AW-GE870 802.11 b/g PCI Express Card User Manual ii COPYRIGHT AzureWave Technologies, Inc. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of AzureWave Technologies, Inc. DISCLAIMER AzureWave provides this document “as is”, without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. AzureWave may make improvements and/or changes in this document or in the product described in this document at any time. This document could include technical inaccuracies or typographical errors. TRADEMARKS AzureWave is a trademark of AzureWave Technologies, Inc. Other names mentioned in this document are trademarks/registered trademarks of their respective owners. USING THIS DOCUMENT This document provides detailed user guidelines to provide AzureWave802.11 b/g PCI Express WLAN Card operation and setting-up. Though every effort has been made to assure that this document is current and accurate, more information may have become available subsequent to the production of this guide. In that event, please contact your AzureWave representative for additional information that may help in the development process. iii Contents Safety statements.......................................................................................................... 2-1 About this guide ............................................................................................................ 2-1 AW-GA800BT802.11 b/g PCI Express WLAN Card specification summary ............................ 2-2 Chapter 1 Product Information...................................................................................... 2-2 1.1 Product overview............................................................................................... 2-2 1.2 Features ...........................................................................................................2-2 1.3 LED and antenna port.........................................................................................2-2 1.4 Supported network setup...................................................................................2-3 1.4.1 Ad-Hoc mode........................................................................................... 2-3 1.4.2 Infrastructure mode .................................................................................2-4 1.4.3 Software access point (Soft AP)..................................................................2-4 Chapter 2 Installation .................................................................................................. 2-1 2.1 System requirements ......................................................................................... 2-1 2.2 Hardware In stallation.........................................................................................2-1 Chapter 3 WiFi-AP Solo Wizard .....................................................................................2-1 3.1 Launch WiFi-AP Solo Wizard ............................................................................... 3-2 3.2 Wi-Setup Wizard Steps....................................................................................... 3-3 3.3 Station Mode Configuration ................................................................................ 3-3 3.3.1 Configure Infrastructure type network ....................................................... 3-4 3.3.2 Build Ad-Hoc networking mode network..................................................... 3-5 3.4 Build Soft AP network ........................................................................................3-6 3.4.1 Normal User ............................................................................................3-6 3.4.2 Advanced User....................................................................................... 3-10 Chapter 4 AzurewaveWLAN: Wireless LAN Management GUI ........................................... 4-1 4.1 How to Launch AzurewaveWLAN......................................................................... 4-3 4.2 Introduction of Main Window.............................................................................. 4-3 4.3 Station mode .................................................................................................... 4-6 4.3.1 Infrastructure and Ad-Hoc......................................................................... 4-7 4.4 AP mode.........................................................................................................4-11 4.5 Windows Zero Configuration............................................................................. 4-14 4.5.1 Swap from AzurewaveWLAN to Windows Zero Configuration...................... 4-14 4.5.2 Rollback from Windows Zero Configuration to AzurewaveWLAN ................. 4-15 Appendix A: Mapping of country and channel plan ....................................................... 4-1 Appendix B: Q&A ...................................................................................................... 4-2 Appendix C: Release History....................................................................................... 4-3 2-1 Safety statements FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. About this guide The user guide contains the information you need to install and configure your AzureWave802.11 b/g PCI Express WLAN Card. Guide organization This guide contains the following chapters: z Chapter 1: Product Information This chapter describes the general functionality, features and configuration modes of AzureWave802.11 b/g PCI Express WLAN Card. z Chapter 2: Installation It is recommended that users shoul…

Text truncated - open the document above for the full version.

December 7, 2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Testing Division of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS Testing Division as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, ________________________________ Ray Lee Director, Product Marketing AzureWave Technologies, Inc.

Date: November 13, 2006 Federal Communications Commission Authorization and Evaluation Division FCC ID: TLZ-GE870 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, ________________________________ Ray Lee Director, Product Marketing AzureWave Technologies, Inc.

1 Helen Zhao Subject: FW: FW: AzureWave Technologies, Inc., FCC ID: TLZ-GE870, Assessment NO.: AN07T6438, Notice#1 From: amanda.wu [mailto:[email protected]]On Behalf Of application Sent: Tuesday, January 16, 2007 7:16 PM To: Helen Zhao Subject: Re:FW: AzureWave Technologies, Inc., FCC ID: TLZ-GE870, Assessment NO.: AN07T6438, Notice#1 Dear Helen: Please see my reply, thank you. Best Regards, Amanda -----Original Message----- Sent: Tuesday, January 16, 2007 6:31 PM Subject: AzureWave Technologies, Inc., FCC ID: TLZ-GE870, Assessment NO.: AN07T6438, Notice#1 Question #1: The test report (page 4) indicates the device comes with four antennas, same type, but different gain, but page 7 indicates "The EUT comes with four types of antenna...", which is confusing. Please update the test report. Ans: The test report had been revsied, please see page 7. Question #2: The block diagram shows the device uses two antennas for diversity, the schematics show J2 (SMA connector) and J3 (3Pin). I could not locate J3 on the internal photos, please provide additional photos to show J3, and explain whether the device is using two antennas for diversity or not. Ans: Please see page 1 on the internal photos. The client confirmed the J3 has RX function and it's option. Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. AW-GE870 Test Report Revised 0... AW-GE870 IntPho Revised 0117.p...

Compliance Certification Services Inc. Report No.: 61111206 Date of Issue: December 19, 2006 Page 1 Total Page: 5 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT

TLZ-GE870 PCI Express Mini Card Made in China 802.11b/gAW-GE870

Compliance Certification Services Inc. Report No.: 61111206 Date of Issue: January 8, 2007 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 61111206 Date of Issue: December 19, 2006 Page 3 Rev.00 Model: W124-100-D200 for 3.00 dBi Compliance Certification Services Inc. Report No.: 61111206 Date of Issue: December 19, 2006 Page 4 Rev.00 Model: R-AN2400-0202RS for 1.79 dBi Model: C056-510223-A for 2.22 dBi Compliance Certification Services Inc. Report No.: 61111206 Date of Issue: December 19, 2006 Page 5 Rev.00 Model: C660-510025-A for 1.80 dBi

Specification For Approval 2006 / 11 / 17 Date 061117007 File No. 1.0 Revision Customer Manufacturer 2.4 GHz Antenna Part Number Description INVAX P/NR-AN2400-0202RS Approved By Invax 北路8154樓 Te l : 886-2-2788-5218 Fax:886-2-2783-1658 COR / F-G-15a Cortec 省路 Te l : 86-769-85388261 Fax: 86-769-85397133 Product Number: R-AN2400-0202RS Product Name: 2.4 GHz Antenna Page 1 Version: 2.0 Issue Date: 2006-11-16 Index: 1. Mechanical Dimension Drawing 2. Technical Specification 3. S11 Return Loss / S.W.R. / Impedance Testing Result 4. Antenna Radiation Pattern 5. Plastic Parts Material Datasheet 6. Metal Parts Material Datasheet 7. Reliability Testing 8. SGS Test Report 1. Mechanical Dimension Drawing Product Number: R-AN2400-0202RS Product Name: 2.4 GHz Antenna Page 2 Version: 2.0 Issue Date: 2006-11-16 2. Technical Specification A. Electrical Characteristics Working Frequency Range 2400 ~ 2500 MHz S.W.R. <= 2.0 Antenna Gain +0.1 ± 0.5 dBi @ 2400 MHz +1.0 ± 0.5 dBi @ 2450 MHz +1.5 ± 0.5 dBi @ 2500 MHz Antenna Radiation Pattern Omni-directional Impedance 50 ohm B. Material Color of Outer Cover Black Material of Outer Cover TPE Material of Hinge ABS Material of Base ABS Connector Type 50 Ohm SMA Male Reverse for RG-174 Au Plated Coaxial Cable RG-174 // 1500 mm Tube Copper // Sn Plated C. Environmental Operation Temperature - 30 ̊C ~ + 85 ̊C Storage Temperature - 30 ̊C ~ + 85 ̊C Product Number: R-AN2400-0202RS Product Name: 2.4 GHz Antenna Page 3 Version: 2.0 Issue Date: 2006-11-16 3. S11 Return Loss / S.W.R. / Impedance Testing Result Product Number: R-AN2400-0202RS Product Name: 2.4 GHz Antenna Page 4 Version: 2.0 Issue Date: 2006-11-16 4. Antenna Radiation Pattern Testing Equipment Specification: Antenna Anechoic Chamber Dimension: 8 x 4 x 4 m Quite Zone: 600mm @1 GHz Isolation: >100dB @ 1 MHz ~ 10 GHz Testing Equipment: Agilent 8720D Received Antenna: 0.7~6.0 GHz for Gain Calibration Double Ridged Horn Antenna Product Number: R-AN2400-0202RS Product Name: 2.4 GHz Antenna Page 5 Version: 2.0 Issue Date: 2006-11-16 5. Plastic Parts Material Datasheet Product Number: R-AN2400-0202RS Product Name: 2.4 GHz Antenna Page 6 Version: 2.0 Issue Date: 2006-11-16 6. Metal Parts Material Datasheet Product Number: R-AN2400-0202RS Product Name: 2.4 GHz Antenna Page 7 Version: 2.0 Issue Date: 2006-11-16 7. Reliability Testing Test Item Procedure Requirement 1. Visual inspection and dimension check Applicable methods using x5 magnification follow Specification 2. Rapid changing of temperature -40 ̊C (30minutes) to 90 ̊C (30minutes); 120 cycles After 2 hours recovery: 1. no visible damage 2. bandwidth tolerance < ±5% 3. Damp Heat 500 hours at 60 ̊C; 90 ~ 95% RH After 2 hours recovery: 1. no visible damage 2. bandwidth tolerance < ±5% 4. Endurance 500 hours at 90 ̊C After 2 hours recovery: 1. no visible damage 2. bandwidth tolerance < ±5% 8. SGS Test Report

1 2 3 4 5 * HP 8714A Vector Network Analyzer Temperature Rale -40 to +80 Commate 6 7 SGS Test Report ProductRF Antenna Contents No Description Report No. Page 1 Cable RG-174 CE/2005/B4386 CE/2005/B4391 CE/2005/B4445 CE/2005/B4446 P.9~20 2 Antenna Body Chassis ABS KE/2006/10288 2027056/EC GZSCR050637293/LP P.21~26 3 Connector SMA Plug Reverse SH570049/CHEM GZML060201325 KA/2006/20922A-01 P.27~32 4 Ground Tube Ni Plated + POM CE/2005/96120 CE/2005/96111 P.33~38 5 H.S Tube Heat Shrink Tube SH6039843/CHEM CE/2006/20175 P.39~57 Result For RoHSPASS 8

Specification 1. Electrical Properties : 1.1 Frequency Range............ 1.2 Impedance .................. 1.3 VSWR ..................... ... 1.4 Return Loss.................. 1.5 Electrical Wave............... 1.6 Gain(peak)................... 1.8dBi 1.7 Admitted Power............ 2. Physical Properties : 2.1 Cable...........................RG-178 Coaxial Cable 2.2 Antenna Cover............ ...TPE 2.3 Antenna Base............... PC 2.4 Antenna Base............... PBT 2.5 Operating Temp. ......... ...-20 ~ +65 2.6 Storage Temp. ............ ...-30 ~ +75 2.7 Color ........................ .Black 2.8 Connector.................. ...SMA Plug Reverse 1W 2.4GHz ~ 2.5GHz 50Ω Nominal 1.92 Max. -10 dB Maximum RF Antenna Cable Assembly 1/2λDipole 1 2 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510223-4-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510223-4-V.nsi 2.4GHz Gain = 1.71342 dBi 2.4GHz Gain = 1.53731 dBi Avg value: 1.266 dB 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510223-4-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510223-4-V.nsi 2.45GHz Gain = 1.80788 dBi 2.45GHz Gain = 1.6137 dBi Avg value: 1.335 dB 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510223-4-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510223-4-V.nsi 2.5GHz Gain = 1.80662 dBi 2.5GHz Gain = 2.21979 dBi Avg value: 1.781 dB 4 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510131-4-H.nsi 2.400000 GHz2.450000 GHz2.500000 GHz C056-510223-A 5 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C056-510131-4-V.nsi 2.400000 GHz2.450000 GHz2.500000 GHz C056-510223-A 6

PPROVAL SHEET CUSTOMER : 海華科技股份有限公司 CUSTOMER NO. Input Output NO. W124-100-D200 DESCRIPTION: 2.4G -2.5GHz Antenna Reverse Polarity SMA Plug Signed By Customers Approved By: 供應商: 垠 旺 精 密 股 份 有 限 公 司 TEL:02-2917-7528;FAX:02-2912-1659 台北縣新店市寶興路37號 3樓 SPECIFICATION 1. Electrical Properties 1-1 Frequency Range .........................2.4~2.5GHz 1-2 Impedance..................................50 Ohms nominal 1-3 V.S.W.R.....................................2.0 (Max.) 1-4 Return Loss...............................-10.0 dB(Max.) 1-5 Max. Gain..................................0.5dBi 1-6 Polarization......................... Vertical 1-7 Admitted Power...........................1W 1-8 Electrical Wave............................1/4 ג Dipole 2. Mechanical Properties 2-1 Connector..............................Reverse SMA Plug Cable......................................RG-174 2-3 Antenna Body...........................T.P.R. 2-4 Operating Temperature Range........-20°C ~ +50°C 2-5 Storage Temperature Range.......... -20°C ~ +50°C 工程成品圖 Return Loss V. S .W .R E-Plane Test Report E-Plane Test Report E-Plane Test Report H-Plane Test Report H-Plane Test Report H-Plane Test Report T

SGS REPORT Insulator材質證明 Insulator材質證明 Insulator材質證明 Insulator材質證明 電鍍材質證明-3 Cable SGS Report

Compliance Certification Services Inc. Report No.: 61111206-RP1 FCC ID: TLZ-GE870 Date of Issue: January 8, 2007 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 58 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For 802.11b/g PCI Express Card Model: AW-GE870 Trade Name: AzureWave Issued to AzureWave Technologies, Inc. 8F., No.94, Baozhong Rd., Xindian, Taipei, Taiwan 231 Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 61111206-RP1 FCC ID: TLZ-GE870 Date of Issue: January 8, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION........................................................................................................3 2. EUT DESCRIPTION..............................................................................................................................4 3. TEST METHODOLOGY.......................................................................................................................4 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................7 4. INSTRUMENT CALIBRATION...........................................................................................................8 4.1 MEASURING INSTRUMENT CALIBRATION......................................................................................8 4.2 MEASUREMENT EQUIPMENT USED.........................................................................................8 5. FACILITIES AND ACCREDITATIONS ..............................................................................................9 5.1 FACILITIES .........................................................................................................................................9 5.2 EQUIPMENT........................................................................................................................................9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.....................................................................................10 6. SETUP OF EQUIPMENT UNDER TEST...........................................................................................11 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................11 6.2 SUPPORT EQUIPMENT ...............................................................................................................11 7. FCC PART 15.247 REQUIREMENTS................................................................................................12 7.1 6 DB BANDWIDTH.............................................................................................................................12 7.2 PEAK POWER....................................................................................................................................16 7.3 A VERAGE POWER............................................................................................................................20 7.4 BAND EDGES MEASUREMENT ................................................................................................24 7.5 PEAK POWER SPECTRAL DENSITY....................................................................................................33 7.6 SPURIOUS EMISSIONS ................................................................................................................37 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................51 APPENDIX I RADIO FREQUENCY EXPOSURE ...................................................................................54 APPENDIX II PHOTOGRAPHS OF TEST SETUP ..................................................................................56 Compliance Certification Services Inc. Report No.: 61111206-RP1 FCC ID: TLZ-GE870 Date of Issue: January 8, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product 802.11b/g PCI Express Card Trade Name AzureWave Model Number AW-GE870 Model Discrepancy N/A Power Supply Powered from host device Frequency Range 2412 ~ 2462 MHz Transmit Power IEEE 802.11b mode: 18.99 dBm IEEE 802.11g mode: 17.05 dBm Modulation Technique IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: DSSS (CCK, DQPSK, DBPSK) + OFDM (QPSK, BPSK, 16-QAM, 64-QAM) Transmit Data Rate IEEE 802.11b: 11, 5.5, 2, 1 Mbps IEEE 802.11g: 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1Mbps Number of Channels 11 Channels Antenna Specification Antenna Type: Dipole Antenna Trade name / Model name: Micon / W124-100-D200 Antenna Gain: 3.00 dBi Trade name / Model name: Invax / R-AN2400-0202RS Antenna Gain: 1.79 dBi Trade name / Model name: Wha Yu / C056-510223-A Antenna Gain: 2.22 dBi Trade name / Model name: Wha Yu / C660-510025-A Antenna Gain: 1.80 dBi Remark: 1. The sample selected for test was production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: TLZ-GE870 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 61111206-RP1 FCC ID: TLZ-GE870 Date of Issue: January 8, 2007 Page 56 Rev. 00 APPENDIX II PHOTOGRAPHS OF TEST SETUP Conducted Emission Setup Photos Compliance Certification Services Inc. Report No.: 61111206-RP1 FCC ID: TLZ-GE870 Date of Issue: January 8, 2007 Page 57 Rev. 00 Radiated Emission Setup Photos Compliance Certification Services Inc. Report No.: 61111206-RP1 FCC ID: TLZ-GE870 Date of Issue: January 8, 2007 Page 58 Rev. 00 Powerline Conducted Emissions Setup Photos
