TE7WN727NV3150Mbps Wireless N USB Adapter

TP-Link Technologies Co., Ltd.
150Mbps Wireless N USB Adapter - FCC ID TE7WN727NV3 - TP-Link Technologies Co., Ltd.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Oct 20, 2011
Application Purpose
Original Equipment
Date of Application
Oct 19, 2011
Equipment Note
150Mbps Wireless N USB Adapter
Frequency Range
2422.00000000 - 2452.00000000
Company
TP-Link Technologies Co., Ltd.
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TL-WN727N 150Mbps Wireless N USB Adapter 1910010464 Rev: 3.0.0 I COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2011 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. H Uhttp://www.tp-link.comUH FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. II FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment has been SAR-evaluated for use in hand. SAR measurements are based on a 5mm spacing from the body and that compliance is achieved at that distance. CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. National restrictions This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below: Country Restriction Reason/remark Bulgaria General authorization required for outdoor use and public service France Outdoor use limited to 10 mW e.i.r.p. within the band 2454-2483.5 MHz Military Radiolocation use. Refarming of the 2.4 GHz band has been ongoing in recent years to allow current relaxed regulation. Full implementation planned 2012 Italy If used outside of own premises, general authorization is required Luxembourg None General authorization required for network and service supply(not for spectrum) Norway Implemented This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Ålesund Russian Federation Only for indoor applications Note: Please don’t use the product outdoors in France. TP-LINK TECHNOLOGIES CO., LTD TP-LINK TECHNOLOGIES CO., LTD South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan, Shenzhen, P. R. China DECLARATION OF CONFORMITY For the following equipment: Product Description: 150Mbps Wireless N USB Adapter Model No.: TL-WN727N Trademark: TP-LINK We declare under our own responsibility that the above products satisfy all the technical regulations applicable to the product within the scope of Council Directives: Directives 1999/5/EC The above product is in conformity with the following standards or other normative documents: ETSI EN 300 328 V1.7.1: 2006 ETSI EN 301 489-1 V1.8.1:2008 & ETSI EN 301 489-17 V2.1.1:2009 EN60950-1:2006+A11:2009+A1:2010 EN62311:2008 Recommendation 1999/519/EC Person is responsible for marking this declaration: Yang Hongliang Product Manager of International Business NCC Notice: CONTENTS Package Contents .................................................................................................... 1 Chapter 1 Introduction .......................................................................................... 2 1.1 Product Overview .............................................................................................. 2 1.2 Main Features ................................................................................................... 2 1.3 LED Status ........................................................................................................ 2 Chapter 2 Installation Guide ................................................................................. 3 2.1 Hardware Installation ........................................................................................ 3 2.2 Software Installation .......................................................................................... 3 2.2.1 Overview ............................................................................................................. 3 2.2.2 Installation Guide ....................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

[email protected] www.adt.com.tw TO: ALL CLIENTS Starting from August 19, 1996, products like PC and PC peripherals could use DoC method for marketing in United States. But the following documents should be prepared before shipping: 1. Test report – issued by NVLAP or A2LA accreditated laboratory. 2. Declaration of Conformity (DoC) Dorm – Should contain importers signature. 3. Original Design drawing (eg. Schematic and block diagram, Users Manual or Service Manual of product) 4. During production of units, the checking procedure should be described to guarantee that each unit of equipment marked under a DoC is identical to the unit tested or within variation that can be expected due to quantity production and testing on a statistical basis. 5. All modifications performed due to EMI should be recorded and tested if necessary. Note: ♦ Doc label should be stuck on the product. (See attachment) ♦ FCC statement should be included on the label as well as Users Manual. (The contents are same as that of FCC ID application) ♦ The responsible person signing the DoC form should take the responsibility that the sold products will have the same EMI characteristics as that of the tested sample and thus comply with the FCC limits. ♦ The above documents should be submitted to FCC during inspection within 14 days. If sample requested, the sample should be submitted to FCC within 60 days. The shipping charges will be bore by the DoC declarer. ♦ The above documents should be held by the responsible person signing the DoC. (附件一:FCC DoC Label 樣本) (For stand-alone test unit) (For unit assembled by modules with DoC) [email protected] www.adt.com.tw FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: 150Mbps Wireless N USB Adapter MODEL NO.: TL-WN727N TRADE NAME: TP-LINK IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: FD110701C18, ISSUED ON Jul. 29, 2011. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION: __________________________________________________________________ (COMPANY NAME) __________________________________________________________________ (COMPANY ADDRESS) TEL: _________________________ FAX:____________________________ __________________________________________________________________ (NAME) (TITLE) __________________________________________________________________ (SIGNATURE) (DATE)

Cover Letter(s)

Date: 2011-8-31 Federal Communications Commission Authorization and Evaluation Division FCC ID: TE7WN727NV3 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP-LINK Technologies Co., Ltd. Tel: 86-755-26525554 Fax: 86-755-26508930 Web site: WWW.TP-LINK.COM E-mail: [email protected]

Cover Letter(s)

AGENCY AUTHORIZATION LETTER FCC ID:TE7WN727NV3 Date: 2011-8-31 To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch(No. 19, Hwa Ya 2 nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C) to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV ADT within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP-LINK Technologies Co., Ltd. Tel: 86-755-26525554 Fax: 86-755-26508930 Web site: WWW.TP-LINK.COM E-mail: [email protected]

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

ID Label/Location Info

Label Location

ID Label/Location Info

TL-WN727N(EN)3.0产品规格标贴 第1版 100#合成纸+可打印雾膜 TL-WN727N(EN)3.0 2010-12-15 白色 PANTONE 426C 白色 王婧婧 等比例放大效果图: 1:1 39.7*9.7mm, 1R 12 E D C B A 12 3456789 E D C 345678 B A 9 料号: 设 计 审 核 颜 色 名 称 版 本 材 质 模 具 机型版本号 完成日期 logo 底色 文字 其它 记 录 与上一版的区别 文字转曲线 code128码,工程部打印 此图条码仅为示意

Internal Photos

Page 3 Page 4

RF Exposure Info

TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1107-1265SAR01R1 Page 1 of 69 TESTING No. L2264 TEST REPORT Product Name 150Mbps Wireless N USB Adapter Model TL-WN727N FCC ID TE7WN727NV3 Client TP-LINK TECHNOLOGIES CO., LTD. TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1107-1265SAR01R1 Page 2 of 69 GENERAL SUMMARY Product Name 150Mbps Wireless N USB Adapter Model TL-WN727N FCC ID TE7WN727NV3 Report No. RZA1107-1265SAR01R1 Client TP-LINK TECHNOLOGIES CO., LTD. Manufacturer TP-LINK TECHNOLOGIES CO., LTD. Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radio frequency Emissions. KDB 248227 D01 SAR meas for 802 11 a b g v01r02: SAR Measurement Procedures for 802.11a/b/g Transmitters. KDB 447498 D02 SAR Procedures for Dongle Xmtr v02: SAR Measurement Procedures for USB Dongle Transmitters. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: September 26 th , 2011 Comment The test result only responds to the measured sample. Approved by Director Revised by SAR Manager Performed by SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1107-1265SAR01R1 Page 3 of 69 TABLE OF CONTENT 1. General Information ........................................................................................................................ 5 1.1. Notes of the Test Report.......................................................................................................... 5 1.2. Testing Laboratory ................................................................................................................... 5 1.3. Applicant Information ............................................................................................................... 6 1.4. Manufacturer Information ......................................................................................................... 6 1.5. Information of EUT................................................................................................................... 7 1.6. The Maximum SAR 1g Values ................................................................................................... 8 1.7. The Maximum Power of Each Tested Mode ............................................................................ 8 1.8. Test Date ................................................................................................................................. 8 2. Operational Conditions during Test ................................................................................................. 9 2.1. General Description of Test Procedures .................................................................................. 9 2.2. Position of Module in Portable Devices.................................................................................. 10 2.3. Picture of Host Product .......................................................................................................... 11 3. SAR Measurements System Configuration ................................................................................... 12 3.1. SAR Measurement Set-up .....................................................................................................12 3.2. DASY5 E-field Probe System ................................................................................................ 13 3.2.1. EX3DV4 Probe Specification .......................................................................................... 13 3.2.2. E-field Probe Calibration ................................................................................................. 14 3.3. Other Test Equipment ............................................................................................................14 3.3.1. Device Holder for Transmitters ....................................................................................... 14 3.3.2. Phantom .........................................................................................................................15 3.4. Scanning Procedure ..............................................................................................................15 3.5. Data Storage and Evaluation ................................................................................................. 17 3.5.1. Data Storage...................................................................................................................17 3.5.2. Data Evaluation by SEMCAD ......................................................................................... 17 3.6. System Check........................................................................................................................ 20 3.7. Equivalent Tissues ................................................................................................................. 22 4. Laboratory Environment................................................................................................................ 22 5. Characteristics of the Test ............................................................................................................. 23 5.1. Applicable Limit Regulations .................................................................................................. 23 5.2. Applicable Measurement Standards.................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF110701C18 R1 1 Report Format Version 4.0.0 Cancels and replaces the report No.:RF110701C18 dated Jul. 29, 2011 FCC TEST REPORT REPORT NO.: RF110701C18 R1 MODEL NO.: TL-WN727N RECEIVED: Jul. 1, 2011 TESTED: Jul. 11 ~ 25, 2011 ISSUED: Sep. 27, 2011 APPLICANT: TP-LINK TECHNOLOGIES CO., LTD. ADDRESS: Building 24 (floors 1,3,4,5) and 28 (floors1-4) Central Science and Technology Park,Shennan Rd, Nanshan, Shenzhen,China ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City 244, Taiwan This test report consists of 77 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110701C18 R1 2 Report Format Version 4.0.0 Cancels and replaces the report No.:RF110701C18 dated Jul. 29, 2011 TABLE OF CONTENTS RELEASE CONTROL RECORD..................................................................................4 1. CERTIFICATION..........................................................................................5 2. SUMMARY OF TEST RESULTS.................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................6 3. GENERAL INFORMATION..........................................................................7 3.1 GENERAL DESCRIPTION OF EUT............................................................7 3.2 DESCRIPTION OF TEST MODES..............................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST..........................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...............9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS............................12 3.4 DESCRIPTION OF SUPPORT UNITS.......................................................12 4. TEST TYPES AND RESULTS....................................................................13 4.1 CONDUCTED EMISSION MEASUREMENT.............................................13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................13 4.1.2 TEST INSTRUMENTS...............................................................................14 4.1.3 TEST PROCEDURES...............................................................................15 4.1.4 DEVIATION FROM TEST STANDARD......................................................15 4.1.5 TEST SETUP.............................................................................................16 4.1.6 EUT OPERATING CONDITIONS...............................................................16 4.1.7 TEST RESULTS........................................................................................17 4.2 RADIATED EMISSION MEASUREMENT..................................................19 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................19 4.2.2 TEST INSTRUMENTS...............................................................................20 4.2.3 TEST PROCEDURES...............................................................................21 4.2.4 DEVIATION FROM TEST STANDARD......................................................21 4.2.5 TEST SETUP.............................................................................................22 4.2.6 EUT OPERATING CONDITIONS...............................................................22 4.2.7 TEST RESULTS........................................................................................23 4.3 6dB BANDWIDTH MEASUREMENT.........................................................36 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT.......................................36 4.3.2 TEST INSTRUMENTS...............................................................................36 4.3.3 TEST PROCEDURE..................................................................................36 4.3.4 DEVIATION FROM TEST STANDARD......................................................36 4.3.5 TEST SETUP.............................................................................................37 4.3.6 EUT OPERATING CONDITIONS...............................................................37 4.3.7 TEST RESULTS........................................................................................38 4.4 MAXIMUM OUTPUT POWER...................................................................42 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT..........42 4.4.2 INSTRUMENTS.........................................................................................42 4.4.3 TEST PROCEDURES...............................................................................42 4.4.4 DEVIATION FROM TEST STANDARD......................................................43 4.4.5 TEST SETUP.............................................................................................43 Report No.: RF110701C18 R1 3 Report Format Version 4.0.0 Cancels and replaces the report No.:RF110701C18 dated Jul. 29, 2011 4.4.6 EUT OPERATING CONDITIONS...............................................................43 4.4.7 TEST RESULTS........................................................................................44 4.5 POWER SPECTRAL DENSITY MEASUREMENT....................................46 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT..................46 4.5.2 TEST INSTRUMENTS...............................................................................46 4.5.3 TEST PROCEDURE..................................................................................46 4.5.4 DEVIATION FROM TEST STANDARD......................................................47 4.5.5 TEST SETUP.................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST

Contact Information

Applicant

Jing Huang(Regulatory Compliance Manager)
[email protected]75521534921Fax: 75526508930

Technical Contact

Bureau Veritas Consumer Products Services (H.K.) LChang Gary
+886 3 318 3232

81-1, Lu Laio Keng, 9th Ling, Wu Lung Tsuen · Hsinchu Hsien · Taiwan

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen
[email protected]886-3-3183232Fax: 886 3 2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.42 GHz - 2.45 GHz145.00 mW
Confidentiality
Long Term
Grant Notes
Power Output is conducted. The SAR data in this filing is applicable to demonstrate compliance for the USB Dongle only as shown in this filing. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The highest reported SAR values are: Body: 0.703 W/kg;
