TE7TDW8950ND150Mbps Wireless Lite N ADSL2+ Modem Router

TD-W8950ND 150Mbps Wireless Lite N ADSL2+ Modem Router Rev: 1.0.0 1910010316 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2010 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. National Restrictions This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below: Country Restriction Reason/remark Bulgaria None General authorization required for outdoor use and public service France Outdoor use limited to 10 mW e.i.r.p. within the band 2454-2483.5 MHz Military Radiolocation use. Refarming of the 2.4 GHz band has been ongoing in recent years to allow current relaxed regulation. Full implementation planned 2012 Italy None If used outside of own premises, general authorization is required Luxembourg None General authorization required for network and service supply(not for spectrum) Norway Implemented This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Ålesund Russian Federation None Only for indoor applications Note: Please don’t use the product outdoors in France. TP-LINK TECHNOLOGIES CO., LTD TP-LINK TECHNOLOGIES CO., LTD South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan, Shenzhen, P. R. China DECLARATION OF CONFORMITY For the following equipment: Product Description: 150Mbps Wireless Lite N ADSL2+ Modem Router Model No.: TD-W8950ND Trademark: TP-LINK We declare under our own responsibility that the above products satisfy all the technical regulations applicable to the product within the scope of Council Directives: Directives 1999/5/EC The above product is in conformity with the following standards or other normative documents ETSI EN 300 328 V1.7.1: 2006 ETSI EN 301 489-1 V1.8.1:2008& ETSI EN 301 489-17 V2.1.1:2009 EN60950-1:2006 Recommendation 1999/519/EC EN62311:2008 Directives 2004/108/EC The above product is in conformity with the following standards or other normative documents EN 55022:2006 +A1:2007 EN 55024:1998+A1:2001+A2:2003 EN 61000-3-2:2006 EN 61000-3-3:1995+A1:2001+A2:2005 Directives 2006/95/EC The above product is in conformity with the following standards or other normative documents EN60950-1:2006 Directive（ErP） 2009/125/EC Audio/Video, information and communication technology equipment- Environmentally conscious design EN62075:2008 Person is responsible for marking this declaration: Yang Hongliang Product Manager of International Business CONTENTS Package Contents....................................................................................................1 Chapter 1. Product Overview...................................................................................2 1.1 Overview of the Router.................................................................................................... 2 1.2 Main Features .................................................................................................................. 3 1.3 Panel Layout.............................................…

Text truncated - open the document above for the full version.

TP-LINK TECHNOLOGIES CO., LTD. Building 7,Section 2,Honghualing Industrial Park,Xili,Nanshan District, Shenzhen, P.R.C. Web Site: http://www.tp-link.com Tel: 86-755-26525554 Email: [email protected] Fax: 86-755-26508930 Attestation for FCC Declaration of Conformity FCC ID: TE7TDW8950ND Data: May. 26, 2010 Please be notified that we, the undersigned, TP-LINK TECHNOLOGIES CO.,LTD. declare that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is 10-05-RBF-045. Testing in regards to this report was done by ELECTRONICS TESTING CENTER, TAIWAN, located at NO. 34. LIN 5. DINGFU TSUEN, LINKOU SHIANG TAIPEI COUNTY, TAIWAN, 24442, R.O.C., which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827. Sincerely, Yongquan Wang / Product Dept. Manager TP-LINK TECHNOLOGIES CO.,LTD. Tel: 86-755-26525554 Fax: 86-755-2650893 Email: [email protected]

AGENCY AUTHORIZATION LETTER FCC ID：TE7TDW8950ND Date: May-11-2010 To whom it may concern: We, the undersigned, hereby authorize Shenzhen Huatongwei International Inspection Co., Ltd （Keji Nan No. 12 Road, Hi-tech Park, Shenzhen, China） to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Huatongwei within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP-LINK Technologies Co., Ltd. Tel: 86-755-26525554 Fax: 86-755-26508930 Web site: WWW.TP-LINK.COM E-mail: [email protected]

External Photos of the EUT

150

Internal Photos of the EUT

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) FCC ID .............................................: TE7TDW8950ND Compiled by ( position+printed name+signature)..: File administrators Xiankun Ding Supervised by ( position+printed name+signature)..: Test Engineer Wenliang Li Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: May 10, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address.............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: TP-LINK TECHNOLOGIES CO.,LTD. Address.............................................: Building 7,Section 2,Honghualing Industrial Park,Xili,Nanshan District, Shenzhen, P.R.C. Test specification: Standard ...........................................: FCC Per 47 CFR 2.1091(b) TRF Originator ..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : 150Mbps Wireless Lite N ADSL2+ Modem Router Trade Mark .......................................: TP-LINK Manufacturer ....................................: TP-LINK TECHNOLOGIES CO.,LTD. Model/Type reference.......................: TD-W8950ND Listed Models ..................................: / Ratings..............................................: DC 12V Adapter From AC 120V/60Hz Frequency Range 2400-2483.5MHz Result................................................: Positive V1.0 Page 2 of 7 FCC ID: TE7TDW8950ND MPE T E S T R E P O R T FCC ID : TE7TDW8950ND May 10, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : 150Mbps Wireless Lite N ADSL2+ Modem Router Model /Type : TD-W8950ND Listed Models : / Applicant : TP-LINK TECHNOLOGIES CO.,LTD. Address : Building 7,Section 2,Honghualing Industrial Park,Xili,Nanshan District, Shenzhen, P.R.C. Manufacturer TP-LINK TECHNOLOGIES CO.,LTD. Address : Building 7,Section 2,Honghualing Industrial Park,Xili,Nanshan District, Shenzhen, P.R.C. The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 7 FCC ID: TE7TDW8950ND Contents 1. SUMMARY............................................................................. 4 1.1. EUT configuration 4 1.2. NOTE 4 2. TEST ENVIRONMENT............................................................... 5 2.1. Address of the test laboratory 5 2.2. Environmental conditions 5 2.3. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT .................................................... 5 3.1. Applicable Standard 5 3.2. Limit 6 3.3. MPE Calculation Method 6 4. CONCLUSION ........................................................................ 7 V1.0 Page 4 of 7 FCC ID: TE7TDW8950ND 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ○ Power Cable Length (m) : / Shield : / Detachable : / ○ Multimeter Manufacturer : / Model No. : / ● AC Adapter MODEL:MU12-2120100-A1 INPUT:100-240V～50/60Hz 0.5A OUTPUT: 12V DC 1.0A Power Cable: 150cm ◇ Shield ◆ Unshield 1.2. NOTE 1. The EUT is an 802.11b/g/n 150Mbps Wireless Lite N ADSL2+ Modem Router, The functions of the EUT listed as below: Test Standards Reference Report WLAN 802.11b/g, 802.11n FCC Part 15 Subpart C (Section15.247) WE10040003 WLAN 802.11b/g, 802.11n FCC Part 15 Subpart B SQE100400010 2. The frequency bands used in this EUT are listed as follows: Frequency Band(MHz) 2400-2483.5 5150-5350 5470-5725 5725-5850 802.11b √ － － － 802.11g √ － － － 802.11n(20MHz) √ － － － 802.11n(40MHz) √ － － － 3. The EUT incorporates a SISO function, Physically, the EUT provides one completed transmitter and one completed receivers. Modulation Mode TX Function 802.11b 1TX 802.11g 1TX 802.11n (20MHz) 1TX 802.11n (40MHz) 1TX V1.0 Page 5 of 7 FCC ID: TE7TDW8950ND 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone: 86-755-26715686 Fax: 86-755-26748089 The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2009) and CISPR Publication 22. 2.2. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 950-1050mbar 2.3. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to CISPR 16 - 4 „Specification for radio disturbance and immunity measuring apparatus and methods – Part 4: Uncertainty in EMC Measurements“ and is documented in the Shenzhen Huatongwei International Inspection Co., Ltd quality system acc. to DIN EN ISO/IEC 17025. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of th…

Text truncated - open the document above for the full version.

FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No......................: FCC ID............................................. : WE10040003 TE7TDW8950ND Compiled by ( position+printed name+signature)..: File administrators Xiankun Ding Supervised by ( position+printed name+signature)..: Test Engineer Wenliang Li Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: May 20, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: TP-LINK TECHNOLOGIES CO.,LTD. Address ............................................: Building 7,Section 2,Honghualing Industrial Park,Xili,Nanshan District, Shenzhen, P.R.C. Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 920-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Direct Sequence System TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: 150Mbps Wireless Lite N ADSL2+ Modem Router Trade Mark .......................................: TP-LINK Model/Type reference.......................: TD-W8950ND Listed Models ..................................: / Result................................................: Positive V1.0 Page 2 of 75 Report No.: WE10040003 T E S T R E P O R T Test Report No. : WE10040003 May 20, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : 150Mbps Wireless Lite N ADSL2+ Modem Router Model /Type : TD-W8950ND Listed Models : / Applicant : TP-LINK TECHNOLOGIES CO.,LTD. Address : Building 7,Section 2,Honghualing Industrial Park,Xili,Nanshan District, Shenzhen, P.R.C. Manufacturer TP-LINK TECHNOLOGIES CO.,LTD. Address : Building 7,Section 2,Honghualing Industrial Park,Xili,Nanshan District, Shenzhen, P.R.C. Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 75 Report No.: WE10040003 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 6 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 2.8. NOTE 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Test Description 9 3.6. Statement of the measurement uncertainty 10 3.7. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS ............................................ 11 4.1. AC Power Conducted Emission 11 4.2. Radiated Emission 14 4.3. Maximum Peak Output Power 30 4.4. Power Spectral Density 33 4.5. Band Edge Compliance of RF Emission 41 4.6. Spurious RF Conducted Emission 50 4.7. 6dB Bandwidth 57 4.8. MPE Evaluation 65 4.9. Antenna Requirement 67 5. TEST SETUP PHOTOS OF THE EUT .......................................... 69 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 71 V1.0 Page 4 of 75 Report No.: WE10040003 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.4-2009: American National Standard for Methods of Measurement of Radio-Noise Emissions From Low Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz. ANSI C63.10 : American National Standard for Testing Unlicensed Wireless Devices V1.0 Page 5 of 75 Report No.: WE10040003 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Apr 06, 2010 Testing commenced on : Apr 06, 2010 Testing concluded on : May 20, 2010 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 12V Adapter from AC 120V/60Hz Description of the test mode IEEE 802.11b/g/n: Thirteen channels are provided to the EUT,but only eleventh channels used for USA. Channel Frequency(MHz) Channel Frequency(MHz) 1 2412 8 2447 2 2417 9 2452 3 2422 10 2457 4 2427 11 2462 5 2432 12 2467 6 2437 13 2472 7 2442 2.3. Short description of the Equipment under Test (EUT) 2.4GHz (150Mbps Wireless Lite N ADSL2+ Modem Router) For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. The Applicant provides software (W8950N_ART_100303) to control the EUT for staying in continous transmitting and receiving mode for testing. V1.0 Page 6 of 75 Report No.: WE10040003 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - sup…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
