TLZ-BT715CBluetooth Module

- 1 - AW-BT715C Bluetooth Module Demo Board User Guide Version 0.1 - 2 - Document release Date Modification Initials Approved Version 0.1 2014/06/26 Initial Version N.C. Chen Chihhao Liao - 3 - Contents 1. Install driver and tool install active perl version: 5.8.4.810 before install Broadcom tool install Broadcom tool BLUETOOL version:1.7.3.3 install CP210X(USB to UART ) driver CP210X_VCP_Win2K_XP_S2K3 2. Connect the EVB to a PC Use the cable to connect EVB with PC - 4 - Check the com port that will be used. A.CONNECT TO A BLUETOOTH TESTER Run BlueTool, and then: - 5 - 1. From the BlueTool View menu, select Log Window. A record of issued commands will be maintained in the log window. 2. From the Transport menu, select HCI Control. a. In the Select HCI Control Window Transport window (screenshot below), select UART, the COM port that will be used, 115200, and CTS flow control. b. Click OK. - 6 - - 7 - B. Reset 1.In the HCI Control window a. Select 7.3 Host Controller & Baseband Commands (3 key) for HCI protocol active b.Double-click Reset. 2. Confirm that this step is done successfully by viewing the log window C. Download the Configuration File 1. In the HCI Control window a. Select 0: Vendor-specific Commands (0 key) for HCI protocol active b.Double-click Download Minidriver. 2. Confirm that this step is done successfully by viewing the log window - 8 - 3. From the BlueTool Transport menu, select Download Firmware/Config.... 4. In the Select Download Firmware/Config Transport window a. select UART, the COM port that will be used, 115200,and CTS flow control. b. Click OK. - 9 - 5. In the Download: com @115200 window, a. select 20702 A0/A1/B0 Runtime RAM for Device configuration b. mark From burn image c. key in 0x00090000 on SS location d. click Locate e. select the configuration f. click open g. click Execute h. close the window D. Verify the DUT condition by reading the BD address 1. In the HCI Control window a. mark HCI protocol active ,select 7.4 Informational Parameters(4 keys)from it b. Double-click Read BD ADDR. 2. The Log Window will show the BD address. - 10 - E. Set Event Filter 1. In the HCI Control window a. select 7.3 Host Controller & Baseband Commands (3 key) for HCI protocol active b. Double-click Set Event Filter. 2.In the HCI Command window a. select connection setup for filter type b. select Allow Connecttion from all devices for Connection_Setup_ Filter _Condition_type c. select Do Auto accept the connection with role switch disabled for Auto_Accept_Flag d. Click OK. 3. Confirm that this step is done successfully by viewing the log window . - 11 - F. Write Scan Enable 1. In the HCI Control window a. select 7.3 Host Controller & Baseband Commands (3 key) for HCI protocol active b. Double-click. Write Scan Enable 2. In the HCI Command window a. select Inquiry and Page Scan enabled for scan_Enable b. Click OK. 3. Confirm that this step is done successfully by viewing the log window . - 12 - G. Enable Device Under Test Mode 1. In the HCI Control window a. select 7.6 Testing Commands (6 key) for HCI protocol active b. Double-click Enable Device Under Test Mode 2. Confirm that this step is done successfully by viewing the log window . - 13 - H.TX Testing 1. In the HCI Control window a. select 0: Vendor-specific Commands (0 key) for HCI protocol active b. Double-click TX Test 2. In the HCI command window a. From the Local_Device_BD_ADDR shortcut menu, select the Bluetooth device address of the DUT. b. From the Hopping_Mode shortcut menu, select single frequency. c. From the frequency shortcut menu, select which frequency you want to test. d. From the Modulation_Type shortcut menu, select PRBS9 Pattern. e. From the Logical_Channel shortcut menu, select ACL Basic. f. From the BB_Packet_Type shortcut menu, DH5/3-DH5, DH3/3-DH3, or DH1/2-DH1. g. From the BB_Packet_length(....) shortcut menu, key 65535 h. From the Tx Power Level shortcut menu, select Specify Power in dBm i. From the Transmit Power dBm shortcut menu, key in which power you want to transmit. j. Click OK. 3. Confirm that this step is done successfully by viewing the log window. - 14 - - 15 - I. RX Testing 1. In the HCI Control window a. select 0: Vendor-specific Commands (0 key) for HCI protocol active b. Double-click RX Test 2. In the HCI command window a. From the Local_Device_BD_ADDR shortcut menu, select the Bluetooth device address of the DUT. b. From the report period shortcut menu, select which period you want to used c. From the frequency shortcut menu, select which frequency you want to test. d. From the Modulation_Type shortcut menu, select PRBS9 Pattern. e. From the Logical_Channel shortcut menu, select ACL Basic. f. From the BB_Packet_Type shortcut menu, DH5/3-DH5, DH3/3-DH3, or DH1/2-DH1. g. From the BB_Packet_length(....) shortcut menu, key in 65535 h. Click OK. 3. Confirm that this step is done successfully by viewing the log window . - 16 - - 17 - Measure performance with instrument for auto testing (ex. Agilent N4010) Step : A to G Measure performance with instrument for manual testing (ex. Spectrum Analyzer) Step :A to D ,H(testing TX) or I(testing RX) The device under test (DUT) should be reset before each procedure. Re-test or replace the DUT need to switch Bluetool and plug DUT. If the Log Window didn’t show successful message in any step (Step B~I),please reset it. - 18 - 2. AW-BT715C EVB - 21 - EVB PCB Stackup Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equ…

Text truncated - open the document above for the full version.

FCC ID: TLZ-BT715C Report No.: RF140804E03 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch November 6, 2014 Dear Application Examiner, AzureWave Technologies, Inc., Bluetooth Module, FCC ID: TLZ-BT715C, would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip BCM20715A1KUBXG. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is BCM20715A1KUBXG. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a USB extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Report No.: 140804E03 Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID： TLZ- BT715C LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label Here Front

Report No.: 140804E03 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 140804E03 Page 2 Ant. No.01_ANT9520LL05R2400A Report No.: 140804E03 Page 3 Report No.: 140804E03 Page 4 Ant. No.02_ANT1204F001R2400A Report No.: 140804E03 Page 5 Report No.: 140804E03 Page 6 Ant. No.03_ANT8010LL04R2400A Report No.: 140804E03 Page 7 Report No.: 140804E03 Page 8 Ant. No.04_FXP74.07.0100A Report No.: 140804E03 Page 9 Report No.: 140804E03 Page 10 Ant. No.05_MSA-4008-25GC1-A1 Report No.: 140804E03 Page 11 Report No.: 140804E03 Page 12 Ant. No.06_FXP73.07.0100A Report No.: 140804E03 Page 13 Report No.: 140804E03 Page 14 Ant. No.07_ANTX100P001B24003 Report No.: 140804E03 Page 15 Report No.: 140804E03 Page 16 Ant. No.08_FPA-4605-2G4C1-A18 Report No.: 140804E03 Page 17 Report No.: 140804E03 Page 18 Ant. No.09_GW11.A153 Report No.: 140804E03 Page 19 Report No.: 140804E03 Page 20 Report No.: 140804E03 Page 21 Ant. No.10_FXP830.24.0100B Report No.: 140804E03 Page 22 Report No.: 140804E03 Page 23 Ant. No.11_EDA-1713-2G4C1-B16

Report No.: SA140804E03 1 of 7 Report Format Version 5.0.1 RF EXPOSURE REPORT REPORT NO.: SA140804E03 MODEL NO.: AW-BT715C FCC ID: TLZ- BT715C RECEIVED: Aug. 04, 2014 TESTED: Aug. 26, 2014 ISSUED: Sep. 26, 2014 APPLICANT: AzureWave Technologies, Inc. ADDRESS: 8 F., No. 94, Baozhong Rd., Xindian,Taipei, Taiwan 231 ISSUED BY : Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA140804E03 2 of 7 Report Format Version 5.0.1 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. EVALUATION RESULT ........................................................................................... 5 2.1 SAR TEST EXCLUSION THRESHOLDS ................................................................ 5 3. ANTENNA GAIN ...................................................................................................... 6 Report No.: SA140804E03 3 of 7 Report Format Version 5.0.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA140804E03 Original release Sep. 26, 2014 Report No.: SA140804E03 4 of 7 Report Format Version 5.0.1 1. CERTIFICATION PRODUCT: Bluetooth Module BRAND NAME: AzureWave MODEL NO.: AW-BT715C TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: AzureWave Technologies, Inc. TESTED: Aug. 26, 2014 STANDARDS: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment (Model: AW-BT715C) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 26, 2014 ( Claire Kuan, Specialist ) APPROVED BY : , DATE: Sep. 26, 2014 ( May Chen, Manager ) Report No.: SA140804E03 5 of 7 Report Format Version 5.0.1 2. EVALUATION RESULT 2.1 SAR TEST EXCLUSION THRESHOLDS Following FCC KDB 447498 D03 “General SAR test exclusion guidance” The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2) At 100 MHz to 6 GHz and for test separation distances > 50 mm, the SAR test exclusion threshold is determined according to the following: a) [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·( f(MHz)/150)] mW, at 100MHz to 1500 MHz b) [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW at > 1500 MHz and ≤ 6 GHz 3) At frequencies below 100 MHz, the following may be considered for SAR test exclusion. a) The threshold at the corresponding test separation distance at 100 MHz in step 2) is multiplied by [1 + log(100/f(MHz))] for test separation distances > 50 mm and < 200 mm. b) The threshold determined by the equation in a) for 50 mm and 100 MHz is multiplied by ½ for test separation distances ≤ 50 mm. c) SAR measurement procedures are not established below 100 MHz. When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any test results to be acceptable. Report No.: SA140804E03 6 of 7 Report Format Version 5.0.1 3. ANTENNA GAIN The antennas provided to the EUT, please refer to the following table: Ant. No. Vender Model No. Antenna Type Antenna Connector Ca…

Text truncated - open the document above for the full version.

Report No.: RF140804E03 1 of 115 Report Format Version 5.2.1 FCC TEST REPORT (BLUETOOTH/DTS) REPORT NO.: RF140804E03 MODEL NO.: AW-BT715C FCC ID: TLZ- BT715C RECEIVED: Aug. 04, 2014 TESTED: Aug. 11 to 26, 2014 ISSUED: Sep. 26, 2014 APPLICANT: AzureWave Technologies, Inc. ADDRESS: 8 F., No. 94, Baozhong Rd., Xindian,Taipei, Taiwan 231 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, Taiwan, R.O.C. TEST LOCATION (2): No.49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF140804E03 2 of 115 Report Format Version 5.2.1 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................................. 5 1 CERTIFICATION ...................................................................................................................... 6 2 SUMMARY OF TEST RESULTS ............................................................................................. 7 2.1 MEASUREMENT UNCERTAINTY ........................................................................................... 9 3 GENERAL INFORMATION .................................................................................................... 10 3.1 GENERAL DESCRIPTION OF EUT ...................................................................................... 10 3.2 DESCRIPTION OF TEST MODES ........................................................................................ 12 3.3 TEST MODE APPLICABLITY AND TESTED CHANNEL DETAIL: ........................................ 13 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................................... 17 3.5 DUTY CYCLE OF TEST SIGNAL .......................................................................................... 18 3.6 DESCRIPTION OF SUPPORT UNITS .................................................................................. 19 3.7 CONFIGURATION OF SYSTEM UNDER TEST ................................................................... 19 4 TEST PROCEDURES AND RESULTS (BT-EDR) ................................................................. 20 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................................ 20 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................ 20 4.1.2 TEST INSTRUMENTS ............................................................................................. 20 4.1.3 TEST PROCEDURES ............................................................................................. 21 4.1.4 DEVIATION FROM TEST STANDARD ................................................................... 21 4.1.5 TEST SETUP ........................................................................................................... 21 4.1.6 EUT OPERATING CONDITIONS ............................................................................ 22 4.1.7 TEST RESULTS ...................................................................................................... 23 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................................ 25 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ............... 25 4.2.2 TEST INSTRUMENTS ............................................................................................. 26 4.2.3 TEST PROCEDURES ............................................................................................. 28 4.2.4 DEVIATION FROM TEST STANDARD ................................................................... 28 4.2.5 TEST SETUP ........................................................................................................... 29 4.2.6 EUT OPERATING CONDITIONS ............................................................................ 29 4.2.7 TEST RESULTS(MODE 1) ...................................................................................... 30 4.2.8 TEST RESULTS(MODE 2) ...................................................................................... 37 4.2.9 TEST RESULTS(MODE 3) ...................................................................................... 44 4.2.10 TEST RESULTS(MODE 4) ...................................................................................... 51 4.3 NUMBER OF HOPPING …

Text truncated - open the document above for the full version.

Report No.: 140710C17 1 of 16 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 140710C17 2 of 16 RADIATED EMISSION TEST (Chip antenna, Below 1GHz) Report No.: 140710C17 3 of 16 Report No.: 140710C17 4 of 16 RADIATED EMISSION TEST (Chip antenna, Above 1GHz) Report No.: 140710C17 5 of 16 Report No.: 140710C17 6 of 16 RADIATED EMISSION TEST (PIFA antenna, Below 1GHz) Report No.: 140710C17 7 of 16 Report No.: 140710C17 8 of 16 RADIATED EMISSION TEST (PIFA antenna, Above 1GHz) Report No.: 140710C17 9 of 16 Report No.: 140710C17 10 of 16 RADIATED EMISSION TEST (PCB antenna, Below 1GHz) Report No.: 140710C17 11 of 16 Report No.: 140710C17 12 of 16 RADIATED EMISSION TEST (PCB antenna, Above 1GHz) Report No.: 140710C17 13 of 16 RADIATED EMISSION TEST (Dipole antenna, Below 1GHz) Report No.: 140710C17 14 of 16 Report No.: 140710C17 15 of 16 RADIATED EMISSION TEST (Dipole antenna, Above 1GHz) Report No.: 140710C17 16 of 16
