TE7WA7210N2.4GHz 150Mbps Indoor/Outdoor Wireless Access Point

TP-Link Technologies Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 07, 2014
Application Purpose: Original Equipment
Date of Application: May 07, 2014
Equipment Note: 2.4GHz 150Mbps Indoor/Outdoor Wireless Access Point
Frequency Range: 2412.00000000 - 2462.00000000
Company: TP-Link Technologies Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TL-WA7210N 2.4GHz 150Mbps Outdoor Wireless Access Point REV2.0.0 1910010786 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2013 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1） This device may not cause harmful interference. 2） This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. S uch modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Canadian Compliance Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1)This device may not cause interference, and (2)This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux norms CNR exemptes de licence d’Industrie Canada. Le fonctionnement est soumis aux deux conditions suivantes: (1)cet appareil ne doit pas provoquer d’interférences et (2)cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un fonctionnement non souhaité de l’appareil. Industry Canada Statement Complies with the Canadian ICES- 003 Class B specifications. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device complies with RSS 210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Korea Warning Statements 당해 무선설비는 운용중 전파혼신 가능성이 있음. NCC Notice & BSMI Notice 注意！依據低功率電波輻射性電機管理辦法第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性或功能。第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通行；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信規定作業之無線電信。低功率射頻電機需忍受合法通信或工業、科學以及醫療用電波輻射性電機設備之干擾。安全諮詢及注意事項 ●請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。 ●清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 ●注意防潮，請勿將水或其他液體潑灑到本產品上。 ●插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。 ●請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。 ●請不要私自打開機殼，不要嘗試自行維修本產品，請由授權的專業人士進行此項工作。 Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів та вимогам, що передбачені чинними законодавчими актами України. Safety Information  When product has power button, the power button is one of the way to shut off the product; when there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source.  Don’t disassemble the product, or make repairs yourself. You run the risk of electric shock and voiding the limited warranty. If you need service, please contact us.  Avoid water and wet locations. This product can be used in the following countries: AT BG BY CA CZ DE DK EE ES FI FR GB GR HU IE IT LT LV MT NL NO PL PT RO RU SE SK TR UA TP-LINK TECHNOLOGIES CO., LTD TP-LINK TECHNOLOGIES CO., LTD. Building 24 (floors 1, 3, 4, 5), and 28 (floors 1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China DECLARATION OF CONFORMITY For the following equipment: Product Description: 2.4GHz 150Mbps Outdoor Wireless Access Point Model No.: TL-WA7210N Trademark: TP-LINK We declare under our own responsibility that the above products satisfy all the technical regulations applicable to the product within the scope of Council D…

Text truncated - open the document above for the full version.

Cover Letter(s)

AGENCY AUTHORIZATION LETTER FCC ID: TE7WA7210N Date: Jan 17, 2014 To whom it may concern: We, the undersigned, hereby authorize Audix Technology (Shenzhen) Co., Ltd (No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park,Nantou,Shenzhen, Guangdong, China) to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Audix within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name of authorized signer: Yo ngq u an Wang Title of authorized signer: Product Dept. Manager Company Name: TP‐LINK Technologies Co., Ltd. Tel: 86‐755‐26525554 Fax: 86‐755‐26508930 Web site: WWW.TP‐LINK.COM E‐mail: public@tp‐link.com.cn

Cover Letter(s)

Date: Jan 17, 2014 Federal Communications Commission Authorization and Evaluation Division FCC ID: TE7WA7210N Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP‐LINK Technologies Co., Ltd. Tel: 86‐755‐26525554 Fax: 86‐755‐26508930 Web site: WWW.TP‐LINK.COM E‐mail: public@tp‐link.com.cn

Cover Letter(s)

Attestation for FCC Declaration of Conformity FCC ID:TE7WA7210N Date: 2013-01-22 Please be notified that we, the undersigned, TP-LINK TECHNOLOGIES CO., LTD declare that the product bears the above FCC ID is also complying with the requirements of FCC DoC. The test report number for FCC DoC is EM-F140054, with is issued by an accredited lab, Audix Technology Corporation, EMC Department located at No. 53-11, Tin-Fu Tsun, Lin-Kou , Taipei Hsien , Taiwan. Which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP‐LINK Technologies Co., Ltd. Tel: 86‐755‐26525554 Fax: 86‐755‐26508930 Web site: WWW.TP‐LINK.COM E‐mail: public@tp‐link.com.cn

External Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-1 14. PHOTOS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-2 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-3 Figure 5 General Appearance of the EUT Figure 6 General Appearance of the EUT

ID Label/Location Info

C B A 12 C 345678 B E D D A 9 料号： 12345 E 6789 与上一版的区别颜色名称版本材质模具机型版本号 logo 底色文字其它结构工程师硬件工程师产品工程师平面负责人记录审核完成日期设计 58*19mm, 1R This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID:TE7WA7210N MADE IN CHINA IC:8853A - WA7210N Default Settings: Power: Model: 2.4GHz 150Mbps Outdoor Wireless Access Point TL-WA7210N(UN)2.0产品规格丝印第1版 0.175哑面细砂纹PC+3M9473 TL-WA7210N(UN)2.0 赵娣 2013-1-25 黑色 PANTONE COOLGRAY 1U 黑色

Internal Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-4 Figure 7 General Appearance of the EUT Figure 8 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-5 Figure 9 Inside of the EUT Figure 10 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-6 Figure 11 Inside of the EUT Figure 12 Components Side of the PCB R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-7 Figure 13 Components Side of the PCB Figure 14 Power Adapter #1 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 14-8 Figure 15 Power Adapter #1 Figure 16 Power Adapter #1

RF Exposure Info

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 10-22 10. MPE ESTIMATION 10.1.Limit for General Population/ Uncontrolled Exposures Frequency Power density (mW/ cm 2 ) Averaging time(minutes) 300MHz----1.5GHz F/1500 30 1.5GHz---100GHz 1.0 30 Frequency(MHz) Power density (mW/ cm 2 ) Averaging time(minutes) 2412 1 30 2437 1 30 2462 1 30 Note: F= Frequency in MHz Estimation Result EUT: 2.4GHz 150Mbps Indoor/Outdoor Wireless Access Point M/N: TL-WA7210N Test date: 2013-11-21 Pressure: 101.3±1.0 kpa Humidity: 50.4±3.0% Tested by: Leo-Li Test site: RF site Temperature:20.1±0.6 °C Antenna Gain Vertical&Horiontal Antenna: 12dBi External Antenna: 5dBi Cable loss: 1 dB Attenuator loss: 20 dB Antenna Type Test Mode CH Frequency （MHz） Peak Output Power (dBm) Output Power (mW) Antenna Gain (dBi) Antenn a Gain (Linear ) MPE CH1 2412 14.53 28.38 12 15.85 0.0895 CH6 2437 17.16 52.00 12 15.85 0.1640 11b CH11 2462 14.65 29.17 12 15.85 0.0920 CH1 2412 17.56 57.02 12 15.85 0.1799 CH6 2437 22.18 165.20 12 15.85 0.5211 11g CH11 2462 18.41 69.34 12 15.85 0.2188 CH1 2412 17.45 55.59 12 15.85 0.1754 CH6 2437 22.38 172.98 12 15.85 0.5457 11n HT20 CH11 2462 17.65 58.21 12 15.85 0.1836 CH1 2422 17.38 54.70 12 15.85 0.1726 CH4 2437 19.59 90.99 12 15.85 0.2870 Vertical 11n HT40 CH7 2452 16.61 45.81 12 15.85 0.1445 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 10-23 CH1 2412 13.55 22.65 5 3.16 0.0143 CH6 2437 16.76 47.42 5 3.16 0.0299 11b CH11 2462 13.57 22.75 5 3.16 0.0143 CH1 2412 16.62 45.92 5 3.16 0.0289 CH6 2437 22.58 181.13 5 3.16 0.1140 11g CH11 2462 17.44 55.46 5 3.16 0.0349 CH1 2412 16.44 44.06 5 3.16 0.0277 CH6 2437 22.31 170.22 5 3.16 0.1071 11n HT20 CH11 2462 16.68 46.56 5 3.16 0.0293 CH1 2422 16.43 43.95 5 3.16 0.0277 CH4 2437 18.60 72.44 5 3.16 0.0456 External 11n HT40 CH7 2452 15.62 36.48 5 3.16 0.0230 CH1 2412 15.11 32.43 12 15.85 0.1023 CH6 2437 17.65 58.21 12 15.85 0.1836 11b CH11 2462 14.54 28.44 12 15.85 0.0897 CH1 2412 18.59 72.28 12 15.85 0.2280 CH6 2437 23.11 204.64 12 15.85 0.6456 11g CH11 2462 18.25 66.83 12 15.85 0.2108 CH1 2412 18.29 67.45 12 15.85 0.2128 CH6 2437 23.33 215.28 12 15.85 0.6791 11n HT20 CH11 2462 18.08 64.27 12 15.85 0.2027 CH1 2422 17.38 54.70 12 15.85 0.1726 CH4 2437 19.04 80.17 12 15.85 0.2529 Horizontal 11n HT40 CH7 2452 16.53 44.98 12 15.85 0.1419 Note: MPE=PG/4πR 2 P=Output Power; G=Antenna Gain; R=20cm

Test Report

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of TP-LINK TECHNOLOGIES CO., LTD. 2.4GHz 150Mbps Indoor/Outdoor Wireless Access Point Model No.: TL-WA7210N FCC ID: TE7WA7210N Prepared for : TP-LINK TECHNOLOGIES CO., LTD. Building 24(floors 1,3,4,5) and 28 (floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ： ACS-F13292 Date of Test ： Oct.25~Nov.09, 2013 Date of Report ： Jan.15, 2014 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 TABLE OF CONTENTS Description Page 1. SUMMARY OF STANDARDS AND RESULTS ......................................................... 1-1 1.1. Description of Standards and Results ................................................................................... 1-1 2. GENERAL INFORMATION ......................................................................................... 2-1 2.1. Description of Device (EUT) ............................................................................................... 2-1 2.2. Test Information ................................................................................................................... 2-2 2.3. Tested Supporting System Details ........................................................................................ 2-2 2.4. Block Diagram of Test Setup ............................................................................................... 2-2 2.5. Test Facility .......................................................................................................................... 2-3 2.6. Measurement Uncertainty (95% confidence levels, k=2) ..................................................... 2-3 3. POWER LINE CONDUCTED EMISSION TEST ....................................................... 3-1 3.1. Test Equipments ................................................................................................................... 3-1 3.2. Block Diagram of Test Setup ............................................................................................... 3-1 3.3. Power Line Conducted Emission Test Limits ...................................................................... 3-1 3.4. Configuration of EUT on Test .............................................................................................. 3-1 3.5. Operating Condition of EUT ................................................................................................ 3-2 3.6. Test Procedure ...................................................................................................................... 3-2 3.7. Power Line Conducted Emission Test Results ..................................................................... 3-2 4. RADIATED EMISSION TEST ...................................................................................... 4-5 4.1. Test Equipment ..................................................................................................................... 4-5 4.2. Block Diagram of Test Setup ............................................................................................... 4-5 4.3. Radiated Emission Limit ...................................................................................................... 4-6 4.4. EUT Configuration on Test .................................................................................................. 4-7 4.5. Operating Condition of EUT ................................................................................................ 4-7 4.6. Test Procedure ...................................................................................................................... 4-7 4.7. Radiated Emission Test Results ........................................................................................... 4-8 5. CONDUCTED SPURIOUS EMISSIONS ..................................................................... 5-1 5.1. Test Equipment ..................................................................................................................... 5-1 5.2. Limit ..................................................................................................................................... 5-1 5.3. Test Procedure ...................................................................................................................... 5-1 5.4. Test result ............................................................................................................................. 5-1 6. BAND EDGE COMPLIANCE TEST ............................................................................ 6-1 6.1. Test Equipment ..................................................................................................................... 6-1 6.2. Limit ..................................................................................................................................... 6-1 6.3. Test Produce ......................................................................................................................... 6-1 6.4. Test Results .......................................................................................................................... 6-1 7. 6dB Bandwidth Test ........................................................................................................ 7-1 7.1. Test Equipment ..................................................................................................................... 7-1 7.2. Limit ..................................................................................................................................... 7-1 7.3. Test Procedure ........................................................…

Text truncated - open the document above for the full version.

Test Report

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-295 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-296 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-297 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-298 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-299 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-300 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-301 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 4-302 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-1 5. CONDUCTED SPURIOUS EMISSIONS 5.1. Test Equipment Item Equipment ManufacturerModel No.Serial No.Last Cal. Cal. Interval 1. Spectrum AnalyzerAgilent E4446AUS44300459 May.08, 13 1 Year 2. Attenuator Agilent 8491BMY39262165 May.08,13 1 Year 3. RF Cable Hubersuhner SUCOFLEX10228618/2May.08,13 1Year 5.2. Limit In any 100kHz bandwidth outside the frequency bands in which the spread spectrum intentional radiator in operating, the radio frequency power that is produced by the intentional radiator shall be at least 20dB below that in the 100kHz bandwidth within the band that contains the highest level of the desired power. 5.3. Test Procedure The transmitter output was connected to a spectrum analyzer, The resolution bandwidth is set to 100 kHz, The video bandwidth is set to 300 kHz and measure all the emissions detected. 5.4. Test result PASS (The testing data was attached in the next pages.) R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-2 Conducted emission test data: Vertical: Test Mode: IEEE 802.11b TX Test CH1: 2412MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-3 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-4 Test CH6: 2437MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-5 Test CH11: 2462MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-6 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-7 Test Mode: IEEE 802.11g TX Test CH1: 2412MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-8 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-9 Test CH6: 2437MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-10 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-11 Test CH11: 2462MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-12 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-13 Test Mode: IEEE 11nTH20 Test CH1: 2412MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-14 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-15 Test CH6: 2437MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-16 Test CH11: 2462MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-17 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-18 Test Mode: IEEE 11nTH40 Test CH1: 2422MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-19 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-20 Test CH4: 2437MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-21 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-22 Test CH7: 2452MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-23 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-24 Horizontal: Test Mode: IEEE 802.11b TX Test CH1: 2412MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-25 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-26 Test CH6: 2437MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-27 Test CH11: 2462MHz R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 5-28 R AUDIX Technology (Shenzhen) Co., Ltd…

Text truncated - open the document above for the full version.

Test Setup Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 13-1 13. PHOTOGRAPH OF TEST 13.1.Photos of Power Line Conducted Emission Test R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 13-2 13.2.Photos of Radiated Emission Test R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WA7210N page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13356 13-3 (Above 1000MHz)

Contact Information

Applicant

Jing Huang(Regulatory Compliance Manager)

[email protected]75521534921Fax: 75526508930

Technical Contact

AUDIX Technology (Shenzhen) Co., Ltd.

[email protected]86-755-26639497

52 Block Shenzhen Science & Industry. · Shenzhen Guang Dong · China

Test Firm

Audix Technology (Shenzhen) Co., Ltd.Smart Tsai

[email protected]86-755-26639495Fax: 86-755-26632877

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	215.30 mW

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz Bandwidth.
