TE7WN62XGWireless USB Adapter

COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd. Copyright © 2005 TP-LINK Technologies Co., Ltd. All rights reserved. FCC STATEMENT This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ¾ Reorient or relocate the receiving antenna. ¾ Increase the separation between the equipment and receiver. ¾ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ¾ Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation . Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. CE Declaration of Conformity For the following equipment: TL-WN620G Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC), Low-voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC), the procedures given in European Council Directive 99/5/EC and 89/3360EEC. The equipment was passed. The test was performed according to the following European standards: ¾ EN 300 328 V.1.4.1 (2003) ¾ EN 301 489-1 V.1.4.1 (2002) / EN 301 489-17 V.1.2.1 (2002) ¾ EN 60950-1: 2001 European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range 2.400-2.4835GHz; In France, the equipment must be restricted to the 2.4465-2.4835GHz frequency range and must be restricted to indoor use. Package Contents............................................................................................................. 1 Chapter 1: Introduction...................................................................................................... 2 1.1 Overview of the product ....................................................................................... 2 1.2 Features............................................................................................................... 2 1.3 LED Status ........................................................................................................... 2 Chapter 2: Installation Guide............................................................................................. 3 2.1 Hardware Installation ........................................................................................... 3 2.2 Software Installation............................................................................................. 3 2.2.1 Overview .................................................................................................... 3 2.2.2 Software Installation for Windows 2000..................................................... 3 Chapter 3: Configuration ................................................................................................... 8 3.1 Current Status ...................................................................................................... 8 3.2 Profile Management ........................................................................................... 10 3.2.1 Add or Modify a Configuration Profile....................................................... 10 3.2.2 Remove a profile...................................................................................... 13 3.2.3 Switch another Profile .............................................................................. 13 3.2.4 Import a Profile......................................................................................... 13 3.2.5 Export a Profile ........................................................................................ 14 3.2.6 Scan Available Networks ......................................................................... 14 3.2.7 Auto Profile Selection Management......................................................... 15 3.3 Diagnostics ........................................................................................................ 16 3.3.1 Check Driver Information ......................................................................... 16 3.3.2 Check Receive and Transmit Statistical Information ................................ 17 Appendix A: Specifications .............................................................................................. 18 Appendix B: Glossary...........................................…

Text truncated - open the document above for the full version.

TP-LINK TECHNOLOGIES CO., LTD. BUILDING 7, SECTION 2, HONGHUALING INDUSTRIAL PARK, SHENZHEN, CHINA POWER OF ATTORNEY Date: July 16, 2005 We, the undersigned, hereby authorize Compliance Certification Services, Inc. to act on our behalf in all matters relating to all processes related to FCC applications and communications issue. Any and all acts carried out by Compliance Certification Services, Inc. on our behalf shall have the same effects as acts of our own. If you have any questions regarding this authorization, please don’t hesitate to contact us. Thank you. Best Regards

TP-LINK TECHNOLOGIES CO., LTD. BUILDING 7, SECTION 2, HONGHUALING INDUSTRIAL PARK, SHENZHEN, CHINA Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: TE7WN62XG To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards

FCC ID: TE7WN62XG Label location LABEL LOCATION

Antenna description TL-WN620G uses microstrip antenna. The radio utilizes the integral antenna with a maximum gain of 0 dBi

Compliance Certification Services (Shenzhen) Inc. Report No: SZ050803B01-RP FCC ID: TE7WN62XG Date of Issue: September 10, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 67 FCC 47 CFR PART 15 SUBPART C TEST REPORT For 108M Wireless USB Adapter Model: TL-WN620G Trade Name: TP-LINK Prepared for TP-LINK TECHNOLOGIES CO., LTD. BUILDING 7, SECTION 2, HONGHUALING INDUSTRIAL PARK, XILI, NANSHAN DISTRICT, SHENZHEN, P.R.C. Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 6, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No: SZ050803B01-RP FCC ID: TE7WN62XG Date of Issue: September 10, 2005 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES 8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT.........................................................................................................9 6.2 SUPPORT EQUIPMENT .................................................................................................................9 7. FCC PART 15.247 REQUIREMENTS...................................................................................... 10 7.1 6DB BANDWIDTH.............................................................................................................................10 7.2 PEAK POWER....................................................................................................................................16 7.3 BAND EDGES MEASUREMENT ................................................................................................22 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................31 7.5 SPURIOUS EMISSIONS.................................................................................................................37 7.6 POWERLINE CONDUCTED EMISSIONS..............................................................................................62 APPENDIX 1 PHOTOGRPHS OF TEST SETUP .......................................................................... 66 Compliance Certification Services (Shenzhen) Inc. Report No: SZ050803B01-RP FCC ID: TE7WN62XG Date of Issue: September 10, 2005 Page 3 1. TEST RESULT CERTIFICATION Applicant: TP-LINK TECHNOLOGIES CO., LTD. BUILDING 7, SECTION 2, HONGHUALING INDUSTRIAL PARK, XILI, NANSHAN DISTRICT, SHENZHEN, P.R.C. Equipment Under Test: 108M Wireless USB Adapter Trade Name: TP-LINK Model: TL-WN620G Date of Test: August 03-September 09, 2005 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services (Shenzhen) Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Reviewed and Approved by Clinton Kao Manager of the Engineering Dept. Compliance Certification Services (ShenZhen) Inc. Compliance Certification Services (Shenzhen) Inc. Report No: SZ050803B01-RP FCC ID: TE7WN62XG Date of Issue: September 10, 2005 Page 4 2. EUT DESCRIPTION Product 108M Wireless USB Adapter Trade Name TP-LINK Model Number TL-WN620G EUT Power Rating Powered from the notebook Frequency Range 802.11b mode: 2412 ~ 2462 MHz 802.11g mode: 2412 ~ 2462 MHz Transmit Power 802.11b mode:10.60 dBm 802.11g mode:10.89 dBm Modulation Technique 802.11b: DSSS (CCK; DQPSK; DBPSK) 802.11g: OFDM Transmit Data Rate 802.11b: 11Mbps(CCK) with fall back rates of 5.5, 2, and 1Mbps 802.11g : 108Mbps with fall back rates of 54/48/36/24/18/12/9/6 Mbps (OFDM) Number of Channels 11 Channels Antenna Specification 0 dBi (Max) Note: This submit…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No: SZ050803B01-RP FCC ID: TE7WN62XG Date of Issue: September 10, 2005 Page 66 APPENDIX 1 PHOTOGRPHS OF TEST SETUP LINE CONDUCTED EMISSION TEST Compliance Certification Services (Shenzhen) Inc. Report No: SZ050803B01-RP FCC ID: TE7WN62XG Date of Issue: September 10, 2005 Page 67 RADIATED EMISSION TEST
