access the device.  Note: 1. The IP Camera needs to be rebooted after it finishes changing the network setting completely. Please go to “Setting ė Basic ė System ė Initialize” page and click the Reboot button after you make some changes. 38 2. If you connect the IP Camera with your computer directly, the default network domain of camera is 192.168.1.xx. 7.3.2 PPPoE (Point-to-Point Protocol over Ethernet) If your ISP provides Dynamic IP with authentication by username and password, type all PPPoE information in this part. When you use the PPPoE function, you need to turn on the DDNS or IP Notification function at same time.  IP Address: The IP address obtained at the PPPoE connecting with network.  User ID: Enter the user ID for authentication necessary for PPPoE connections. Type it up to 64 characters.  Password: Enter the password for authentication necessary for PPPoE connections. Type it up to 32 characters.  Re-type Password: Re-type the password to confirm.  Obtain DNS server address automatically: Select this to obtain the address of DNS server automatically.  Use the following DNS server address: Select this when you set the fixed address as the IP address of DNS server.  Primary DNS server: Enter the IP address of the primary DNS server.  Secondary DNS server: Enter the IP address of the secondary DNS server.  Note: 1. PPPoE (Point-to-Point Protocol over Ethernet): PPPoE is a network protocol for encapsulating Point-to-Point Protocol frames insider Ethernet frames. PPPoE connection is used mainly with ADSL service where individual users connect to the ADSL transceiver (modem) over Ethernet work. It also widely used in XDSL. (digital affiliate line such as ADSL, VDSL or SDSL) 2. The IP Camera needs to be rebooted after it finishes changing the network completely. 3. The IP Camera with Intelligent IP Installer can’t be found after PPPoE is active, but you can get the IP address of the camera by IP Notification function. For more details, please refer to Section 7.3.6 . 4. If the IP Notification function is not configured to report the IP address of the camera, you can reset the camera to its factory default settings by pressing the Reset button. Then the camera can be found by Intelligent IP Installer. 39 7.3.3 DDNS (Dynamic DNS) DDNS is a system which allows the domain name data held in a name server to be updated in real time. The most common use for DDNS is allowing an internet domain name to be assigned to a computer with a varying/dynamic IP Address. This makes it possible for other sites on the internet to establish connection to the machine without needing to track the IP Address themselves.  Server name: Choose the DDNS Server from the list.  User ID: Enter the user ID for authentication necessary for DDNS connections. Type it up to 64 characters.  Password: Enter the password for authentication necessary for DDNS connections. Type it up to 32 characters.  Re- type password: Re-type the password to confirm.  Host name: Enter the host name that is registered to the DDNS server.  Periodical Update:  Auto: The domain name data will be updated automatically.  Periodical: The domain name data will be updated once in a period. The period can be chosen among 5, 10, 15, 30 and 60 minutes.  Note: How to apply DDNS username and Host name? You can apply DDNS username and Host name by the following steps: 40 1. Login http://www.dyndns.org, click the Create Account. 2. Input all information and follow step by step with DynDNS. 41 3. Login with new account and click Account  My Hosts  Add Host Services. 4. Type domain in the Hostname field and select sub-domain. 42 5. After type information, check your DDNS service. 6. Type your DDNS User ID, Password and Host name in Setting  Network  DDNS. After completing setting, reboot IP Ca…

Text truncated - open the document above for the full version.

Date: 2011-10-8 Federal Communications Commission Authorization and Evaluation Division FCC ID: TE7SC4171G Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP-LINK Technologies Co., Ltd. Tel: 86-755-26525554 Fax: 86-755-26508930 Web site: WWW.TP-LINK.COM E-mail: [email protected]

Attestation for FCC Declaration of Conformity FCC ID: TE7SC4171G Date: 2011-9-30 Please be notified that we, the undersigned, TP-LINK TECHNOLOGIES CO., LTD declare that the product bears the above FCC ID is also complying with the requirements of FCC DoC. The test report number for FCC DoC is T110509302-D is issued by an accredited lab, Compliance Certification Services Inc. Hsinchu Lab. located at NO. 989-1 Wen Shan Rd., Shang Shan Village, Qionglin Shiang Hsinchu County 30741, Taiwan, R. O. C, which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP-LINK Technologies Co., Ltd. Tel: 86-755-26525554 Fax: 86-755-26508930 Web site: WWW.TP-LINK.COM E-mail: [email protected]

Report No.T110509302 Page 1 of 18 External Photo Report No.T110509302 Page 2 of 18 Report No.T110509302 Page 3 of 18 Internal Photo

12 E D C B A 12 3456789 E D C 345678 B A 9 料号： 设 计 审 核 颜 色 名 称 版 本 材 质 模 具 机型版本号 完成日期 logo 底色 文字 其它 记 录 与上一版的区别 TL-SC4171G英文标贴 第一版 80g艾利铜版纸+雾膜 TL-SC4171G\1.0.0\欧 2011-6-20 陈巍 白色 黑色 30%黑色 2:1效果图 标贴框为30%黑 Max 12W FCC ID:TE7SC4171G

Report No.T110509302 Page 3 of 18 Internal Photo Report No.T110509302 Page 4 of 18 Report No.T110509302 Page 5 of 18 Report No.T110509302 Page 6 of 18 Report No.T110509302 Page 7 of 18 Report No.T110509302 Page 8 of 18 Report No.T110509302 Page 9 of 18 Report No.T110509302 Page 10 of 18 Report No.T110509302 Page 11 of 18 Report No.T110509302 Page 12 of 18 Report No.T110509302 Page 13 of 18 Report No.T110509302 Page 14 of 18 Report No.T110509302 Page 15 of 18 Report No.T110509302 Page 16 of 18 Report No.T110509302 Page 17 of 18 Power Adapter Photo (Model : MU12-S120100-A1) Report No.T110509302 Page 18 of 18

FCC IDTE7SC4171G Report No.T110509302-RP1 Page 63 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate theenvironment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b)LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational / Control Exposures 300-1,500 -- -- F/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300-1,500 -- -- F/1500 6 1,500-100,000 -- -- 1 30 CALCULATIONS Given d G×P×30 =E & 3770 E =S 2 Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 d3770 G×P×30 =S Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 22 d G×P ×0796.0= 100/d×3770 G×1000/P×30 =S Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm2 FCC IDTE7SC4171G Report No.T110509302-RP1 Page 64 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. LIMIT Power Density Limit, S=1.0mW/cm 2 TEST RESULTS Mode Antenna Gain (dBi) Minimum separation distance (cm) Output Power (dBm) Numeric antenna gain (mW) Power Density Limit (mW/cm 2 ) Power Density at 20cm (mW/cm 2 ) IEEE 802.11b 2.17 20.0 19.74 1.65 1.00 0.030883 IEEE 802.11g 2.17 20.0 20.02 1.65 1.00 0.032940 Remark: For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.

FCC IDTE7SC4171G Report No.T110509302-RP1 Page 1 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4:2003 TEST REPORT For Wireless Pan/Tilt Surveillance Camera Model : TL-SC4171G Trade Name : TP-LINK Issued for TP-LINK TECHNOLOGIES CO.,LTD. Building 24 (floors 1,3,4,5) and 28 (floors1-4) Central Science and Technology Park,Shennan Rd, Nanshan, Shenzhen,China Issued by Compliance Certification Services Inc. Hsinchu Lab. NO. 989-1 Wen Shan Rd., Shang Shan Village, Qionglin Shiang Hsinchu County 30741, Taiwan, R.O.C TEL: +886-3-5921698 FAX: +886-3-5921108 http://www.ccsrf.com E-Mail : [email protected] Issued Date: October 27, 2011 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. FCC IDTE7SC4171G Report No.T110509302-RP1 Page 2 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 05/18/2011 Initial Issue All Page 68 Winnie Chen 01 09/13/2011 Change Power LED Layout. Page 1, 4, 39, 43 Winnie Chen 02 10/27/2100 Revised Test Procedure. Page 1, 11, 17, 25, 42, 60 Winnie Chen FCC IDTE7SC4171G Report No.T110509302-RP1 Page 3 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 6 4. TEST METHODOLOGY ............................................................................................... 6 5. FACILITIES AND ACCREDITATION ........................................................................... 7 5.1 FACILITIES ............................................................................................................ 7 5.2 ACCREDITATIONS................................................................................................ 7 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST......................................................................9-10 7. FCC PART 15.247 REQUIREMENTS.......................................................................... 11 7.1 6dB BANDWIDTH .................................................................................................. 11-16 7.2 MAXIMUM PEAK OUTPUT POWER..................................................................... 17-22 7.3 AVERAGE POWER ............................................................................................... 23-24 7.4 POWER SPECTRAL DENSITY............................................................................. 25-30 7.5 CONDUCTED SPURIOUS EMISSION .................................................................. 31-37 7.6 RADIATED EMISSION........................................................................................... 38-57 7.7 CONDUCTED EMISSION ...................................................................................... 58-62 APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE ..................................................... 63-64 APPENDIX II SETUP PHOTOS ....................................................................................... 65-68 FCC IDTE7SC4171G Report No.T110509302-RP1 Page 4 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant TP-LINK TECHNOLOGIES CO.,LTD. Address Building 24 (floors 1,3,4,5) and 28 (floors1-4) Central Science and Technology Park,Shennan Rd, Nanshan, Shenzhen,China Equipment Under Test Wireless Pan/Tilt Surveillance Camera Model TL-SC4171G Trade Name TP-LINK Tested Date April 28 ~ May 17, 2011 ; September 07 ~ 08, 2011 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.4:2003 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Sb Lu Gundam Lin Sr. Engineer Sr. Engineer FCC IDTE7SC4171G Report No.T110509302-RP1 Page 5 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 2. EUT DESCRIPTION Product Name Wireless Pan/Tilt Surveillance Camera Model Number TL-SC4171G Identify Number T110509302 Received Date April 28, 2011 Frequency Range IEEE 802.11b/g : 2412MHz ~ 2462MHz IEEE 802.11b : 19.74 dBm (0.0942W) Transmit Power IEEE 802.11g : 20.02 dBm (0.1005W) Channel Spacing IEEE 802.11b/g : 5MHz Channel Number IEEE 802.11b/g : 11 Channels IEEE 802.11b : 11, 5.5, 2, 1 Mbps Transmit Data Rate IEEE 802.11g : 54, 48, 36, 24, 18, 12, 9, 6 Mbps IEEE 802.11b : DSSS (CCK, DQPSK, DBPSK) Type of Modulation IEEE 802.11g : OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Type Dipole Antenna, Antenna Gain 2.17dBi Power Rating 12Vdc Test Voltage 120Vac, 60Hz DC Pow…

Text truncated - open the document above for the full version.

! FCC IDΚTE7SC4171GReport No.ΚT110509302-RP1 ! Page 65 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX II SETUP PHOTOS RADIATED EMISSION SETUP Below 1 GHz ! FCC IDΚTE7SC4171GReport No.ΚT110509302-RP1 ! Page 66 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Above 1 GHz ! FCC IDΚTE7SC4171GReport No.ΚT110509302-RP1 ! Page 67 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP ! FCC IDΚTE7SC4171GReport No.ΚT110509302-RP1 ! Page 68 / 68 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. CONDUCTED EMISSION SETUP !
