TNE-7276LMA172.0236 TO 75.9938 MHz VHF TRANSMITTER

#5 Four Coins Drive Canonsburg, PA 15317-1751 800.288.8178 800.298.3503 Fax www.magnetek.com Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: TNE-7276LMA1. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematic, Block Diagram, Parts List, User Manual TNE-7276LMA1 Schem, TNE-7276LMA1 BlkDia, TNE-7276LMA1 PartsLst, TNE7276LMA1 UserMan The above proprietary exhibits above are all trade secrets of Magnetek specifically the schematics and circuit layout, BOM and component selection, pictures that include the size and shape of the module, and User Manual. All of these contain specific information including our main RF foundation, philosophy of standardizing throughout our products, and our proprietary protocols which are described in the manual. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Eugene Novak

FCC ID: TNE-7276LMA1 MODEL: XLTX SERIES IC ID: 6145A-7276LMA1 MAGNETEK

Operational Description General Description Magnetek’s licensed transmitter board is a 100mW data transmitter. The board is configured for 100mW output power and any four frequencies in the 72-76 MHz range. One of four channels is user selectable via jumpers on the board. Logic level data, at either 2400 or 4800 baud, is accepted from the companion CPU board and modulated on the RF carrier using frequency-shift keying (FSK), with a +/- 3 kHz deviation. In addition, the RF output may be keyed on and off to send individual data packets. This allows up to four users on a single channel. Data is FSK modulated on a carrier frequency of 72-76 MHz. RF duty cycle can be up to 100% and a maximum of 128 bits can be transmitted per transmission. Circuit Description Voltage Regulation The transmitter board will operate over the range of 4.5-9.8V or 10-15V depending on the jumper selection made. The jumpers select which main switching regulator is used to generate 3.6V, used for the transmitter line-up. Following the main regulator is a linear regulator that further decreases the voltage to 3.3V, to power the remainder of the circuits on the board. Modulation The modulation is set and limited by adjusting the two digital to analog converters (DAC), U8-A and U8-B. These DAC outputs are switched (analog switch, U6) in cadence with the incoming data and passed through a 4-pole, 3.25 kHz, Butterworth low pass filter. This filter limits the harmonic content of the baseband data. The filtered data is then sent to the synthesizer’s reference oscillator, which modulates the voltage-controlled oscillator (VCO). Since the synthesizer loop bandwidth is 1 kHz, any modulation applied to the reference oscillator would see a low pass response with cutoff at 1kHz. To obtain modulation components above the 1 kHz cutoff, modulation is also applied to the VCO. The VCO response will be a high pass with cutoff at 1 kHz. This is generally referred to as two-port modulation. The modulation flatness adjustment (R44) will match the modulation sensitivity of the two ports. Amplifier Line-up The buffer amplifier (Q9) follows the VCO and provides reverse isolation to prevent unwanted modulation of the VCO. The buffer amplifier drives the pre-driver, which can be keyed on and off to send data packets. Following the pre-driver is the 100mW driver. This is a class C amplifier that suffices for a final amplifier in the 100mW version. The amplifier is followed by a 7-pole Chebyshev low pass filter. This filter rejects harmonics of the carrier. Micro-controller The micro-controller provides the following functions: 1) Reads the channel jumpers and sets the synthesizer to the appropriate channel and at the same time sets the channel’s respective output power and deviation settings. 2) Communicates with an external computer through connector J4 to set the frequencies for, up to, four channels. This would include deviation settings and output power settings on these channels. Antenna An external PCB antenna with a gain of -33.6 dB is used with the transmitter and is connected by an RF MCX connector.

Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Engrage, FCC ID: TNE-7276LMA1 Page 1 of 21 Technical Information APPLICANT MANUFACTURER Name: Magnetek / Enrange Name: Magnetek / Enrange Address: 5 Coins Drive Address: 5 Coins Drive City, State, Zip: Canonsburg, PA 15317 City, State, Zip: Canonsburg, PA 15317 Date: August 27, 2012 FILING TYPE: Original Application - Limited Modular Approval TEST SPECIFICATION: FCC Rules and Regulations Part 90.257 TEST PROCEDURE: FCC Part 2 TEST SAMPLE DESCRIPTION TEST SAMPLE: VHF Transmitter BRANDNAME: Pulse Star MODEL XLTX FCC ID: TNE-7276LMA1 TYPE: Wireless Radio Remote Control POWER REQUIREMENTS: 4.5 VDC Derived from (3) 1.5 V Alkaline Batteries FREQUENCY OF OPERATION: 72.0236 to 75.9938 MHz CONFIGURATION: The VHF Transmitter was tested in a stand alone configuration and connected to a remote control assembly, which was used as support equipment. EMISSIONS DESIGNATOR: TNB The module complies with the requirements for a limited modular approval under Section 90.257 of the FCC Rules. Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Engrage, FCC ID: TNE-7276LMA1 Page 2 of 21 Tests Performed The test methods performed on the VHF Transmitter are shown below: FCC Part 90 Section FCC Part 2 Section Test Method 90.205 2.1046 RF Power Output 90.209 2.1049 Occupied Bandwidth 90.210 2.1051 Spurious Emissions at Antenna Terminals 90.210 2.1053 Field Strength of Spurious Radiation 90.213 2.1055 Frequency Stability GENERAL REQUIREMENTS 1. All user accessible controls were adjusted to produce maximum emissions. 2. The unit operates at the following frequencies:  72.0236 – 75.9938 MHz 3. The unit was tested at the following frequencies:  Channel 0: 72.0236 MHz  Channel 2: 75.9938 MHz 4. The frequency range was scanned from 9 kHz to 760 MHz. All emissions not reported were more than 20 dB below the specified limit. Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Engrage, FCC ID: TNE-7276LMA1 Page 4 of 21 Requirements and Test Results Requirement: FCC Sections 90.205 and 2.1046 RF Power Output The RF Power Output of the EUT was measured with the transmitter adjusted for maximum power output. The highest observed power output was measured to be 19.66 dBm (92.47 mW), 17.34 dBm below the limit of 37.0 dBm (5 Watts). The measured power output is in compliance with the requirements specified in section 90.205(o) of the FCC Rules. Requirement: FCC Sections 90.209 and 2.1049 Occupied Bandwidth The Occupied Bandwidth of the transmitter was measured and found to be 10 kHz. Utilizing this Bandwidth, the transmitter complied with the requirements for Emissions Mask B contained in section 90.210(b) and the Bandwidth Limitations of section 90.209(b)(5). Requirement: FCC Sections 90.210 and 2.1051 Spurious Emissions at Antenna Terminals The Spurious Emissions present at the antenna terminals were measured over the frequency range of 9 kHz to 760 MHz (ten times the operating frequency) in accordance with section 2.1057. Spurious emissions were attenuated at least 43 + 10 Log P (5 Watts), 49.9897 dBm from the carrier as required by sections 90.209 and 90.210. Requirement: FCC Sections 90.210 and 2.1053 Field Strength of Spurious Radiation The Field Strength of Spurious Radiation was measured over the frequency range of 9 kHz to 760 MHz. All spurious emissions complied with the requirements of sections 90.209 and 90.210. In addition, spurious digital emissions in the frequency range of 30 to 1000 MHz were found to be in compliance with the requirements for a Class B Digital Device as contained in section 2.1053. Requirement: FCC Sections 90.213 and 2.1055 Frequency Stability The frequency stability of the transmitter was measured over temperature extremes of - 30 o to + 50 o C. For varying of the DC power input, the voltage was reduced to the operating end point, which was 3.2 VDC. The EUT carrier frequency was found to remain within the ± 0.05% tolerance as specified in section 90.213(a). Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Engrage, FCC ID: TNE-7276LMA1 Page 5 of 21 Requirements and Test Results (con’t) RF Exposure Limits Transmitters operating under Part 2.1091 are categorically excluded from routine environmental evaluation for demonstrating RF exposure compliance with respect to MPE or SAR limits however per 2.1091(b) must be operated in a manner that ensures the public is not exposed to RF energy levels in excess of the commission’s guidelines. The user/installation manual contains the proper cautionary statements and specifies that the device be installed and operated so that a minimum separation distance of 20 cm will be maintained. Based on the transmitter power and maximum antenna gain (see calculation below) the 20 cm separation distance exceeds the calculated distance for acceptable MPE power density levels to meet both the Occupational/Controlled Exposure and the General Population/Uncontrolled Exposure requirements of FCC Part 1.1310. The calculation below uses the more stringent General Population MPE Limits. S = Dsq PG 4 D = Minimum Separation Distance in cm S = Max allowed Power Density in mW/cmsq Per 1.1310 For the Frequency of 72-76 MHz S = 0.2 mW/cmsq Power = Max Power Input to Antenna = 100 mW Gain = Max Power Gain of Antenna = 1 dBi = 1.26 numeric 0.2 mW/cmsq = 2^)14.3(4 26.1100 xDx x = 2^56.12 126 xD D^2 = 2.056.12 126 x D = 16.50 = 7.08 cm Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Engrage, FCC ID: TNE-7276LMA1 Page 6 of 21 Equipment List Sections 90.205 and 2.1046, RF Power Output EN Manufacturer Description Range Model No. Cal Date Due Date 8357 NARDA 10.0DB ATTENUATOR DC - 11 GHz, 20 W 768-10 6/5/2012 6/30/2013 8381 BOONTON POWER METER 10 kHz - 100 GHz 4232A 1/23/2012 1/31/2013 8381B BOONTON POWER SENSOR 10 kHz - 8 GHz 51011-EMC 5/11/2012 5/31/2013 Sections 90.209 and 2.1049, Occupied Bandwidth EN Manufacturer Description Range Model No. Cal Date Due Date 8100 NARDA 20DB ATTEN…

Text truncated - open the document above for the full version.

Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Enrange, FCC ID: TNE-7276LMA1 Page 1 of 6 Test Setup Photographs Magnetek / Enrage FCC ID: TNE-7276LMA1 Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Enrange, FCC ID: TNE-7276LMA1 Page 2 of 6 FCC Part 90, Section 2.1046, RF Power Output Test Setup Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Enrange, FCC ID: TNE-7276LMA1 Page 3 of 6 FCC Part 90, Section 2.1049, Occupied Bandwidth Test Setup Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Enrange, FCC ID: TNE-7276LMA1 Page 4 of 6 FCC Part 90 Section 2.1051, Spurious Emissions at Antenna Terminal 9 kHz to 760 MHz Test Setup Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Enrange, FCC ID: TNE-7276LMA1 Page 5 of 6 FCC Part 90 Section 2.1053, Field Strength of Spurious Emissions 9 kHz to 760MHz Test Setup Horizontal Antenna Polarization Retlif Testing Laboratories, Test Report R-1840P-1, Magnetek/Enrange, FCC ID: TNE-7276LMA1 Page 6 of 6 Sections 90.213 and 2.1055, Frequency Stability - Temperature Variation Test Setup
