TLZ-NU150802.11b/g/n wireless USB Adapter

User Manual Wireless 802.11 b/g/n dongle Chapter 1: Product Overview AzureWave Technologies, Inc. introduces the advanced IEEE 802.11 b/g/n 1x1 WLAN USB 2.0 dongle - AW-NU150. The dongle supports 2.4GHz , By using AW-NU150, the customers can easily enable the development of USB 2.0-based 802.11n WLAN client. In Compliance with the IEEE 802.11b/g/n standard, the AW-NU150 uses Direct Sequence Spread Spectrum (DSSS), orthogonal frequency division multiplexing (OFDM), DBPSK, DQPSK, CCK and QAM baseband modulation technologies. A high level of integration and full implementation of the power management functions specified in the IEEE 802.11 standard minimize the system power requirements. By using AW-NU150, state-of-the-art security is provided by industry standard system support for WPA, WPA2, and hardware accelerated AES encryption/decryption coupled with TKIP and IEEE 802.1X support. The AW-NU150 dongle adopts 802.11n-based chip, AR9271 supports 1*1 stream up to 300Mbps. Chapter 2: Installation Note: The dongle is using with televisions and embedded application only and will be with the platform model names as following: This dongle must be away from human body at least 20 cm. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. . IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Page 1 CONSTRUCTION PHOTOS OF EUT

Label

- 1 - AW-NU150 label location <Label location>

Page 2 Page 3 Page 4

FCC ID: TLZ-NU150 Report No.: RF991119C12 Operational Description This device is a WLAN 802.11b/g/n wireless USB adapter, which operates in the 2.4GHz band; the maximum data rate could be up to 135Mbps which OFDM technique. If the signal to noise ratio is too poor which could not support 135Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antennas are PIFA antennas without any antenna connectors. For more detailed instruction, please take a look at the user’s manual.

Report No.: SA991119C12 Report Format Version 3.0.1 1 RF EXPOSURE REPORT REPORT NO.: SA991119C12 MODEL NO.: AW-NU150 FCC ID: TLZ-NU150 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: AzureWave Technologies, Inc. ADDRESS: 8F, No. 94, Baozhong Rd., Xindian, Taipei, Taiwan 231. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. Report No.: SA991119C12 Report Format Version 3.0.1 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 4. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 24.0 0.9 20 0.061 1.00

Report No.: RF991119C12 1 Report Format Version 3.0.1. FCC TEST REPORT REPORT NO.: RF991119C12 MODEL NO.: AW-NU150 FCC ID: TLZ-NU150 RECEIVED: Nov. 19, 2010 TESTED: Nov. 23 ~ Nov. 26, 2010 ISSUED: Nov. 30, 2010 APPLICANT: AzureWave Technologies, Inc. ADDRESS: 8F, No.94, Baozhong Rd., Xindian, Taipei , Taiwan 231. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 67 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Report No.: RF991119C12 2 Report Format Version 3.0.1. TABLE OF CONTENTS 1. CERTIFICATION............................................................................................................4 2. SUMMARY OF TEST RESULTS ...................................................................................5 2.1 MEASUREMENT UNCERTAINTY.................................................................................5 3. GENERAL INFORMATION ............................................................................................6 3.1 GENERAL DESCRIPTION OF EUT ..............................................................................6 3.2 DESCRIPTION OF TEST MODES ................................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ...........................................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ................................8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................10 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................................10 4. TEST TYPES AND RESULTS ..................................................................................... 11 4.1 RADIATED EMISSION MEASUREMENT ................................................................... 11 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................. 11 4.1.2 TEST INSTRUMENTS.................................................................................................12 4.1.3 TEST PROCEDURES .................................................................................................13 4.1.4 DEVIATION FROM TEST STANDARD........................................................................13 4.1.5 TEST SETUP...............................................................................................................14 4.1.6 EUT OPERATING CONDITIONS ................................................................................14 4.1.7 TEST RESULTS ..........................................................................................................15 4.2 CONDUCTED EMISSION MEASUREMENT ..............................................................28 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................................28 4.2.2 TEST INSTRUMENTS.................................................................................................28 4.2.3 TEST PROCEDURES .................................................................................................29 4.2.4 DEVIATION FROM TEST STANDARD........................................................................29 4.2.5 TEST SETUP...............................................................................................................30 4.2.6 EUT OPERATING CONDITIONS ................................................................................30 4.2.7 TEST RESULTS ..........................................................................................................31 4.3 6dB BANDWIDTH MEASUREMENT...........................................................................33 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................................33 4.3.2 TEST INSTRUMENTS.................................................................................................33 4.3.3 TEST PROCEDURE....................................................................................................33 4.3.4 DEVIATION FROM TEST STANDARD........................................................................33 4.3.5 TEST SETUP...............................................................................................................34 4.3.6 EUT OPERATING CONDITIONS ................................................................................34 4.3.7 TEST RESULTS ..........................................................................................................35 4.4 MAXIMUM OUTPUT POWER .....................................................................................39 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT......................................39 4.4.2 INSTRUMENTS ...........................................................................................................39 4.4.3 TEST PROCEDURES .................................................................................................39 4.4.4 DEVIATION FROM TEST STANDARD........................................................................40 4.4.5 TEST SETUP...............................................................................................................40 Report No.: RF991119C12 3 Report Format Version 3.0.1. 4.4.6 EUT OPERATING CONDITIONS ................................................................................4…
