TE7WN822NV3300Mbps High Gain Wireless USB Adapter

TP-Link Technologies Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Feb 03, 2013
Application Purpose: Original Equipment
Date of Application: Jan 31, 2013
Equipment Note: 300Mbps High Gain Wireless USB Adapter
Frequency Range: 2422.00000000 - 2452.00000000
Company: TP-Link Technologies Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TL-WN821/TL-WN822N/TL-WN823N 300Mbps Wireless N USB Adapter TL-WN821N TL-WN822N TL-WN823N Rev: 4.0.0 1910010780 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2013 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: x Reorient or relocate the receiving antenna. x Increase the separation between the equipment and receiver. x Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. x Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment has been SAR-evaluated for use in hand. SAR measurements are based on a 20cm spacing from the body and that compliance is achieved at that distance. CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Canadian Compliance Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1)This device may not cause interference, and (2)This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux norms CNR exemptes de licence d’Industrie Canada. Le fonctionnement est soumis aux deux conditions suivantes: (1)cet appareil ne doit pas provoquer d’interférences et (2)cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un fonctionnement non souhaité de l’appareil. Industry Canada Statement Complies with the Canadian ICES-003 Class B specifications. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device complies with RSS 210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Korea Warning Statements ╏䟊 ⶊ㍶㍺゚⓪ 㤊㣿㭧㩚䕢䢒㔶 Ṗ⓻㎇㧊㧞㦢UG NCC Notice 15点ൟᓣ䁡䄝ড়ḐПԢࡳ⥛ᇘ丏䳏′′ˈ䴲15点䀅ৃˈ݀ৌǃଚ㰳៪Փ⫼㗙ഛϡᕫ᪙㞾䅞᳈丏⥛ǃࡴ໻ ࡳ⥛៪䅞᳈ॳ䀁㿜П⡍ᗻঞࡳ㛑DŽ Ԣࡳ⥛ᇘ丏䳏′′ПՓ⫼ϡᕫᕅ䷓亯㟾ᅝܼঞᑆ᫒ড়⊩䗮ֵ˗15点ⱐ⧒᳝ᑆ᫒⧒䈵ᰖˈឝゟेذ⫼ˈ Ϻᬍ୘㟇⛵ᑆ᫒ᰖᮍᕫ㑐㑠Փ⫼DŽࠡ䷙ড়⊩䗮ֵˈᣛձ䳏ֵ⊩㽣ᅮ԰ὁП⛵㎮䳏䗮ֵDŽԢࡳ⥛ᇘ 丏䳏′′䷜ᖡফড়⊩䗮ֵ៪Ꮉὁǃ里ᅌঞ䝿Ⱆ⫼䳏⊶䔏ᇘᗻ䳏′′䀁٭Пᑆ᫒DŽ ɉɪɨɞɭɤɬ ɫɟɪɬɢɮɿɤɨɜɚɧɨ ɡɝɿɞɧɨ ɫ ɩɪɚɜɢɥɚɦɢ ɫɢɫɬɟɦɢ ɍɤɪɋȿɉɊɈ ɧɚ ɜɿɞɩɨɜɿɞɧɿɫɬɶ ɜɢɦɨɝɚɦ ɧɨɪɦɚɬɢɜɧɢɯ ɞɨɤɭɦɟɧɬɿɜ ɬɚ ɜɢɦɨɝɚɦ,ɳɨ ɩɟɪɟɞɛɚɱɟɧɿ ɱɢɧɧɢɦɢ ɡɚɤɨɧɨɞɚɜɱɢɦɢ ɚɤɬɚɦɢ ɍɤɪɚʀɧɢ. Safety Information z When product has power button, the power button is one of the way to shut off the product; when there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source. z Don’t disassemble the product, or make repairs yourself. You run the risk of electric shock and voiding the limited warranty. If you need service, please contact us. z Avoid water and wet locations. This product can be used in the following countries: AT BG BY CA CZ DE DK EE ES FI FR GB GR HU IE IT LT LV MT NL NO PL PT RO RU SE SK TR UA TP-LINK TECHNOLOGIES CO., LTD TP-LINK TECHNOLOGIES CO., LTD. Building 24 (floors 1, 3, 4, 5), and 28 (floors 1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China DECLARATION OF CONFORMITY For the following equipment: Product Description: 300Mbps Wireless N USB Adapter Model No.: TL-WN821/TL-WN822N/TL-WN823N Trademark: TP-LINK We declare under our own responsibility that the above products satisfy all the technical regulations applicable to the product within the scope of Council Directives: Directives 1999/5/EC, Directives 2006/95/EC, Directives1999/519/EC, Directives 2011/65/EU The above product is in conformity with the following standards or other normative documents: ETSI EN 300 328 V1.7.1: 2006 ETSI EN 301 489-1 V1.9.2:2011 & ETSI EN 301 489-17 V2.1.1:2009 EN 60950-1:2006+…

Text truncated - open the document above for the full version.

Cover Letter(s)

AGENCY AUTHORIZATION LETTER FCC ID: TE7WN822NV3 Date: 2013-1-18 To whom it may concern: We, the undersigned, hereby authorize Audix Technology (Shenzhen) Co., Ltd (No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park,Nantou,Shenzhen, Guangdong, China) to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Audix within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name of authorized signer: Yo ngq u an Wang Title of authorized signer: Product Dept. Manager Company Name: TP‐LINK Technologies Co., Ltd. Tel: 86‐755‐26525554 Fax: 86‐755‐26508930 Web site: WWW.TP‐LINK.COM E‐mail: public@tp‐link.com.cn

Cover Letter(s)

Date: January 18, 2013 Federal Communications Commission Authorization and Evaluation Division FCC ID: TE7WN822NV3 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP‐LINK Technologies Co., Ltd. Tel: 86‐755‐26525554 Fax: 86‐755‐26508930 Web site: WWW.TP‐LINK.COM E‐mail: public@tp‐link.com.cn

Cover Letter(s)

Attestation for FCC Declaration of Conformity FCC ID: TE7WN822NV3 Date: 2013-01-16 Please be notified that we, the undersigned, TP-LINK TECHNOLOGIES CO., LTD declare that the product bears the above FCC ID is also complying with the requirements of FCC DoC. The test report number for FCC DoC is EM-F1010958, with is issued by an accredited lab, Audix Technology Corporation, EMC Department located at No. 53-11, Tin-Fu Tsun, Lin-Kou , Taipei Hsien , Taiwan. Which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827. Sincerely, Name of authorized signer: Yongquan Wang Title of authorized signer: Product Dept. Manager Company Name: TP‐LINK Technologies Co., Ltd. Tel: 86‐755‐26525554 Fax: 86‐755‐26508930 Web site: WWW.TP‐LINK.COM E‐mail: public@tp‐link.com.cn

External Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 14-1 14. PHOTOS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 14-2 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT

ID Label/Location Info

C B A 12 C 345678 B E D D A 9 料号： 12345 与上一版的区别 E 6789 颜色名称版本材质模具机型版本号 logo 底色文字其它结构工程师硬件工程师产品工程师平面负责人记录审核完成日期设计 IC:8853A - WN822N FCC ID:TE7WN822NV3 ModelTL-WN822N Label Location

Internal Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 14-3 Figure 5 USB Cable Figure 6 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 14-4 Figure 7 Components Side of the PCB Figure 8 Components Side of the PCB

RF Exposure Info

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 11-1 11. MPE ESTIMATION 11.1.Limit for General Population/ Uncontrolled Exposures Frequency Power density (mW/ cm 2 ) Averaging time(minutes) 300MHz----1.5GHz F/1500 30 1.5GHz---100GHz 1.0 30 Frequency(MHz) Power density (mW/ cm 2 ) Averaging time(minutes) 2412 1 30 2437 1 30 2462 1 30 Note: F= Frequency in MHz 11.2. Estimation Result EUT: 300Mbps High Gain Wireless USB Adapter M/N: TL-WN822N Test date: 2012-13-31 Pressure: 101.2±1.0 kpa Humidity: 51.6±3.0% Tested by: Leo-Li Test site: RF Site Temperature：20.8±0.6 °C Cable loss: 1 dB Attenuator loss: 20 dB Test Mode CH Frequency （MHz） Peak Output Power (dBm) Output Power (mW) Antenna Gain (dBi) Antenna Gain (Linear) MPE CH1 2412 20.26 106.17 2.5 1.78 0.0376 CH6 2437 18.10 64.57 2.5 1.78 0.0229 11b CH11 2462 18.37 68.71 2.5 1.78 0.0243 CH1 2412 21.29 134.59 2.5 1.78 0.0476 CH6 2437 22.60 181.97 2.5 1.78 0.0644 11g CH11 2462 21.52 141.91 2.5 1.78 0.0502 CH1 2412 23.35 216.27 2.5 1.78 0.0766 CH6 2437 25.42 348.34 2.5 1.78 0.1233 11n HT20 CH11 2462 24.27 267.30 2.5 1.78 0.0946 CH1 2422 22.52 178.65 2.5 1.78 0.0632 CH4 2437 23.18 207.97 2.5 1.78 0.0736 11n HT40 CH7 2452 22.84 192.31 2.5 1.78 0.0681

Test Report

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 1-1 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of TP-LINK TECHNOLOGIES CO., LTD. 300Mbps High Gain Wireless USB Adapter Model No.: TL-WN822N FCC ID: TE7WN822NV3 Prepared for : TP-LINK TECHNOLOGIES CO., LTD. Building 24(floors 1,3,4,5) and 28 (floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number Κ ACS-F13010 Date of Test Κ Dec.21, 2012~Jan.05, 2013 Date of Report Κ Jan.17, 2012 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 1-2 TABLE OF CONTENTS Description Page 1.SUMMARY OF STANDARDS AND RESULTS ......................................................... 1-5 1.1.Description of Standards and Results ...................................................................................1-5 2.GENERAL INFORMATION ......................................................................................... 2-1 2.1.Description of Device (EUT) ...............................................................................................2-1 2.2.Test Information ...................................................................................................................2-2 2.3.Tested Supporting System Details........................................................................................2-3 2.4.Block Diagram of Test Setup ...............................................................................................2-3 2.5.Test Facility ..........................................................................................................................2-4 2.6.Measurement Uncertainty (95% confidence levels, k=2).....................................................2-4 3.POWER LINE CONDUCTED EMISSION TEST....................................................... 3-1 3.1.Test Equipments ...................................................................................................................3-1 3.2.Block Diagram of Test Setup ...............................................................................................3-1 3.3.Power Line Conducted Emission Test Limits ......................................................................3-1 3.4.Configuration of EUT on Test..............................................................................................3-1 3.5.Operating Condition of EUT ................................................................................................3-2 3.6.Test Procedure ......................................................................................................................3-2 3.7.Power Line Conducted Emission Test Results .....................................................................3-2 4.RADIATED EMISSION TEST ...................................................................................... 4-1 4.1.Test Equipment.....................................................................................................................4-1 4.2.Block Diagram of Test Setup ...............................................................................................4-1 4.3.Radiated Emission Limit ......................................................................................................4-2 4.4.EUT Configuration on Test ..................................................................................................4-3 4.5.Operating Condition of EUT ................................................................................................4-3 4.6.Test Procedure ......................................................................................................................4-3 4.7.Radiated Emission Test Results ...........................................................................................4-4 5.CONDUCTED SPURIOUS EMISSIONS ..................................................................... 5-1 5.1.Test Equipment.....................................................................................................................5-1 5.2.Limit .....................................................................................................................................5-1 5.3.Test Procedure ......................................................................................................................5-1 5.4.Test result .............................................................................................................................5-1 6.BAND EDGE COMPLIANCE TEST............................................................................ 6-1 6.1.Test Equipment.....................................................................................................................6-1 6.2.Limit .....................................................................................................................................6-1 6.3.Test Produce .........................................................................................................................6-1 6.4.Test Results ..........................................................................................................................6-1 7.6dB Bandwidth Test ........................................................................................................ 7-1 7.1.Test Equipment.....................................................................................................................7-1 7.2.Limit .....................................................................................................................................7-1 7.3.Test Procedure ......................................................................................................................7-1 …

Text truncated - open the document above for the full version.

Test Report

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 5-45 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-1 6. BAND EDGE COMPLIANCE TEST 6.1.Test Equipment Item Equipment Manufacturer Model No.Serial No. Last Cal. Cal. Interval 1. Spectrum Agilent E4446A US44300459 May.08, 12 1 Year 2. Amp HP 8449B 3008A08495 May.08, 12 1 Year 3. Antenna EMCO 3115 9510-4580 May.08, 12 1Year 4. HF Cable Hubersuhne Sucoflex104- May.08, 12 1 Year 6.2.Limit All the lower and upper band-edges emissions appearing within 2310MHz to 2390MHz and 2483.5MHz to 2500MHz restricted frequency bands shall not exceed the limits shown in 15.209, all the other emissions outside operation frequency band 2400MHz to 2483.5MHz shall be at least 20dB below the fundamental emissions, or comply with 15.209 limits. 6.3.Test Produce 1. The EUT is placed on a turntable, which is 0.8m above the ground plane and worked at highest radiated power. 2. The turntable was rotated for 360 degrees to determine the position of maximum emission level. 3. EUT is set 3m away from the receiving antenna, which is varied from 1m to 4m to find out the highest emission. 4. Set the spectrum analyzer in the following setting in order to capture the lower and upper band-edges of the emission: (a) PEAK: RBW=1MHz; VBW=3MHz; Sweep=AUTO (b) AVERAGE: RBW=1MHz; VBW=10Hz; Sweep=AUTO 6.4.Test Results Pass (The testing data was attached in the next pages.) R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-2 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-3 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-4 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-5 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-6 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-7 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-8 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-9 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-10 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-11 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-12 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-13 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-14 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-15 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-16 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-17 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-18 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-19 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-20 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-21 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-22 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-23 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-24 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-25 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-26 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-27 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-28 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-29 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-30 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-31 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-32 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 6-33 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 7-1 7. 6dB Bandwidth Test 7.1.Test Equipment Item Equipment Manufacturer Model No.Serial No. Last Cal. Cal. Interval 1. Spectrum Analyzer Agilent N9030A MY5138022 May.08, 12 1 Year 2. Amp HP 8449B 3008A0…

Text truncated - open the document above for the full version.

Test Setup Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 13-1 13. PHOTOGRAPH OF TEST 13.1.Photos of Power Line Conducted Emission Test R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 13-2 13.2.Photos of Radiated Emission Test R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:TE7WN822NV3 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13010 13-3 (Above 1000MHz)

Contact Information

Applicant

Jing Huang(Regulatory Compliance Manager)

[email protected]75521534921Fax: 75526508930

Technical Contact

Audix TechnologySunny Lu

[email protected]8675526639497

52 Block Shenzhen Science and Industry · Shenzhen · China

Test Firm

Audix Technology (Shenzhen) Co., Ltd.Smart Tsai

[email protected]86-755-26639495Fax: 86-755-26632877

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.42 GHz - 2.45 GHz	208.00 mW

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. This device has a 20 MHz and 40 MHz bandwidth mode. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance.
