TFB-1001TiWi-C-W Module

TiWi-C-W Module APPLICATION GUIDE The information in this document is subject to change without notice. TiWi-C-W User Manual.docx Copyright © 2015 LSR Page 1 of 33 TIWI-C-W MODULE APPLICATION GUIDE Last updated February 23, 2015 TiWi-C-W Module APPLICATION GUIDE The information in this document is subject to change without notice. TiWi-C-W User Manual.docx Copyright © 2015 LSR Page 2 of 33 Table of Contents 1 Introduction ................................................................................................................... 3 1.1 Purpose & Scope ....................................................................................................................... 3 1.2 Applicable Documents ............................................................................................................... 3 2 TiWi-C-W Module and Accessories .............................................................................. 4 3 TiWi-C-W Approved Antenna Specifications ............................................................... 5 3.1 Chip Antenna Specifications...................................................................................................... 5 3.2 LSR FlexPIFA Antenna Specifications ...................................................................................... 7 3.3 Dipole Antenna Specifications ................................................................................................. 11 4 PCB Layout Requirements ......................................................................................... 14 4.1 4-Layer Trace Antenna Design................................................................................................ 15 4.2 2-Layer Trace Antenna Design................................................................................................ 21 5 EMC Compliance ......................................................................................................... 26 5.1 Summary ................................................................................................................................. 26 5.2 Module Integration Considerations - Antenna Systems .......................................................... 26 5.3 Module Integration Considerations - Substitute Antenna Systems ......................................... 26 5.4 Module Integration Considerations - Circuit Implementation .................................................. 27 5.5 Module Integration Considerations - Top Assembly................................................................ 27 5.6 Testing Requirements for End-Product ................................................................................... 27 5.7 Design and Production Validation ........................................................................................... 27 5.8 Agency Certifications ............................................................................................................... 28 5.9 Agency Statements ................................................................................................................. 28 5.10 OEM Responsibilities To Comply With FCC and Industry Canada Regulations .................... 30 5.11 OEM Labeling Requirements For End-Product ....................................................................... 31 5.12 OEM End-Product User Manual Statements ........................................................................... 32 6 Contacting LSR ........................................................................................................... 33 TiWi-C-W Module APPLICATION GUIDE The information in this document is subject to change without notice. TiWi-C-W User Manual.docx Copyright © 2015 LSR Page 3 of 33 1 Introduction 1.1 Purpose & Scope The purpose of this document is to provide details regarding the design and integration of certified antennas to the TiWi-C-W module. It covers all three certified antenna options, which consist of a ceramic chip, dipole, and LSR FlexPIFA antenna. It will inform the designer as to the required PCB details required to retain the LSR modular certification for the TiWi-C-W module. 1.2 Applicable Documents  LSR 2.4 GHz FlexPIFA Antenna Datasheet (330-0149)  LSR 2.4 GHz Dipole Antenna Datasheet (330-0016)  LSR U.FL to RPSMA Cable Datasheet (330-0018) TiWi-C-W Module APPLICATION GUIDE The information in this document is subject to change without notice. TiWi-C-W User Manual.docx Copyright © 2015 LSR Page 4 of 33 2 TiWi-C-W Module and Accessories The TiWi-C-W Module is a System in Package (SIP) module. The TiWi-C-W module is certified with three antennas. Part Number Description LSR 450-0118R LSR 450-0118C TiWi-C-W Module, Tape & Reel TiWi-C-W Module, Cut Tape Johanson 2450AT18A100 2.4 GHz Ceramic Chip Antenna LSR 001-0014 2.4 GHz FlexPIFA Antenna with U.FL Cable LSR 001-0001 2.4 GHz Dipole Antenna with Reverse Polarity SMA Connector LSR 080-0001 U.FL to Reverse Polarity SMA Bulkhead Cable 105 mm Hirose U.FL-R-SMT(10) PCB Mounted U.FL Connector Table 1 TiWi-C-W Module and Accessories TiWi-C-W Module APPLICATION GUIDE The information in this document is subject to change without notice. TiWi-C-W User Manual.docx Copyright © 2015 LSR Page 5 of 33 3 TiWi-C-W Approved Antenna Specifications 3.1 Chip Antenna Specifications The Johanson 2450AT18A100 Ceramic Chip Antenna is one option for a trace antenna design for use with the TiWi-C-W module. Specification Value Manufacturer and Part Number Johanson 2450AT18A100 Peak Gain .5 dBi Type Ceramic Chip Polarization Linear Frequency 2400-2500MHz Table 2 Chip Antenna Specifications 3.1.1 Chip Antenna Typical Radiation Patterns Figure 1 Chip Antenna XY Cut Radiation Pattern TiWi-C-W Module APPLICATION GUIDE The information in this document is subject to change without notice. TiWi-C-W User Manual.docx Copyright © 2015 LSR Page 6 of 33 Figure 2 Chip Antenna XZ Cut Radiation Pattern Figure 3 Chip Antenna YZ Cut Radiation Pattern 3.1.2 Mechanical Di…

Text truncated - open the document above for the full version.

LS Research, LLC | W66 N220 Commerce Court | Cedarburg WI 53012 O: 262.375.4400 | F: 262.375.4248 | www.lsr.com Request for Confidentiality Date: February 24, 2015 Subject: Confidentiality Request for: FCC ID: __TFB-1001 IC ID: ___5969A-1001 To Whom It May Concern, Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 6.4, the applicant requests that a part of the subject FCC and/or IC application be held confidential. The applicant requests the exhibits listed below be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Block Diagram TiWi-C-W Schematic V0a.pdf Theory of Operation LS Research, LLC has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Sincerely, By: _____ __William Steinike / President_____ (Signature) (Print name/Title)

EXTERNAL PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 1 of 7 4‐Layer Design (Chip Antenna) EXTERNAL PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 2 of 7 4‐Layer Design (u.fl Antenna) EXTERNAL PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 3 of 7 EXTERNAL PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 4 of 7 Back side of 4‐Layer Design EXTERNAL PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 5 of 7 2‐Layer Design (Chip Antenna) EXTERNAL PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 6 of 7 4‐Layer Design (u.fl Antenna) EXTERNAL PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 7 of 7

LS Research, LLC | W66 N220 Commerce Court | Cedarburg WI 53012 O: 262.375.4400 | F: 262.375.4248 | www.lsr.com February 24, 2015 Re: Internal Photos of the TiWi-C-W Module FCC ID: __TFB-1001 IC ID: ___5969A-1001 To Whom It May Concern, LSR does not have internal photos of the TiWi-C-W Module, as the modules are manufactured using a SIP (System In Package) process. This process results in the final modules being encapsulated in the packaging material during time of manufacture. Based on this we are unable to provide pictures of the module without the cover. Sincerely, William Steinike President, LS Research

W66 N220 Commerce Court ● Cedarburg, WI 53012 USA ● Phone: 262.375.4400 ● Fax: 262.375.4248 ● www.lsr.com Prepared For: LSR Name: TiWi-C-W Report: TR 314413 B Model: TiWi-C-W LSR: C-2114 Serial: See Section 2.1 Page 1 of 8 i. Title Page ENGINEERING TEST REPORT # TR 314413 B LSR Job #: C-2114 RF Exposure Compliance of : TiWi-C-W Test Date(s): December 2, 4 2014, January 6, 20, 21, 30, and February 3, 4, 16, 17 2015 Prepared For: LSR Attn: Josh Bablitch W66N220 Commerce Ct Cedarburg, WI 53012 This Test Report is issued under the Authority of: Adam Alger, EMC Engineer Signature: Date: 3-26-15 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: LSR Name: TiWi-C-W Report: TR 314413 B Model: TiWi-C-W LSR: C-2114 Serial: See Section 2.1 Page 2 of 8 ii. Table of Contents Table of Contents i. Title Page ................................................................................................................................... 1 ii. Table of Contents ....................................................................................................................... 2 iii. LS Research, LLC ...................................................................................................................... 3 1.0 Conformance Summary ............................................................................................................. 4 2.0 Equipment Under Test (EUT) Information ................................................................................ 4 2.1 Product Description ................................................................................................................... 4 2.2 Additional Information .............................................................................................................. 4 3.0 RF Conducted Measurement Data ............................................................................................. 5 4.0 MPE Calculation ........................................................................................................................ 6 5.0 Industry Canada Low Power Exemption ................................................................................... 7 Prepared For: LSR Report: TR 314413 B LSR: C-2114 iii. LS Research, LLC As an EMC Testing Laboratory, our Accreditation and following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) Listing of 3 Meter Semi-Anechoic Chamber based on Title 47 CFR FCC Registration Number: 90756 Industry Canada On file, 3 Meter Semi- Anechoic Chamber based on RSS File Number: IC 3088-A On file, 3 and 10 Meter OATS based on RSS File Number: IC 3088 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S./EU, Mutual Recognition Electromagnetic Compatibility 10.2). Date of Validation: January 16, 2001 Validated by the European Commission as a U.S. Notified Body operati /EU, Mutual Recognition Agreement (MRA) operating under the European Union Telecommunication Equipment Date of Validation: November 20, 2002 Notified Body Identification Number: 1243 Name: TiWi-C-W Model: TiWi-C-W Serial: See Section 2.1 Page 3 of 8 LS Research, LLC in Review As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 with Electrical (EMC) Scope of A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) – USA Anechoic Chamber based on Title 47 CFR – Part 2.948 FCC Registration Number: 90756 Anechoic Chamber based on RSS-212 – Issue 1 On file, 3 and 10 Meter OATS based on RSS-212 – Issue 1 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S./EU, Mutual Recognition Agreement (MRA) operating under the European Union Electromagnetic Compatibility –Council Directive 2004/108/EC (formerly 89/336/EEC, Article Date of Validation: January 16, 2001 Validated by the European Commission as a U.S. Notified Body operating under the U.S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union Telecommunication Equipment – Council Directive 99/5/EC, Annex V. Date of Validation: November 20, 2002 Notified Body Identification Number: 1243 Assessments are recognized through the with Electrical (EMC) Scope of Accreditation Part 2.948 Validated by the European Commission as a U. S. Competent Body operating under the U. Agreement (MRA) operating under the European Union Council Directive 2004/108/EC (formerly 89/336/EEC, Article ng under the U.S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union Prepared For: LSR Name: TiWi-C-W Report: TR 314413 B Model: TiWi-C-W LSR: C-2114 Serial: See Section 2.1 Page 4 of 8 1.0 Conformance Summary The EUT was found to MEET the MPE threshold for FCC §2.1091(mobile) using methods of FCC KDB 447498 D01 General RF Exposure Guidance v05r02 as a standalone device. 2.0 Equipment Under Test (EUT) Information The following information has been supplied by the applicant. Product Name: TiWi-C-W Model Number: TiWi-C-W Serial Number: 4-layer Chip Antenna (20E1F0018); U.FL (20E2D0037) 2-layer Chip Antenna (20E2D0073); U.FL (20E280006) FCC ID TFB-1001 IC Number 5969A-1001 2.1 Product Description The TiWi-C-W Module is a radio module that implements an 802.11 b/g/n WLAN (Wireless Local Area Network) transceiver in the 2.4 GHz band and multiple antenna options. Chip Antenna: Johanson Part # 2450AT18A100 (Peak Gain 0.5 dBi) U.FL Antenna port utilizes the following antenna options: LSR 2.4 GHz Dipole Antenna (Gain +2 dBi) LSR 2.4 GHz FlexPIFA 2 dBi Antenna w/U.FL Cable 2.2 Additional Information 1. Programmed for continuous transmit or receive on low (2412 MHz), middle (243…

Text truncated - open the document above for the full version.

W66 N220 Commerce Court ● Cedarburg, WI 53012 USA ● Phone: 262.375.4400 ● Fax: 262.375.4248 ● www.lsr.com Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 1 of 125 i. Title Page ENGINEERING TEST REPORT # TR 314413 A LSR Job #: C-2114 Compliance Testing of : TiWi-C-W Test Date(s): December 2, 4 2014, January 6, 20, 21, 30, February 3, 4, 16, 17, and March 16-25 2015 Prepared For: LSR Attn: Josh Bablitch W66N220 Commerce Ct Cedarburg, WI 53012 This Test Report is issued under the Authority of: Adam Alger, EMC Engineer Signature: Date: 4-22-15 Test Report Reviewed by: Michael Hintzke EMC Engineer Signature: Date: 2/21/15 Report by: Adam Alger, EMC Engineer Signature: Date: 2-18-15 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 2 of 125 ii. Table of Contents Table of Contents i. Title Page ................................................................................................................................... 1 ii. Table of Contents ....................................................................................................................... 2 iii. LS Research, LLC in Review .................................................................................................... 3 1.0 Summary of Test Report ............................................................................................................ 4 2.0 Test Facilities ............................................................................................................................. 4 3.0 Client Information ...................................................................................................................... 5 3.1 Equipment Under Test (EUT) Information ................................................................................ 5 3.2 Product Information ................................................................................................................... 5 3.3 Modifications Incorporated In the EUT for Compliance Purposes ........................................... 5 3.4 Deviations & Exclusions from Test Specifications ................................................................... 5 3.5 Additional Information .............................................................................................................. 6 4.0 Conditions of Test ...................................................................................................................... 6 5.0 Test Equipment .......................................................................................................................... 6 6.0 Conformance Summary ............................................................................................................. 7 Appendix A – Test Equipment ............................................................................................................. 8 Appendix B – Test Data ........................................................................................................................ 9 B.1 – RF Conducted Emissions ........................................................................................................ 9 B.2 – Radiated Emissions ............................................................................................................... 85 B.3 – AC Mains Conducted Emissions ........................................................................................ 120 Appendix C - Uncertainty Summary ................................................................................................ 123 Appendix D - References .................................................................................................................. 124 Prepared For: LSR Report: TR 314413 LSR: C-2114 iii. LS Research, LLC in Review As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) Listing of 3 Meter Semi-Anechoic Chamber based on Title 47 CFR FCC Registration Number: 90756 Industry Canada On file, 3 Meter Semi-Anechoic File Number: IC 3088-A On file, 3 and 10 Meter OATS based on RSS File Number: IC 3088 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body o S./EU, Mutual Recognition Agreement (MRA) operating under the European Union Electromagnetic Compatibility 10.2). Date of Validation: January 16, 2001 Validated by the Eur opean Commission as a U.S. Notified Body operating under the U.S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union Telecommunication Equipment Date of Validation: November 20, 2002 Notified Body Identification Number: 1243 Name: TiWi-C-W Model: TiWi-C-W Serial: See Section 3.1 Page 3 of 125 LS Research, LLC in Review LS Research, LLC in Review As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 with Electrical (EMC) Scope of A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) – USA Anechoic Chamber based on Title 47 CFR – Part 2.948 FCC Registration Number: 90756 Anechoic Chamber based on RSS-212 – Issue 1 On file, 3 and 10 Meter OATS based on RSS-212 – Issue 1 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S./EU, Mutual Recognition Agreement (MRA) operating under the European Union Electromagnetic Compatibility –Council Directive 2004/108/EC (formerly 89/336/EEC, Article Date of Validation: January 16, 2001 opean Commission as a U.S. Notified Body oper…

Text truncated - open the document above for the full version.

Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 93 of 125 Upper band edge - 4-layer board – Antenna 2 – Chip Antenna 802.11b – Average 802.11b – Peak 802.11g – Average 802.11g – Peak 802.11n – Average 802.11n – Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 94 of 125 Lower Band-Edge Restricted Band 4-layer board – Antenna 2 – Chip Antenna Average Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin b 1 2.390000 48.325 54 5.7 g 6 2.390000 48.431 5.6 n MCS 0 2.390000 47.179 6.8 Peak Mode (802.11) Mode (Mbps) Frequency (GHz) Peak Meas (dBμV/m) Limit Margin b 1 2.3892000 60.751 74 13.2 g 6 2.3896800 62.860 11.1 n MCS 0 2.3876000 61.030 13.0 Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 95 of 125 Lower band edge - 4-layer board – Antenna 2 – Chip Antenna 802.11b – Average 802.11b – Peak 802.11g – Average 802.11g – Peak 802.11n – Average 802.11n – Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 96 of 125 Upper Band-Edge Restricted Band 4-layer board – Antenna 2 – u.fl port with termination Average Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin b 1 2.494374 46.031 54 8.0 g 6 2.497789 46.061 54 7.9 n MCS 0 2.492889 46.046 54 8.0 Peak Mode (802.11) Mode (Mbps) Frequency (GHz) Peak Meas (dBμV/m) Limit Margin b 1 2.4846220 59.875 74 14.1 g 6 2.4910900 61.109 74 12.9 n MCS 0 2.4951820 59.684 74 14.3 Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 97 of 125 Upper Band Edge - 4-layer board – Antenna 2 – u.fl port with termination 802.11b – Average 802.11b – Peak 802.11g – Average 802.11g – Peak 802.11n – Average 802.11n – Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 98 of 125 Lower Band-Edge Restricted Band 4-layer board – Antenna 2 – u.fl port with termination Average Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin b 1 2.373440 45.650 54 8.4 g 6 2.372640 45.678 8.3 n MCS 0 2.374960 45.609 8.4 Peak Mode (802.11) Mode (Mbps) Frequency (GHz) Peak Meas (dBμV/m) Limit Margin b 1 2.3152000 59.070 74 14.9 g 6 2.3506400 59.375 14.6 n MCS 0 2.3446400 59.394 14.6 Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 99 of 125 Lower Band Edge - 4-layer board – Antenna 2 – u.fl port with termination 802.11b – Average 802.11b – Peak 802.11g – Average 802.11g – Peak 802.11n – Average 802.11n – Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 100 of 125 Upper Band-Edge 2-layer board – Antenna 1 802.11b (worst case mode) Average Antenna Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin Chip b 1 2.483500 50.350 54 3.7 U.FL b 1 2.494258 45.267 54 8.7 Peak Antenna Mode (802.11) Mode (Mbps) Frequency (GHz) Peak Meas (dBμV/m) Limit Margin Chip b 1 2.4878725 61.658 74 12.3 U.FL b 1 2.4925585 59.063 74 14.9 Plots Chip Antenna - Average Chip Antenna - Peak U.FL Ant. Port w/ termination - Average U.FL Ant. Port w/ termination - Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 101 of 125 Lower Band-Edge 2-layer – Antenna 1 802.11b (worst case mode) Average Antenna Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin Chip b 1 2.387200 51.923 54 2.1 U.FL b 1 2.386320 44.920 54 9.1 Peak Antenna Mode (802.11) Mode (Mbps) Frequency (GHz) Peak Meas (dBμV/m) Limit Margin Chip b 1 2.3897600 62.043 74 12.0 U.FL b 1 2.3875200 58.965 74 15.0 Plots Chip Antenna - Average Chip Antenna – Peak U.FL Ant. Port w/ termination - Average U.FL Ant. Port w/ termination - Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 102 of 125 Upper Band-Edge Restricted Band 2-layer board – Antenna 2 – Chip Antenna Average Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin b 1 2.483500 48.453 54 5.5 g 6 2.483500 47.081 6.9 n MCS 0 2.489094 46.191 7.8 Peak Mode (802.11) Mode (Mbps) Frequency (GHz) Peak Meas (dBμV/m) Limit Margin b 1 2.4835330 60.606 74 13.4 g 6 2.4895225 62.451 11.5 n MCS 0 2.4878065 59.944 14.1 Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 103 of 125 Upper Band Edge - 2-layer board – Antenna 2 – Chip Antenna 802.11b – Average 802.11b – Peak 802.11g – Average 802.11g – Peak 802.11n – Average 802.11n – Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 104 of 125 Lower Band-Edge Restricted Band 2-layer board – Antenna 2 – Chip Antenna Average Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin b 1 2.390000 47.147 54 6.9 g 6 2.390000 47.725 6.3 n MCS 0 2.390000 46.915 7.1 Peak Mode (802.11) Mode (Mbps) Frequency (GHz) Peak Meas (dBμV/m) Limit Margin b 1 2.3885600 59.085 74 14.9 g 6 2.3900000 62.857 11.1 n MCS 0 2.3879200 60.945 13.1 Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 105 of 125 Lower Band-Edge - 2-layer board – Antenna 2 – Chip Antenna 802.11b – Average 802.11b – Peak 802.11g – Average 802.11g – Peak 802.11n – Average 802.11n – Peak Prepared For: LSR Name: TiWi-C-W Report: TR 314413 Model: TiWi-C-W LSR: C-2114 Serial: See Section 3.1 Page 106 of 125 Upper Band-Edge Restricted Band 2-layer board – Antenna 2 – u.fl port with termination Average Mode (802.11) Mode (Mbps) Frequency (GHz) Average Meas (dBμV/m) Average Limit (dBμV/m) Margin b 1 2.…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 1 of 3 Flat – 2‐layer Design Horizontal – 2‐layer Design TEST SETUP PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 2 of 3 Vertical – 2‐layer Design Horizontal – 4‐layer Design (terminated) TEST SETUP PHOTOS Company Name LS Research, LLC Model # TiWi‐C‐W FCC ID # TFB‐1001 IC # 5969A‐1001 Page 3 of 3 Flat – 4‐layer Design (terminated) Vertical – 4‐layer Design (terminated)
