TNE-400ULC1411-470 MHz Transceiver Module

70 Abele Road Suite 1201 Bridgeville, PA 15017 800.288.8178 800.298.3503 Fax www.magnetekmh.com Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: TNE-400ULC1. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematic, Operating Description, Block Diagram, Parts List, User Manual TNE-400ULC1_Schem, TNE-400ULC1_OpDes, TNE- 400ULC1_BlkDia, TNE-400ULC1_PartsLst, TNE- 400ULC1_UserMan The above proprietary exhibits above are all trade secrets of Magnetek specifically the schematics and circuit layout, parts list and component selection, pictures that included the size and shape of the module, and Users Manual. All of these contain specific information including philosophy of standardizing throughout our products, and our proprietary protocols which are described in the manual. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The RF module in question is housed within Magnetek products, and those products are supplied to the customer with a separate user’s manual. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. The user’s manual is an internal document, which includes proprietary information including circuit details held confidential in other exhibits. The user’s manual is very technical and is not provided to the consumer as the consumer cannot service the device. It is solely used as a design guide for Magnetek engineers to use as a reference on how to correctly incorporate this module into Magnetek products only. Sincerely, Eugene Novak

70 Abele Road Suite 1201 Bridgeville, PA 15017 800.288.8178 800.298.3503 Fax www.magnetekmh.com Date: April 17, 2014 To: Federal Communications Commission Authorization and Evaluation Division From: Eugene Novak Subject: Agent Authorization for certification of FCC ID: TNE-400ULC1. Magnetek hereby appoints Richard Reitz of Retlif Testing Laboratories to act as our agent in the matter of FCC filings for the certification of FCC ID: TNE-400ULC1. Magnetek further attests that no party to the application is subject to denial of federal benefits pursuant to section 5301 of the Anti-Drug Abuse act of 1988, 21 USA 853(a). Sincerely, Eugene Novak Radio Product and Development Manager

70 Abele Road Suite 1201 Bridgeville, PA 15017 800.288.8178 800.298.3503 Fax www.magnetekmh.com Federal Communications Commission Authorization and Evaluation Division Note regarding application for certification of FCC ID: TNE-400ULC 1. Magnetek Inc. radio control products are used in industrial applications where safe operation is critical. As such, all Magnetek radio products come equipped with safety features to prevent un-commanded motion of the equipment being controlled. Any un-intended motion could result in serious injury or even death to others. For instance, if the operator moves out of radio range and the controlled machine stops receiving messages, a safety relay opens to de-power the equipment being controlled remotely. Without polling in this application, the equipment remains powered when the radio link is lost and serious injury or death could result. Typical international industry standards call for radio controlled equipment to be powered by redundant emergency stop safety relays 1 . These relays must remove power from the equipment being controlled within a maximum of 2 seconds of no c ommunication with the controlling device 1 . In order to maintain this communication link, polling of the link status is required. Magnetek, Inc. wishes to make use of 15.231(3) and 15.231(4) which allows operation during the pendency of the alarm condition in order to prevent serious injury or death to others. Sincerely, Eugene Novak 1 BS EN 13557:2003+A2:2008 annex C.3

70 Abele Road Suite 1201 Bridgeville, PA 15017 800.288.8178 800.298.3503 Fax www.magnetekmh.com Federal Communications Commission Authorization and Evaluation Division Note regarding application for certification of FCC ID: TNE-400ULC1. The modular transmitter being submitted for approval complies with the following criteria: • The radio elements of the modular transmitter must have their own shielding • The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. • The modular transmitter must have its own power supply regulation. • The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a ‘‘unique’’ antenna coupler (at all connections between the module and the antenna, including the cable). The ‘‘professional installation’’ provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. • The modular transmitter must be tested in a stand-alone configuration • The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. • The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. • The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Sincerely, Eugene Novak

Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID: TNE-400ULC1, IC: 6145A-400ULC1 Page 1 of 2 Internal and External Photographs FCC ID: TNE-400ULC1 / IC: 6145A-400ULC1 Front View of Module Close-up of Front of Module Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID: TNE-400ULC1, IC: 6145A-400ULC1 Page 2 of 2 Internal / External Photographs FCC ID: TNE-400ULC1 / IC: 6145A-400ULC1 Rear View of Module Module with Shield

Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID: TNE-400ULC1, IC: 6145A-400ULC1 Page 1 of 2 Internal and External Photographs FCC ID: TNE-400ULC1 / IC: 6145A-400ULC1 Front View of Module Close-up of Front of Module Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID: TNE-400ULC1, IC: 6145A-400ULC1 Page 2 of 2 Internal / External Photographs FCC ID: TNE-400ULC1 / IC: 6145A-400ULC1 Rear View of Module

FCC Part 15, Subpart C, Section 15.231 Industry Canada, RSS-210 and RSS-GEN Test Report On 411 to 470 MHz Transceiver Module FCC ID: TNE-400ULC1 IC: 6145A-400ULC1 Customer Name: Magnetek Customer P.O: 145756, 146371, 147367 Date of Report: June 18, 2014 Test Report No: R-2148P-1 Test Report Date: June 20, 2014 Test Technician: B. Willhauer, D. Fiore, S. MacDonald Dean F. Landers EMC Test Engineer: Approved By: Richard C. Gaynor Report Prepared By: C. Reitz Our letters, procedures and reports are for the exclusive use of the customer to whom they are addressed and their communication or the use of the name of Retlif Testing Laboratories must receive our prior written approval. Our letters, procedures and reports apply only to the sample tested and are not necessarily indicative of the qualities of apparently identical or similar products. The letters, procedures and reports and the name of Retlif Testing Laboratories or insignia are not to be used under any circumstances in advertising to the general public. This test report shall not be reproduced, except in full, without the written approval of Retlif Testing Laboratories. Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1, IC: 6145A-400ULC1 Page 2 of 49 Technical Information Report Number: R-2148P-1 Customer: Magnetek Address: N49 W13650 Campbell Drive Menomonee Falls, WI 53051 Manufacturer: Magnetek Manufacturer Address: N49 W13650 Campbell Drive Menomonee Falls, WI 53051 Test Sample: 411 to 470 MHz Transceiver Module Model Number: 71000-10400 FCC ID: TNE-400ULC1 IC: 6145A-400ULC1 Type (IC): Land-Mobile Transmitter and Receiver (27.41 to 960 MHz) Power Requirements: 3.3 VDC derived from Host Frequency of Operation: 411 to 470 MHz Equipment Class: DXT Equipment Use: Mobile >20 cm Test Specification: FCC Rules and Regulations Part 15, Subpart C, Section 15.231 Radio Standards Specification, RSS-210, Issue 8, December, 2010 Test Procedure: ANSI C63.4:2003 RSS-GEN, Issue 3, December 2010 Test Facility: Retlif Testing Laboratories 3131 Detwiler Road Harleysville, PA 19438 The module complies with the requirements for a modular approval under Section 15.212(a) of the FCC Rules. Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1, IC: 6145A-400ULC1 Page 3 of 49 Tests Performed The test methods performed on the 411 to 470 MHz Transceiver Module are shown below: FCC Part 15, Subpart C Industry Canada RSS-210 Issue 8, Dec. 2010 Industry Canada RSS-GEN Issue 3, Dec. 2010 Test Method 15.231(b) A1.1.2(1) N/A Field Strength of Emissions 15.231(b)(2) A1.1.2(2) 4.5 Duty Cycle Determination 15.231(b)(3) A1.1.2(3) N/A Field Strength of Spurious Emissions 15.231(c) A1.1.3 N/A Bandwidth of Emission 15.107 / 15.207(a) N/A 7.2.2 Conducted Emissions 15.109(a) N/A 7.2.3 Receiver Radiated Emissions General Test Requirements 1. The measurement procedures of ANSI C63.4:2003 were utilized as specified in FCC Part 15, Subpart C, Section 15.31(a)(3) and IC RSS-GEN Section 4.1. 2. All radiated emissions measurements were performed on an Open Area Test Site (OATS), listed with the FCC and IC, in accordance with FCC Section 15.31(d) and IC Section 4.2. 3. The level of the fundamental field strength was recorded with a new battery installed in the EUT, in accordance with FCC Section 15.231(e) and IC Section 4.3(e). 4. All measurements were performed at the specified 3 meter test distance as required by FCC Section 15.31(f) and IC Section 7.25. 5. The EUT was rotated throughout 360 degrees for all radiated emissions measurements as specified in FCC Section 15.31(f)(5) and IC Section 4.3(h). 6. All readily accessible EUT controls were adjusted in such a manner as to maximize the level of emissions in accordance with FCC Section 15.31(g) and IC Section 4.3(h). 7. Appropriate accessories were attached to all EUT ports during the performance of radiated emissions measurements as required by FCC Section 15.31(i) and IC Section 4.3(d). 8. The EUT operated over the frequency range of 411 to 470 MHz, a total range of 59 MHz. Testing was performed with the device operating at 3 frequencies, 1 at the top, 1 in the middle and 1 at the bottom of the range of operation in accordance with FCC Section 15.31(m) and IC Section 4.3(f)(g). 9. The frequency spectrum was investigated from the lowest frequency generated in the device up to the 10 th harmonic of the highest fundamental frequency in accordance with FCC Section 15.33(a)(1) and IC Section 4.9. 10. All measurements were taken with a peak detector function as specified in FCC Section 15.35(a) and IC Section 4.4. The duty cycle, calculated in accordance with FCC Section 15.35(c) and IC Section 4.5, was applied to the peak readings in order to obtain the average value of emissions. The peak value of emissions was verified to meet the 20 dB requirement of FCC Section 15.35(b) and IC Section 7.2.1. Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1, IC: 6145A-400ULC1 Page 5 of 49 Requirements and Test Results Requirement: FCC Section 15.231(a) - Periodic operation in the band 40.66 - 40.7 MHz and above 70 MHz The provisions of this Section are restricted to periodic operation within the band 40.66-40.7 MHz and above 70 MHz. Except as shown in Paragraph (e) of this Section, the intentional radiator is restricted to the transmissions of a control signal such as those used with alarm systems, door openers, remote switches, etc. Continuous transmissions, voice, video and the radio control of toys are not permitted. Data is permitted to be sent with a control signal. IC RSS-210, A1.1 - Momentarily Operated Devices The frequency bands and field strength limits in Tables 4 and 5 are only for the transmission of a control signal such as that used with alarm systems, door openers, remote switches, etc. Radio control of toys or model aircrafts, and continuous transmissions such as voice or video are not permitted except as provided in A1.1.5. Data is permitte…

Text truncated - open the document above for the full version.

Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 1 of 13 Test Setup Photographs FCC ID: TNE-400ULC1 IC: 6145A-400ULC1 Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 2 of 13 Test Setup Photographs Field Strength of Emissions Biconilog Antenna, Vertical Polarization - 30 MHz to 1000 MHz Biconilog Antenna, Horizontal Polarization, 30 MHz to 1000 MHz Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 3 of 13 Test Setup Photographs Field Strength of Emissions Double Ridged Guide, Vertical Polarization, 1 GHz to 4 GHz Double Ridged Guide, Horizontal Polarization, 1 GHz to 4 GHz Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 4 of 13 Test Setup Photographs Field Strength of Emissions Y Axis X Axis Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 5 of 13 Test Setup Photographs Field Strength of Emissions Z Axis Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 6 of 13 Test Setup Photographs Duty Cycle Determination Test Setup Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 7 of 13 Test Setup Photographs Field Strength of Spurious Emissions Test Setup, Internal Antenna Test Setup, External Antenna Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 8 of 13 Test Setup Photographs Field Strength of Spurious Emissions Biconilog Antenna, Vertical Polarization, 30 MHz to 2000 MHz Biconilog Antenna, Horizontal Polarization, 30 MHz to 2000 MHz Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 9 of 13 Test Setup Photographs Bandwidth of Emission Test Setup Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 10 of 13 Test Setup Photographs Conducted Emissions Test Setup Test Setup, Hot Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 11 of 13 Test Setup Photographs Conducted Emissions Test Setup, Neutral Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 12 of 13 Test Setup Photographs Receiver Radiated Emissions Test Setup, Internal Antenna Test Setup, External Antenna Retlif Testing Laboratories, Test Report R-2148P-1, Magnetek FCC ID:TNE-400ULC1 / IC: 6145A-400ULC1 Page 13 of 13 Test Setup Photographs Receiver Radiated Emissions Biconilog Antenna, Vertical Polarization, 30 MHz to 2000 MHz Biconilog Antenna, Horizontal Polarization, 30 MHz to 2000 MHz
